ARCHITECTURAL STRIP LIGHT
INSTALLATION INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
Make all electrical and ground connections in accordance with local codes or the National
Electrical Code. If you are not familiar with these codes and requirements, consult a
qualified electrician. This Professional should be familiar with the construction and
operation of this product and hazards involved. Failure to do so may result in serious
personal injury.
To reduce the risk of fire, electric shock, personal injury, or property damage, please read
and follow all safety instructions. If you do not understand these instructions or if any
additional information is required, contact your local Topaz representative. Retain these
instructions for maintenance reference.
Do not exceed the allowed supply voltage marked on the luminaire label information.
Disconnect power at the circuit breaker panel before any installation.
Do not expose wire to any sharp objects such as sheet metal to prevent wiring damage or
abrasion.
While the light is on, please avoid direct eye exposure.
Combustible material should be kept away from fixture/LENS.
Do not make or alter any open holes in any enclosure or any electrical component during
installation.
Do not use when the enclosure is damaged or broken in any way.
Do not alter, relocate or remove wiring, lamp holder power supply or any other electrical
component.
©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark
LSA-LCONN-B
LSA-TCONN-B
LSA-XCONN-B
LSA-CORD5-B
LSA-E2ECONN-B
LSA-DWC-CNPY-B
LSA-OS-PIT-BT-WH
LSA-RMKIT
WARNING
CAUTION
800-666-2852 | SOUTHWIRE.COM
&
Trademark of Southwire Company, LLC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Topaz LSA4-50PCS-W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Southwire Topaz LSA4-50PCS-W

  • Page 1 Do not use when the enclosure is damaged or broken in any way.  Do not alter, relocate or remove wiring, lamp holder power supply or any other electrical component. 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 2: Mounting Instructions

    7. Connect the opposite end of the sling to the threaded mount on the fixture. See Figure 3. Figure 3 8. Open the end of the fixture for wiring. See Figure 4. Figure 4 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 3 7. Make wiring connections at the fixture according to the Wiring Diagram. 8. Installation complete. Figure 7 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 4 5. Attach the free end of the sling assembly to the built in threaded standoffs. Adjust the suspending length of aircraft cable to be suitable for the installed environment. See Figure 11. Figure 1 1 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 5 WARNING: Ensure that anchors are acceptable for the mounting surface and can support fixture weight. Other wall anchors (not provided) may be required Figure 15 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 6 2. Remove the 4 rubber plugs from the mounting bracket, then fit the mounting bracket onto the fixture. See Figure 19. Figure 19 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 7 See Figure 23. Figure 23 7. Install rubber plugs to hide the screw heads. See Figure 24. 8. Installation complete. Figure 24 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 8: Wiring Diagram

    1. Remove the upper cover from both the sensor module and the fixture. Then remove the end cap from the fixture. See Figure 26. Figure 26 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 9 See Figure 29. Figure 29 6. Reinstall the upper cover to both the fixture and the sensor module. See Figure 30. Figure 30 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 10: Connecting Accessories

    4. Fit the baffle to the profile and remove diffuser plate. Only install half of each baffle. See Figure 34. Baffle Figure 34 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 11 11. Connect the wires according to the Wiring Diagram. @120V Max connected length is 32’ @277V Max connected length is 80’ Figure 38 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 12 Figure 41 4. Adjust the lifting bracket on the fixture to a suitable position for suspending and linking. . See Figure 42. Figure 42 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 13 7. Cut off the connectors in one end for wiring to line voltage. Figure 45. Figure 45 8. Reinstall the cover of “L” connector and the fixture. Figure 46. Figure 46 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 14 3. Make the mounting marks on the ceiling for fixtures, please refer to Mounting Instructions for suspend the fixture. 4FT suggested hole distance 31.5" Figure 50. Figure 50 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 15 7. Open a cover from 1 end and cut off the connectors in one of end for wiring to line voltage. Make wiring connections according to the Wiring Diagram. Figure 54. Figure 54 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 16 3. Make the mounting marks on the ceiling for fixtures, please refer to Mounting Instructions for suspending the fixture. See Figure 58. Figure 58 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
  • Page 17 7. Cut off the connectors in one of end for wiring to line voltage. Make wiring connections according to the Wiring Diagram. See Figure 62. Figure 62 800-666-2852 | SOUTHWIRE.COM ©2024 Southwire Company, LLC. All rights reserved.*Registered Trademark & Trademark of Southwire Company, LLC.
