- Page 1 T151B/ T131B/ T111B Touch Monitor User Manual V240703 How-to Videos...
-
Page 2: Lcd Pixel Statement
10.Exclusions from Warranty Service Please read the warranty terms below carefully, and follow the usage guide and pre- cautionary notes. Please keep this manual for future reference. GeChic does not war- rant uninterrupted or error-free operation of this Product. The warranty only covers failure /malfunction under normal use conditions during warranty period. -
Page 3: Parts Description
Parts Description LED Light Instruction ● It shows green light when the monitor is "On" and shows red light when the monitor is standby. There is no light when the monitor is "Off". OSD Hotkeys ● Press once to turn on the monitor and press again to turn off Power the monitor. -
Page 4: Accessories Description
Accessories Description 12V-2A AC-DC HDMI-A Video Cable (1.5m) x1 Power Adapter x1 USB-A(Dual) to USB-C Power& Touch Signal Cable (1.5m) x1 Warning! This adapter is used for this monitor USB Type-C Video Cable (1m) x1 only. Please DO NOT con- nect it to other products. - Page 5 Connect to the Computer via the USB-C Port Notice 1: The USB Type-C ports on computers or other devices must: 1. support DisplayPort Alternate Mode (USB Type-C (DP Alt)). 2. be able to stably output 5V 1.6A current to the monitor (if the computer cannot supply sufficient current, please connect 12V adapter to the monitor.) Notice 2: The USB-C port on the monitor cannot supply power to the computer.
- Page 6 3. Erect the Monitor Stand the monitor up on the desktop. It is suggested the user faces the ③ short side(21.3cm) of the stand base to keep the stand stable when adjust- ing the tilt angles. Horizontal Display Vertical Display Warning! When adjusting the monitor’s angle, please ensure its center of grav- ity remains within the turntable range to prevent tilting during use or touch oper- ations.
- Page 7 Connect to speakers (USB-A for power supply, headphone jack ● to output sound) Connect to Wireless Display Adapter (HDMI port) ● Use USB-A port on T1 monitor to power HDMI Wireless Display Adapter. Power Supply Connection Instructions 12V and 5V Current Input ●...
-
Page 8: Osd Menu Description
Control the Monitor On/Off Press the power button to turn the monitor on or off. If the monitor is embed- ded in the case or hung on the wall, rendering the power button unusable, the monitor can be turned on or off in the following ways. 1. - Page 9 3. Advanced Settings 1) Auto Power Off: Select "Yes" to activate this func- tion. When there is no image input, the monitor will enter Standby mode, and power off itself after 270 seconds. The power button shall be pressed to turn on the monitor again.
- Page 10 Touch Monitor Settings Not to Turn off the Power of USB Device Automatically on ● Windows 11/ 10 When the Windows 11/10 PC enters Sleep mode, the PC will turn off the power of USB device automatically. If touch screen function is disabled or USB-C video input disappears after the PC wakes up from sleep mode, it’s recom- mended to set the PC not to turn off the power of USB devices automatically.
- Page 11 Multi-Monitor and Touch Monitor Settings (Windows 11/ 10/ 7) If the computer does not activate touchscreen function automatically or the monitor doesn’t sense touch position accurately, please use "Tablet PC Settings" in Windows 7 "Control Panel" to start touch screen setting. In Windows 11/ 10, search for "Calibrate"...
- Page 12 Monitor Dimension ● T151B T131B T111B To request the drawing of the monitor's dimension and product EOL notifica- tions, please write to : service@gechic.com...
-
Page 13: General Specification
General Specification Spec T151B T131B T111B Wide Screen Wide Screen Wide Screen Panel 15.6 inch(16:9) 13.3 inch(16:9) 11.6-inch(16:9) True Resolution/ 1920x1080/ 16.7M Colors Color Depth Brightness(Typical)/ 250 (cd/m²)/ 250 (cd/m²)/ 300 (cd/m²)/ Contrast 700:1 1000:1 1000:1 Viewing Angle 170°(H)/170°(V)(CR>10) Projected Capacitive Touch Screen;... - Page 14 Whether Your Operation System Supports External Touch Monitor T1 series touch monitors comply with Microsoft® multi-touch protocol. No driver installation is required for Windows 11/ 10 /7 computer to use T1 touch monitor. If your computer is running Linux, Ubuntu or Chrome OS, please con- sult your computer manufacturer whether the computer is enabled to sup- port "...
-
Page 15: Troubleshooting
Troubleshooting Problem Solution The computer is connected with Please open "Tablet PC Settings" in Win- multiple monitors. When touching dows "Control Panel” to start touch monitor T1 monitor, the cursor appears on settings. another monitor. 1. T1 monitor needs to be connected with a 12V adapter. -
Page 16: Fcc Compliance Statement
Consult the dealer or an experienced radio/TV technician for help. ˙ Caution: Changes or modifications not expressly approved by GeChic Corp. could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits.
