Page 1 Task Oriented Practice (TOP) 4ESS SWITCH Time Slot Interchange (TSI) Frame Trouble-Clearing TOP Switching Network START Do you understand Go to 893 Go to 001 how to use TOP TOP Comments Hot Line: Issue 6 DEC 1997 Monday through Friday 8:00 a.m.
Page 2 Lucent Technologies Business Units or Divisions without the expressed written consent of the Customer Training and Information Products Organization. For permission to reproduce or distribute, please contact:...
Page 3 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Acceptance ........... NTP-002 Circuit Filter Capacitor —...
Page 4 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO Phase 20 Failure — Controller 0 ........TAD-136 Phase 20 Failure —...
Page 5 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO TTY Printout — DGN:TSI a,[(CONTR b |IPUB c)] PH d STF ANALY:TLPFILE:TSI a,[(CONTR b |IPUB c)] SUMMARY DATA QUEUE ACCESS DENIED:DATA NOT RETAINED: CODE 0004 .
Page 6 FIND YOUR JOB IN THE LIST BELOW ....THEN GO TO DGN:TSI a,[(CONTR b |IPUB c)] PH d STF ANALY:TLPFILE:TSI a,[(CONTR b |IPUB c)] TLP TLP TAPE ACQUISITION ERROR MOUNT TAPE WITH FILE ID=f .
Page 7 No acceptance test procedures are required for this frame. The readiness of this frame to become a part of the working system was established by the successful completion of Installation Handbook test procedures Issue 6 DEC 1997 234-151-012 PAGE 1 of 1 ACCEPTANCE...
Page 8 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO If Circuit Pack To Be Replaced Is an FC463 or FC464 Type, 1. Identify Units That Get Clock Signals From TSI Controller Containing FC463 DLP-511 or FC464 Pack 2.
Page 9 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Ensure OS Lamp Goes Out After Diagnostic Is Completed — — If Units Were Removed From Service, Restore by Typing: A.
Page 10 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Identify Power Controls Required To Remove Power From Nonbulk Converter — A. SD-4A011-01 Frame DLP-516 B. SD-4A011-02 Frame DLP-517 C.
Page 11 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At Frame Power Control Switch in Bay Containing Converter, Rotate ROS/OFF Switch — to ROS Position Ensure OS Lamp Lighted on Power Control Switch —...
Page 12 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Request Printout of Equipment Status by Typing: — OP:OOSUNITS! Restore Any Affected Out-of-Service Unit to Service by Typing: —...
Page 13 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Remove TSI Member and Controller From Service by Typing: RMV:TSI a,CONTR b! a = Member Number, b = Controller Number —...
Page 14 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO NOTE: This procedure provides details for replacing one splitting transformer by pesting the TSI controller and associated port (EST — if provided, DIF, DT, or VIF) before replacing the bad transformer.
Page 15 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Remove TSI Controller 1 Pest (ALW:TSI a,CONTR 1,SPEC!) — Remove TSI Controller 0 Pest (ALW:TSI a,CONTR 0,SPEC!) — Remove DIF/DT/VIF Pest by Typing A, B, or C: —...
Page 16 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO NOTE: Degrow the seven DIU, DTU or VIU ports or the DS-120 connector board by doing items 1 through 22.
Page 17 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Remove Degrowth DIU/DTU/VIU From Service by Typing A, B, or C: A. (RMV:DIF a,DIU b!) DLP-538 B. (RMV:DT a,DTU b!) DLP-538 C.
Page 18 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO Recent Change Submember Equipage From OPER to SGRO Using RC Form 701 (Degrow) (TSI Port DLP-533 Associated With Degrowth DIU/DTU/VIU) Enter Message To Apply TSI Port Pest Control to Degrowth Associated TSI Port ( INH:TSI a,SPC b, PORT c!) —...
Page 19 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO If Nailup Connections Were Deleted in Item 11, Request Appropriate Administration Center To — Connect Each Nailup Using RC Form 205 Repeat Procedure From Item 24a Until All Active Degrown Ports on the DS-120 Connector Board Are Grown and Restored If Any Service Circuit Trunks Are Required, Request Appropriate Administration Center To Add...
