Whirlpool AFG 527/G Product Description Sheet

PRODUCT DESCRIPTION SHEET
Controls
1
1 2 3
1 2 3 4
The exact configuration of the controls may vary according to the model.
Notes:
For correct operation of the appliance and to allow the lid to open freely without damage,
leave at least 7 cm clearance at the sides and rear.
After installation, wait for at least two hours without moving the appliance before connecting
it to the power supply.
If the freezer is left empty for short periods, it is preferable not to switch it off.
Frost formation on the upper edges and interior walls of the appliance is a natural
phenomenon and will not affect the performance of the freezer.
D GB F NL E P
1. Lid handle.
2. Lock.
3. Seal.
4. Separator.
5. Defrost water drain plug.
6. Control panel.
7. Motor compartment ventilation grille.
8. Upper edge.
1. Thermostat: Temperature adjustment.
2. Red LED: Indicates that the freezer
temperature is not sufficiently low.
3. Green LED: Illuminates when the appliance
is on.
4. Orange illuminated button: Fast freeze
function ON/OFF. The fast freeze function is
active when the orange LED in the button
is lit.
DK
I GR S N FIN
GB
