Lucent Technologies 4ESS Switch Maintenance Operations

With 1b processor maintenance operations center task oriented practice

Hide thumbs Also See for 4ESS Switch:

Manual (365 pages)

,

Manual (164 pages)

,

Manual (336 pages)

Table Of Contents

Advertisement

Quick Links

Download this manual

Task Oriented Practice (TOP)

TM

4ESS

Switch

With 1B Processor

Maintenance Operations Center

No

Go to 893

TOP Comments Hot Line:

Monday through Friday

8:00 a.m. - 4:00 p.m. (Eastern)

Call: 1-800-645-6749

START

Do you

Yes

understand

how to use TOP

Copyright

2000 Lucent Technologies

C

Unpublished and Not for Publication

All Rights Reserved

Printed in U.S.A.

Go to 001

Issue 7

JUN 2000

234-351-002

TPG

000

TITLE PAGE

Table of Contents

Advertisement

Need help?

Need help?

Do you have a question about the 4ESS Switch and is the answer not in the manual?

Questions and answers

Summary of Contents for Lucent Technologies 4ESS Switch

Page 1 Go to 893 Go to 001 how to use TOP TOP Comments Hot Line: Issue 7 JUN 2000 Copyright 2000 Lucent Technologies Monday through Friday Unpublished and Not for Publication 234-351-002 All Rights Reserved 8:00 a.m. - 4:00 p.m. (Eastern) TITLE PAGE Printed in U.S.A.
Page 2 This material is protected by the copyright laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to Lucent Technologies), except in accordance with applicable agreements, contracts or licensing, without the express written consent of the Toll Switching, Voice and Signaling Information Development Organization and the business management owner of the material.
Page 3 234-351-002 Issue Number: 7 Date: Jun 2000 Lucent Technologies welcomes your feedback on this document. Your comments can be of great value in helping us improve our documentation. 1. Please rate the effectiveness of this document in the following areas:...
Page 4 Do Not Cut—Fold Here And Tape NO POSTAGE NECESSARY IF MAILED IN THE UNITED STATES Lucent Technologies Bell Labs Innovations BUSINESS REPLY MAIL FIRST CLASS MAIL PERMIT NO. 201 ALTAMONTE SPRNGS, FL POSTAGE WILL BE PAID BY ADDRESSEE DOCUMENTATION SERVICES COORDINATOR LUCENT TECHNOLOGIES 240 E.
Page 5 ....NTP-006 4ESS Switch Emergency Recovery Trouble Isolation Procedures ......TAP-111 AMA Control File Data —...
Page 6 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Broadcast Warning Message — Access Scans Network and Obtain Hardcopy ..... . NTP-003 Broadcast Warning Message;...
Page 7 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Exit Emergency Mode ..........DLP-501 Generic Big GULP Partial Update —...
Page 8 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Partial Update; Generic — Perform Using 3B Compuer Tape Units ......NTP-006 Partial Update;...
Page 9 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Request Initialization Phase ......... . DLP-504 SCANS Network —...
Page 10 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Teleprocessing Capability — Test for ........DLP-519 Test for Teleprocessing Capability .
Page 11 Volumes 234-355-001, 234-355-005, and 234-355-010. Readiness of individual frames, which are the responsibility of the 4ESS Switch Maintenance Operations Center (MOC), to become a part of the working system was established by successful completion of Installation Handbook test procedures.
Page 13 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO If Broadcast Warning Messages (BWMs) Are Stored on Support Organization’s System, Do Not — Perform This Procedure Connect Terminal Equipment as Required to Access SCANS Network and Print Hardcopy of BWMs —...
Page 15 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At APS MCRT Terminal, Enter OP:OOS! — — Using OP:OOS Response, Identify All APS Units That Are Out-of-Service Enter RST:a b! for All Out-of-Service Units (a = Unit Type;...
Page 16 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Using OP:OOS Response, Identify All APS Units That Are Out-of-Service — At APS MCRT Terminal, Enter RST:a b! for All Out-of-Service Units (a = Unit Type; —...
Page 17 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO — If Tapes Are Being Written in an AT&T Office, Perform Items 2 Through 5; Otherwise Go To Item 6 At APS MCRT, Enter Message INH:ADB,APP IBGTT! To Inhibit Automated Database Backup —...
Page 18 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At APS MCRT, Enter Message ALW:DCC! To Allow Data Consistency Checks Response: On APS ROP, ALW DCC IN PROGRESS —...
Page 19 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE NOTES: 1. If a Received response does not match the given response in this document, contact next higher support group for resolution 2.
Page 20 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE Safe Stop Point (following local procedure) — At 1B Processor MTC Terminal, Enter INH: MACLI,CLASS MTCE;REX! Notify Network Management That Generic Big GULP Update is to be Performed.
Page 21 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE CAUTION: The layout of some Recent Change forms can change on a Quarterly Release boundary. Item 28 saves the buffered Recent Change data and converts it to the format used by the new Quarterly Release.
Page 22 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE — NOTE: START RCBUFGET command may cause INH:APPDB and ALW:APPDB Error Messages — in some offices, THIS IS EXPECTED, AND PROCEDURE CAN BE CONTINUED At 3B MTCE Terminal, Enter START:RCBUFGET,DATA! This Process Captures the 1B Recent Change Buffered Messages.
Page 23 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE If Item 28 Was Not Performed, go to Item 40. The START:RCBUFPUT Command in — Item 39 is Only Required When the START:RCBUFGET Command is Entered in Item 28 1.
Page 24 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE NOTE: Audits will take approximately 30-40 minutes to complete At 1B Processor MTC Terminal, Enter ALW:AUD:NUM (43,44,45,66,72)! —...
Page 25 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE Soak Period Begins to Ensure No Errors Are Encountered (Length Is Determined by Following Local Procedure) Copy APS ROOT to BROOT or BROOT to ROOT DLP-558 Write 1B Processor Generic Tapes...
Page 27 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO If BMW Overwrites Are Stored on Support Organization’s System, Do Not Perform This Procedure — Connect Terminal Equipment as Required To Access SCANS Network and Print Hard Copy of SCANS —...
Page 29 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE Contact Next Higher Support Organization Before Doing this Procedure NOTE: Procedure. To go back to the old load after NTP-006, Item 41 UPD:CORE is COMPLETED in the event of problems encountered with the new load, return to the original data base in the following manner Remove This Procedure and Reproduce All Pages...
Page 30 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE Enter Poke Command 01 (Hard A) To Select Override In Effect Function. Wait for Recovery to Take Place. Ensure That 86-CODE Field Is Incrementing —...
Page 31 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO DATE TIME SIGNATURE If PCRV Boots Successfully, Go To Item 26, Otherwise If PCRV Boot Fails (Second — Time) Continue With Item 23 —...
Page 33 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO NOTE: It is recommended that this procedure be performed during an office low-traffic period and while diagnostic routine exercises (REXs) are not active. Office personnel should contact —...
Page 35 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Obtain Latest Copy Of 1B Processor Generic Tape — At 3B MCRT, Enter Poke Command 137 to Obtain Current Status of Tape Unit —...
Page 37 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Obtain Latest Copy Of 1B Processor Office Data Assembly (ODA) Tape — At 3B MCRT Enter Poke Command 137 to Obtain Current Status of Tape Unit —...
Page 39: Maintenance Philosophy
GENERAL EXAMPLE In the event of serious service-affecting trouble, time Decision has to be made: is of essence and office personnel should follow system Is recent change activity suspected? recovery guidelines provided to each office. Trouble If recent change activity is suspected, take the analysis procedures (TAPs) and detailed level procedures following action: (DLPs) are intended to be used as "backup"...
Page 40 DOCUMENTATION TABLE A is a list of the appropriate documentation to clear diagnostics or frame/cabinet failures: TABLE A TROUBLE- TROUBLE- UNIT TYPE UNIT TYPE CLEARING CLEARING VOLUME VOLUME 1B Processor 234-351-004 234-151-041 3B20D Model 1 254-301-812 MISC A, B, C 234-151-043 254-301-813 NCLK...
Page 41 [1] Enter emergency mode (full [4] Identify [2] See NOTE 1. configuration) by available equipment Was emergency manually triggering and some probable mode entered PC sequencer troubles [TABLE A] [DLP-503] Page 2 [5] Diagnose, repair and restore one PU [3] Enter emergency bus, one simplex base mode (full SP, and CC to obtain...
Page 42 [7] Enter 1B Processor [9] Diagnose, [8] See NOTE 2. emergency mode [10] Exit repair and restore Identify available (minimum configuration) emergency mode sufficient CSs and equipment and by forcing an override [DLP-501] PSs for a full probable troubles configuration [DLP-560] simplex system [TABLE B] Page 3...
Page 43 [17] Perform 4ESS [11] Allow [12] Does Switch emergency sufficient time [16] See phase complete recovery trouble (4 1/2 minutes NOTE 3. Does successfully isolation/recovery maximum) for system recover procedure [TAP-111] phase to complete NOTE 3 [18] Does System has recovered REPT:PHASE output if following message indicate...
Page 45 [1] At 1B Processor MCC terminal, depress EA DISP key to obtain EAI page On 1B Processor MCC terminal EAI page: [2] Enter poke command 61 (NORM FILE) [3] Enter poke command 84 (MODIFY RECV) [7] Select valid processor override Page 3 configuration [4] Enter poke command...
Page 46 TABLE A 1B PROCESSOR MANUAL CONFIGURATIONS AND ASSOCIATED POKE COMMANDS OVERRIDE CONTROL SELECTIONS MANUAL CONFIG PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 SEQUENCE Issue 7 JUN 2000 234-351-002 PAGE 2 of 3 RECOVER 1B PROCESSOR FOLLOWING PARTIAL UPDATE...
Page 47 [10] See NOTE 2. [8] On 1B Processor Restore 1B [9] See MCC terminal EAI Processor NOTE 1. Does page, enter poke conditions system recover command 01 (HARD A) following phase [DLP-505] [12] Recover 1B Processor and [11] Have all NOTES peripheral unit valid override...
Page 49: System Activity
[1] See NOTE 1. Perform 1B NOTES [2] On 1B Proccessor modified [4] Has [4] Has 1. Functions of DIRECT DATA Processor EAI page, recovery action machine machine INSERT bits are: is PHASE IN PROG with DIRECT DATA recovered recovered 0 —...
Page 50 [5] See Note 1, Page 1. [6] On 1B Processor Perform 1B Processor MCC terminal, MCC terminal, modified recovery action depress depress EA DISP with DIRECT DATA INSERT to obtain EAI page bits 0, 6, 16, and 17 set to one [DLP-502] [7] On 1B Processor [9] Has [9] Has...
Page 51 [10] See Note 1, Page 1. [11] On 1B [11] On 1B Perform 1B Processor Processor MCC Processor MCC modified recovery action terminal, depress with DIRECT DATA INSERT key to EA DISP bits 0, 5, 6, 16, and 17 obtain EAI page set to one [DLP-502] [15] See Note 2, [12] On 1B...
Page 52 [17] Contact support group and determine [18] Restore [19] Per local safe time when system 1B Processor procedure, add is stable and seems to conditions following recent changes be operating properly SR using following SR before restoring conditions tapes [DLP-584] following system reinitialization (SR) Issue 7...
Page 53 [1] See NOTE 1. From displayed response on APS MCRT termminal, identify error message [3] Is problem solved [2] Using TABLE A, locate identified error message and perform corrective action associated with reason for output [4] Request technical assistance from applicable support organization NOTE 1...
Page 54 TABLE A ERROR MESSAGE REASON CORRECTIVE ACTION AIMCHECK a FAILED TO CREATE PROCESS Contact local support organization. a = AMdwriter, IC or OC pathname AMA CONTROL FILE AUDIT COULD NOT ATTACH TO PAS Contact local support organization. CONTROL FILE AUDIT FAILED Use the OP:STATUS:LISTDIR message to see if /amafiles/ic.file or /amafiles/oc.file is there.
Page 55 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION AMA DISK WRITER • TERMINATION CODE a Do not worry about intermittent cases. a = Termination code number If problem persists, contact local support organization. • FAULT CODE a a = Fault code number (Hex) AMA FORMATTER [IC/OC] RECORD LOST —...
Page 56 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION DF BUFFER OVERFLOWED — Contact local support organization AMA FORMATTER PROCESS COULD NOT CONNECT TO ITS PORT Contact local support organization AMA FORMATTER NO DISK MODE (DM) NOTE: NO DISK MADE PARTITIONS If the Switch is in Call Detail PARTITIONS EQUIPPED, DM CANNOT HAVE BEEN EQUIPPED...
Page 57 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION CONTROL FILE WAS AUDITED Use OP:AMA,DISK message and obtain disk message and obtain disk AMA MONITOR AMA SESSION ABORTED (CONTD) space occupancy for HOC/RAO. (TELEPROCESSING) Enter OP:AMA;CONTROL FILE message to examine all field entries. Correct any errors using SET:AMA;CONTROL message.
Page 58 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION AMA/ICDR FORMATTER • DEFERRED FORMATTING DISK STATUS IS Contact local support organization. NOT AVAILABLE. CANNOT ACTIVATE DEFERRED FORMATTING • COULD NOT DEVELOP RECEIVE BUFFER, PROCESS TERMINATING AND RESTARTING • RECEIVE BUFFER POINTER OUT OF RANGE, PROCESS TERMINATING AND RESTARTING •...
Page 59 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION AMA SESSION CONNECT FAILED INVALID SESSION CONNECT MESSAGE Use OP:OOS message to identify out-of- UNRECOGNIZABLE MESSAGE RECEIVED service units. If AMA data link or its HIGHER LEVEL FAILURE controller is OOS, using RST:SDL or RST:SDLC message, call HOC/RAO and request another poll.
Page 60 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION AMA TAPE VERIFY TAPE COULD NOT BE OPENED Make sure tape is properly loaded and reload if necessary. Diagnose tape drive and proceed according to result. Select another drive if necessary. Mount and verify tape.
Page 61 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION AMA TAPE VERIFY (Contd) TAPE HAS NOT EXPIRED Enter VER:AMATAPE! message. If verify is successful, try writing tape again. If error persists, send tape to RAO for erasure and relabeling. If error does not recur, write is successful.
Page 62 TABLE A (Contd) ERROR MESSAGE REASON CORRECTIVE ACTION AMA TELEPROCESSING • FAILED TO CREATE TEST FILE To resolve problems in this area, refer • FAILED TO WRITE ENTIRE TEST FILE to TOP 254-301-812. • ERROR DURING OPEN OF AMA TEST FILE •...
Page 63 [1] At APS Read-Only Printer (ROP), identify message reporting problem [4] Clear ICDR [3] Is teleprocessing problem system problem resolved [TAP-108] [2] Using TABLE A, locate identified message and perform corrective action listed TABLE A MESSAGE CORRECTIVE ACTION REPT ICDR DISK STORAGE IS (70-89) PERCENT FULL 1.
Page 64 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR SESSION TERMINATED (FORMAT 1) - 1. Call processing center and set up another poll. ABNORMAL SESSION TERMINATION 2. Continue monitoring the ICDR disk space occupancy using the OP:ICDR;DISK input message. 3. Be prepared to give the following information to processing center personnel: Current disk space occupancy Abnormal termination reason from printout.
Page 65 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT AMA/ICDR TRANSFER BUFFER ALARM 1. Investigate any disk alarms that accompany this message. 3B BUFFER IS x% FULL 2. Otherwise, use the OP:STATUS:PROCESS,ALLKERNS input message to make sure AMformat is running. (In the UTID column of the printout, AMformat is 0x625.) If not, restart APS processes [DLP-537].
Page 66 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT AMA FORMATTER ICDR SDS FULL 1. Use the OP:STATUS:PROCESS,ALLKERNS input message to make sure /ama/INdwriter is running. (In the UTID column of the printout, INdwriter is 0x671.) If it is running, go to Step 3. If it is not running, restart processes [DLP-537] and then go to Step 2.
Page 67 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR DISK WRITER TERMINATION CODE a Term a = Reason for termination Code Consequences/Actions To Be Taken Use the OP:STATUS:PROCESS,ALLKERNS input message to make sure INdwriter is running. (In the UTID column of the printout, INdwriter is 0x671.) If INdwriter is not running, seek technical assistance.
Page 68 TABLE A (Contd) MESSAGE MESSAGE CORRECTIVE ACTION REPT ICDR DISK WRITER ERROR CODE a Error a = Error code number Code Consequences/Actions To Be Taken Both copies of a partition’s disk map were invalid (this message will always be preceded by an error code 4). Both disk maps are intialized as a result, so any primary data that may have been on the partition is lost.
Page 69 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR DISK WRITER ERROR CODE a Error a = Error code number Code Consequences/Actions To Be Taken 9 to 13 Error 13 may also be caused by an invalid device file for (Contd) one of the AMA partititons (eg, pointing to a nonexistent disk).
Page 70 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR DISK WRITER ERROR CODE a Error a = Error code number Code Consequences/Actions To Be Taken 18 to 20 If the problem is with the primary copy, restore the (Contd) primary copy from the backup copy. If the problem is with the backup copy, then both copies must be initialized and all partitions reequipped from scratch (be sure to use the "NOINIT"...