Page 20 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At Frame Power Control Switch in Bay Containing Converter, Rotate ROS/OFF Switch — to ROS Position Ensure OS Lamp Lighted on Power Control Switch —...
Page 21 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At Frame Power Control Switch in Bay Containing Converter, Rotate ROS/OFF Switch — to ROS Position Ensure OS Lamp Lighted on Power Control Switch —...
Page 22 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At Frame Power Control Switch in Bay Containing Converter, Rotate ROS/OFF Switch — to ROS Position Ensure OS Lamp Lighted on Power Control Switch —...
Page 23 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At Frame Power Control Switch in Bay Containing Converter, Rotate ROS/OFF Switch — to ROS Position Ensure OS Lamp Lighted on Power Control Switch —...
Page 24 DO THE ITEMS BELOW IN THE ORDER LISTED ..FOR DETAILS, GO TO At Frame Power Control Switch in Bay Containing Converter, Rotate ROS/OFF Switch — to ROS Position Ensure OS Lamp Lighted on Power Control Switch —...
Page 25: Maintenance Philosophy
GENERAL the REPT:PA printout which would identify the frame with power fault. The precise structure of the message is given The maintenance philosophy contained in this volume is in the input/output (I/O) message manuals. The symptoms based upon the design of equipment (hardware), diagnostic described in the IXL reflect the assumptions above, and software and test equipment employed.
Page 26 on three levels. Level one [TAP-101] addresses what to do access TOP documents at a point in trouble-clearing where with a software-generated TLP SUSPECTED FAULTY EQUIPMENT analyzation is completed (faulty component determined) and only repair or replacement required. In many instances, list and provides a step-by-step procedure for replacing circuit packs one at a time, and analyzing the results.
Page 27 SUMMARY trouble was cleared. After all listed packs located in Replace all listed packs located in failed TSI frame half failed TSI frame half have been replaced, any listed packs beginning with first pack listed. After each pack in TMS frame helper unit are replaced. If trouble is not replacement, check diagnostic results to determine if cleared, perform raw data analysis using TAP-102 [1] Type...
Page 28 TABLE B [8] See NOTE 1 and TABLE B. Identify FRAME PROCEDURE power switch and/or SD-4A011-01 DLP-519 fuse associated SD-4A011-02 DLP-520 with pack to be replaced SD-4A083-01 DLP-521 [9] Replace [10] Is ATP/CATP Page 4, pack diagnostic Step 27 [DLP-500] result Page 3 NOTE 1...
Page 29 [12] Have all [15] Were any [16] See TABLE C, [11] Replace [14] Are any listed packs controllers Page 4. Restore original in failed TSI listed packs removed from controllers to pack in TMS frame half been service service replaced [13] See NOTE 2.
Page 30 [25] Identify [24] Have all next pack on [23] Replace [22] Is listed packs in list in TMS and diagnostic original TMS frame been repeat from pack results replaced Page 3, Step 20 ATP/CATP TABLE C MESSAGE [26] Go to MESSAGE NUMBER Page 3,...
Page 31 SUMMARY failing test. Use PK information and knowledge of first Read first failing phase prologue. Determine if subroutines failing test function to identify and replace any suspect were used and identify their location and function. Locate packs other than those on TLP list previously replaced. first failing test and determine test function.
Page 32: Supplementary Data
NUMBER OF SUPPLEMENTARY NUMBER OF MISMATCHES DATA WORDS TO FOLLOW BEFORE PRINT BUFFER OVERFLOWED NUMBER OF DOLOOP DATA FAILING WORDS TO FOLLOW TEST SKIPPED CODE PHASE NUMBER OF SUBROUTINE DGN: TSI 22, CONTR 0 PH 8 STF-BOF (16,00000000 000000000) MSG IP DATA WORDS TO FOLLOW TEST MISMATCH...
