- Page 1 T152C/ T112C Touch Monitor User Manual V240927 How-to Videos...
-
Page 2: Lcd Pixel Statement
If you need to use this monitor in an abnormal environ- ment such as high temperature, high humidity, confined space, low atmos- pheric pressure, etc., please contact Gechic customer service center for further advice on operating environment. - Page 3 Monitor Parts Description Monitor Parts and I/O Ports ● OSD Light Instruction ● It shows green light when the monitor is "On" and shows red light when the moni- tor is standby. There is no light when the monitor is "Off". OSD HotKeys ●...
-
Page 4: Accessories Description
Accessories Description HDMI-A Video Cable(1.5m) × 1 USB-A Power & Touch Signal Cable (1.5m) × 1 Optional Accessories Optional Accessories Description Connect the two USB-A male plug to two USB-A USB-A Power & Touch ports on the computer. On the other end, insert the USB-A connector into the monitor's USB-1 port to Signal Cable(2.5m) transfer power and touch signals. - Page 5 Connect to One Computer Notice! The power requirement of this monitor is 5V 1.8A, so one USB-A port of the computer must output 5V 0.9A current. Notice: When inputting video through the HDMI-1 port, it is necessary to connect a USB cable to the USB-1 port, or the touchscreen function will not work.
- Page 6 The monitor can only display the image from one PC. Press to switch input sources between HDMI-1 and HDMI-2. When HDMI-1 is selected, the monitor will display the image from PC 1; also, the touch signal is transmitted to PC 1. Use T1S5 Swivel Stand (Optional) 1.
-
Page 7: Osd Menu Description
Power on, Standby and Power off Status 1. When the monitor is connected to power, it will automatically boot up and enter the “ON” state. 2. If there is no image input, the monitor will enter ”Standby” status after 8 seconds. - Page 8 2. Color Settings Color Settings 1) Color Effect: If the output format of computer image is RGB Limited, it is recommended to select "Standard 1"; if it is RGB Full format, it is recommended to select "Standard 2". Select "Dark Highlight" mode to brighten up dark Color Effect Blue Light Reduction areas;...
- Page 9 4. OSD Menu OSD Menu 1) Language: Change to the other language. 2) H. Position: Move the OSD menu left/right. 3) V. Position: Move the OSD menu up/down 4) Timer(sec): Adjust the idle time before OSD Language menu disappears. H.Position V.Position 5) Transparency: Make the OSD menu transpar- Timer(sec)
- Page 10 Multi-Monitor and Touch Monitor Settings (Windows 11/ 10/ 7) If the computer does not activate touchscreen function automatically or the monitor doesn’t sense touch position accurately, please use "Tablet PC Settings" in Windows 7 "Control Panel" to start touch screen setting. In Windows 11/ 10, search for "Calibrate"...
- Page 11 If there are several HID-compliant touch screen, please click “Events” and check the VID number under “Information”. The VID number should be 222A. Touch Operation and Touch Sensitivity Setup Use the touch Stylus ● The touch monitor does not support the proprietary active styluses of other tablet PCs or smartphones.
-
Page 12: Supported Video Modes
Touchscreen Settings and Precautions Whether Your Operation System Supports External Touch ● Monitor T1 series touch monitors comply with Microsoft® multi-touch protocol. No driver installation is required for Windows 11/ 10 /7 computer to use T1 touch monitor. If your computer is running Linux, Ubuntu or Chrome OS, please consult your computer manufacturer whether the computer is enabled to support "Microsoft Multi-touch protocol". -
Page 13: General Specification
General Specification Spec T152C T112C Wide Screen Wide Screen Panel 15.6 inch(16:9) 11.6-inch(16:9) True Resolution 1920x1080 Color Depth 16.2M Colors 250 (cd/m²)/ 300 (cd/m²)/ Brightness/ Contrast (Typical) 700:1 1000:1 Viewing Angle 170°(H)/170°(V)(CR>10) Projected Capacitive Touch Screen; Touch Technology Support 10-point touch inputs recognition... - Page 14 Monitor Dimension ● T152C T112C To request the drawing of the monitor's dimension and product EOL notifications, please write to : service@gechic.com...
-
Page 15: Troubleshooting
Troubleshooting Problem Solution The computer is connected with Please refer to “Multi-Monitor and Touch multiple monitors. When touching Monitor Settings (Windows 11/ 10/ 7)”. Enter T1 monitor, the cursor appears on "Tablet PC Settings" in Windows "Control another monitor. Panel” to start touch monitor settings. Please Enter [Device Manager], unfold When my PC wakes up from Sleep [Human Interface Devices], find [HID-... -
Page 16: Fcc Compliance Statement
Consult the dealer or an experienced radio/TV technician for help. ˙ Caution: Changes or modifications not expressly approved by GeChic Corp. could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
