Smacq USB-5200 Series User Manual

Multifunctional data acquisition devices

Advertisement

Quick Links

USB-5200 Series Multifunctional Data
Acquisition Devices
User 's Manual
Rev: C
Smacq Technologies. Co., Ltd
Smacq.com
Smacq.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB-5200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Smacq USB-5200 Series

  • Page 1 USB-5200 Series Multifunctional Data Acquisition Devices User 's Manual Rev: C Smacq Technologies. Co., Ltd Smacq.com Smacq.cn...
  • Page 2: Statement

    Without prior consent and written permission, no content of this manual may be copied, modified, or deleted. Trademark information It is a registered trademark of Smacq Technologies. Co., Ltd. The other products and company names mentioned in this document are trademarks or business names of their respective companies.
  • Page 3: Safety Requirements

    Safety requirements Warning: Only connect voltage within the specified range. If the voltage exceeds the specified range, it may cause equipment damage and even affect personal safety. The voltage range that can be connected to each port is detailed in the product specification section.
  • Page 4: Measurement Category

    Measurement category Warning: This device can only be used in measurement category I (CAT I). Do not use this device to connect signals or perform measurements in measurement categories II/III/IV. Measurement category description Measurement Category I (CAT I) refers to measurements taken on circuits that are not directly connected to the main power supply.
  • Page 5: Environment

    Environment Temperature Operation 0℃~55℃ Storage -40℃~85℃ Humidity Operation 5% RH~95% RH, non-condensing Storage 5% RH~95% RH, non-condensing Pollution level Highest altitude 2000m Pollution level description Pollution level 1: No pollution, or only dry non-conductive pollution occurs. This pollution level has no impact.
  • Page 6: Table Of Contents

    CONTENT Statement ............................. 1 Copyright ............................1 Trademark information ........................1 Other statements ..........................1 Contact us ............................1 Safety requirements ........................2 Measurement category ........................3 Environment ..........................4 1. Getting Started ........................7 1.1. Product introduction ........................7 1.2. Function Diagram ........................8 1.3.
  • Page 7  Clear Trigger ........................21  Pre-Trigger ...........................22 7. Digital Output (DO) ....................... 23 7.1. Signal output mode ......................... 23  Immediate output .........................23  Hardware timing ........................23  Finite number output mode ....................23  Infinite loop output mode ..................... 23 ...
  • Page 8: Getting Started

    1. Getting Started This chapter describes the basic functions of USB-5200 Series Data Acquisition Device, as well as product specifications and precautions in the process of product unpacking. 1.1. Product introduction USB-5200 Series data acquisition device is the multifunctional data acquisition device based on high-speed USB2.0 interface.
  • Page 9: Function Diagram

    1.2. Function Diagram USB-5200 series data acquisition device functions schematic 1.3. Product specifications The following product specification parameters, unless otherwise stated, are acquired at the temperature of 25°C and the humidity of 40%, while the device is turned on for 20 minutes.
  • Page 10 Analog input USB-5420/5421/5620/5621/5220/5221: 16-CH Channel(Single End) USB-5410/5411/5610/5611/5310/5311: 8-CH ADC type USB-5210/5211/5220/5221: 16-Bit Resolution USB-5610/5611/5620/5621: 14-Bit USB-5410/5411/5420/5421: 12-Bit USB-5411/5421/5611/5621/5211/5221: 500kS/s/Ch, continuous Sampling rate USB-5410/5420/5610/5620/5210/5220: 250kS/s/Ch, continuous Timing resolution 10ns Channel synchronization Range ±10V / ±5V Input coupling mode Input impedance AI+ to AI- : 10GΩ, AI- to AGND : 1MΩ Small signal bandwidth(-3dB) 450kHz Input bias current...
  • Page 11 External trigger Channel 1 input 、 1 output High level: 1.95 V~5 V Input voltage Low level: 0 V~1.2 V High level: 3.3 V Output voltage Low level: 0 V ~ 0.003 V Output power-on status Low level Ascending edge: 6ns Output edge time Descending edge: 8ns External sampling clock I/O...
  • Page 12: Product Unpacking And Packing List

