- Page 2 All rights reserved. The information in this document is subject to change without notice. Publish statement Thank you for purchasing this series UPS. This series UPS is an intelligent, single phase in single phase out, high frequency online UPS designed by our R&D team who is with years of designing experiences on UPS.
-
Page 3: Table Of Contents
Table of Contents Important Safety Warning ........................3 Transportation ..........................3 Preparation ........................... 3 Installation ............................ 3 Operation ............................4 Maintenance, service and faults ................... 4 Symbols used in this guide ..................... 5 Installationand setup ..........................5 Unpack checking ........................5 Real panel view ........................... -
Page 4: Important Safety Warning
1. Important Safety Warning Important safety instructions – Save these instructions Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully There exists dangerous voltage and high temperature inside the UPS. -
Page 5: Operation
The ups should reserve sufficient heat dissipation channels and be careful not to let other objects block the front and rear panels. It's recommended to leave at least 50cm space in front and back of the UPS for heat dissipation. 1-4 Operation ... -
Page 6: Symbols Used In This Guide
and eyes. It may be toxic. Please replace the fuse only with the same type and amperage in order to avoid fire hazards. Do not dismantle the UPS system. 1-6 Symbols used in this guide WARNING! Risk of electric shock CAUTION! Read this information to avoid equipment damage 2. -
Page 7: Real Panel View
2-2 Real panel view 1KVA/1.5KVA: 2KVA: 3KVA: 1. AC Input 2. Input circuit breaker 3. Output receptacles 4. Battery Terminal (option) 5. SNMP intelligent slot (option) 6. Network /Fax/Modem Surge Protection (option) 7. EPO (option) 8. RS232 communication port 9. USB (option) -
Page 8: Installing The Ups
2-3 Installing the UPS Rackmount installation The Rackmount cabinet comes with all of the hardware required for installation in a standard EIA or JIS seismic Rackmount configuration with square and round mounting holes. The rail assemblies adjust to mount in 19” racks with a distance from front to rear around 70~76 cm (27 to 30 inches) deep. - Page 9 Figure2 Fixing the Rails Repeat Steps 3 and 4 for the other rail assembly. Tighten the four butterfly nuts in the middle of each rail assembly. If installing optional cabinets, repeat Step 1 through Step 6 for each rail kit. Place the UPS on a flat, stable surface with the front of the cabinet facing to you.
- Page 10 To install the UPS Do not make unauthorized changes to the ups; otherwise, NOTE damage may occur to your equipment and void your warranty. Do not connect the ups power cord to utility until after NOTE installation is completed. a) Remove the front cover of each UPS Press the cover side with LCD display, hold the other side and quickly extract it, then extract the other side with display.
- Page 11 Figure 6 Connecting the UPS Internal Batteries d) Replace the UPS front cover. To replace the cover, verify that the ribbon cable is protected and (if EBPS are installed) the EBP cable is routed through the knockouton the bottom of the cover. Put the front cover hooks of side with display to the cover port, put another side to the other two ports, then press it until the cover and the chassis are combined tightly.
-
Page 12: Rackmount Converted To Tower Installation
Connecting the EBP(s) 1. To install the optional EBP(s) for a UPS a. Disconnect the switch of the EBP , then remove the cover plate of the UPS and EBP b. Connect the UPS and EBP by battery cable. c. - Page 13 Figure 11 plastic base installation ③ If an EBP is needed to be placed in the middle, the assembly of plastic base is similar(Figure 11 ).The difference is that two 1U plastic base extended boards are added in the middle.(as the following shows) （A）...
- Page 14 （2）Rack mount converted to Tower LCD Display plastic base installation （A） （B） （C） Figure 13 increase UPSplasticbase installation The installation between UPS and EBPS can be referred to Figure 14 Figure 14 The installation for UPS and battery boxes...
-
Page 15: Ups Startup And Turn Off
Figure15 Long backup external battery connection a) Install the base, then place the RT UPS on the base one by one as Fig.13 shows. b) The cover installation and cable connection of the UPS and EBPS are the same as RT. (To install the optional EBP(s) for a UPS) 2-4 UPS startup and turn off ... -
Page 16: Configuring Battery Setings
Turn off operation (1) Turn off the UPS in line mode a) Press and hold the OFF key for more than half a second to turn off the UPS and inverter. b) After the UPS shutdown, the LEDs go out and there is no output. If output is needed, you can set bps“ON”onthe LCD setting menu. -
Page 17: Led Indicator
（1）LED（from right to left: “alarm”,“bypass”,“battery”,“inverter”); （2）On-Line UPS LCD display;（3）Function keys LED Indicator Status Indicator Description The UPS has an active alarm or fault. The UPS is in Bypass mode. The UPS is operating normally on bypass during High Efficiency operation. Yellow The UPS is in Battery mode. -
Page 18: Lcd Display Icons
Function Key Description ESC/OFF To turn off the ups or exit setting mode without save. To go to previous selection. Down To go to next selection. To turn on the ups or confirm the selection in setting mode or enter setting ENTER/ON mode. -
Page 19: Output Information
Indicates the warning and fault codes. Warning: flashing with warning code. Fault: lighting with fault code Output Information Indicate output voltage, output frequency, load percent, load in VA, load in Watt and discharging current. Battery Information Indicates battery level by 0-24%, 25-49%, 50-74% and 75-100% in battery mode and charging status in line mode. - Page 20 Indicates the DC/AC inverter circuit is working. Indicates the UPS is working converter frequency mode. Indicates the UPS is working Generator mode. Indicates the UPS is working ECO mode. Alarm Information Indicates unit alarm buzzer is disabled. Indicates unit overload alarm. Indicates unit battery low status.
