- Page 1 Rev.07 07/2022 USE AND MAINTENANCE MANUAL ERA ARMCHAIR GYNECOLOGY SERIES ERA COUCH MODELS Description Code 119A37H4N...
-
Page 2: Table Of Contents
Table of contents INTRODUCTION p. 3 SAFETY p. 4 WARNINGS – WARRANTY – PACKAGING – UNPACKING p. 5 LABEL p. 6 DISPOSAL AND TECHNICAL SPECIFICATIONS p. 7 TECHNICAL SPECIFICATIONS OF THE POWER GRID p. 8 WARNINGS p. 9 HOW TO USE THE ARMCHAIR p. - Page 3 In case of transfer of use to a third party, this manual must be transferred as well, along with the other documents, as provided by EU Regulation 2017/745. Intended use The ERA armchair is a professional armchair used by gynaecology professionals for visit and treatment. Manufacturer details...
- Page 4 WARNING! Do not use the armchair: Beyond its declared maximum safe working load. On unstable floors or near inclined floors, steps, etc. If it has been tampered with or modified. In a potentially explosive atmosphere where a fire hazard or corrosion may occur, or exposed to the weather.
-
Page 5: Technical Specifications Of The Power Grid
The ERA armchair warranty covers only the manufacturing defects for 24 months starting from the date of delivery. The warranty does not cover: consumables and items of normal wear – such as upholstery, foot pedals/hand controls, power cables and bearings –, breakdowns caused by any impact and/or fall, wrong or... - Page 6 Manufacturer Product Code Serial Number Date of manufacture Max working load Warning Temperature limit Humidity limitation Keep away from sunlight and heat sources Keep away from rain Read the instructions This symbol on a product means that it should not be thrown with regular waste, but disposed of following the laws on recycling/disposal in force in your country/region.
- Page 7 WARNING! This product should not be thrown with regular waste, but disposed of following the laws on recycling/disposal in force in your country/region. Adjustable height between 53 and 85 cm. Electric elevation with hand control. Backrest angle +80. Electric movement with hand control. ...
- Page 8 Class II 230V 50Hz power cord. Low voltage 24V direct current motor. Low voltage 24V foot switch/hand control. Automatic limit switch. With resettable thermal fuse. WARNING! Please note that the actuator/motor should be ran intermittently: max 2 minutes on/18 minutes off. 8 of 17...
-
Page 9: Warnings
WARNING The professional should be very careful: 1. Not to step on the footrest, the backrest and on the armrests to avoid the overturning of the armchair. 2. Not to use the armrests to lift the armchair, in particular when the patient sits on it. 3. -
Page 10: How To Use The Armchair
HOW TO USE THE ARMCHAIR The height adjustment between 53 and 85 cm is carried out through the hand control. The adjustment of the backrest is carried out through the hand control. The adjustment of the footrest is carried out through the hand control. - Page 11 Use knob 1 to adjust the side armrests in height. Use knob 2 to adjust the side armrests in inclination. KNOB 2 KNOB 1 The paper roll holder is placed on the backrest. PAPER ROLL HOLDER The padded headrest is secured to the backrest with hook and loop fasteners.
-
Page 12: Problems, Causes And Solutions
This device allows inhibiting all electrical functions. With the magnet inserted, all the electrical functions are active. Removing the magnet all the electrical functions inhibited. In addition to the SAFETY MAGNET (described above), a software is inserted thanks to which the adjustment of the bed is activated only by double impulse of the command (DOUBLE CLICK). -
Page 13: Maintenance
Maintenance must be carried out by a specialist, an electrician or someone who is familiar with the content of this manual. Check the safety conditions of the device after any incident such as falls, violent impacts, spilling of liquids, etc. and any time you deem it necessary. Immediately change faulty elements. -
Page 14: Cleaning The Upholstery
The use of disinfectants is recommended in order to disinfect hands and other parts of the body that came into contact with the patient or other surfaces. WARNING! Unplug the couch before cleaning the electrical parts. CLEANING THE UPHOLSTERY: Clean with a damp soft cloth with a neutral detergent solution, rinse with clean water. WARNING! After cleaning dry immediately with a soft cloth. -
Page 15: Optional Accessories
WARNING! The presence of Alcohol and other chemical agents may increase surface weak and aesthetic appearance could change overtime. The use of detergents containing additives and/or alcohol has a tendency to increase wear and aging process of the treated surface. CLEANING THE POWDER COATED STEEL: Gently dust with a dry or at most a lightly damp non-abrasive cloth. -
Page 16: Upholstery Colours
16 of 17... -
Page 17: Inspection Record Sheet
INSPECTION RECORD SHEET DEVICE MODEL / CODE: INSTALLATION DATE SERIAL No. ……………………………………… ……………………… ……………………. Inspection Maintenance Name of the inspector Signature Date 17 of 17...
