PCI-5000 Series Multifunctional Data Acquisition Devices User 's Manual Rev: A Smacq Technologies. Co., Ltd Smacq.com Smacq.cn...
Page 2
Smacq Technologies. Co., Ltd. shall not be liable for any errors or inaccurate descriptions that may be ⚫...
Page 3
Safety requirements Warning: Only connect voltage within the specified range. If the voltage exceeds the specified range, it may cause equipment damage and even affect personal safety. The voltage range that can be connected to each port is detailed in the product specification section.
Page 4
Measurement category Warning: This device can only be used in measurement category I (CAT I). Do not use this device to connect signals or perform measurements in measurement categories II/III/IV. Measurement category description Measurement Category I (CAT I) refers to measurements taken on circuits that are not directly connected to the main power supply.
Page 5
Environment Temperature Operation 0℃~55℃ Storage -40℃~85℃ Humidity Operation 5% RH~95% RH, non-condensing Storage 5% RH~95% RH, non-condensing Pollution level Highest altitude 2000m Pollution level description Pollution level 1: No pollution, or only dry non-conductive pollution occurs. This pollution level has no impact.
Page 8
1. Getting Started This chapter describes the basic functions of PCI-5000 Series Data Acquisition Device, as well as product specifications and precautions in the process of product unpacking. 1.1. Product introduction PCI-5000 Series data acquisition device is based on PCI bus interface. When connected to the computer, it can be used for continuous high-speed signal acquisition and high-speed control signal output.
Page 9
1.2. Function Diagram PCI-5000 series data acquisition device functions schematic 1.3. Product specifications The following product specification parameters, unless otherwise stated, are acquired at the temperature of 25° C and the humidity of 40%, while the device is turned on for 20 minutes.
Page 10
Software FIFO 2 MPts/Ch Hardware FIFO 4096 Pts Analog input mode Continuous / Oneshot / Single read Analog input accuracy (With temperature coefficient of 5 ppm/℃) Zero offset Random noise Full range absolute accuracy Range Gain error (ppm of range) (μV rms) (μV) (ppm of reading)
Page 11
If you find that the product comes in damaged after unpacking, please get in touch with us as soon as possible. Do not install damaged equipment on your devices. 2.3. Packing list Name Specification Description Quantity PCI-5000 Series Multifunctional Data PCI-5000 Series Acquisition Devices...
Page 12
3. Installation This chapter describes signal connection and drive installation of PCI-5000 series. 3.1. Connector signal pins distribution PCI-5000 series signal pins distribution Signal connector distribution diagram...
Page 13
Clock interface signal distribution diagram Signal pin allocation list Signal name NOTE Analog input 0 Analog input 1 Analog input 2 Analog input 3 Analog input 4 Analog input 5 Analog input 6 Analog input 7 DI/O 0 Digital input/output 0 DI/O 1 Digital input/output 1 DI/O 2...
Page 14
3.2. Drive installation PCI-5000 series data acquisition device can be used in Windows 7 and Windows 10, including 32-bit and 64-bit. Here, taking the driver installation in Windows 10 environment as an example, we will introduce how to install the driver of PCI-1316 data acquisition device step by step. The steps of installing drivers in Windows 7 environment are the same as those in Windows 10 environment.
Page 15
3) Then in the pop-up dialog box, click "Browse" button, locate the operating system version folder corresponding to the driver, and then click "Next", as shown below. Locate the folder where the driver is located. 4) The computer starts to enter the driver installation process. After the installation is successful, the dialog box shown below pops up, and the driver installation is completed.
Page 16
AI here is short for Analog Input. Each analog input channel of PCI-5000 series data acquisition device has an independent ADC, so there is no time difference between the measured data of each channel during analog input acquisition, and multi-channel synchronous acquisition is realized.
Page 17
4.3. Sampling rate setting When the PCI-5000 series data acquisition device collects in a single channel, the channel can achieve the maximum sampling rate. If two channels are enabled for one acquisition, the sample rate for each channel is half the set sample rate;...
Page 18
5. Digital Input (DI) This chapter introduces the digital input signal acquisition on PCI-5000 series data acquisition cards. DI is the abbreviation of Digital Input here. 5.1. Signal acquisition mode When the PCI-5000 series data acquisition device performs DI acquisition, it supports continuous acquisition mode or limited number acquisition mode: ◼...
Page 19
5.2. Trigger The PCI-5000 series data acquisition device provides rich trigger options. The DI acquisition trigger options are shown below. DI trigger options The DI acquisition uses the DiSoftTrig software trigger as the trigger source by default. The DI acquisition can use other trigger sources via software settings to achieve the synchronization of each function.
Page 20
The digital input is referred to as DO here, the abbreviation of Digital Output. 6.1. Signal output mode When the PCI-5000 series data acquisition card is utilized for digital output, the following four output modes are supported: ◼ Immediate output ◼...
Page 21
PCI-5000 series data acquisition device DO output update rate can reach up to 10MSa/ s/Ch. 6.3. Trigger The PCI-5000 series of data acquisition devices provide a rich set of trigger options, as shown below, which describes trigger options for the DO output.
Page 22
7. Synchronization System This chapter introduces the multi-card synchronization system of the PCI-5000 series data acquisition device. The synchronous system has three ports, synchronous clock, external trigger input, and trigger output. 7.1. Synchronous clock The synchronous n clock is the key signal to ensure the synchronization of multiple devices, which is used to eliminate clock errors among multiple devices.
Page 23
8. After sales service and warranty Smacq Technologies. Co., Ltd. promises that its products are under warranty. If the product malfunctions during normal use, we will provide free repair or replacement of parts for the user. For detailed warranty instructions, please refer to the warranty instructions inside the packaging box.