-
Page 21: Operations
3. Operations 3-1 Button operation Function Button Turn on the UPS: Press and hold ON button for at least 2 seconds to turn on the UPS. Confirm current settings: When the UPS enters the setting mode, must press this button to confirm the settings value what ON /ENTER Button you want, nest press up/down button to... -
Page 22: Setup The Ups
3-2 Setup the UPS Step 1: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. For 100/110/115/120/125VAC models: The power cord is supplied in the UPS package. Step 2: UPS output connection ... -
Page 23: Lcd Display
Step 4: Turn on the UPS Press the ON button on the front panel for two seconds to power on the UPS. Note: The battery charges fully during the first five hours of normal operation. Do not expect full battery run capability during this initial charge period. Step 5: Install software Find the download link on the software installation guide in the packaging box, download the corresponding software package then install. - Page 24 There are 8 interfaces available in the LCD display. Item Interface Description Content Displayed Input voltage& Output voltage Input frequency& Output frequency Battery voltage& Battery capacity Environment Temperature Load...
-
Page 25: Ups Setting
Firmware Version UPS model. Alarm Code(Warming Message) All alarm codes are present when abnormal behavior(s) occur(s) 3-4 UPS setting TheUPS has setting functions. This user settings can be done under any kind of UPS working mode. The setting will take effect under certain condition. Below table describes how to set the UPS. - Page 26 Note: Press “Down”button to confirm selection and exit setting mode when LCD display the last selection in UPS setting mode. Item Settings Content display Mode setting Press Enter button to change the setting (NOR or CF or GEN or ECO). Press UP button ▲...
- Page 27 Output voltage setting Press Enter button to change the setting(100,110,115,120,125). Press UP button ▲ to select the previous setting. Press DOWN button ▼ to select the next setting. Frequency setting Press Enter button to change the setting (50 or 60Hz). Press UP button▲...
- Page 28 Battery EOD voltae setting(Group 2) Press Enter button to change the setting (1.6/1.67/1.75/1.84). Press UP button ▲ to select the previous setting. Press DOWN button ▼ to select the next setting. Bypass voltage upper limit setting Press Enter button to change the setting(The bypass voltage upper limit range is 120-132Vac ).
-
Page 29: Operational Status And Mode(S)
BYPASS enable/disable setting Press Enter button to change the setting(ON or OFF). Press UP button ▲ to select the previous setting. Press DOWN button ▼ to save and exit the setup. Bypass disable setting 3-5 Operational Status and Mode(s) item Content Displayed Standby Mode No Output... -
Page 30: Alarm Or Fault Reference Code
3-6 Alarm or Fault reference code Event log UPS Alarm Warning Buzzer Inverter fault(Including Inverter Beep continuously Fault LED lit bridge is shorted) Fan fault Beep continuously Fault LED lit Initiail fault Beep continuously Fault LED lit Battery Charger fault Beep continuously Fault LED lit DC Bus over voltage... -
Page 31: Trouble Shooting
4. Trouble shooting If the UPS system does not operate correctly, please solve the problem by using the table below and theTrouble Shooting Chart. Symptom Possible cause Remedy Check if input power cord The AC input power is not firmly connected to the connected well. - Page 32 Trouble Shooting Chart...
-
Page 33: Storage And Maintenance
5. Storage and Maintenance Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. Be sure to deliver the spent battery to a recycling facility or ship it to your dealer in the replacement battery packing material. - Page 34 Relay card Mini dry contact card is used for providing the interface for UPS peripheral monitoring. The contact signals can reflect UPS running status.The card is connected to peripheral monitoring devices via terminal board to facilitate the effective monitoring of the real-time status of UPS and timely feedback the status to monitor when abnormal situation occurs(such as UPS failure, mains interruption,UPS bypass and ect.).
- Page 35 Type (Max Switched Voltage) AC:120V AC:120V DC:5~12V DC:24V Relay card contact (Max Switched Current) AC:1A AC:1A DC:1A DC:1A Emergency Power-off (EPO) EPO is used to shut down the UPS from a distance. This feature can be used for shutting down the load and the UPS by thermal relay, for instance in the event of room overtemperature.
-
Page 36: Specification
7. Specification 1.5KVA(S) 3B 2KVA(S) 1KVA(S) 2B 1KVA(S) 3B MODEL 3KVA(S) 6B 1.5KVA(S) 4B 2KVA(S) Capacity (VA/Watts) 1000VA//900W 1000VA/1000W 1500VA/1350W 2000VA / 1800W 3000VA / 2700W INPUT Nominal voltage 100/110/115/120/125Vac Input voltage range 90-150Vac@full load; 55-150Vac@50% load (Ambient Temp. <40 ℃ ) Operating frequency 40~70Hz (50/60Hz Auto-Sensing) range... - Page 37 SYSTEM FEATURES 105%-125%: UPS transfer to bypass after 1 minute when the utility is normal Over Load Capability 125%~130%: UPS transfer to bypass after 30 seconds when the utility is normal (Online mode) >130%:UPS transfer to bypass after 0.2 second when the utility is normal 105%-125%: UPS after 1minute shut down Over Load Capability 125%~130%: UPS after 10 seconds shut down...