Page 71 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR DISKWRITER ERROR CODE a Error a = Error code number Code Consequences/Actions To Be Taken 21 to 26 (Contd) If a create or write fails for the primary copy of the global map, the disk reader will probably be unable to access it which will prevent ICDR sessions from starting up (the disk reader does not access the backup copy).
Page 72 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR TELEPROCESSING FAILED TO ATTACH TO PAS 1. Contact technical support group and request a backup copy of /ama/INftp be moved from broot to root. REPT ICDR TELEPROCESSING ICDR DATA UNREADABLE 1. Check to see if the disk pair being read is duplex failed. NEXT PARTITION OOS If so, the duplex fail condition must be resolved before teleprocessing can continue.
Page 73 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR CONFIG FILE a If text phrase "a" is one of the following: a = Text phase COULD NOT ATTACH TO ECD DATABASE COULD NOT RETRIEVE ECD ORIGIN RECORD COULD NOT RELEASE ECD DATABASE COULD NOT OBTAIN INFORMATION ABOUT THE PARTITION INVALID SPECIAL DEVICE TYPE DEVICE DOES NOT HAVE MAJOR/MINOR NUMBERS...
Page 74 TABLE A (Contd) MESSAGE CORRECTIVE ACTION REPT ICDR DISK MAPS a If text phrase "a" is one of the following: a = Text phrase COULD NOT OPEN CONFIG FILE COULD NOT READ CONFIG FILE Perform the following action: Restore the ICDR configuration file from the backup copy. If text phrase "a"...
Page 75 [1] At MTC terminal, identify message reporting problem [3] Is problem resolved [2] Using TABLE A, locate identified message and perform corrective action listed [4] Clear ICDR teleprocessing system problems [TAP-108] Issue 7 JUN 2000 234-351-002 CLEAR ICDR TELEPROCESSING PROBLEM DISPLAYED AT 1B PROCESSOR PAGE 1 of 2 MAINTENANCE TERMINAL AND PRINTER...
Page 76 TABLE A MESSAGE CORRECTIVE ACTION REPT AMA/ICDR TRANSFER TO 3B HALTED 1. Check to see if any of the following conditions are present: DATA MAY SOON BE LOST - 3B duplex failed REPT AMA/ICDR 1B TRANSFER BUFFER OVERFLOW - 3B AMA disks are duplex failed AMA/ICDR INFORMATION RECORDING HALTED - APIs are duplex failed - AU bus is duplex failed...
Page 77 [1] At APS MCRT terminal, identify message receiving a RL or NG response [4] Request technical [3] Is assistance from problem applicable solved support organization [2] Using TABLE A, locate identified message and perform corrective action listed TABLE A INPUT MESSAGE RESPONSE CORRECTIVE ACTION ALW:ICDR;SESSION...
Page 78 TABLE A (Contd) INPUT MESSAGE RESPONSE CORRECTIVE ACTION SET:AMA;STREAM 1. Use input message CLR:FILESYS:FILE,FN"a" to delete the file. 2. Create a new file using the SET:AMA;STREAM input message. 3. If problem persists, contact next higher technical support group ABORT:AMATAPE 1. Use the OP:STATUS:PROCESS,ALL input ALW:AMA;AUTOST message to get the process id of AMmon.
Page 79 TABLE A (Contd) INPUT MESSAGE RESPONSE CORRECTIVE ACTION ABORT:AMATAPE 1. Check stream value entered ALW:AMA;AUTOST 2. Use OP:AMA;STREAM message to determine ALW:AMA;SESSION office configuration COPY:AMATAPE 3. Retype message with the correct INH:AMA;AUTOST stream specified INH:AMA;SESSION OP:AMA;CONFIG 4. If stream value is invalid, use the OP:AMA;CONTROLFILE SET:AMA;STREAM to set the stream to OP:AMA;DISK...
Page 81 [2] Was [1] Restore APS a problem SDLC and SDL discovered with [DLP-530] SDLC or SDL [4] Was [3] Verify APS a problem SYSTYPE field discovered with data [DLP-531] SYSTYPE field data [5] Verify APS [6] Was a ICDR control problem discovered Page 3, file parameters...
Page 82 [8] Was Page 3, a problem Step 17 discovered with ICDR processes [10] Was [9] Verify APS a problem ICDR partitions discovered with equipped [DLP-534] ICDR partitions equipped [11] Verify APS ICDR recording is activated [DLP-535] [12] Was a problem Page 3, discovered with Step 17...
Page 83 [13] Verify APS unit control block (UCB) data [DLP-536] [14] Was [17] Call data [20] Inform DPC a problem [18] Was test processing center that office is discovered with poll session (DPC) and request ready to accept APS unit control successful test poll session polling requests...
Page 85 [1] Perform 1AFILE reload and attempt [2] See NOTE 1. 1B Processor Does system Page 4 recovery on the recover 3B APS using DLP-552 Response: All FORCE FNCT poke commands color white on black 84 - MODIFY RECV colors white on black NOTE 1 [3] On 1B Processor MCC terminal EAI 61 - NORM FILE colors...
Page 86 [7] Restore attached processor system (APS) direct link nodes (DLNs) using DLP-563 [8] Contact next higher support group to determine save time when system is stable and operating properly before restoring conditions following System Reinitialization (SR). All earlier recent changes not on the ODA tape that was loaded, can start to be entered at this time.
Page 87 [12] See NOTE 2. [14] At 1B Processor Is COPY APPFILE MTC terminal, enter COMPLETED message response UPD:COMMIT;NORMFILE! received [13] Contact next [17] Write 1B higher support [15] Is Processor group and inform UPD:COMMIT COMPLETED Office Data personnel of actions TO NORMFILE response Assembly (ODA) tape performed and...
Page 88 [18] At APS MCRT terminal, enter VER:APPFILE UPD ! [22] Contact next [20] See Figure 1. higher technical Did printout support group and indicate 0 ERRORS inform personnel DETECTED for each of actions performed verified area and results obtained [19] See NOTE 3. Observe printout for zero errors [21] Repeat from Step 1...
Page 89 [4] See NOTE 1. [1] Perform [2] Did Restore APS APS system APS SR conditions reinitialization complete following SR [DLP-555] successfully [DLP-561] [3] Request assistance from appropriate support organization NOTE 1 Contact technical support group and determine safe time when system is stable and seems to be operating properly before...
Page 91 [1] Is there [3] On APS MCRT evidence of power terminal or read- Page 7 problems or air only printer (ROP), conditioning are APS PRMs being failures received [4] Identify [2] Notify appropriate APS PRMs as work group of Page 2 successful or potiential problem failing PRMs...
Page 92 One or two failing within 15 minutes PRMs among many successful PRMs does not indicate system sanity is in Page 7 jeopardy Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 2 of 29...
Page 93 [10] Power down units being worked on [DLP-564] [12] See [13] Repeat NOTE 2. from Step 3, from Step 3, Does APS Page 1 Page 1 recover [11] Allow ample time (5 minutes) for APS to recover Page 29 NOTE 2 System has recovered if following conditions have been...
Page 94 ROOT [21] On APS MCRT terminal EAI page, Page 5 enter poke command 53 in command mode to request boot Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 PAGE 4 of 29 RECOVERY PROCEDURE...
Page 95 FIG. 2 — Sample Layout of Attached Processor successful PRMs does System (APS) Processor Recovery not indicate system Message (PRM) sanity is in jeopardy Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 5 of 29...
Page 96 [27] Has another [29] See [30] Repeat APS boot (52 or NOTE 4. from Step 3, from Step 3, 53) followed a Does APS Page 1 Page 1 previous boot recover within 15 minutes Page 29 [28] APS boot was unsuccessful.
Page 97 [35] Perform C. No current recent APS recovery change activity minimum going on configuration D. PRMs are not being received [DLP-566] continuously Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 7 of 29...
Page 98 [42] On 1B [44] Is work [49] Power down Processor EAI being performed 4ESS Switch page [FIG. 3], is Page 10 on a 4ESS Switch frame IPUBs PHASE IN PROG peripheral unit [DLP-564] text lighted [50] Power down [43] Has a 1B...
Page 99 "bbbb" does begin to increment, this is a failure. If at any time "aaaa" stops incrementing for 30 seconds while "bbbb" continues to increment, this is a failure Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 9 of 29...
Page 100 [51] Allow ample time (3 minutes) NOTES for Phase to 8. A phase is in complete progress if in 86- (See NOTE 8) CODE field, the leftmost "a" is alternating between 0 and 4 every half second 9. System has recovered [52] See NOTE 9.
Page 101 [55] On 1B Processor MCC terminal EAI page, enter poke command 70 to set DIS AUTO PC (text lighted BLACK on PURPLE or YELLOW on RED) [56] On APS MCRT, enter INIT:APDRV:FPI! to initialize Attached Processor Driver [57] On 1B Processor MCC terminal EAI page, enter poke command 99 to clear all requests Page 13...
Page 102 SEQUENCE PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 NOTE: All forces must be cleared before next manual configuration can be selected Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 12 of 29...
Page 103 MODIFY RECV text lights [60] On 1B Processor MCC terminal EAI page, PURPLE on WHITE enter poke command 84 MODIFY RECV [61] On 1B Processor MCC terminal EAI page, enter poke commands to select current active CC, PS, PSB, CSB, IFB and AUB [TABLE A] HARD A Page 14 text lights...
Page 104 [64] On 1B Processor [67] Perform MCC terminal EAI page [66] See NOTE 10. 1B Processor Does 1B Processor under PC PROGRESSION, system recovery is CMPL text lighted recover [TAP-113] BLACK on GREEN Page 29 NOTE 10 System has recovered [65] Perform 1B if following Processor system...
Page 105 [68] On 1B Processor MCC terminal 108 page, enter poke command 832 (APS) to obtain status of API frames [69] On 1B Processor MTC terminal, does OP:APS message indicate a duplex API failure [70] At APS MCRT terminal, enter INIT:APDRV:FPI! Page 19 [71] At 1B Processor MTC [74] On 1B processor...
Page 106 [75] At 1B Processor MTC terminal, are [80] See NOTE 11. REPT: APS 0 RECOVERY SUCCESS Allow ample time Page 29 1B FILE ACCESS DUPLEX FAILED for 1B Processor to recover 1B FILE ACCESS RECOVERY IN PROGRESS messages being received [76] See NOTE 10.
Page 107 [81] Power down API 0 [DLP-564] [82] At APS MCRT terminal, enter [84] Does Page 16, INIT:APDRV:FPI! API 1 restore Step 75 to service [83] At 1B Processor MTC terminal, enter RST:API 1;UCL! [85] Power down API 1 [DLP-564] [86] Restore power to API 0 [89] Does [DLP-565] Page 18...
Page 108 [90] Restore power to API 1 [DLP-565] [91] At APS MCRT terminal, depress DIS EA key to obtain EAI page [94] Does [92] On APS MCRT terminal Page 16, API 0 or API 1 EAI page, enter poke Step 75 restore to command 53 ( ) in...
Page 109 [99] Is approximately 80% of DIFs, DTs, VIFs, TSIs or SPs duplex failed [101] At 1B Processor MCC terminal, depress EA DISP key to obtain EAI page [100] Are all TMSPs duplex [102] On 1B Processor MCC terminal failed EAI page, enter poke DDI keys command 402 (RESET ALL) to set to zero...
Page 110 [108] After phase [107] Allow [114] See NOTE completes, is 80% sufficient time sufficient time 12. Does 4ESS of TSIs, DIFs, (3 minutes) for (3 minutes) for Switch recover VIFs and DTs phase to phase to duplex failed complete complete Page 29 [109] On 1B Processor MCC PHASE 4...
Page 111 [115] At APS MCRT terminal or read-only Page 22 printer (ROP), is REPT:CNI RING IN QUIET MODE message being received [116] At APS MCRT [117] On APS terminal, enter MCRT terminal 1105 in command 1105 page, is mode to obtain status of RPCNs 1105 page active...
Page 112 [121] At APS MCRT terminal, depress EA DISP key to obtain EAI page [122] On APS MCRT terminal EAI page, enter poke command 53 (BOOT) in [124] Does command mode Page 29 CNI ring recover [123] Allow 6 minutes for CNI ring to recover [125] On APS MCRT terminal EAI page, enter poke...
Page 113 CNI ring CNI ring to 54 in command mode recover recover to request boot [133] Perform attached processor system (APS) recovery [TAP-112] Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 23 of 29...
Page 114 SDC units [135] Is 1B Processor MCC terminal active and responsive to request Page 26 Page 25 Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 24 of 29...
Page 115 SYSTEM ACTIVITY, actions performed displayed data is and results obtained normal for time of day (takes 3 minutes for data to be updated) Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 25 of 29...
Page 116 SYSTEM ACTIVITY, displayed data is normal for time of day (takes 3 Page 29 minutes for data to be updated) Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 26 of 29...
Page 117 SYSTEM STATUS page under SYSTEM ACTIVITY, displayed data is normal for time of day (takes 3 minutes for data to be updated) Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 27 of 29...
Page 118 MCRT terminal, is EAI page displayed [166] Contact next higher technical support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 28 of 29...
Page 119 Issue 7 JUN 2000 PERFORM 4ESS SWITCH EMERGENCY RECOVERY TROUBLE ISOLATION/ 234-351-002 RECOVERY PROCEDURE PAGE 29 of 29...
Page 121 [1] Is there evidence of power problems or air conditioning [3] Contact next higher support failure group while continuing this procedure. After contacting, inform personnel of actions performed and results obtained [2] Notify appropriate [4] At 1B Processor MCC work group of terminal, depress EA DISP potential problem key to obtain EAI page...
Page 122 [8] Select first manual configuration [TABLE A] [10] On APS MCRT terminal EAI page, [11] If 3B21D, enter poke command enter Y 54 in command mode to confirm to request phase [9] On APS MCRT terminal EAI page, enter 4 boot poke commands in command mode as listed (left to right) for selected manual configuration [TABLE A]...
Page 123 [12] Is CU a RECOVERY STARTED Page 4 message received indicating that CU recovery has started [13] Have all manual configurations Page 6 been exhausted [TABLE A, Page 2] [14] On APS MCRT terminal page, enter poke command 14 in command mode to clear EAI page [15] Select next manual...
Page 124 [20] Have all [16] See NOTE 1. manual Are failing APS configurations Page 6 PRMs being received been exhausted continuously [TABLE A, Page 2] [FIG. 1] [17] Are APS PRMs [21] On APS MCRT being received where terminal EAI page, the "BOOT STEP"...
Page 125 [23] On 1B Processor MCC terminal EAI page, enter poke command [25] See 70 to clear DISABLE NOTE 2. AUTO PC function Page 18 Does APS recover [24] Allow ample time (5 minutes) for APS to recover [26] On 1B Processor MCC terminal EAI page, enter poke command 70 to select...
Page 126 [30] Power down APS CU 1 [DLP-564] [31] Power down APS IOP 1 [DLP-564] [32] Power down DFC 1 [DLP-564] Page 7 [33] Power down 1B Processor Complex API 1 [DLP-564] [34] Unseat all equipped TN69B circuit packs in CNI ring TABLE B cabinet 32 [TABLE B] TN69B CIRCUIT PACK LOCATIONS IN...
Page 127 [36] At APS MCRT terminal, depress EA DISP key to obtain EAI page [37] On APS MCRT terminal EAI page, enter poke command 14 in command mode to clear EAI page [38] Select first manual configuration [TABLE C] [42] Is CU a RECOVERY STARTED [39] On APS MCRT terminal EAI page, enter Page 8...
Page 128 [50] Have all [46] See NOTE 3. manual Are failing APS configurations Page 10 PRMs being received been exhausted continuously [TABLE C, Page 7] [FIG. 1, Page 4] [47] Are APS PRMs [51] On APS MCRT being received where terminal EAI page, the "BOOT STEP"...
Page 129 [53] On 1B Processor MCC terminal EAI page, enter poke command [55] See 70 to clear DISABLE NOTE 4. AUTO PC function Page 18 Does APS recover [54] Allow ample time (5 minutes) for APS to recover [56] On 1B Processor MCC terminal EAI page, enter poke command 70 to select...
Page 130 [60] Power down APS TABLE D CU 0 [DLP-564] TN69B CIRCUIT PACK LOCATIONS IN CNI RING CABINET 0 (NOTE) TN69B — 19-086 [61] Power down APS IOP 0 [DLP-564] TN69B — 28-086 or 37-086 TN69B — 45-086 or 53-086 [62] Power down DFC 0 EIN 0* 45-118 or 37-118 [DLP-564] (cabinet 06 or 38)
Page 131 [72] At APS MCRT terminal, depress EA DISP key to obtain EAI page [73] On APS MCRT terminal EAI page, enter poke command 14 in command mode to clear EAI page [74] Select first manual configuration [TABLE E] [78] Is CU a RECOVERY STARTED [75] On APS MCRT terminal EAI page, enter Page 12...
Page 132 [86] Have all [82] See NOTE 5. manual Are failing APS Page 14 configurations PRMs being received been exhausted continuously [TABLE E, Page 11] [FIG. 1, Page 4] [83] Are APS PRMs [87] On APS MCRT being received where terminal EAI page, the "BOOT STEP"...
Page 133 [89] On 1B Processor MCC terminal EAI page, enter poke command [91] See 70 to clear DISABLE NOTE 6. AUTO PC function Page 18 Does APS recover [90] Allow ample time (5 minutes) for APS to recover [92] On 1B Processor MCC terminal EAI page, enter poke command 70 to select...
Page 134 [96] Restore power to CU 0 [DLP-565] [97] Restore power to IOP 0 [DLP-565] [98] Restore power to DFC 0 [DLP-565] [99] Restore power to Page 15 1B Processor Complex API 0 [DLP-565] [100] Seat all equipped TN69B circuit packs previously unseated in CNI ring cabinet 0 [TABLE D, Page 10]...
Page 135 [102] At APS MCRT terminal, depress EA DISP key to obtain EAI page [103] On APS MCRT terminal EAI page, enter poke command 14 in command mode to clear EAI page [104] Select first manual configuration [TABLE F] [108] Is CU a RECOVERY STARTED [105] On APS MCRT terminal EAI page, enter Page 16...
Page 136 [120] Recover [117] Have all [113] See NOTE 7. attached Processor manual Are failing APS system (APS) by configurations PRMs being received performing system been exhausted continuously reinitialization [TABLE F, Page 15] [FIG. 1, Page 4] (SR) [TAP-110] [114] Are APS PRMs [118] On APS MCRT being received where terminal EAI page,...
Page 137 [121] On 1B Processor MCC terminal EAI page, enter poke command [129] Perform APS [123] See 70 to clear DISABLE recovery minimum NOTE 8. AUTO PC function configuration Does APS [DLP-566] recover [122] Allow ample time (5 minutes) for APS to recover [131] Recover [124] On 1B Processor attached Processor...
Page 138 [132] See NOTE 21. [133] Perform Has sanity been 4ESS Switch restored to entire emergency recovery system (1B Processor, trouble isolation/ APS, CNI ring, 4ESS recovery procedure Switch peripheral, [TAP-111] etc.) [134] Contact support group and determine safe time when system...