    If you find that the product comes in damaged after unpacking, please get in touch with us as soon as possible. Do not install damaged equipment on your devices. 2.3. Packing list Name Specification Description Quantity USB-5200 Series Multifunctional Data USB-5200 Series Acquisition Devices Include Attachments USB cable USB cable/black/1.5 meters Wiring terminals 10Pin/Green/3.81mm pitch terminal...
  • Page 13: Installation

    3. Installation This chapter describes signal connection and drive installation of USB-5200 series. 3.1. Connector signal pins distribution USB-5200 series signal pins distribution Signal pin allocation list Signal name Notes Signal name Notes AI 0 Analog input 0 AGND Simulated ground...
  • Page 14: Usb Cable Reinforcement Design

    3.2. USB cable reinforcement design USB cable connectors are prone to be pulled off during operation. USB-5200 series data acquisition devices provide a cable reinforcement design, with which a strap can be used to fix the USB cable to the device to prevent the accidents.
  • Page 15: Drive Installation

    3.3. Drive installation Smacq USB-5200 series data acquisition device support Microsoft Windows XP, Windows 7, Windows 8/8.1, and Windows 10, including all the 32-bit and 64-bit versions. To install the driver for USB-5200 devices, you need to turn off driver signature enforcement first. Here is an example step-by-step tutorial on how to install the driver in Windows 7.
  • Page 16: Analog Input (Ai)

    4. Analog Input (AI) This chapter describes measuring the relevant content of analog input signals on USB-5200 series data acquisition cards. AI here is short for Analog Input. 4.1. Circuit diagram analog input circuit 4.2. Signal Connection Mode The AI acquisition connection mode of the USB-5200 series data acquisition device supports grounding reference single-ended input.
  • Page 17: Limited Number Acquisition Mode

    Attention The set number of collection points cannot exceed 2MPts. 4.4. AI sampling clock The USB-5200 series data acquisition device has a rich collection timing option. The schematic diagram of the AI sampling clock. AI sampling clock options The AI acquisition uses the AI timer signal as the AI sampling clock by a default. The AI acquisition can be set via software to use other sampling clock sources to achieve the synchronization of each function.
  • Page 18: Trigger

    4.5. Trigger The USB-5200 series data acquisition device provides rich trigger options. The schematic diagram of the AI acquisition trigger options. AI trigger options The AI acquisition uses the AiSoftTrig software trigger as the trigger source by default. The AI acquisition can use other trigger sources via software settings to achieve the synchronization of each function.
  • Page 19: Pre-Trigger

     Pre-trigger The pre-trigger function is used to record the pre-trigger signal. The pre-trigger function relies on the hardware FIFO to store the data of the pre-trigger signal, so the number of pre-triggered points is limited and cannot exceed 4kPts. AI pre-trigger function diagram When the pre-trigger point is set to 0, the data before the trigger signal is not stored, and the user will not be able to obtain the signal state before the trigger signal.
  • Page 20: Digital Input (Di)

    5. Digital Input (DI) This chapter introduces the digital input signal acquisition on USB-5200 series data acquisition cards. DI is the abbreviation of Digital Input here. digital input circuit 5.1. Signal acquisition mode When the USB-5200 series data acquisition device performs DI acquisition, it supports continuous acquisition mode or limited number acquisition mode.
  • Page 21: Sampling Rate

    5.2. Sampling rate For USB-5200 series of data acquisition devices, the DI sampling rate is up to10MSa/s/ch. This is parallel simultaneous sampling of all channels, with each channel able to achieve this highest sampling rate. 5.3. DI sampling clock The USB-5200 series data acquisition device has a rich DI acquisition timing option. The DI sampling clock is shown in below.
  • Page 22: Trigger

