Delfield Shelleymatic N10 Specifications

Shelleymatic
by Del eld
N6/N10/N14
Free-Standing Self-Contained Milk Or Beverage Dispensers
Models
• N6-1313-34 6 crate capacity, 34" height
• N6-1313-36 6 crate capacity, 36" height
• N10-1313-34 10 crate capacity, 34" height
N10-1313-36

Specifications

Exterior sides shall be 20-gauge stainless steel. Top and corner
supports shall be 16-gauge stainless steel, welded, ground and
polished into one integral unit.
Interior liner shall be water-tight and constructed of 22-gauge
stainless steel with a 1.00" (2.54cm) I.P.S. drain. Unit shall be
insulated with high-density, foamed-in-place environmentally
friendly, Kyoto Protocol Compliant, Non ODP (Ozone Depletion
Potential), Non GWP (Global Warming Potential) polyurethane
insulation with a non-conductive top breaker strip. Refrigerated
compartment is equipped with drain plumbed to a drain valve
located at the bottom of the counter. Each opening shall have
a stainless steel sliding lid recessed handles. Three stainless
steel louvers shall be installed in the end and sides of the
cabinet to allow proper air flow to the condensing unit.
Each self-leveling mechanism shall be field adjustable by
adding or removing stainless steel extension springs in the
elevator housing inside the unit. The elevators shall be
connected by removable platform carriers constructed of 18-
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
®
Standard Features
• Cabinet top and corners to be 16-gauge
stainless steel
• 1" IPS drain
• Units insulated with foamed in place
environmentally friendly, Kyoto Protocol
Compliant, Non ODP (Ozone Depletion
Potential), Non GWP (Global Warming
Potential) polyurethane
• Units to have sliding stainless steel lids with
recessed handle
• Self-leveling
adjustable by adding and removing
stainless steel extension springs located
inside the elevator housing
• Dispenser platform carrier shall
gauge stainless steel and removable for
cleaning
• 6" adjustable stainless steel legs
• Refrigeration system shall be HFC-134A
refrigerant
• Expansion valve and pressure control
• 9' cord and plug
• One year parts and 90 day labor standard
warranty
gauge stainless steel.
Refrigeration system shall use HFC-134a refrigerant.
Refrigerant flow shall be controlled by an expansion valve.
Cabinet shall maintain 36°F to 40°F (2°C to 4°C) temperature
with lids closed for storage. Refrigeration system shall be
controlled by a pressure control, located near the condensing
unit.
Electrical connections shall be 115 volt, 60 cycle, single phase.
Unit shall have a 9' (2.7m) long electrical cord and NEMA 5-15P
plug. Exterior has an ON/OFF switch.
Legs: Unit shall be mounted on 6.00" (15.2cm) high adjustable
stainless steel legs.
NOTE: This equipment is intended for storage and /or display
of pre-packaged or bottled products only.
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
• N10-1313-36 10 crate capacity, 36" height
• N14-1313-34 14 crate capacity, 34" height
• N14-1313-36 14 crate capacity, 36" height
mechanisms shall be
be 18-
www.delfield.com
Options &
Accessories
• 4.00" (10.2cm) diameter swivel
casters (two locking) with corner
bumpers (adds 1.75" [4.4cm]
to overall length and depth and
reduces overall height by 1.00"
[2.5cm])
• Wrap-around bumpers (adds 1.75"
[4.4cm] to overall length and
depth)
• Lid locking device
• Special voltages
• Dial or digital style thermometer