Page 139 [2] On 1B Processor [3] At 1B Processor [1] At 1B MCC terminal EAI page MCC terminal EAI Processor MCC [FIG. 1, Page 2], is page [FIG. 1, Page 2], terminal, depress OVERRIDE IN EFFECT enter poke command key to EA DISP text lighted to clear force in...
Page 140 MUP INDICATOR REPEATED PC INDICATOR TOWNSTBLSUB 4E<NN>4B.nn PORT PAGE EAI mm/dd/yy hh:mm:ss PC STATE CRITICAL MAJOR MINOR PGM CTRL PWR/BLDG SYS NORM INDICATOR IF/AU CMD: DIS AUTO PC 99 - CLEAR ALL REQUESTS 100 - PAGE INDEX INDICATOR -FORCE FNCT- - MANUAL PROG REQ- -PC SEQUENCER- -REPEATED PC- -PC ATTEMPT-...
Page 141: Table Of Contents
[7] See NOTES 1 Page 4, and 2. Is machine Step 16 attempting to recover NOTES In EAI FAIL DATA DISPLAY section, for every PC attempt and every Hard A (01) [8] On 1B Processor request, the octal digits MCC terminal EAI [9] Has machine "aaaa"...
Page 142: See Notes
[15] Contact next higher technical [14] See NOTE 4. support group, Does system determine reason for recover outage and attempt NOTES to normalize system 4. System has recovered if following conditions have been met: A. On 1B Processor MCC terminal [17] See CAUTION [16] If data in the 86 EAI page under PC PROGRESSION,...
Page 143: On 1B Processor Mcc Terminal Eai
[21] On 1B Processor MCC terminal EAI page [FIG. 1, [20] On 1B Processor Page 2], enter poke command MCC terminal EAI page to set disable automatic [FIG. 1, Page 2], is processor configuration text lighted DIS AUTO PC selection (text lighted BLACK on PURPLE or BLACK on PURPLE or YELLOW YELLOW on RED...
Page 144 On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: 10 ( CC 0) [28] Enter poke command to select function [29] Enter poke command 20 ( PS 0) to select function [30] Enter poke command 22 (PSB 0) to select function [35] See NOTE 6.
Page 145: Phase In Prog Text
[37] If data in the 86 NOTES [36] On 1B Processor (CODE) field is not 7. A phase is in MCC terminal EAI page, incrementing properly, progress if the left- [FIG. 1, Page 2], is record data displayed Page 8 most "a"...
Page 146 [43] See CAUTION and NOTE 9. At 1B Processor MCC terminal, enter ESC CTRL X sequence and ESC CTRL R sequence to force and reset MUP 1 [45] On 1B Processor [44] On 1B Processor [46] On 1B Processor MCC terminal EAI page MCC terminal EAI page MCC terminal EAI page [FIG.
Page 147 [48] At APS MCRT, enter INIT:APDRV:FPI! to initialize attached processor driver On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: [49] Enter poke command 99 to clear all requests [52] On 1B Processor [53] On 1B Processor MCC terminal EAI MCC terminal EAI page page [FIG.
Page 148 On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: [54] Enter poke command 11 ( CC 1) to select function [55] Enter poke command 21 ( PS 1) to select function [56] Enter poke command 23 (PSB 1) to select function [61] See Note 10.
Page 149 [63] If data in the 86 NOTES [62] On 1B Processor (CODE) field is not 11. A phase is in MCC terminal EAI page, incrementing properly, progress if the left- [FIG. 1, Page 2], is record data displayed Page 12 most "a"...
Page 150 [70] On 1B Processor MCC [69] On 1B Processor terminal EAI page [FIG. 1, MCC terminal EAI page Page 2], enter poke command [FIG. 1, Page 2], is to set disable automatic DIS AUTO PC text processor configuration lighted BLACK on selection (text lighted PURPLE or YELLOW on BLACK on PURPLE or...
Page 151 TABLE A [76] See NOTE 14. 1B PROCESSOR EVEN UNITS Power down all 1B Processor units in CC 0 (041-014) (KLW11) Cabinet 0 [TABLE A] PS 0, 2... (041-128, -136...) (KLW2) CS 0,2,4,6,8... (024-006, -014...) (KLW1) [77] Power down both 1B CSB0 (KLW26) (024-086) CSB1 (KLW27) (024-096) Processor DUS units In Cabinet 0...
Page 152 [80] See NOTE 15. At 1B Processor MCC terminal, depress ESC, CTRL and R keys simultaneously to reset MUP 1 [81] On 1B Processor [84] On 1B Processor [83] On 1B Processor MCC terminal EAI page MCC terminal EAI page MCC terminal EAI page [FIG.
Page 153 On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: [85] Enter poke command 99 to clear all requests [88] On 1B Processor [89] On 1B Processor [86] Enter poke command 402 MCC terminal EAI page MCC terminal EAI page to reset all DDI keys [FIG.
Page 154 On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: 11 ( CC 1) [90] Enter poke command to select function [91] Enter poke command PS 1) to select function [92] Enter poke command 23 (PSB 1) to select function [97] See NOTE 16.
Page 155 [99] If data in the 86 NOTES [98] On 1B Processor (CODE) field is not 17. A phase is in MCC terminal EAI page, incrementing properly, progress if the left [FIG. 1, Page 2], is record data displayed Page 18 most "a"...
Page 156 [105] Power down all 1B TABLE B Processor units in 1B PROCESSOR ODD UNITS Cabinet 1 [TABLE B] CC 1 (141-014) (KLW11) PS 1, 3... (141-128, -136...) (KLW2) CS 1,3,5,7,9... (124-006, -014...) (KLW1) [106] Power down 1B Processor CSB0 (KLW26) (124-086) CSB1 (KLW27) API 1 (124-096) In Cabinet 1 AUI 1 (KLW18)
Page 157 [111] See CAUTION and NOTE 20. At 1B Processor MCC terminal, force and reset MUP 0 with ESC CTRL X sequence and ESC CTRL R sequence [114] On 1B Processor [112] On 1B Processor [115] On 1B Processor MCC terminal EAI page MCC terminal EAI page MCC terminal EAI page [FIG.
Page 158 [116] At APS MCRT, enter INIT:APDRV:FPI! to initialize attached processor driver On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: [117] Enter poke command to clear all requests [121] On 1B Processor [120] On 1B Processor MCC terminal EAI page MCC terminal EAI page [FIG.
Page 159 On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: 10 ( CC 0) [122] Enter poke command to select function [123] Enter poke command 20 ( PS 0) to select function [124] Enter poke command 22 (PSB 0) to select function [129] See NOTE 21.
Page 160 [131] If data in the 86 NOTES [130] On 1B Processor (CODE) field is not 22. A phase is in MCC terminal EAI page, incrementing properly, progress if the left- [FIG. 1, Page 2], is record data displayed Page 23 most "a"...
Page 161 [137] Power up all remaining 1B Processor units except SSD 0 and 1 and DUS 0 and 1 [TABLE D] [138] Power up API 1 [141] See NOTE 24. Does APS/3B [139] On APS/3B MCRT terminal Page 24 phase 3 complete EAI page, enter poke successfully command 53 (BOOT) to...
Page 162 [143] See NOTE 25. At 1B Processor MCC terminal, depress ESC, CTRL and R keys simultaneously to reset MUP 0 [144] On 1B Processor [147] On 1B Processor [146] On 1B Processor MCC terminal EAI page MCC terminal EAI page MCC terminal EAI page [FIG.
Page 163 On 1B Processor MCC terminal EAI Page [FIG. 1, Page 2]: [148] Enter poke command to clear all requests [152] On 1B Processor [149] Enter poke command [151] On 1B Processor MCC terminal EAI page to reset all DDI keys MCC terminal EAI page [FIG.
Page 164 [153] Select and check off applicable manual configuration for MUP 0 [TABLE E] [154] See NOTE 26. On 1B Processor MCC terminal EAI page, enter poke commands as listed (left to right) [156] See NOTE 27. for selected manual configuration Allow sufficient [TABLE E] time (3 minutes)
Page 165 TABLE E 1B PROCESSOR MANUAL CONFIGURATIONS AND ASSOCIATED POKE COMMANDS (MUP 0) OVERRIDE CONTROL SELECTIONS MANUAL SEQUENCE CHECK PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 (See NOTE) NOTE: All forces must be cleared before next manual configuration can be selected Issue 7 JUN 2000 234-351-002...
Page 166: Step 143
[157] On 1B Processor NOTES [158] Have 28. A phase is in MCC terminal EAI page [159] Repeat all manual [FIG. 1, Page 2], is progress if the left- from configurations most "a" position in PC PROGRESSION CMPL Step 143, been exhausted the 86 (CODE) field text lighted...
Page 167 [167] On APS/3B [168] See NOTE 30. MCRT terminal Allow sufficient EAI page, enter NOTES time (3 minutes) poke command 30. System has recovered for phase to 53 (BOOT) to complete if following select function conditions have been met: A. On APS MCRT terminal, SYS EMER [171] See CAUTION INDICATOR...
Page 168 [174] On 1B Processor MCC terminal EAI page [FIG. 1, Page 2], is OVERRIDE IN EFFECT text lighted BLACK on PURPLE (force in effect) [175] Enter poke command 01 to clear force in effect On 1B Processor MCC terminal EAI Page, [FIG. 1, Page 2]: [176] Enter poke command to clear all requests [180] On 1B Processor...
Page 169 [181] Select and check off applicable manual configuration for MUP 1 [TABLE F] [182] See NOTE 32. On 1B Processor MCC terminal EAI page, enter poke commands as listed (left to right) [184] See NOTE 33. for selected manual configuration Allow sufficient [TABLE F] time (3 minutes)
Page 170 TABLE F 1B PROCESSOR MANUAL CONFIGURATIONS AND ASSOCIATED POKE COMMANDS (MUP 1) OVERRIDE CONTROL SELECTIONS MANUAL SEQUENCE CHECK PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 (See NOTE) NOTE: All forces must be cleared before next manual configuration can be selected Issue 7 JUN 2000 234-351-002...
Page 171: Step 176
[185] On 1B Processor NOTES [186] Have 34. A phase is in MCC terminal EAI page [187] Repeat all manual [FIG. 1, Page 2], is progress if the left- from configurations most "a" position in PC PROGRESSION CMPL Step 176, been exhausted the 86 (CODE) field text lighted...
Page 172: System Status
[195] Contact next higher [194] Is support group and generic tape inform personnel current of actions performed and results obtained NOTE 35 System has recovered if following [196] Perform conditions have been [197] Was 1AFILE 1AFILE reload [199] See reload and attempt met: and attempt NOTE 35.
Page 173 [201] Restore attached processor system (APS) direct link nodes (DLNs) [DLP-563] [202] Contact support group and determine safe [203] Restore time when system is 1B Processor stable and seems to be conditions following operating properly before SR using tapes restoring conditions [DLP-585] following system reinitialization (SR)
Page 175 [1] On 1B Processor MCC terminal EAI page, enter poke command 70 (DIS AUTO PC) [3] On 1B Processor [3] On 1B Processor to select function. (Under [2] On 1B Processor [2] On 1B Processor MCC terminal EAI MCC terminal EAI DISABLE AUTO PC PC SEQUENCER, MCC terminal EAI...
Page 176 [12] Identify next valid override configuration [10] After 10 seconds, [TABLE A] and repeat on 1B Processor MCC from Step 3 (If system terminal EAI page under fails to respond after , is EMER CFG FULL doing manual sequences text lighted BLACK on 1 and 2, go to Emergency PURPLE (See NOTE 1) Mode (Minimum...
Page 177 TABLE A 1B PROCESSOR MANUAL CONFIGURATIONS AND ASSOCIATED POKE COMMANDS OVERRIDE CONTROL SELECTIONS MANUAL CONFIG PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 SEQUENCE STATE Issue 7 JUN 2000 234-351-002 ENTER 1B PROCESSOR EMERGENCY MODE (FULL CONFIGURATION) BY PAGE 3 of 3 FORCING AN OVERRIDE CONFIGURATION...
Page 179 [1] On 1B Processor MCC terminal, enter poke command 118 to obtain 1B Processor STATUS page [2] On 1B Processor MCC terminal 1B Processor STATUS page under FORCE FNCT, identify active units (units with text [6] On 1B Processor lighted BLACK on GREEN) [5] On 1B Processor MCC EAI page, enter MCC EAI page under...
Page 180 [8] On 1B Processor MCC terminal Under MANUAL PROG REQ, EAI page, enter poke command PHASE 4 text lights 54 (PHASE 4) and set DDI PURPLE on WHITE key 17, 16, and 11 [9] On 1B Processor MCC terminal EAI Page, enter poke command 84 (MODIFY RECOVERY) to request modified recovery action...
Page 181 [1] At 1B Processor MCC terminal, depress EA DISP key to obtain EAI page [2] On 1B Processor MCC terminal EAI page, enter poke command 84 (MODIFY RECV) [3] On 1B Processor MCC terminal EAI page, enter poke command 402 to set all bits to zero [4] On 1B Processor MCC terminal EAI page, enter poke command...
Page 182 TABLE A DIRECT DATA INSERT BIT OPTIONS (MCD REGISTER) OPTION APPLICATION OPTION APPLICATION SET ALL INH PH 2, 3, 4 ZERO ALL MEMORY AO, PC (pump) RB RC TO TAPE 1 PH 3, 4 SKIP HASHSUM CALCULATION SR, AO, PC RB RC TO TAPE 2 PH 3, 4 BYPASS CC SANITY TESTS...
Page 183 [1] At 1B Processor MCC terminal, depress EA DISP key to obtain EAI page [2] On 1B Processor MCC terminal EAI page, ensure OVERRIDE IN EFFECT text is not lighted [3] On 1B Processor MCC terminal EAI page, enter poke command 70 (DIS AUTO PC) to select function [4] On 1B Processor MCC terminal EAI page under MANUAL PROG REQ, ensure no...
Page 184 [10] See NOTE 1. Does CC, CS, IF, AU, and PS text extinguish [15] See NOTE 1. On 1B Processor MCC terminal EAI page under EMER CFG, ensure that FULL text is lighted BLACK on PURPLE [11] On 1B Processor [13] On 1B MCC terminal EAI page Processor MCC...
Page 185 [1] At 1B Processor MCC terminal, enter poke command 108 to obtain SYSTEM STATUS page Under SYSTEM CONTROLS, [2] On 1B Processor MCC terminal System RESTRICT RC text Status page (108), enter poke lights BLACK on WHITE command 801 (RESTRICT RC) [3] At 1B Processor MCC terminal, depress EA DISP key to obtain EAI page...
Page 187 [1] If technical assistance is not already on line, obtain technical assistance [2] If phase 4 was requested, set system clock [DLP-506] [3] At 1B Processor MTC terminal, enter OP:SDC! and obtain printout identifying service degrading units [4] Using printout of service degraded units, note all units that need to be restored [5] At 1B Processor MTC terminal, enter RST:...
Page 189 [1] See CAUTION 1 and NOTE 1. At 1B Processor MTC terminal, type, but do not enter: SET:CLK:DAY a,DATE b,TIME cde! (complete all entries except minutes and seconds) a = Day (SUN, MON, TUE, WED, THU, FRI or SAT) b = Date (6-digit number, MMDDYY) c = Hour (2-digit number, 01 to 24) d = Minutes (2-digit number, 00 to 59) NOTES...
Page 191 [1] At 1B Processor MCC terminal, enter poke command 108 to obtain SYSTEM STATUS page [3] Does status [5] Does status [2] On 1B Processor MCC report printout report printout terminal SYSTEM STATUS indicate indicate page, enter poke command UTIL:ACT! OPT:UTIL! 811 (PGM CNTL OFF NORM) to obtain status report...
Page 193 SUMMARY Form 800 to change binary value of bit 0 in office status Assure that office is officially cut over and first set of translator word from precutover (1) to post-cutover (0) trunks are turned up. Using 1B Processor MTC terminal, state and enter message.
Page 194 On display of RC Form 800 [FIG. 1]: [6] Complete all entries and ensure NEWDATA entry is 0 and OLDDATA entry is 1 [8] See NOTES 1 RC Form 800 and 2. Was recent Accepted entered Page 3 change accepted or rejected for test state [7] Depress Enter (return) key to...
Page 195 [15] At 1B Processor [10] At 1B Processor MTC terminal, enter [11] Was activate MTC terminal, enter VER:ABSOLUTE;COR: Accepted message accepted RCACT:ORNU a! ADR a,CORE! or rejected a = RC order a = Office status translator number word address Rejected [12] Was [14] Repeat [16] Ensure...
Page 197 [1] Notify next higher technical support group of activity to be performed [2] At 1B Processor MTC terminal, enter RMV:TGR a,TER b! a = TGR member number b = Terminal number [3] At 1B Processor MTC terminal, enter MON:IAOFC,NEW;ADD:IA IDB,TIMEON x, TIMEOFF x,FHC 289! x = Time of day [4] At 1B Processor MTC terminal,...
Page 198 [8] Using machine load and service summary (MLSS) report, machine performance report (MPR), machine service report (MSR) and network switching performance measurement plan (NSPMP), monitor machine performance for significant ineffective machine attempts (IMAs) [9] At 1B Processor MCC terminal, [11] Were any enter poke command 108 to system obtain SYSTEM STATUS page...
Page 199 [13] See CAUTION 1. At 1B Processor MTC CRT displays terminal, enter RC Form 801 OP:RCFORM 801! On display of RC Form 801 [FIG.1]: [14] Following RC:FUNC;CHG;OPT(TRANS), enter TST [15] Following TRANSID, enter UTTGR Page 4 [16] Following ORNU, enter recent change order number RC:FUNC;CHG;OPT(TRANS), TRANSID -------,...
Page 200 TABLE A [18] Using TABLE A, determine UTMN SELF- UTMN SELF- UTMN SYNCHRONIZED DECIMAL SYNCHRONIZED DECIMAL decimal word corresponding to TERMINAL UNIT WORD TERMINAL UNIT WORD self-synchronized terminal unit [19] Following WORDNO, enter identified UTMN decimal word [20] Following SIZE, enter 1 [21] Following DISP, enter 23 [22] Following BINOCT, enter B RC Form 801...
Page 201 [30] At 1B Processor MTC [26] Was RC ORNU Accepted terminal, enter accepted or VER:UTYPE;INA:TGR a,ENTRY! rejected a = TGR member number Rejected [27] Was data [28] Repeat entered correctly from [31] Are format, on RC Form 801 Step 13 unit type (UTYN), and Page 6 member number (MEMN)
Page 202 [33] Using TABLE B, determine octal word associated with self-synchronized terminal unit Page 7 UNIT TYPE [34] On TTY printout, locate MEMBER NO OCTAL WORD 26 octal word identified in previous step [FIG. 2] VER:UTMN;OPT(ENTRY),INA: FLN 32004.02 UTYN MEMN ME OPER, OCTAL ENTRY ADDRESS 07623144, ENTRY SIZE...
Page 203 [37] At 1B Processor [35] Is leftmost MTC terminal, enter octal digit a RCACT:ORNU a! 0, 1, 2 or 3 a = RC order number [36] Contact next [40] At 1B Processor MTC higher technical [38] Was terminal, enter Accepted support group and RC ORNU VER:UTYPE;TGR...
Page 204 OCTAL WORD 42 UNIT TYPE [41] Are format, [42] Contact next [42] Contact next OCTAL WORD 25 OCTAL WORD 26 MEMBER NUMBER unit type (UTYN), higher technical higher technical and member number support group and support group and VER:UTMN;OPT(ENTRY),CUR: FLN 3200//4.0/2 UTYN (MEMN) correct on inform personnel...
Page 205 1. General 2.4 Enter password 1.1 Cursor must be at left margin prior to each entry. Response: Enter subpassword: 1.2 Execution character for all messages in this 2.5 Enter subpassword procedure is the RETURN key Response: Enter up to 5 initials 1.3 If at any time during SCANS session the message 2.6 Enter your name or initials up to ENTER SYSTEM SELECT CODE is obtained, link to...