    5.4. Trigger The USB-5200 series data acquisition device provides rich trigger options. The DI acquisition trigger options are shown in below. DI trigger options The DI acquisition uses the DiSoftTrig software trigger as the trigger source by default. The DI acquisition can use other trigger sources via software settings to achieve the synchronization of each function.
  • Page 23: Pre-Trigger

     Pre-Trigger The pre-trigger function is used to record the pre-trigger signal. The pre-trigger function relies on the hardware FIFO to store the data of the pre-trigger signal, so the number of pre-triggered points is limited and cannot exceed 4kPts. The pre-trigger function diagram is shown in below. DI pre-trigger function When the pre-trigger point is set to 0, the data before the trigger signal is not stored, and the user will not be able to obtain the signal state before the trigger signal.
  • Page 24: Digital Output (Do)

    Digital output circuit 6.1. Signal output mode When the USB-5200 series data acquisition card is utilized for digital output, the following four output modes are supported:  Immediate output Immediate output refers to the output state without buffer and no waveform. The computer sends a command to the acquisition device, and it immediately outputs the specified level state.
  • Page 25: Infinite Non-Loop Output Mode

    6.2. Output update rate USB-5200 series data acquisition device DO output update rate can reach up to 10MSa/ s/Ch. This means parallel simultaneous sampling of all channels, while each channel can achieve this highest sampling rate.
  • Page 26: Trigger

    6.4. Trigger The USB-5200 series of data acquisition devices provide a rich set of trigger options, as shown in below, which describes trigger options for the DO output. DO trigger options The DO output uses the channel exclusive software trigger signal DoSoftTrig as the trigger source by default.
  • Page 27: Synchronization System

    7. Synchronization System This chapter introduces the multi-card synchronization system of the USB-5200 series data acquisition device. The synchronous system has 4 ports, sampling clock input, sampling clock output, external trigger input, and external trigger output. 7.1. Sampling clock The sampling clock is used to eliminate the error of the clock between multiple acquisition devices and achieve the synchronization of the sampling rate between multiple acquisition devices.
  • Page 28: External Trigger

    7.2. External trigger The pins of external trigger input and output are used to trigger the USB-5200 series acquisition card in synchronization with an external device. Each function trigger source of the acquisition device can select the external trigger input pin Ext_Trig_In as the trigger source.
  • Page 29: After Sales Service And Warranty

    8. After sales service and warranty Smacq Technologies. Co., Ltd. promises that its products are under warranty. If the product malfunctions during normal use, we will provide free repair or replacement of parts for the user. For detailed warranty instructions, please refer to the warranty instructions inside the packaging box.
  • Page 30: Ordering Information

    9. Ordering Information Main Equipment Model Notes USB-5221 16-Bit, 16-AI(500 kSa/s)、2-DI、2-DO USB-5220 16-Bit, 16-AI(250 kSa/s)、2-DI、2-DO USB-5211 16-Bit, 8-AI (500 kSa/s)、8-DI、8-DO USB-5210 16-Bit, 8-AI (250 kSa/s)、8-DI、8-DO USB-5621 14-Bit, 16-AI(500 kSa/s)、2-DI、2-DO USB-5620 14-Bit, 16-AI(250 kSa/s)、2-DI、2-DO USB-5611 14-Bit, 8-AI (500 kSa/s)、8-DI、8-DO USB-5610 14-Bit, 8-AI (250 kSa/s)、8-DI、8-DO USB-5421 12-Bit, 16-AI(500 kSa/s)、2-DI、2-DO USB-5420...
  • Page 31: Document Revision History

    10. Document Revision History Date Edition Remarks 2018.11.07 Rev: A First release. Update analog input sampling rate. 2019.03.05 Rev: B Add new model USB-56xx/54xx and it parameter. 2021.11.25 Rev: C...