Page 207 1. General 1.1 Cursor must be at left margin prior to each entry 1.2 Execution character for all messages in this procedure is the RETURN key 1.3 If at any time during SCANS session the message ENTER SYSTEM SELECT CODE is obtained, link to host computer has been lost.
Page 209 1. General (c) For all BWMs associated with a specific generic issue within a given range of BWMs, 1.1 Cursor must be at left margin prior to each entry enter BWM,S 4E,G 4E(a),I b,R c-d 1.2 Execution character for all messages in this a = Generic designation number procedure is the RETURN key b = Generic issue number...
Page 211 [1] At 1B Processor [4] Contact next [3] Identify MTC terminal, enter [2] Have all higher technical explanation of error IN:OWBUF:a! required IN:OWBUF support group and code received using a = Overwrite data messages been input inform personnel 4ESS IM-4B000-01 from verbal and a PF response of actions performed...
Page 212 [10] Allow a [7] Does system 5-minute maintain normal "soak" period operations [11] Do any problems [12] At 1B occur (that is; [13] At 1B Processor MCC unidentified or Processor MTC terminal, depress abnormal number of terminal, enter EA DISP key to interrupts, interjects, UPD:HDATA obtain EAI page...
Page 213 [19] See NOTE 1. [21] Contact next Compare hard copy higher technical printouts from 1B [18] Was error [20] Were any support group and Processor MTC channel code 152 errors found inform personnel against verbal received of actions performed instructions or paper and results obtained copy [25] Can...
Page 215 [1] Ensure local support organization is notified when overwrites are ready for installation [3] Do all [5] Does any overwrites have overwrite have a Bell Laboratories special FR/MR number instructions assigned [2] Ensure all overwrites have a Bell Laboratories FR/MR number assigned [6] Ensure [4] Do NOT...
Page 217 [1] Select available APS tape unit for mounting tape to be verified [2] If tape is mounted on selected tape unit, demount tape [DLP-528] [6] Contact next higher technical [5] Is output support group and response IP inform personnel of [3] Mount AMA tape with (write enable actions performed and ring installed) on selected APS...
Page 218 [8] Does output data indicate errors [FIG. 1] [10] Diagnose [9] Demount tape on tape unit and correct AMA problems [DLP-528] [TAP-104] REPT AMATAPE VERIFY FOR IC STREAM TEXT VOL SER NUMBER 6.306 DATA SET ID 123456789987654 PHRASE STATEMENT EXPIRATION DATE 92-356 TAPE DRIVE NUMBER 2 AMA TAPE CAN BE WRITTEN FIG.
Page 219 [1] Select available APS tape unit for mounting tape to be verified [2] If tape is mounted on selected tape unit, demount tape [DLP-528] [5] Was verification Page 2 output message received [FIG. 1] [3] Mount AMA tape (supplied by RAO) with write enable ring installed on APS tape unit [DLP-527] [6] Contact next...
Page 220 [10] At APS MCRT terminal, enter [7] Is record Primary COPY:AMATAPE;PRIM,MT a:b! data primary a = Tape unit member or secondary number [8] Contact technical b = IC or OC support group and Secondary obtain sequence number for first and second block of secondary data [9] At APS MCRT terminal, enter...
Page 221 [11] Does output [12] Contact next response indicate higher technical REPT AMA TAPE WRITING support group and HAS BEGUN FOR a STREAM inform personnel of actions performed and results obtained [13] Allow tape writing to continue until another output response is received [14] See NOTE 1.
Page 222 [16] Does output [21] Does output [22] Demount tape response text phrase response text phrase on tape unit statement indicate statement indicate [23] Repeat [DLP-528] and label NORMAL TERMINATION — NORMAL TERMINATION — from Step 1 per local procedure NO MORE DATA MORE DATA TO BE [FIG.
Page 223 TEXT PHRASE REPT AMATAPE COMPLETE FOR IC STREAM STATEMENT VOL SER NUMBER 6,306 TAPE DRIVE NUMBER 2 START TIME 0629 240000 PRIMARY START BLOCK 6206 0628240000 END BLOCK 8863 0629240000 RECORDS WRITTEN 880 TAPE SEQUENCE NUMBER 33 NORMAL TERMINATION NO MORE DATA FIG.
Page 224 TABLE A TEXT PHRASE STATEMENTS EXPLANATION NORMAL TERMINATION - NO MORE DATA ALL DATA HAS BEEN WRITTEN STOP MESSAGE HAS BEEN ENTERED TERMINATION REQUESTED VIA STOP AMA TAPE MESSAGE TO TERMINATE WRITE PROCEDURE TERMINATION IS NORMAL BUT ALL NORMAL TERMINATION - MORE DATA TO BE WRITTEN DATA HAS NOT BEEN WRITTEN SOMETHING IN TRAILER LABEL CONTENTS TRAILER LABELS COULD NOT BE WRITTEN...
Page 225 [1] Select available APS tape unit for mounting tape [2] If tape is mounted on selected tape unit, demounted tape [DLP-528] [3] Mount AMA tape with write enable ring installed on selected APS tape unit [DLP-527] Page 2 [4] At APS MCRT terminal, enter System responds with OP:AMA;CONTROLFILE a! REPT AMA CONTROL FILE printout...
Page 226 [6] Is start time, stop time, and [8] Is AMA tape default MT number [10] Is AMA Page 3 writing session shown correctly for sessions inhibited inhibited automatic tape writing process [9] At APS MCRT [11] At APS MCRT [7] At APS MCRT terminal, terminal, enter terminal, enter enter...
Page 227 [14] Contact next higher technical [12] At start time [13] Is REPT support group and of tape write AMA TAPE WRITING HAS BEGUN inform personnel of process, verify message received actions performed that write begins and results obtained [16] Wait until [15] Is REPT tape write process AMA TAPE WRITE...
Page 229 [1] Do start and TAPE WRITING stop times apply to tape writing or teleprocessing TELEPROCESSING Page 2 [2] At APS MCRT terminal, enter SET:AMA;CONTROL;a:OFFICEID b, EXPDATE c,START (dd,dd)! a = IC or OC b = Office ID number c = Number of days until AMA tape expires Page 2, dd = Start time...
Page 230 [4] At APS MCRT terminal, enter SET:AMA;CONTROL;a :OFFICEID b,START (cc,cc)! a = IC or OC b = Office ID number cc = Start time [5] At APS MCRT terminal, enter SET:AMA;CONTROL:a;STOP (bb,bb), OPTION TP,HOCPSWD a = IC or OC bb = Stop time [7] Is system c = HOC password (10 digits) response...
Page 231 [2] Does control [1] At APS MCRT file data match data Page 2 terminal, enter provided by HOC/RAO OP:AMA;CONTROLFILE! for teleprocessing [FIG. 1] 24 REPT AMA CONTROL FILE OFFICE ID 123456 Page 3 DAYS UNTIL EXPIRATION PROCESS START TIME 0/ 0/:0/0/ PROCESS STOP TIME 0/ 0/:0/0/ DEFAULT MT FOR AUTO TAPE START...
Page 232 [3] Call HOC/RAO and request test poll [5] Contact next [4] At APS MCRT higher technical terminal, is support group and TELEPROCESSING inform personnel of STARTED message actions performed received and results obtained [6] Did test poll complete successfully [7] Notify HOC/RAO that teleprocessing is ready...
Page 233 [8] At APS MCRT terminal, enter SET:AMA;CONTROL;a:OFFICEID b,EXPDATE c,START d! a = OC or IC b = Office ID number (0040 followed by six digits) c = Number of days until AMA tape expires d = Stop time (Hours and minutes) [9] At APS MCRT terminal, enter SET:AMA;CONTROL;a:STOP b,MT c,OPTION TP! a = OC or IC...
Page 235 [5] Is AMA Tape CRITICAL processing option tape or teleprocessing Teleprocessing [1] Does disk contain AMA/ICDR [4] What type Page 6 of alarm occured records or deferred [TABLE A] formatting (DF) data [6] Is AMA Tape MAJOR processing option Page 2 tape or teleprocessing [3] Use SET:AMA:CONFIG...
Page 236 [8] Obtain tape from RAO for recording AMA data [9] Verify AMA tape [DLP-515] LOAD [10] At APS tape unit control lamp panel, ensure LOAD [13] Is lighted switch is depressed Page 3 output response IP ON LINE [11] At APS tape unit control panel, lamp ensure ON LINE switch lighted...
Page 237 [15] Allow tape writing process to continue for 15 minutes from initial start [16] After 15 minutes has elapsed, at APS MCRT terminal, enter STOP:AMATAPE:a! a = IC or OC [19] Is disk [20] Repeat storage occupancy from less than 87 [17] Demount AMA tape on tape Step 7 percent full...
Page 238 [21] Obtain tape from RAO for recording AMA data [22] Verify AMA tape [DLP-515] LOAD [23] At APS tape unit control lamp panel, ensure LOAD [26] Is lighted switch is depressed output Page 5 response IP ON LINE [24] At APS tape unit control lamp panel, ensure ON LINE lighted...
Page 239 [28] Allow tape writing process to continue uninterrupted until tape fills or normal termination occurs [31] Repeat from [30] Did Step 20 until disk normal termination storage occupancy occur indicating is normal for COPY was complete time of day [29] Demount tape on tape unit [DLP-528] [32] Collect all tapes written and...
Page 240 [33] See NOTE 1. At APS MCRT terminal, enter SET:AMA;CONTROL;a:OPTION TAPE! a = IC or OC [34] Obtain tape from RAO for recording AMA data [35] Verify AMA tape [DLP-515] [39] Is output Page 7 LOAD [36] At APS tape unit control response IP lamp panel, ensure LOAD...
Page 241 [41] Allow tape writing process to continue for 15 minutes from initial start [42] After 15 minutes has elapsed, at APS MCRT terminal, enter STOP:AMATAPE:a! a = IC or OC [45] Is disk [46] Repeat storage occupancy from less than 87 [43] Demount AMA tape on tape Step 32 precent full...
Page 242 [47] Obtain tape from RAO for recording AMA data [48] Verify AMA tape [DLP-515] LOAD [49] At APS tape unit lamp control panel, ensure lighted [52] Is output LOAD switch is depressed Page 9 response IP ON LINE [50] At APS tape unit control lamp panel, ensure ON LINE lighted...
Page 243 [54] Allow tape writing process to continue uninterrupted until tape fills or normal termination occurs [57] Collect all [56] Did tapes written and normal termination send to regional occur indicating accounting COPY was complete organization (RAO) for processing [55] Demount tape on tape unit [DLP-528] [58] At APS MCRT terminal,...
Page 244 [63] Set start [62] Is present and stop time time between for automatic AMA designated start record output and stop times [DLP-518] in control file [64] Contact regional accounting office [67] Has disk (RAO) and request [66] Has storage occupancy [68] Repeat demand poll polling...
Page 245 [72] At APS MCRT terminal, enter SET:AMA;CONTROL;a:OPTION TAPE! a = IC or OC [73] Obtain tape from RAO for recording AMA data [76] Is Page 3 output [74] Verify AMA tape response IP [DLP-515] [75] At APS MCRT terminal, enter COPY:AMATAPE:PRIM,MT a:b! [77] Contact next a = Tape unit member number...
Page 246 [80] Enter [78] Is one of [81] Is one of the SCSI Interface RST:LNxx y! the SIN Links Node (SIN) links to restore SINs In-Service In-Service (IS) [79] No action [82] Enter necessary CHG:SLK(xx,y);ARST! to restore the links [83] Is one of the SIN Links In-Service [84] Contact...
Page 247 [1] At APS MCRT [2] Are terminal, enter diagnostic DGN:CU a! results ATP a = Control unit member number [6] Identify [7] Are CATP [3] What are conditions causing CATP results diagnostic diagnostics to explainable and results complete with acceptable CATP results [4] Record [8] Contact next...
Page 249 [1] At APS MCRT terminal, enter DGN:CU a,CC b:PH 1-92! [2] Are a = Control unit Page 2 diagnostic member number results ATP b = Central control member number [6] Identify [3] What are conditions causing CATP diagnostic diagnostics to results complete with CATP results...
Page 250 [9] At APS MCRT terminal, depress EA DISP key to obtain EAI page [11] See Note 1. At APS MCRT terminal, enter DGN:CU a,CC b:PH 93! a = Control unit member [10] On APS MCRT terminal number (0 or 1) EAI page, enter poke b = Central control command 14 in command...
Page 251 [17] At control unit EAI unit (TN11) under test, identify hexidecimal hardware status digits (0—F) [21] At control unit [22] Ensure EAI unit (TN11) under OOS lamp flashes twice, [18] Were test, ensure each LED and FORCED OFF-LINE digits O-F lights and then lamp is lighted and observed...
Page 252 [26] At APS MCRT terminal, enter DGN:CU a,MASC b:PH 1-95! [27] Are a = Control unit Page 5 diagnostic member number results ATP b = Main store controller member number [31] Identify [28] What are conditions causing CATP diagnostic diagnostics to results complete with CATP results...
Page 253 [34] At APS MCRT terminal, enter DGN:DFC a:PH 8,CU b! [35] Are a = Disk file controller diagnostic member number results ATP b = Control unit member number [39] Identify [40] Are CATP [36] What are condition causing CATP results diagnostic diagnotics to explainable and...
Page 255 [4] See NOTE 2. At [1] At APS MCRT APS MCRT terminal, terminal, enter [2] See NOTE 1. Is enter DGN:MHD a! Page 2 VFY:MHD a COMPLETED VFY:MHD a! a = Moving head disk a = Moving head disk message received member number member number [3] Clear moving...
Page 256 [5] Are diagnostic results ATP [9] Identify [10] Are CATP [6] What are conditions causing CATP results diagnostic diagnostics to explainable and results complete with acceptable CATP results [7] Record [11] Contact next failing phases higher technical and errors support group and indicated inform personnel of actions performed...
Page 257 [1] At APS MCRT terminal, enter DGN:DFC a:PH 15,CU b! [2] Are a = Disk file controller Page 2 diagnostic member number results ATP b = Control unit member number [6] Identify [3] What are conditions causing CATP diagnostic diagnostics to results complete with CATP results...
Page 258 [9] At APS MCRT terminal, enter DGN:DFC a:PH 8,CU b! [10] Are a = Disk file controller diagnostic member number results ATP b = Control unit member number [14] Identify [15] Are CATP [11] What are conditions causing CATP results diagnostic diagnostics to explainable and...
Page 259 [1] At APS MCRT terminal, enter [2] Are DGN:IOP a! diagnostic a = Input/Output results ATP processor member number [6] Identify [7] Are CATP [3] What are conditions causing CATP results diagnostic diagnostics to explainable and results complete with acceptable CATP results [4] Record [8] Contact next...
Page 261 [1] At APS MCRT terminal, enter DGN:IOP aPH 15,CU b! [2] Are a = Input/Output diagnostic processor member results ATP number b = Control unit member number [6] Identify [7] Are CATP [3] What are conditions causing CATP results diagnostic diagnostics to explainable and results...
Page 263 3B21D APS Page 4 3B20 Model 2/3 APS [1] Office Page 3 3B20 Model 1 APS SUPPLY REEL [2] Open tape unit dust cover [3] Lift supply (upper) reel hub tab HUB TAB and place tape reel onto supply reel hub [FIG. 1] [4] While holding tape reel, secure Page 2 reel by returning supply...
Page 264 [9] On tape unit [7] On tape control panel, [10] Close [8] Does tape unit control depress ON LINE tape unit stop at LOAD panel, depress switch and ensure dust cover POINT LOAD switch ON LINE lamp lights [11] On tape unit control panel, depress REWIND switch...
Page 265 [16] On tape SUPPLY CONTROL PANEL [15] On tape unit control REEL unit control panel, depress LATCH panel, is LOGIC RELEASE LOGIC ON switch BUTTON OFF LED lighted Response: LOGIC OFF LED goes off LATCH BEARINGS MAGNETIC HEAD COVERS TAKE-UP [17] Open tape unit dust cover REEL [18] Place supply (upper) reel on hub...
Page 266: Write-Protect Tab
[29] See NOTE 1 and CAUTION 1. At available [27] Is in-service digital tape to be audio tape (DAT) unit written (EQL 11-124 or 62-124), carefully insert 4-mm tape [FIG. 4] [28] Put write- protect tab on WRITE-PROTECT 4-mm tape in the up (unlocked) position [FIG.
Page 267 3B21D APS SUPPLY Page 3 CONTROL PANEL REEL LATCH RELEASE 3B20 Model 1 APS [1] Office BUTTON Page 3 LATCH 3B20D Model 2/3 APS BEARINGS MAGNETIC HEAD ON LINE COVERS [2] At control panel, if ON LINE LED LED off TAKE-UP on, touch RESET switch REEL...
Page 268 [9] On tape unit control panel, [8] On tape unit depress ON LINE control panel, SUPPLY switch is ON LINE LED REEL Response: ON LINE lighted [FIG. 1] LED goes off LOAD POINT [10] On tape unit control panel, HUB TAB LED lights depress REWIND switch Tape rewinds...
Page 269 [17] At digital audio tape (DAT) unit that [18] Was tape EJECT contains tape to be BUTTON just written removed, depress eject button [FIG. 3] [19] Put write- protect tab in the down (locked) ROS/RST position [FIG. 4] ACO-T WRITE-PROTECT DOWN = LOCKED FIG.
Page 271 TABLE A [1] See NOTE 1. At RESPONSIBLE 1B Processor MTC TROUBLE AREA terminal and/or APS Page 2 MCRT terminal, do APS duplex failed any conditions shown APS AMA disks are duplex failed in TABLE A appear APIs are duplex failed APS/1B AU bus (1B side) is duplex failed AMA disk partition is 100% full...
Page 272 [4] Contact next [3] Is REPT higher technical AMA/ICDR support group and RECORDING RESTARTED inform personnel of message received actions performed and results obtained [5] At APS MCRT terminal, enter AMdwriteric, AMdwriteroc, STOP:EXC:ANY,FN "/AMA/AM dwriteric", UCL! AMformat and INdwriter [6] At APS MCRT terminal, enter processes killed STOP:EXC:ANY,FN "/AMA/AM dwriteroc",...
Page 273 [11] Are AMAarcur, AMdwriteric, AMAdwriteroc, AMformat and INdwriter processes running [12] Contact next higher technical support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000 234-351-002 CLEAR ATTACHED PROCESSOR SYSTEM (APS) AMA/ICDR PAGE 3 of 3 TRANSFER BUFFER OVERFLOW PROBLEM...
Page 275 [2] Are [1] At APS MCRT RST SDLC a COMPLETED terminal, enter Page 2 RST:SDLC a! RST SDL a COMPLETED a = Unit member number message received [3] Contact next higher technical support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000...
Page 276 [6] On APS MCRT [8] On APS MCRT [4] At APS MCRT terminal 115 terminal 114 terminal, is Page Page, is SDLC Page, is SDL 115 displayed active stby [7] Contact next [5] At APS MCRT [9] At APS MCRT higher technical terminal, depress terminal, enter...
Page 277 [2] At recent change [1] Is office and verify equipped with APS terminal, enter recent change and RCV:MENU:RCVECD! verify terminal (Response: 199 Page displayed) At APS MCRT terminal: [3] Depress PF2 (NORM/DISP) key [4] Enter poke command 199 in command mode to obtain 199 Page Cursor positioned at On 199 Page:...
Page 278 eaiopt form displayed [9] Enter eaiopt [11] Is third [13] Enter < character twice to exit position of recent change systype field 6 eaiopt form filled in and an I Enter Review, Validate, Screen #, or Print displayed [10] Enter eaiop0 Page 3 [12] Enter <...
Page 279 [15] At recent [14] Is office change and verify equipped with APS terminal, enter recent change and RCV:MENU:RCVECD! verify terminal (Response: 199 Page displayed) At APS MCRT terminal: [16] Depress PF2 (NORM/DISP) key [17] Enter poke command 199 in command mode to obtain 199 Page Cursor positioned at On 199 Page:...
Page 280 tr_name form On 199 Page: displayed [22] Enter trbegin Enter Execute, Change, Substitute, Validate, or Print: displayed [23] Enter rceaiopt FORM EXECUTED displayed momentarily; then, Enter Form Name: displayed [24] Enter e Enter Database Operation Page 5 I=Insert R=Review U=Update D=Delete displayed [25] Enter eaiopt eaiopt form displayed...
Page 281 Change field: On 199 Page: displayed [28] Enter c Cursor positioned to change SYSTYPE [29] Enter 6 [30] Record value in SYSTYPE field including blank spaces Page 6 [31] Replace third character position of recorded value (Step 30) with an I [32] Enter new SYSTYPE value (Step 31) including blank spaces Enter Update, Change,...
Page 282 FORM UPDATED On 199 Page: displayed momentarily [34] Enter u eaiop0 form exited and Enter Form Name: displayed [35] Enter < tr_name form displayed [36] Enter trend Page 7 [37] Enter rceaiopt Form filled in with default values and Enter Execute, Change, [38] Depress RETURN Substitute, Validate, or Print: key three...
Page 283 ACTIVATE FORM displayed [40] Enter activate Enter Execute, Change, Substitute, Validate, or Print: displayed [41] Enter yes FORM EXECUTED displayed momentarily then, Enter Form Name: displayed [42] See Note 1. Enter e Recent change exited [43] Enter << [44] Update APS backup database [DLP-538] NOTE 1 It may take several minutes...
Page 285 [2] Does printout [1] At APS MCRT indicate Page 2 terminal, enter PROCESS START TIME and OP:ICDR;CONTROLFILE! PROCESS STOP TIME requirements [FIG. 1] [3] At APS MCRT terminal, enter SET:ICDR;CONTROL: (aa,aa), (bb,bb)! a = Start time in hours and minutes (2330) b = Stop time in hours and minutes (0230) [4] Does printout indicate times were...
Page 286 [6] Does printout indicate DATA TRANSFER IS NOT MANUALLY INHIBITED [7] At APS [8] Does printout MCRT terminal, indicate enter DATA TRANSFER IS NOT ALW:ICDR;SESSION! MANUALLY INHIBITED [9] Contact next higher technical support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000...
Page 287 Status printout [1] At APS MCRT terminal, enter received OP:STATUS:PROCESS,ALLKERNS! [3] Are AMformat and INdwriter processes Page 2 [2] On status printout under column listed on status heading DEVICE, determine if printout AMformat (UTID code 0x625) and INdwriter (UTID code 0x671) are listed Page 2, Step 8...
Page 288 [5] At APS MCRT terminal, enter OP:STATUS:PROCESS,PATH! [7] Is INmon process listed on status printout [6] On status printout under column heading CMD, determine if INmon is listed [8] At APS MCRT terminal, depress EA DISP key to obtain EAI page [9] At APS MCRT terminal, [12] Allow 2 enter poke command...
Page 289 [2] Does [1] At APS printout indicate MCRT terminal, at least one ICDR enter partition equipped OP:ICDR;CONFIG! [3] Obtain Telephone Equipment Order (TEO) covering office-dependent APS ICDR disk partition specifications and requirements [8] Are [6] Does printout additional indicate partition partitions to was successfully [4] Determine from TEO how ICDR...
Page 291 [2] Does printout [1] At APS MCRT indicate ICDR terminal, enter recording is OP:ICDR;RECORDING! turned ON [3] At APS MCRT terminal, enter SET:ICDR;RECORDING:ON! [4] Does printout indicate ICDR recording is turned [5] Contact next higher support group and inform personnel of actions performed and results obtained Issue 7...
Page 293 [2] At recent change [1] Is office and verify terminal, equipped with APS enter recent change and RCV:MENU:RCVECD! verify terminal (Response: 199 Page displayed) At APS MCRT terminal: [3] Depress PF2 (NORM/DISP) key (See Note 1) [4] Enter 199 in command mode to obtain 199 Page Cursor positioned at On 199 Page:...
Page 294 ucb option form On 199 Page: displayed [9] Enter ucb Cursor positioned at unit_name [10] Depress RETURN key twice [13] Is ucb Page 3 form for unit displayed Cursor positioned [11] Enter unit name at unit_number (SDL, SDLC) [12] Enter unit member number [14] Contact next higher technical support group and inform personnel of...
Page 295 [15] Is all data correct [17] At APS MCRT terminal, enter < twice to exit recent change [16] Enter < twice to exit [18] At APS MCRT terminal, enter Page 4 recent change RMV:SDLC a! a = SDLC member number [19] Wait for RMV SDLC a COMPLETE message...
Page 296 [21] At recent [20] Is office change and verify equipped with APS terminal, enter recent change and RCV:MENU:RCVECD! verify terminal (Response: 199 Page displayed) At APS MCRT terminal: [22] Depress PF2 (NORM/DISP) key [23] Enter poke command 199 in command mode to obtain 199 Page Cursor positioned On 199 Page:...
Page 297 tr_name form On 199 Page: displayed [28] Enter trbegin Enter Execute, Change, Substitute, Validate, or Print: displayed [29] Enter rcoos FORM EXECUTED displayed momentarily; then, Enter Form Name: displayed [30] Enter e Enter Data Base Operation Page 6 I=Insert R=Review U=Update D=Delete displayed [31] Enter ucb ucb option form...
Page 298 On 199 Page: Cursor positioned [34] Enter unit name at unit_number (SDL or SDLC) ucb form filled in and Enter Update, Change, Substitute, Validate, Screen #, or Print: [35] Enter unit member displayed number Change field: displayed [36] Enter c Page 7 [37] Change data fields as required...
Page 299 FORM UPDATED On 199 Page: displayed momentarily [39] Enter u ucb form exited and Enter Form Name: displayed [40] Enter < tr_name form displayed [41] Enter trend Page 8 [42] Enter rcoos Form filled in with default values and Enter Execute, Change, [43] Depress RETURN Substitute, Validate, or key three...
Page 300 FORM EXECUTED displayed momentarily; then, Enter Form Name: displayed [44] Enter e Enter ACTIVATE FORM [45] Enter displayed activate Enter Execute, Change, Substitute, Validate, or Print: displayed [46] Enter yes FORM EXECUTED displayed momentarily [NOTE 1]; then, Enter Form Name: displayed [47] Enter e Recent change...
Page 301 Status At APS MCRT terminal: printout [1] Enter received OP:STATUS:PROCESS,ALLKERNS! [2] Depress PF1 (EA DISP) key to display EAI page [3] Depress PF3 (CMD/MSG) key to enter command mode [4] Enter poke command 42 in command mode to obtain the application parameter prompt [5] Enter I to restart dead processes...
Page 303 [5] Contact next [4] Is [3] At APS MCRT higher technical [1] At APS MCRT AUD FSLINK 1 INS terminal, enter support group and terminal, enter "/dev/root" COMPLETED inform personnel AUD:FSLINK 1,INS OP:STATUS:FILESYS! message received of actions performed "/dev/root"! and results obtained [2] Does response [6] At APS MCRT indicate APS is...
Page 304 [12] Contact next [11] Is higher technical [10] At APS MCRT AUD FSBLK 1,INS terminal, enter support group and "/dev/root" COMPLETED inform personnel AUD:FSBLK 1,INS message received "/dev/ root "! of actions performed and results obtained [13] At APS MCRT terminal, enter AUD:FSBLK 1,INS "/dev/etc"!
Page 305 [19] Contact next [18] Is higher technical [17] At APS MCRT AUD FSLINK 1 INS terminal, enter support group and "/dev/broot" COMPLETED inform personnel AUD:FSLINK 1,INS message received "/dev/broot"! of actions performed and results obtained [20] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/betc"! [21] Is...
Page 306 [26] Contact next [25] Is higher technical [24] At APS MCRT AUD FSBLK 1,INS terminal, enter support group and "/dev/broot" COMPLETED inform personnel AUD:FSBLK 1,INS message received "/dev/broot"! of actions performed and results obtained [27] At APS MCRT terminal, enter AUD:FSBLK 1,INS "/dev/betc"! [28] Is...
Page 307 [33] Contact next INH RCV COMPLETED [31] At APS MCRT higher technical [32] Was 4ESS INH RCV COMPL terminal, enter suport group and INH RCV COMPLETED INH:RCV:ON! inform personnel of RECENT CHANE INHIBIT ON message received to inhibit DMS actions performed [FIG.
Page 308 [37] Is [39] At APS MCRT [40] Was REPT QCOPY:DISK terminal, enter INH RCV COMPLETED COPY COMPLETED INH:RCV:OFF! to message received message received allow DMS activity [FIG. 2] [38] Contact next [41] Contact next higher technical higher technical support group and support group and inform personnel of inform personnel of...
Page 309 [2] Does response [1] At APS MCRT indicate APS is broot Page 2 terminal, enter operating on root OP:STATUS:FILESYS! or broot file system root [3] At APS MCRT terminal, depress EA DISP (PF1) key to display the EAI page [4] Depress CMD/MSG (PF3) key to enter command mode [5] Enter poke command 12 to force active CU on-line...
Page 310 [8] At APS MCRT terminal, depress EA DISP (PF1) key to display the EAI page [9] Enter poke command 12 to force active CU on-line [10] Enter poke command 31 to clear broot [11] See NOTE 1. Enter poke command 53 to request phase 3 boot Issue 7 JUN 2000...
Page 311 [8] At 1B Processor MTC [2] At 1B [1] See CAUTION 1. terminal, enter message [3] Does status Processor MCC At 1B Processor AUD:NUM (43,44,45,66,72)! printout identify terminal, enter MCC terminal, enter (takes approximately any active generic 811 (PGM CNTL 108 to obtain System 30-40 minutes for audits utilities...
Page 312 [10] At 1B Processor [9] Was 0 MTC terminal, run ERRORS DETECTED each audit with received for each errors. Response audit that was run AUD:NUM a COMPLETE 0 ERRORS DETECTED [12] Contact next higher technical [11] Was 0 support group and ERRORS DETECTED inform personnel received for each...
Page 313 [13] Select available APS tape unit [14] If tape is mounted on selected tape unit, demount tape [DLP-528] [18] Contact next higher support [17] Is [15] Mount blank or erasable tape with group and inform GEN TAPE WRITTEN personnel of write enable ring installed message received (1600 BPI) or protect tab in...
Page 315 [1] At 1B Processor MCC terminal, enter 108 to obtain System Status (106) display page [3] At 1B Processor MTC [2] On display terminal, enter message page, is AUD:NUM (43,44,45,66,72)! 801 - RESTRICT RC (takes approximately Page 2 colored black on 30-40 minutes for audits white to complete)
Page 316 [9] At 1B Processor [7] Was 0 MTC terminal, run ERRORS DETECTED each audit with received for each errors. Response audit that was run AUD:NUM a COMPLETE 0 ERRORS DETECTED [11] Contact next [10] Was 0 [8] Select higher support ERRORS DETECTED available group and inform...
Page 317 [12] If tape is mounted on selected tape unit, demount tape [DLP-528] [13] Mount blank or erasable tape with [16] Contact next write-enable ring installed (1600 BPI) or [15] Is higher support protect tab in up (unlocked) position (4mm) ODA TAPE WRITTEN group and inform on tape unit [DLP-527] message received...
Page 318 [22] At APS MCRT [20] Has file been NORM terminal, enter copied to file UPDATE since Generic Retrofit COPY:APPFILE NORM! [25] On 1B Processor MCC terminal SYSTEM STATUS [23] Is [21] At APS MCRT page, enter poke command terminal, enter COPY APPFILE COMPLETE 801 RESTRICT RC message received...
Page 319 [1] Select available APS tape unit [2] If tape is mounted on selected tape unit, demount tape [DLP-528] [3] Mount blank or erasable tape with write Page 2 enable ring installed (1600 BPI) or protect tab in up (unlocked) position (4mm) on tape unit [DLP-527] [4] At APS MCRT terminal, enter COPY:APPTAPE:TOSL,MT a!
Page 320 [9] Contact next higher technical [7] Were output [5] Was output support group and messages 2 through message 1 inform personnel 6 (as required) received of actions performed received [TABLE A] [TABLE A] and results obtained [8] Demount tape [6] Determine on tape unit cause and [DLP-528] and...
Page 321 [1] Select available APS tape unit [2] If tape is mounted on selected tape unit, demount tape [DLP-528] [3] Mount blank or erasable tape write Page 2 enable ring installed (1600 BPI) or protect tab in up (unlocked) position (4mm) on tape unit [DLP-527] [4] See NOTE 1.
Page 322 [9] Contact next higher technical [7] Were output [5] Was output support group and messages 2 through message 1 inform personnel 4 received received of actions performed [TABLE A] [TABLE A] and results obtained [8] Demount tape [6] Determine on tape unit cause and [DLP-528] and resolve;...
Page 323 Manual entry Page 6 [1] Contact technical support [2] What Page 2 group and determine process is process to be used to be used to insert overwrites Support organization entry [3] Request support organization to insert overwrites [4] Are more overwrites to be inserted by any other process...
Page 324 [5] Request technical support group to download BWM to APS disks [6] At APS MCRT terminal, depress NORM DISP ( PF2) key and enter poke command 1960 in command mode to obtain display page 1960 [7] Enter poke comand 9000, AAAxx-xxxx to select BWM (AAAxx-xxxx = BWM number to be applied) [8] Enter poke command 9010 to verify BWM [9] Enter poke command 9110 to select and display...
Page 325 [12] Enter poke command 9120 to display SOAK [13] Enter poke command 9320 to execute SOAK section [14] Wait for SOAK SECTION COMPLETED: TIMER HAS BEEN SET message to be received in RESPONSE field, and ROP printout indicating that soak timer is in progress [15] Wait for SOAK SECTION COMPLETED: SOAK SECTION message to be received [16] Enter poke command 9130 to display OFC section...
Page 326 [24] At APS MCRT terminal, enter [21] What message EXC: EXC:ENVIR:UPROC,FN "a"! is to be used to a = Full pathname insert overwrites specified in SCANS file LOAD: [22] At APS MCRT terminal, enter [27] Contact next [25] Follow LOAD:GULP:GENERIC "a"! [26] Were higher technical progress messages...
Page 327 IN:OSOW:START! BUILDING OW BUFFER — OW BLOCK 1 READY FOR OVERWRITE DATA BUILDING OW BUFFER — OW BLOCK 2 IN:OSOW:a b,DATA c! IN:OSBUF:COMPLETED MM ADR FS ADR OLD DATA NEW DATA vvvvvvvv wwwwwwww xx yyyyyyyy zzzzzzzz DATABASE UPDATED WITH OVERWRITES READY FOR OVERWRITE DATA IN:OSOW:UPD[,HASHSUM d]! EXC ENV UPROC COMPLETED...
Page 328 [30] Collect and list overwrites to be inserted into 1B Processor generic via update file [33] See NOTE 2. At APS MCRT terminal, enter IN:OSOW:FSADR a, DATA b [,OLDDATA c]! [32] Is overwrite a = Disk address (octal) only applicable to for data to be changed main memory or b = Data (octal) to be...
Page 329 [35] Was IN:OSOW:COMPLETED message received Page indicating overwrites accepted [38] At APS MCRT [36] Are additional terminal, enter overwrites to be IN:OSOW:UPD[,HASHSUM a]! inserted into the to process buffered data buffer area a = Hashsum designator [37] Repeat from Step 31 [40] Are more [39] Was overwrites to...
Page 330 [44] Contact next higher technical [43] Identify OSOW ABORTED REASON a support group and output message inform personnel abort code of actions performed [TABLE A] and results obtained MISMATCH ON OLD AND NEW [45] Correct DATA input message and repeat from Step 30 [42] What failure is indicated by...
Page 331 [48] Contact next higher technical OW BUFFER CAPACITY EXCEEDED support group and inform personnel of actions performed and results obtained [47] What failure [49] At APS MCRT HASH FAILURE is indicated by [50] Repeat terminal, enter ENTER UPD OR ABORT MESSAGE output message from IN:OSOW:START!
Page 332: System Error Codes
TABLE A SYSTEM ERROR CODES ERROR EXPLANATION CODE Failure on access of 1ASTAT file UPDATE file is in update mode Cannot allocate main memory for buffers Cannot open UPDATE for reading Invalid ID2FS Cannot open overwrite file Cannot translate valid MM address to FS address Out-of-range MM address for translation to FS address Failure on seek of 1AFILE Failure on read of 1AFILE...
Page 333 [1] At APS MCRT terminal, enter VER:APPFILE UPD! [3] Was verification completed with zero errors [FIG. 1] [2] See NOTE 1. Observe printout for zero errors [5] Contact next [4] At 1B Processor higher technical MCC terminal, enter support group and STOP:UPD;CORE! to inform personnel abort process...
Page 335 [1] At APS MCRT terminal, enter LOAD:UPDATE:DIFF! [3] Is READY FOR MAIN MEMORY UPDATE message received [FIG. 1] [2] Observe printout for progress messages [FIG. 1] [4] Contact next higher technical support group and inform personnel of actions performed and results obtained DETERMINING DIFFERENCES FOR ADDRESS 0 DETERMINING DIFFERENCES FOR ADDRESS 2000000 DETERMINING DIFFERENCES FOR ADDRESS 4000000...
Page 337 MCC terminal EAI page UPDATE IN PROGRESS text lights Black on Yellow and upper six octal digits of data under EAI FAIL DATA DISPLAY following [1] At 1B Processor MTC CODE indicate action terminal, enter being performed [TABLE A] UPD:FS;GEN PARTIAL! [3] Is Page 2 UPD:FS INIT.COMPLETED...
Page 338 [5] At APS MCRT terminal, enter LOAD:GULP:GENERIC "a"! a = BIG GULP or BWM pathname [7] Is DATABASE UPDATED WITH OVERWRITES [6] Observe printout for message received progress messages indicating an updated database [FIG. 2] [8] See TABLE B. Abort 1B Processor generic update process [DLP-548]...
Page 339 TABLE B SYSTEM ERROR CODES ERROR EXPLANATION CODE Failure on access of 1ASTAT file UPDATE file is in update mode Cannot allocate main memory for buffers Cannot open UPDATE for reading Invalid ID2FS Cannot open overwrite file Cannot translate valid MM address to FS address Out-of-range MM address for translation to FS address Failure on seek of 1AFILE Failure on read of 1AFILE...
Page 341 [1] At 1B Processor MTC terminal, enter STOP:UPD;CORE! [2] On 1B Processor MTC terminal EAI Page, enter Poke Command 61 ( NORM FILE! ) [3] At 1B Processor MTC terminal, enter Poke Command 108 to Obtain SYSTEM STATUS Page [4] At 1B Processor MTC terminal, SYSTEM STATUS Page, Enter Poke Command 801 (Restrict RC) [5] At APS MCRT terminal, enter COPY:APPFILE NORM! To put update 1Afile back in order...
Page 343 [3] Contact next higher technical [1] At APS support group and [2] Was AMA disk MCRT terminal, inform personnel of map printout enter actions performed received [FIG. 1] OP:AMA;MAPS! and results obtained [8] Contact next [4] Record LPO values higher technical [6] At APS [7] Was AMA disk for later use...
Page 345 [1] Contact network management group and request personnel to manually inhibit any network management database changes via network management display terminal (NMDT) CN20 page [2] Select available APS tape unit [7] Contact next higher support [6] Is [3] If tape is mounted on select group and inform NWM TAPE WRITTEN type unit, demount tape [DLP-528]...
Page 347 [1] See NOTE 1. Mount one backup tape on available tape unit [DLP-527] [4] Determine [3] After tape cause and resolve. verifies, was Tapes may need to printout received be rewritten [2] At APS MCRT terminal, enter per TABLE A VFY:TAPE,TD"/dev/mtX0",RETRY 3! X = Tape unit member number...
Page 349 [1] Obtain 1600 BPI/4mm Generic, ODA and TOSL tapes and ensure that they are compatible [4] Remove [3] Is tape tape from 3B mounted on APS tape unit selected [DLP-528] tape unit [2] See NOTE 1. Select in-service 3B APS tape unit for mounting tapes to be loaded [7] On 1B Processor MCC terminal EAI...
Page 350 TAPE HEADER [9] At 3B APS MCRT [10] Using Generic terminal, enter message [11] Repeat from tape header VER:UPDATE:TAPE,MT a! printout [FIG. 1], Step 1, Page 1 TAPE FILE 10 LOADED TO FS a = tape unit using proper is proper generic TAPE FILE 20 LOADED TO FS member number with Generic tape...
Page 351 BASE AND CONTROL DATA [15] Remove Generic tape from 3B APS (MUST BE IN CAPS) tape unit [DLP-528] TAPE TYPE: ODA BASE 908F, CONTROL H6 GENERIC 4E<xx>.4R-23, 4019 MOST RECENT OFL GENERATION: YR yy, MON 03, DAY 05 AT 16:23 [16] Mount the ODA tape on same THIS TAPE WRITTEN: YR yy, MON 03, DAY 09 AT 08:23 3B APS tape unit [DLP-527]...
Page 352 [22] Remove ODA tape from 3B APS tape unit [DLP-528] [26] Repeat [23] Mount TOSL tape on same [25] Is from Step 22, 3B APS tape unit [DLP-527] LOAD APPTAPE COMPLETED using different message received tape unit [24] At 3B APS MCRT terminal enter message LOAD:APPTAPE:TOSL,MT a! a = Tape unit member number with...
Page 353 [29] On 1B Processor MCC terminal EAI page, enter appropriate poke command ( 10 or 11) to release selected CC. [28] At 1B processor Response: All FORCE FNCT poke commands MCC terminal, in color purple on white (except FORCE FNCT section, selected CC colors white on are any FORCE FNCT black)
Page 354 TABLE A 1B Processor Manual Configurations and Associated Poke Commands Override Control Selections Manual Config PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 Sequence State Issue 7 JUN 2000 234-351-002 PERFORM 1AFILE RELOAD AND ATTEMPT 1B PROCESSOR RECOVERY ON PAGE 6 of 9 NORMAL FILE...
Page 355 [34] On 1B [33] On 1B Processor Processor MCC MCC terminal EAI terminal EAI page, page, is enter poke command 70 — DIS AUTO PC 70 (DIS AUTO PC) colored black on [70 — DIS AUTO PC purple colors black on purple] On 1B Processor MCC terminal EAI page: [35] Enter poke command 402 (RESET ALL) to reset all Direct Data...
Page 356 [40] On 1B Processor MCC terminal EAI page, under Page 9, PC PROGRESSION, does Step 47 CMPL text color BLACK on GREEN within 45 seconds [41] On 1B Processor MCC [42] On 1B Processor MCC terminal EAI page under terminal EAI page under [43] Has ample EAI FAIL DATA DISPLAY time (10 minutes)
Page 357 [46] Is system running successfully with I/O communication established at 1B Processor MTC terminal [47] Have all valid configurations in the [48] Request 1B Processor Manual technical Configurations and assistance from Associated Poke appropriate support Commands Table organization [Page 6] been tried [49] See NOTE 4.
Page 359 [1] If tape is mounted on available tape unit, demount tape [DLP-528] [5] Contact next higher support [4] Was output [2] Mount TOSL tape on available group and inform message 1 APS tape unit [DLP-527] personnel of received actions performed [TABLE A, Page 2] and results obtained [3] At APS MCRT terminal, enter...
Page 360 TABLE A TOSL TAPE LOADING OUTPUT MESSAGES MESSAGE OUTPUT MESSAGES NUMBER APPTAPE TYPE: TOSL, WRITTEN mm/dd/yy hh:mm APPTAPE ADDRESS RANGE aaaaaaaa — bbbbbbbb STARTED APPTAPE ADDRESS RANGE aaaaaaaa — bbbbbbbb COMPLETED APPTAPE ADDRESS RANGE cccccccc — dddddddd STARTED APPTAPE ADDRESS RANGE cccccccc — dddddddd COMPLETED APPTAPE COMPLETED * Only received if office has Mass Status Table (MST) mm/dd/yy hh:mm = Month/day/year hour:minute tape was written...
Page 361 [1] If tape is mounted on available tape unit, demount tape [DLP-528] [5] Contact next higher support [4] Was output [2] Mount LTS tape on available group and inform message 1 APS tape unit [DLP-527] personnel of action received performed and [TABLE A] results obtained [3] See NOTE 1.
Page 363 [1] Obtain APS backup tape-only program (TOP) tape [2] Obtain latest set of backup [5] Demount [4] Are tapes generic (RT0-x) tapes and backup tape on selected mounted on APS database (DB) tape tape units tape units 0 [DLP-528] and/or 1 [3] Select available APS tape unit to mount TOP tape [6] Mount tape-only program (TOP)
Page 364 TABLE A [11] On APS MCRT SELECTED CU AND ASSOCIATED PRIMARY/SECONDARY MHDs [9] Which terminal EAI page, CU 0 APS CU is to enter poke command SELECTED CU PRIMARY MHD SECONDARY MHD be forced 10 in command mode MHD0 MHD1 on-line to force CU 0 MHD1...
Page 365 [18] On APS MCRT [17] Which terminal EAI page, [20] If 3B21D, APS tape unit MT 0 enter poke command enter Y is to be forced 55 in command mode to confirm on-line to to load TOP tape load tape MT 1 [21] See NOTE 1.
Page 366 [32] On APS MCRT [30] Which APS [25] Obtain terminal EAI page, MT 0 [26] Select tape unit is to latest APS enter poke command available APS be forced on-line backup generic 55 in command tape unit to load tape RTO-1 tape mode to load tape MT 1...
Page 367 [36] Initial PRM for generic RT0-1 tape. Repeat from Step 35 06 Followed [37] Initial PRM By 74 for generic RT0-2, RT0-3, RT0-4, RT0-x tape. Repeat from Step 35 [38] Initial PRM 54 Followed for DB tape. By 74 Repeat from Step 35 [39] Tape is still being loaded.
Page 368 [49] On APS MCRT [48] What are 00 or terminal EAI page, characters 14 and enter poke command 15 of last PRM 31 in command mode received on APS to force APS to ROP [FIG. 1] boot on "root" 01 or [50] On APS MCRT [51] On APS MCRT terminal EAI page,...
Page 369 [58] Contact [54] See NOTE 3. next higher Are failing APS support group and PRMs being received inform personnel continuously of actions performed [FIG. 2] and results obtained [55] Are APS PRMs being received where PRM TYPE the "BOOT STEP" E = SUCCESSFUL F = FAILING counts up and then...
Page 370 [59] Demount all backup tapes on tape units [DLP-528] [60] Store backup tapes per local procedures [61] Record corrective action for local records Issue 7 JUN 2000 PERFORM ATTACHED PROCESSOR SYSTEM (APS) SYSTEM 234-351-002 REINITIALIZATION (SR) PAGE 8 of 8...
Page 371 [1] At APS MCRT [1] At APS MCRT [2] Does any terminal, enter terminal, enter partition OP:AMA;MAPS! need to be equipped Page 2 Issue 7 JUN 2000 234-351-002 PAGE 1 of 6 EQUIP ATTACHED PROCESSOR SYSTEM (APS) AMA PARTITIONS...
Page 372 [3] At APS MCRT terminal, enter [4] Does printout [6] Are more SET:AMA;CONFIG;a: indicate partition PART b,EQUIP! partitions to Page 3 was successfully be equipped a = IC, OC, DF or DM equipped [FIG. 1] b = Partition number to be equipped (0-23) [5] Contact next [7] Repeat higher technical...
Page 373 [8] Were any IC partitions Page 4 equipped using this procedure [9] At APS MCRT terminal, [10] Was enter [12] At APS MCRT COPY FILESYS FILE COPY:FILESYS:FILE, terminal, enter COMPLETED message SRC "/amafiles/config.ic", OP:AMA;CONFIG:IC! received DEST "/amabfiles/config.ic"! [11] Contact next [14] Contact next higher technical higher technical...
Page 374 [15] Were any OC partitions Page 5 equipped using this procedure [16] At APS MCRT terminal, [17] Was enter [19] At APS MCRT COPY FILESYS FILE COPY:FILESYS:FILE, terminal, enter COMPLETED message SRC "/amafiles/config.oc", OP:AMA;CONFIG:OC! received DEST "/amabfiles/config.oc"! [18] Contact next [21] Contact next higher technical higher technical...
Page 375 [22] Were any DF partitions Page 6 equipped using this procedure [23] At APS MCRT terminal, [24] Was enter [26] At APS MCRT COPY FILESYS FILE COPY:FILESYS:FILE, terminal, enter COMPLETED message SRC "/amafiles/config.df", OP:AMA;CONFIG:DF! received DEST "/amabfiles/config.df"! [25] Contact next higher technical [27] Does printout support group and...
Page 376 [29] Were any DM partitions equipped using this procedure [30] At APS MCRT terminal, [31] Was enter [33] At APS MCRT COPY FILESYS FILE COPY:FILESYS:FILE, terminal, enter COMPLETED message SRC "/amafiles/config.dm", OP:AMA;CONFIG:DM! received DEST "/amabfiles/config.dm"! [32] Contact next higher technical [34] Does printout support group and show all equipped...
Page 377 [1] At APS MCRT terminal, enter OP:AMA;CONTROLFILE! [3] Does control file data need to be set up [2] Using printout, determine if control file data needs to be set up Page 2 Issue 7 JUN 2000 234-351-002 PAGE 1 of 5 SET UP ATTACHED PROCESSOR SYSTEM (APS) AMA CONTROL FILE DATA...
Page 378 [4] Does IC stream control Page 5 file data need to be set up [5] Is AMA [6] At APS MCRT data processed terminal, enter Page 3 via AMA messages 3 and 4 teleprocessing [TABLE A] [7] At APS MCRT terminal, enter TABLE A message 1...
Page 379 [10] See NOTE 1. At APS MCRT terminal, enter SET:AMA;CONTROL;IC:DF a! a = Deferred format feature switch setting (ON or OFF) [13] Contact next higher technical [12] Was printout system group and received indicating inform personnel changed parameters [11] See NOTE 1. At APS MCRT terminal, of actions performed [FIG.
Page 380 REPT AMA CONTROL FILE AUDIT FOR a STREAM OFFICE ID b DAYS UNTIL EXPIRATION c PROCESS START TIME d PROCESS STOP TIME e DEFAULT MT FOR AUTO TAPE START f AMA OPTION IS g DATA TRANSFER h MANUALLY INHIBITED AMAT PASSWORD i HOC PASSWORD j BACKUP HOC PASSWORD k PASSWORD FROM LAST SESSION x...
Page 381 [15] Is AMA [20] Was printout [14] Does OC [19] At APS MCRT data processed received indicating stream control terminal, enter via AMA changed parameters file data need messages 3 and 4 teleprocessing [FIG. 1] to be set up [TABLE B] [17] Is [16] At APS MCRT [21] Contact next...
Page 383 [2] Was APS [1] At APS MCRT broot booted on root Page 3 terminal, enter or broot file OP:STATUS;FILESYS! system root [3] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/root"! [4] At APS MCRT terminal, enter AUD:FSBLK 1,INS "/dev/root"! [11] See NOTE 1. [5] At APS MCRT terminal, enter At APS MCRT [9] Do any...
Page 384 [12] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/bdb"! [13] At APS MCRT terminal, enter AUD:FSBLK 1,INS "/dev/bdb"! [14] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/betc"! [18] Do any errors [15] At APS MCRT terminal, enter exist AUD:FSBLK 1,INS "/dev/betc"! [16] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/broot"!
Page 385 [20] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/bdb"! [21] At APS MCRT terminal, enter AUD:FSBLK 1,INS "/dev/bdb"! [22] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/betc"! [28] See NOTE 2. [26] Do At APS MCRT any errors [23] At APS MCRT terminal, enter terminal, enter exist AUD:FSBLK 1,INS...
Page 386 [29] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/db"! [30] At APS MCRT terminal, enter AUD:FSBLK 1,INS "/dev/db"! [31] At APS MCRT terminal, enter AUD:FSLINK 1,INS "/dev/etc"! [35] Do any errors [32] At APS MCRT terminal, enter exist AUD:FSBLK 1,INS "/dev/etc"! [33] At APS MCRT terminal, enter AUD:FSLINK 1,INS...
Page 387 [3] Are lighted [2] On 1B [1] At 1B forces and/or Processor MCC Processor MCC requests under terminal EAI page, Page 2 terminal, depress FORCE FNCT or are any forces and/ EA DISP key to MANUAL PROG REQ or requests lighted obtain EAI page [6] On 1B Processor MCC terminal EAI page, enter...
Page 388 [12] At 1B Processor [13] On 1B MCC terminal, enter Processor MCC poke command 119 terminal MRA DDI KEY Page 3 to obtain ASSIGNMENTS page, MRA DDI KEY are any requests ASSIGNMENTS page lighted [17] On 1B Processor MCC terminal MRA DDI KEY ASSIGNMENTS page, enter [14] Should [14] Should...
Page 389 [19] On 1B Processor MCC terminal MRA DDI KEY ASSIGNMENTS page, enter poke command 499 (TOGGLE MRA/INHIBIT INTERRUPT OPTIONS) to obtain INHIBIT INTERRUPT DDI KEY ASSIGNMENTS page [23] On 1B Processor MCC terminal INHIBIT INTERRUPT [20] On 1B Processor DDI KEY ASSIGNMENTS page, [21] Should any [21] Should any MCC terminal INHIBIT...
Page 390: Status And Control
[27] On 1B Processor [25] At 1B [26] On 1B Processor MCC terminal MUP STATUS Processor MCC MCC terminal MUP AND CONTROL page, enter terminal, enter STATUS AND CONTROL [28] Repeat applicable poke commands poke command 106 page under UNIQUE from Step 25 to clear all lighted to obtain MUP...
Page 391 [1] At 1B Processor MCC terminal, depress EA DISP key to obtain EAI page Under PC SEQUENCER, [2] On 1B Processor MCC terminal EAI DISABLE AUTO PC text page, enter poke command 70 lights BLACK on PURPLE (DIS AUTO PC) to select function [3] On 1B Processor MCC terminal EAI page, enter poke command 99 (CLEAR ALL REQUESTS)
Page 392 [9] After 10 seconds, [11] Identify next on 1B Processor MCC valid override terminal EAI page under configuration , is EMER CFG [TABLE A] and text lighted BLACK on repeat from Step 4 PURPLE (See NOTE 1) [10] At 1B Processor MTC terminal, ensure that REPT:TROUBLE-EMERGENCY MODE ENTERED:MIN PROCESSOR...
Page 393 TABLE A 1B PROCESSOR MANUAL CONFIGURATIONS AND ASSOCIATED POKE COMMANDS OVERRIDE CONTROL SELECTIONS MANUAL SEQUENCE PSB0 PSB1 CSB0 CSB1 IFB0 IFB1 AUB0 AUB1 STATE Issue 7 JUN 2000 234-351-002 ENTER 1B PROCESSOR EMERGENCY MODE (MIN CONFIGURATION) BY PAGE 3 of 3 FORCING AN OVERRIDE CONFIGURATION...
Page 395 [1] At APS MCRT [9] Copy APS terminal, [8] At APS MCRT [2] Are terminal, enter enter OP:OOS! and any units root to broot ALW:DMQ;SRC ADP! obtain printout of or broot to out-of-service out-of-service root [DLP-558] units [3] At 1B APS MCRT terminal, enter RST: a b! a = Unit type...
Page 397 [1] See NOTE 1. At 1B Processor MCC terminal, clear all forces and/or requests [DLP-559] [3] Are any units Page 2 out-of-service [2] At 1B Processor MTC terminal, enter ! and obtain OP:OOSUNITS printout of all out-of-service units [4] At 1B Processor MTC terminal, enter RST:a b! a = Unit type...
Page 398 [9] At 1B Processor [12] Restore MTC terminal, [10] Are any additional enter OP:SDC! and any units conditions as obtain printout of service identified per service degraded degraded local procedure units [11] Contact next higher support group and inform personnel of actions performed and results obtained Issue 7...
Page 399 [6] Enter message [6] Enter message [1] At APS MCRT SW:DLN,LN:aa b,LNxx yy! terminal enter 1107 terminal enter 1107 (aa = Group number of DLN [2] Select [3] Is [3] Is [5] Is DLN [5] Is DLN in command mode to in command mode to b = Member number of DLN first DLN...
Page 401 [4] At identified power than 1B Processor switch, rotate ROS/OFF Cabinet switch clockwise to ROS position 1B Processor/ 3B APS Cabinet Page 3 Issue 7 JUN 2000 234-351-002 PAGE 1 of 4 POWER DOWN 4ESS SWITCH/1B PROCESSOR UNIT...
Page 402 PWR OFF lamp lighted lamp lighted switch lamp lighted [6] Contact next higher support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000 234-351-002 PAGE 2 of 4 POWER DOWN 4ESS SWITCH/1B PROCESSOR UNIT...
Page 403 ROS/NORM switch right to position [13] At circuit pack containing power switch, depress switch [14] At circuit pack containing power switch, is LED lighted Issue 7 JUN 2000 234-351-002 PAGE 3 of 4 POWER DOWN 4ESS SWITCH/1B PROCESSOR UNIT...
Page 404 BUS 1 24-096 KLW27 CS 22 KLW01 24-136 BUFFER BUFFER CS 18 KLW01 24-144 3B21D PROCESSOR UNIT DFC 0 58-178 DFC 1 28-178 UN580B UN580B Issue 7 JUN 2000 234-351-002 PAGE 4 of 4 POWER DOWN 4ESS SWITCH/1B PROCESSOR UNIT...
Page 405 There may also be cases when a "known" unit is left in a powered down state Issue 7 JUN 2000 234-351-002 PAGE 1 of 4 POWER UP 4ESS SWITCH/1B PROCESSOR UNIT...
Page 406 PWR OFF lamp switch counterclockwise go off to normal position [6] Contact next higher support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000 234-351-002 PAGE 2 of 4 POWER UP 4ESS SWITCH/1B PROCESSOR UNIT...
Page 407 ON switch [12] At circuit pack containing power switch, move ROS/NORM switch left to NORM position (continue thru any other powered off unit) Issue 7 JUN 2000 234-351-002 PAGE 3 of 4 POWER UP 4ESS SWITCH/1B PROCESSOR UNIT...
Page 408 BUS 1 24-096 KLW27 CS 22 24-136 KLW01 BUFFER BUFFER CS 18 24-144 KLW01 3B21D PROCESSOR UNIT DFC 0 DFC 1 58-178 28-178 UN580B UN580B Issue 7 JUN 2000 234-351-002 PAGE 4 of 4 POWER UP 4ESS SWITCH/1B PROCESSOR UNIT...
Page 409 [1] At APS MCRT terminal, enter EXC:ENVIR:UPROC,FN "/tools/bootaud", ARGS (" sa ","xxx ") in message mode to switch FULL CONFIG boot image with one saved after last retrofit xxx = SID parameter supplied by support group [4] Contact next higher [3] Does APS respond with support group and EXC ENVIR UPROC...
Page 410 [9] See NOTE 1. Are failing APS PRMs being received Page 3 continuously [FIG. 1] [10] Are APS PRMs being received where the "BOOT STEP " counts up and then starts over [FIG. 1] [11] Allow sufficient time (5 minutes) for APS to recover PRM SUCCESSFUL (E) OR FAILING (F) INDICATOR...
Page 411 [12] At APS MCRT terminal, depress EA DISP key to obtain EAI page [13] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select minimum configuration [16] See NOTE 2. Are failing APS PRMs being received Page 4 [14] On APS MCRT terminal EAI page, continuously...
Page 412 [19] See NOTE 3. On APS MCRT EAI page, identify active file system (root or broot) [22] On APS MCRT [20] Is APS terminal EAI page, active file broot enter poke command system root 31 in command mode or broot to clear broot root [21] On APS MCRT...
Page 413 [23] At APS MCRT terminal, depress EA DISP key to obtain EAI page [24] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select minimum configuration [27] See NOTE 4. [29] Recover attached Are failing APS processor system (APS) PRMs being received by performing APS...
Page 414 [30] At APS MCRT terminal, enter EXC:ENVIR:UPROC,FN "/tools/bootaud", ARGS ("se2"," ") in message mode to switch FULL CONFIG ECD with one saved most recently xxx = SID parameter supplied by support group [32] Does APS respond with EXC ENVIR UPROC /tools/bootaud COMPLETED Page 7...
Page 415 [34] At APS MCRT terminal, depress EA DISP key to obtain EAI page [35] On APS MCRT terminal EAI page, enter poke command 33 in command mode to select full configuration [38] See NOTE 5. Are failing APS PRMs being received Page 8 [36] On APS MCRT terminal EAI page, continuously...
Page 416 [41] At APS MCRT terminal, depress EA DISP key to obtain EAI page [42] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select minimum configuration [45] See NOTE 6. Are failing APS PRMs being received [43] On APS MCRT terminal EAI page, Page 9 continuously...
Page 417 [48] See NOTE 7. On APS MCRT EAI page, identify active file system (root or broot) [51] On APS MCRT [49] Is APS terminal EAI page, broot active file enter poke command system root 31 in command mode or broot to clear broot root [50] On APS MCRT...
Page 418 [52] At APS MCRT terminal, depress EA DISP key to obtain EAI page [53] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select minimum configuration [56] See NOTE 8. [58] Recover attached Are failing APS processor system (APS) PRMs being received by performing APS...
Page 419 [59] At APS MCRT terminal, enter EXC:ENVIR:UPROC,FN "/tools/bootaud", ARGS ("se1"," xxx )! " in message mode to switch FULL CONFIG ECD with one saved most recently xxx = SID parameter supplied by support group [61] Does APS respond with EXC ENVIR UPROC /tools/bootaud COMPLETED Page 12...
Page 420 [63] At APS MCRT terminal, depress EA DISP key to obtain EAI page [64] On APS MCRT terminal EAI page, enter poke command 33 in command mode to select full configuration [67] See NOTE 9. Are failing APS PRMs being received Page 13 [65] On APS MCRT terminal EAI page, continuously...
Page 421 [70] At APS MCRT terminal, depress EA DISP key to obtain EAI page [71] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select minimum configuration [74] See NOTE 10. Are failing APS PRMs being received Page 14 [72] On APS MCRT terminal EAI page, continuously...
Page 422 [77] See NOTE 11. On APS MCRT EAI page, identify active file system (root or broot) [80] On APS MCRT [78] Is APS terminal EAI page, broot active file enter poke command system root 31 in command mode or broot to select root root [79] On APS MCRT...
Page 423 [81] At APS MCRT terminal, depress EA DISP key to obtain EAI page [82] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select minimum configuration [85] See NOTE 12. [87] Recover attached Are failing APS processor system (APS) PRMs being received by performing APS...
Page 424 [88] At APS MCRT terminal, enter EXC:ENVIR:UPROC,FN "/tools/bootaud", ARGS ("se0"," xxx )! " in message mode to switch FULL CONFIG ECD with one saved most recently xxx = SID parameter supplied by support group [90] Does APS respond with EXC ENVIR UPROC /tools/bootaud COMPLETED Page 17...
Page 425 [92] At APS MCRT terminal, depress EA DISP key to obtain EAI page [93] On APS MCRT terminal EAI page, enter poke command 32 in command mode to select full configuration [96] See NOTE 13. [100] Perform 4ESS Are failing APS switch emergency PRMs being received recovery trouble...
Page 426 [101] See NOTE 14. [102] Perform Has sanity been 4ESS Switch restored to entire emergency recovery system (1B Processor, trouble isolation/ APS, CNI ring, 4ESS recovery procedure Switch peripheral, [TAP-111] etc.) NOTE 14 [103] Contact support group System has and determine safe time...
Page 427: Current Level
See NOTE 1. On APS MCRT terminal Is DFC depress [3] Go to status page NORMAL display key and enter displayed on APS Step 5 poke command MCRT terminal Contact next Is DFC higher technical status page support group and support group and CURRENT LEVEL inform personnel of...
Page 429 [2] At APS MCRT See NOTE 1. terminal, enter command Ensure DFC0, DFC1, Ensure DFC0, DFC1, to restore DFCs 602,x MHD0, and MHD1 MHD0, and MHD1 to service are powered up are powered up (x=0 or 1;DFC out of service) [4] Correct [4] Correct [3] Did...
Page 430 [9] Exchange identities of primary disk (MHD0 or MHD1) and software disk (MHD14 or [8] Power down MHD15). both MHD0 and (If SMD, change MHD0 ID-plug to 7 MHD14 (or MHD1 change MHD14 ID-plug to 0) and MHD15) (If SCSI, change MHD1 ID-plug to 3 change MHD15 ID-plug to 0) [10] Power up [10] Power up...
Page 431 [15] Obtain most [13] Do both MHDs recent set of verify successfully backup tapes [16] Determine [14] Repair or first MHD to be replace to loaded using loaded using correct and repeat criteria criteria from Step 13 in Table A [17] Use DIOP-LDFT TABLE A...
Page 432 [18] Was other [18] Was other [20] Obtain next [20] Obtain next system MHD system MHD most recent set most recent set rendered rendered of backup tapes of backup tapes unbootable unbootable [19] Perform [19] Perform [21] Use DIOP-LDFT Recovery Recovery Decision procedures to reload Procedures...
Page 433 [2] On 120 page enter command 620,x y z Where: x = 0 or 1 MHD to be loaded [1] See CAUTION. y = for 3B21D tape, /dev/mt00 (tape drive 0) Mount RT0 or /dev/mt10 (tape drive 1) backup tape on = for 3B20D tape, /dev/mt08 (tape drive 0) tape drive or /dev/mt18 (tape drive 1)
Page 434 [5] See NOTE. Was [6] Seek PRM_x E15x 54xx xxxx xxxx xx xx xx technical LOAD MHD x FROM TD y IN PROGRESS) assistance output [7] Was PRM_x E15x 58xx xxxx xxxx xx xx xx LOAD MHD x FROM TD y MOUNT NEXT TAPE) [13] Has DB [9] Have all RT0 output...
Page 435 [1] On EAI page, enter poke command [3] Enter poke [2] Was selected per TABLE A to MHD recovered command select MHD that was from backup loaded from tape to be used for the recovery attempt [4] Decide when to perform actual boot per the following criteria: *Are unessential application functions (AMA) still working and unessential to customer...
Page 437: Boot Procedures
[1] See NOTE 1. [2] Was MHD system [2] Was MHD system [3] Enter poke [3] Enter poke Ensure that booted or restored booted or restored command 52 to command 52 to MIN-CONGIF from backup tapes, boot 3B20D/ indicator is cleared backup software or 3B21D computer on EAI page...
Page 438 [9] If selected MHD [11] Have both was not restored MHDs been tried from backup tapes, Page 3 using forced CUs was backup root tried [12] Choose and [10] Enter poke boot other MHD. command 30 Enter poke to force backup command per root and repeat Table A...
Page 439 [17] Seek technical At this assistance. [16] Has other point all possible CU been tried combinations have been tried have been tried without without success [18] On EAI Page, enter poke command to force other CU. (If CU0 active, enter 11. If CU1 active, enter 10) [19] Repeat from...
Page 441 [1] See NOTE 1. Ensure power is ON to both CCs and both MUPs [2] Perform a NOTE 1 quick sanity The 1B Processor is in deadstart if the check on the following conditions occur: CC [DLP-573] A. Critical alarms have gone off and field support contacted B.
Page 442 [5] Force MUP with ESC CTRL X and ESC CTRL R. See NOTE 2. [12] On 1B Processor MCC Terminal EAI Page, enter poke [7] On 1B Processor [6] On 1B Processor command 84 to select MCC terminal EAI MCC terminal EAI modified recovery Page, enter poke page [FIG.
Page 443 PC STATE INDICATOR TOWNSTBLSUB 4E<NN>4B.nn PORT PAGE EAI mm/dd/yy hh:mm:ss CRITICAL MAJOR MINOR PGM CTRL PWR/BLDG SYS NORM IF/AU CMD: PC PROGRESSION 99 - CLEAR ALL REQUESTS 100 - PAGE INDEX CMPL INDICATOR -FORCE FNCT- - MANUAL PROG REQ- -PC SEQUENCER- -REPEATED PC- -PC ATTEMPT- 01 - HARD A 02 - SOFT A...
Page 444 [16] Configuration [15] See pumped the 80K. Not NOTE 3. a deadstart Is system situation. Go to pumping Step 80, Page 22 [17] On 1B Processor MCC terminal EAI [18] This is Page, is ADDR field in a deadstart Page 5 EAI FAIL DATA DISPLAY situation section stuck at...
Page 445 [24] Set up CC for deadstart (flip [25] Is DIS [23] Force a MCC [ interference AUTO PC on MUP up with switches to left EAI page BLACK ESC CTRL X and <UTIL_ALW in on PURPLE MCC [ ESC CTRL R back of CC [FIG.
Page 446 [30] On 1B Processor [29] On 1990 Page, MCC terminal EAI enter poke command page, enter poke 701 to suspend 1B command 01 (HARD A) Processor to clear force in effect On 1B Processor MCC terminal EAI Page [FIG. 1]: [31] Enter poke command 10 ( CC 0) to select function...
Page 447 [43] On 1B Processor [40] On 1B Processor [42] On 1B Processor MCC terminal EAI MCC terminal EAI Page MCC terminal EAI Page Page [FIG.1], enter [FIG. 1], is [FIG. 1], is DIS AUTO PC OVERRIDE poke command text lighted BLACK on text lighted IN EFFECT to clear force in...
Page 448 [50] Is 1B Processor [49] On 1990 Page, suspended and MUP enter poke command duplex failed (responds 701 again (in case Page 9 quickly with entries 1B Processor did 70, 20, 106 on EAI not stop on this page) [51] Reset MUP with ESC CTRL R and enter poke command 118 (1B PROCESSOR...
Page 449 [54] On 1B [55] Enter poke [56] Enter poke Processor MCC command 613 to command 701 to terminal EAI Page, allow MUP suspend 1B enter poke command interference Processor 70 (DIS AUTO PC) [57] On 1990 page, enter poke command 730 to perform MUP tests [58] Does response indicate...
Page 450 [61] On 1990 [60] Enter poke [62] Does Page, enter poke command 613 to response indicate command 731 to Page 11 allow MUP MUP/MUI tests perform MUP/MUI interference passed ATP tests [63] On 1B Processor EAI Page, enter poke command 01 (HARD A) to force other CC with Full Configuration (10 or 11)
Page 451 [68] Enter poke [67] Enter poke command 740 to command 613 to [72] See NOTE 4. Does response run automatic allow MUP indicate Tests SUCCEED EAI displays tests of 1B interference 37700000+DEAD_GOTO_PCRVFAIL Processor Page 13 This address is in PCRVBOOT. (In 5rof bootrom KLW384 Series 17, address is 37763730.) [See TABLE A] [69] Enter poke...
Page 452 TABLE A MCC PAGE 1990 DISPLAY-INTERPRETING RESULTS WITH AC1BS2 ???????? critical CMD: 740! OK -CC CONTROL- - CC REG ACCESS - 701 - SUSPEND 720,X - READ CC REG - DIAG MUP 702 - RUN 721,X,Y - WRITE CC REG - DIAG MUP MUI INT 703 - SINGLE STEP 722,X,Y - WRITE BOL BOR...
Page 453 [74] See NOTE 5. [76] On 1B Processor [75] Does system MCC terminal EAI Replace routine response indicate that failed or Page, enter poke Tests SUCCEED, EAI displays Page 22 select unit mate command 01 to get 37700000+DEAD_GOTO_PCRVFAIL with Hard A ( 01). 1B Processor up [See FIG.
Page 454 bootrom deadstart table has: 0067000 -002- 04 DEAD_SETUP_MUP_LOOPBACK EQU * -002- 05 # ’SETUPS- NONE’ -002- 06 # ’RESULT IS F = - G’ 067000 3330001077763527R 52530L -002- 07 DEAD_MUP_LOOPBACK # TEST 0 0067002 -002- 08 DEAD_NEXT_MUP_LOOPBACK EQU * 0067002 -002- 12 DEAD_SETUP_DEAD_SETUP EQU * -002- 13 # ’SETUPS- NONE’...
Page 455 TABLE C DEADSTART TEST SETUPS SETUP TEST REQUIREMENT EXPLANATION DEAD_SETUP must be run (once) before individual tests are run. Test 1 - SETUP No setup Input:BS1=pest_inh Sets up configuration word from Hard A forces on MCC via AC1MC0 into AC1BS5 and shadow Z register Test 2 - PS_CONF Setup:1 CONFIG_PSB_PS configures the Program Store Bus and the...
Page 456 TABLE C DEADSTART TEST SETUPS (CONTD) SETUP TEST REQUIREMENT EXPLANATION Setup:1 CONFIG_CSB configures the Call Store Bus. Same routine is used Test 9 - CSB_CONF No inputs in normal Boot. Does not check for failure Test 10 - IFB_CONF Setup:1 and 2 CONFIG_IFB configures the Interface Bus.
Page 457 TABLE C DEADSTART TEST SETUPS (CONTD) SETUP TEST REQUIREMENT EXPLANATION Test 18 - UTILHAND Setup:1,2,10 and 16 INFORM_UTL informs the Maintenance and Utility Processor Unit No inputs (UTIL SR) that a UTIL SR is starting. Same routine is used in UTIL SR. This routine only runs if UTIL SR is selected on the MCC EAI Page.
Page 458 TABLE C DEADSTART TEST SETUPS (CONTD) SETUP TEST REQUIREMENT EXPLANATION Test 24 - IFFRTIBC Setup:1,2,10 and 11 IFFRTIBC tests the IFB Controller in the CC. This is a deadstart No inputs only routine. Fails lock up in a tight deadstart loop, with started and finished bits both set in AC1BS2 AUFRTIFC tests AUI Client Access via CC MMIO Operations.
Page 459 TABLE C DEADSTART TEST SETUPS (CONTD) SETUP TEST REQUIREMENT EXPLANATION Test 32 - TUC_WRIT Setup:1,2,10,11 and 19 TUC_WRITE_REG reads registers in the DUC/TUC. This is a deadstart No inputs (NORM SR) only routine. It is only run when NORM SR is set up on the MCC EAI page.
Page 460 TABLE C DEADSTART TEST SETUPS (CONTD) SETUP TEST REQUIREMENT EXPLANATION Intended for use when memory is available. CANNOT work on Test 41 - SETBREAK Setup:2 Bootrom. Only the last breakpoint set can be cleared by Input: BS0 = Breakpoint CLEAR_BREAKPOINT. Multiple single address breakpoints can be set Address up with this test failure (This is usually used for Returns on J, J+1 and J+2.) The success leg is saved for last, so the breakpoint...
Page 461 TABLE C DEADSTART TEST SETUPS (CONTD) SETUP TEST REQUIREMENT EXPLANATION This is an infinite monitor loop (IEP or IEPIFB). It is Test 47 - IEPIFB Setup:1 recommended to rerun Test 1 after this test to assure the Input: BS3=FRL(command configuration setup in AC1BS5 is correct. IEPIFB is a program to BS4=Y(device) test IFB clients and memory.
Page 462 [81] Perform 1B Processor [80] Does 1B Processor recovery recover procedures [TAP-113] [83] Ensure Maintenance [84] Is 1B Channel Printer is on, [85] Power up [82] Power off Processor rolling then power up one CC MUP and repeat both MUPs and in PCs or does (with all other units from Step 67,...
Page 463 [2] Set up CC for deadstart (flip [3] Is [1] Force a interference switches MUP up with DIS AUTO PC to left <UTIL_ALW in on EAI Page ESC CTRL X back of CC) BLACK on PURPLE and ESC CTRL R [4] On 1B Processor MCC terminal EAI Page, enter poke...
Page 464 [8] Depress EA DISP [7] On 1990 Page, key to get EAI Display enter poke page, then enter command poke command suspend 1B (HARD A) to clear Processor force in effect On 1B Processor MCC terminal EAI Page [FIG. 1]: [9] Enter poke command 10 (CC 0) to select function...
Page 465 [21] On 1B Processor [18] On 1B Processor [20] On 1B Processor MCC terminal EAI MCC terminal EAI Page MCC terminal EAI Page Page [FIG.1], enter [FIG. 1, is DIS AUTO PC [FIG. 1], is OVERRIDE poke command text lighted BLACK on text lighted IN EFFECT to clear force...
Page 466 On 1B Processor MCC terminal EAI Page [FIG. 1]: [27] Enter poke command 11 (CC 1) to select function [28] Enter poke command 21 (PS 1) to select function [29] Enter poke command 23 (PSB 1) to select function [34] Enter poke [35] Allow command [30] Enter poke command...
Page 467 [36] On 1B Processor MCC terminal EAI Page, PC PROGRESSION Page 6 text lighted CMPL BLACK on GREEN NOTE 1 System has recovered if following [37] On 1B Processor [38] Allow conditions have been MCC terminal sufficient met: EAI Page, is time (3 minutes) A.
Page 468 [41] On 1990 [46] Go to EAI Page, enter poke [45] Does Page and enter command again CAR display a Hard A ( (In case 1B 7777700000 twice and repeat Processor did not from Step 41. or 7777700002 stop on this CC) [47] See NOTE 2.
Page 469 [54] Continue to single- step ( ), the 1B [56] This CC Processor, until CAR is bad. [52] Is CAR [55] Does 77777702034 Switch CCs and display BOL contain (a maximum of 6 repeat from 7777702024 67017775 entries of 703) Step 52 [53] Enter 703 [57] Single-step...
Page 471 [2] Has a [1] Is BWM BWM already being installed Page 2 been installed in AT&T office for this update Page 2 [4] Does [3] At 3B MCRT, printout show enter message all equipped Page 2 OP:NODES;SIN! SIN nodes UNEQUIP [FIG.
Page 472 TABLE A [7] Is BWM to [6] At 3B MCRT, be installed, MESSAGE enter message listed in Page 3 INPUT MESSAGES NUMBER 1 in TABLE A AAAxx-xxxx format OP:STATUS:LISTDIR,FN"/etc/bwm"! COPY:BWM xxxxxx! xxxxxx = BWM, CFT, or DMT number to be installed [8] At 3B MCRT, enter message 2 in TABLE A...
Page 473 [10] At 3B MCRT, press NORM DISP ( PF2) key and enter 1960 in command mode to obtain display page 1960 [11] Enter 9000, AAAxx-xxxx in command mode to select BWM AAAxx-xxxx = BWM number to be installed Page 4 [12] At 3B MCRT, enter 9260,SCANS in command mode to obtain printout of SCANS file...
Page 474 [14] If back out is necessary during this procedure, contact next higher technical support group IMMEDIATELY [17] Was [15] At 3B MCRT, enter 9010 in command UPD VFY COMPLETED mode to verify BWM Page 5 message displayed in RESPONSE field [16] Wait for COMPLETED message to be [18] Determine received in RESPONSE field...
Page 475 [19] At 3B MCRT, enter 9310 in command mode to execute APPLY section [21] Was COMPLETED: APPLY SECTION Page 6 message displayed in RESPONSE field [22] Determine [20] Wait for COMPLETED message to be cause and received in RESPONSE field resolve;...
Page 476 [23] At 3B MCRT, enter 9320 in command mode to execute SOAK section [25] See NOTE 1. Was message displayed in Page 8 RESPONSE field per TABLE C [24] Wait for printout per FIG. 2, Page 7 to be received before continuing [26] Determine cause and...
Page 477 -----------------UPD PRINT SOAK TIMER IN PROGRESS---------------- BWM NAME = AAAxx-xxxx REMAINING SOAK PERIOD = (HH:MM) CURRENT SOAK TIMER START (DD MM dd hh:mm:ss YY) (DD MM dd hh:mm:ss YY) DURATION (HH:MM) PREVIOUS SOAK TIMER START (DD MM dd hh:mm:ss YY) (DD MM dd hh:mm:ss YY) DURATION (HH:MM)
Page 478 [27] Obtain printout saved in Step 12, Page 3 and determine if special instructions are required to be performed before executing OFC section [28] At 3B MCRT, enter 9330 in [30] See NOTE 2. Was command mode to execute COMPLETED: OFFICIAL OFC section SECTION message...
Page 479 [32] Obtain printout saved in Step 12, Page 3 [33] Are more and determine if special BWMs to be instructions are required entered at to be performed at this this time time [34] Repeat from Step 6, Page 2 Issue 7 JUN 2000 234-351-002 PAGE 9 of 9...
Page 481 [1] Select available APS tape unit [2] If tape is mounted on select type unit, demount tape [DLP-528] [8] Determine [5] Is cause and LIB TAPE WRITTEN [3] Mount blank or erasable tape with resolve; repeat message received write enable ring installed (1600 BPI) or from Step 4 in FIG.
Page 483 [1] Select available APS tape unit [2] If tape is mounted on select type unit, demount tape [DLP-528] [8] Determine [5] Is cause and TPM TAPE WRITTEN [3] Mount blank or erasable tape with resolve; repeat message write enable ring installed (1600 BPI) or from Step 4 received protect tab in up (unlocked) position (4mm)
Page 485 [1] Select available APS tape unit [2] If tape is mounted on selected tape unit, demount tape [DLP-528] [3] Mount blank or erasable tape with Page 2 write enable ring installed (1600 BPI) or protect tab in up (locked) position (4mm) on tape unit [DLP-527] [4] At APS MCRT terminal, enter COPY:APPTAPE:ERAP,MT a!
Page 486 [7] Were output [5] Was output [9] Determine messages 2 through message 1 cause and 4 (as required) resolve; repeat received received [TABLE A] from Step 4 [TABLE A] [8] Demount tape [6] Determine on tape unit cause and [DLP-528] and resolve;...
Page 487 [1] If tape is mounted on available tape unit, demount tape [DLP-528] [4] Was output [5] Determine [2] Mount ERAP tape on available message 1 cause and APS tape unit [DLP-527] received resolve; repeat [TABLE A] from Step 3 [3] See NOTE 1. At APS MCRT terminal, enter LOAD:APPTAPE:ERAP,MT a = Tape unit member number...
Page 489 [1] If tape is mounted on idle tape unit, demount tape [DLP-528] [2] Mount TLP tape on tape unit [DLP-527] [3] At 3B MCRT, enter message [7] At 3B MCRT, note VER;UPDATE:TAPE,MT a [6] Was error printout, a = Tape unit number TLP JOB COMPLETED determine cause message received...
Page 491 [1] At 1B MTC terminal, enter message OP:LIBSTAT,FS! [3] Are required library packages listed [2] Using printout, determine if required library packages are listed [4] Is proper library tape Page 2 for office generic available [5] Contact next higher support to obtain proper library tape Issue 7...
Page 492 [8] Insert new library tape with 3B21D write-protect tab in [6] 3B APS down (locked) position type is into available 3B DAT unit [DLP-527] 3B20D [7] Mount new library tape without a write-enable ring Page 3 attached on available 3B computer tape unit [DLP-527] Issue 7 JUN 2000...
Page 493 [11] In [10] In TAPE ORIGINAL GENERIC [9] At 3B MCRT, TYPE field field in TAPE enter message in TAPE HEADER Page 4 HEADER printout, is per TABLE A printout, is LIB proper office generic listed [FIG. 1] listed [FIG. 1] TABLE A [12] Demount tape [DLP-528]...
Page 494 [13] At 1B MTC terminal, enter message AUD:LIBSYS,TD a ;UCL! a = Tape unit number that library tape is mounted AUD:LIBSYS,TD a;UCL IN PROGRESS [15] Was 0 ERROR(S) IN CS2FS MAP DETECTED AUD:LIBSYS,TD a; UCL COMPLETED AUD:LIBSYS,TD a;UCL IN PROGRESS message received 0 ERROR(S) IN ID2SEG MAP DETECTED [FIG.
Page 495 [1] Mount original library tape on available APS tape unit [DLP-527] [2] At 1B MTC terminal, enter message LOAD:LIBSYS,FS;TAPE:TD a ! [4] Were (a = tape unit with library tape INIT:LIBSYS COMPLETED mounted) LOAD:LIBSYS COMPLETED messages received [3] Wait for INIT:LIBSYS COMPLETED and LOAD:LIBSYS COMPLETED messages to be received [5] Determine...
Page 497 [1] Is TPM tape [3] At 3B MCRT, mounted on available enter message APS tape unit? per TABLE A [5] In [4] In TAPE ORIGINAL GENERIC [2] Mount TPM TYPE field field in TAPE HEADER tape on available Page 2 in TAPE HEADER printout, is proper APS tape...
Page 498 [7] At 1B MTC terminal, enter message AUD:TPM,TD a;UCL! a = Tape unit number where TPM tape is mounted AUD:TPM,TD a;UCL IN PROGRESS [9] Was 0 ERROR(S) IN CS2FS MAP DETECTED AUD:TPM,TD UCL COMPLETED AUD:TPM,TD a;UCL IN PROGRESS message received 0 ERROR(S) IN ID2SEG MAP DETECTED [FIG.
Page 499 [1] Is NWM tape [3] At 3B MCRT, mounted on available enter message APS tape unit? per TABLE A [5] In [4] In TAPE ORIGINAL GENERIC [2] Mount NWM TYPE field field in TAPE HEADER tape on available in TAPE HEADER Page 2 printout, is proper APS tape...
Page 500 [7] At 1B MTC terminal, enter message AUD:NWM,TD a;UCL! a = Tape unit number where NWM tape is mounted AUD:NWM,TD a;UCL IN PROGRESS [9] Was 0 ERROR(S) IN CS2FS MAP DETECTED AUD:NWM,TD a! UCL COMPLETED AUD:NWM,TD a;UCL IN PROGRESS message received 0 ERROR(S) IN ID2SEG MAP DETECTED [FIG.
Page 501 [1] See NOTE 1. Set 1B Processor MCC terminal, on top right hand side of screen, is proper time indicated [4] At 1B Processor MTC terminal, enter [2] Set 1B [3] Is SET:CAMATRFS a! Processor office CAMA to establish traffic clock equipped sampling rate...
Page 502 [8] Are any units listed [9] See NOTE 2. At 1B Processor MTC [10] Are all terminal, enter out-of-service message RST: a b! for units restored each out-of-service unit to service a = Unit type b = Unit member number Page 1, Step 7 [11] Proceed with this procedure...
Page 503 [18] Load and verify NWM tape using DLP-583 [19] Remove NWM tape from 3B APS tape unit using DLP-528 and store per local practice [20] Obtain latest backup 1600-BPI/4-mm traffic and plant measurement (TPM) tape. Verify write-enable ring is not installed for the 1600-BPI tape or the write-protect tab is in the down (locked) position for the 4-mm tape...
Page 504 [26] Load and verify LTS data using [DLP-554] [27] Remove LTS tape from 3B APS tape unit using DLP-528 and store per local practice [30] Is AUD NUM nn COMPLETED [28] At 1B Processor Page 5 0 ERROR DETECTED message MTC terminal, enter received for each message AUD:NUM (43,44,45,66,72)!
Page 505 System responds with OP:MSGRCD,FS COMPL or [32] At 1B Processor MTC NG (will be received if there terminal, enter are no messages to clear) OP:MSGRCD,FS! Page 6 [33] At 1B Processor MTC terminal, enter OP:SDC! Issue 7 JUN 2000 234-351-002 RESTORE 1B PROCESSOR CONDITIONS FOLLOWING SYSTEM PAGE 5 of 8 REINITIALIZATION (SR) USING TAPES...
Page 506 [37] Does system [36] At 1B [34] Does system respond with Processor MTC respond with printout Page 7 printout indicating terminal, enter of service degraded interrupts are OP:INHINT! units inhibited [35] Contact next higher technical support group and inform personnel of actions performed and results obtained Issue 7...
Page 507 [38] At 1B Processor MTC terminal, enter OP:PERIFINH! [39] Does system respond with printout Page 8 of inhibited peripheral units [40] Contact next higher technical support group and inform personnel of actions performed and results obtained Issue 7 JUN 2000 234-351-002 RESTORE 1B PROCESSOR CONDITIONS FOLLOWING SYSTEM PAGE 7 of 8...
Page 508 [41] Was 84 (MODIFY RECV) [43] Were any with 401,00 (DIRECT DATA units found to be INSERT -0) poke commands faulty during used when recovering recovery of system system [44] Repair any faulty [42] See NOTE 4. units using Reset PESTS appropriate frame/ cabinet trouble clearing documentation...
Page 509 [3] In [4] At 1B Processor [1] At ORIGINAL GENERIC [2] In TAPE TYPE MCT terminal, enter 3B MCRT, field in TAPE field in TAPE HEADER AUD:ODA,TD a;NCG! enter message HEADER printout, is printout, is proper a = tape unit number per TABLE A ODA listed [FIG.
Page 510 [8] At 1B Processor [6] See NOTE 1, MTC terminal, enter [7] Were any Page 3. Wait for STOP:AUD;ODA! errors AUD:ODA,TD a;NCG COMPLETED Response: encountered message AUD:ODA;TD a;NCG ABORTED message received [9] Attempt to verify validity of all mismatches (Mismatches may be due to valid RCs or absolute ODA overwrites, etc.)
Page 511 [13] At 1B [14] Wait for Processor MTC AUD:ODA,TD a;CORR COMPLETED terminal, enter message AUD:ODA,TD a;CORR! NOTE 1 SAST will time out 30 minutes after noncorrecting audit completes. As audit is being run, the following messages will be printed if no errors are encountered: AUD:ODA,TD a;NCG IN PROGRESS 0 ERROR(S) IN CS2FS MAP DETECTED...
Page 513 [4] At 1B Processor [3] In MTC terminal, enter [1] At ORIGINAL GENERIC [2] In TAPE TYPE AUD:GEN,TD a;NCG! 3B MCRT, field in TAPE field in TAPE HEADER a = tape unit number enter message HEADER printout, is printout, is proper where GEN tape per TABLE A GEN listed [FIG.
Page 514 [8] At 1B Processor [6] See NOTE 1, MTC terminal, enter [7] Were any Page 3. Wait for STOP:AUD;GEN! errors AUD:GEN,TD a;NCG COMPLETED Response: encountered message AUD:GEN;TD a;NCG ABORTED message received [9] Attempt to verify validity of all mismatches (Mismatches may be due to valid RCs or absolute GEN overwrites, etc.)
Page 515 [13] At 1B [14] Wait for Processor MTC AUD:GEN,TD a;CORR COMPLETED terminal, enter message AUD:GEN,TD a;CORR! NOTE 1 SAST will time out 30 minutes after noncorrecting audit completes. As audit is being run, the following messages will be printed if no errors are encountered: AUD:GEN,TD a;NCG IN PROGRESS 0 ERROR(S) IN CS2FS MAP DETECTED...
Page 517 3B21D Page 3 [1] Office 3B20D APS [2] Mount 2400 - foot tape on available tape drive (write enable ring attached) [DLP-527] 4AP15 or [7] At MCRT, [3] At MCRT, enter message [6] Is office Earlier enter Message 1 EXC:ENVIR:UPROC,FN"/tools/bootaud"! Generic per TABLE B [4] Wait for...
Page 518 Wait for COPY BKDISK DISMOUNT GENERIC TAPE AND MOUNT NEXT TAPE message [10] Demount tape [DLP-528], label rt0 1 tape per local practice [11] Mount 2400-foot tape on same tape [15] Demount tape drive (write - enable ring attached [14] Which message [DLP-528], label Message 1 [DLP-527]...
Page 519 [18] Insert blank or erasable 4-mm tape with write-protect tab is up (unlocked) position into available APS DAT unit [DLP-527] [19] At APS MCRT, enter message DUMP:FILE:ALL, FN"/etc/pdtspec"! to dump the /etc/pdtspec file [20] Wait for DUMP FILE ALL COMPLETED message and ensure that printout in TABLE D is received [21] At APS MCRT, enter message Page 4...
Page 520 [24] Insert blank or erasable 4-mm tape with write-protect tab in up (unlocked) position into same available APS DAT unit [DLP-527] [28] Demount tape [DLP-528], label [25] At APS MCRT, enter message [27] Which message Message 1 and put COPY:BKDISK;ACK:TPSIZE 90! is received per write-protect tab TABLE E...
Page 521 [1] See WARNING 1. [4] Is BWM to [3] At 3B MCRT, Is BWM being be installed, enter message installed as a part of listed in Page 2 1 in TABLE A 1B Big Gulp Office AAAxx-xxxx Update format [2] Discontinue [5] At 3B MCRT, use of this enter message...
Page 522 [7] At 3B MCRT, press NORM DISP ( PF2) key and enter 1960 in command mode to obtain display page 1960 [8] Enter 9000, AAAxx-xxxx in command mode to select BWM AAAxx-xxxx = BWM number to be installed Page 3 [9] At 3B MCRT, enter 9260,SCANS in command mode to obtain printout of SCANS file...
Page 523 [11] If back out is necessary during this procedure, contact next higher technical support group IMMEDIATELY [14] Was [12] At 3B MCRT, enter 9010 in command UPD VFY COMPLETED mode to verify BWM Page 4 message displayed in RESPONSE field [13] Wait for COMPLETED message to be [15] Determine received in RESPONSE field...
Page 524 [16] At 3B MCRT, enter 9310 in command mode to execute APPLY section [18] Was COMPLETED: APPLY SECTION Page 5 message displayed in RESPONSE field [19] Determine [17] Wait for COMPLETED message to be cause and received in RESPONSE field resolve;...
Page 525 [20] At 3B MCRT, enter 9320 in command mode to execute SOAK section [22] See NOTE 1. Was message displayed in Page 7 RESPONSE field per TABLE C [21] Wait for printout per FIG. 2, Page 6 to be received before continuing [23] Determine cause and...
Page 526 -----------------UPD PRINT SOAK TIMER IN PROGRESS---------------- BWM NAME = AAAxx-xxxx REMAINING SOAK PERIOD = (HH:MM) CURRENT SOAK TIMER START (DD MM dd hh:mm:ss YY) (DD MM dd hh:mm:ss YY) DURATION (HH:MM) PREVIOUS SOAK TIMER START (DD MM dd hh:mm:ss YY) (DD MM dd hh:mm:ss YY) DURATION (HH:MM)
Page 527 [24] Obtain printout saved in Step 9, Page 2 and determine if special instructions are required to be performed before executing OFC section [25] At 3B MCRT, enter 9330 in [27] See NOTE 2. Was command mode to execute COMPLETED: OFFICIAL OFC section SECTION message...
Page 528 [29] Obtain printout saved in Step 8, Page 2 [30] Are more and determine if special BWMs to be instructions are required entered at to be performed at this this time time [31] Repeat from Step 3, Page 1 Issue 7 JUN 2000 234-351-002 PAGE 8 of 8...
Page 529 1. Remove this procedure and Reproduce page each time a Big GULP TABLE A BWM is done Active Unit Poke Value CC 0 2. See Figure 1, Page 2 (For Reference Only). At 1B Processor CC 1 MCC Terminal, depress EAI page key to display EAI page PS 0 3.
Page 530 TOWNSTBLSUB 4E<NN>4B.nn PORT PAGE EAI mm/dd/yy hh:mm:ss CRITICAL MAJOR MINOR PGM CTRL PWR/BLDG SYS NORM IF/AU MISC MCC DPFL CMD: 99 - CLEAR ALL REQUESTS 100 - PAGE INDEX -FORCE FNCT- - MANUAL PROG REQ- -PC SEQUENCER- -REPEATED PC- -PC ATTEMPT- 01 - HARD A 02 - SOFT A 03,xx - SET PC STATE:...
Page 531 TOWNSTBLSUB 4E<NN>4B.nn PORT PAGE 118 mm/dd/yy hh:mm:ss CRITICAL MAJOR MINOR PGM CTRL PWR/BLDG SYS NORM IF/AU MISC MCC DPFL CMD: -1B PROCESSOR STATUS- -PROCESSOR- -BUSES- -IFB BOOT CLIENTS- -AUXILIARY- -CC- -UNITS- ARAR PFAMTHD CC 0 ACTIVE PSB 0 ACT MUP 0 ACT AUB 0 ACT CC 1 STOP PSB 1 STBY...
Page 532 TOWNSTBLSUB 4E<NN>4B.nn PORT PAGE 109 mm/dd/yy hh:mm:ss CRITICAL MAJOR MINOR PGM CTRL PWR/BLDG SYS NORM IF/AU MISC MCC DPFL CMD: - PROGRAM STORE STATUS AND CONTROL PAGE - -BUS STATUS- -STORE STATUS- MRSS -CC- PS00 ACT ARAR PS01 ACT PSB 0 ACT PS02 ACT PSB 1 STBY PS03 STBY M...
Page 533 [1] Select available APS tape unit [2] If tape is mounted on selected tape unit, demount tape [DLP-528] [3] Mount blank or erasable tape with Page 2 write enable ring installed (1600 BPI) or protect tab in up (locked) position (4mm) on tape unit [DLP-527] [4] At APS MCRT terminal, enter message per TABLE A...
Page 534 [7] Demount tape [5] Was output on tape unit message 1 [DLP-528] and received label per local [TABLE A] procedure [6] Determine cause and resolve; repeat from Step 4 TABLE B MESSAGE OUTPUT MESSAGES NUMBER EXC ENVIR UPROC /bin/dd STOPPED x+y record in x+y record out x+y = whole and partial number of input and output blocks...
Page 535 ITEM ISSUE ITEM ISSUE ITEM ISSUE ITEM ISSUE ITEM ISSUE ITEM ISSUE IXL-001 DLP-511 DLP-546 DLP-581 NTP-002 DLP-582 DLP-512 DLP-547 NTP-003 DLP-583 DLP-513 DLP-548 NTP-004 DLP-584 DLP-514 DLP-549 NTP-005 DLP-585 DLP-515 DLP-550 NTP-006 DLP-516 DLP-586 DLP-551 NTP-007 DLP-587 DLP-517 DLP-552 NTP-008 DLP-518 DLP-553...
Page 537 This book is called a Task Oriented Practice or "TOP." Non-Trouble Clearing It is a programmed document that gives step-by-step instructions to enable you to do a job (or task). If used Non-trouble clearing procedures are performed to accept a system after a system has been installed, turn up a correctly, a TOP can be a very useful aid when completing everyday tasks.
Page 538 FIND YOUR JOB IN THE LIST BELOW ......THEN GO TO Alert; External — Horn, Ringer, Etc. — Remove ....... . . NTP-028 Amplifiers;...
Page 539: Perform System Test
Look over the following example which shows a typical page in the " FOR DETAILS, GO TO " column. If, on the other hand, of NTP-016. Note that the items are numbered in the left you need additional details on how to do the task, "...
Page 540 look further for details, three other ways of " bypassing " operate the VTVM. Here again, if you already are provided in TOP to help you bypass information know how to operate the VTVM, perform the procedure you already know (see Figure 2): without looking up any further information.
Page 541 SUMMARY Summary Statement — If you can do Mount empty take-up reel and proper file reel with write the procedure after reading, go enable ring (if required). Release brakes. Thread tape and ahead and do it. wind onto take-up reel. Advance tape until it stops at beginning of tape marker.
Page 542 This idea can be carried further. In some cases, a A TOP shows hard-wired and plug-in units on Isolation decision block may have more than one abnormal output. Diagrams (ISD) in the following manner: This means that you should try more than one solution to the problem.
Page 543 FIND YOUR JOB IN THE LIST BELOW ..THEN GO TO Alert; External — Horn, Ringer, Etc. — Remove ... NTP-028 FROM CHANN FCU INHIBIT...
Page 544 TABLE A IMPORTANT TOP SYMBOLS AND DEFINITIONS SYMBOL DEFINITION The AND operation symbol is used where the successful completion of a group of instructions accomplishes a meaningful result that can be defined. Result statement The symbol indicates that each input instruction must be performed in the order given to accomplish the output (result statement).