Page 33 [5] Locate and determine function NOTES First of subroutines [DLP-501] 1. Phase PIDENT may Failing consist of more Test [6] Locate fourth raw data word following than one strip Located mismatch data [FIG. 1, Page 2] with this address appearing in more than one strip.
Page 34 [16] Using summary data [19] See NOTE 3. Using printout and Issue 2 or PR prologue data, knowledge later Test Access PK of failing test function, [17] Was a Document, attempt to failing bits indicated by TLP list of identify an SD lead in mismatch data, lead packs printed path of failing bit...
Page 35 [23] Identify [26] Remove from units that get [22] Is an [24] Is DIF service units clock signals from FC463 or FC464 or PUC identified in Step pack to be TSI controller identified 23 using messages containing pack to be replaced in TABLE B, Page 7 replaced [DLP-511]...
Page 36 [34] Was a TMS [36] Were [29] Is frame removed ATP/CATP any units diagnostic from service to removed from result replace packs service [30] Replace original [35] Type [37] See TABLE D, pack RST:TMSP a, CONTR b! Page 7. Restore a = TMS frame member units to service number...
Page 37 TABLE B MESSAGE VARIABLE RMV:VIF a, CONTR b! a = Member number RMV:DT a, CONTR b! b = Controller number RMV:EST a, CONTR b! TABLE C FRAME PROCEDURES SD-4A011-01 DLP-519 SD-4A011-02 DLP-520 SD-4A083-01 DLP-521 TABLE D MESSAGE VARIABLE RST:EST a, CONTR b! a = Member number RST:DT a, CONTR b! b = Controller number...
Page 38 POWER FILTER J1A053AG-1 +140V FILTER FROM DCPD FS 17 SWITCHING AND +24V FILTER POWER CONVERTER UNITS PERMUTING UNITS SD-4A084-01 FUSE PANEL 0AOA OR 1A0A (3) +140V TO 3V DC TO DC 0AOB OR 1A0B +3V BUS BULK CONVERTERS +3V FILTER AND 245A OVERCURRENT 0AOC OR 1A0C...
Page 39 ISD-103 OS lamp [1] Rotate ROS/OFF switch lights to ROS position [2] Depress ROS/OFF switch to OFF position [3] If blown fuse is listed in TABLE B, Page 2 on associated bulk converter, operate converter switch to OFF position. If not listed, continue to next step [8] Rotate [7] Does...
Page 40 TABLE B Page 3 BULK BULK FUSE FUSE CONVERTERS CONVERTERS Page 5 BAY 0 BAY 1 FED AT LOCATION FED AT LOCATION [10] Is blown 0-14-12 1-14-12 0A0A 1A0A fuse listed Page 6 0-14-36 1-14-36 0A0B 1A0B in table 0-14-60 1-14-60 0A0C 1A0C...
Page 41 [12] Unseat converters fed by blown fuse [TABLE A, Page 2] [16] Investigate [15] Does fuse leads to [13] Replace fuses power alarm converter for sound short (SD-4A083-01) [14] Depress and hold ON pushbutton for 2 seconds [17] Depress ROS/OFF switch to OFF position [21] Does power alarm...
Page 42 [25] Depress ROS/OFF switch [26] Replace converter just seated [30] Investigate [29] Does near converter power alarm connector for sound short (SD-4A083-01) [27] Replace blown fuse [28] Depress and hold ON pushbutton [31] Rotate for 2 seconds ROS/OFF switch to normal position Issue 6 DEC 1997...
Page 43 [32] Replace bulk [35] Rotate converter with [33] Does ROS/OFF switch LED not lighted power alarm to normal and replace blown sound position fuse [DLP-509] [34] Investigate for shorts at converter mounting or +3 volt bus (SD-4A083-01) Issue 6 DEC 1997 234-151-012 PAGE 5 of 8 CLEAR BLOWN FUSE, SD-4A083-01 FRAME...
Page 44 [36] Replace a pack fed by blown fuse [TABLE C, Page 2] [40] Rotate [39] Depress [38] Does ROS/OFF switch and hold ON power alarm to normal pushbutton sound position for 2 seconds [37] Replace blown fuse [41] Have all [43] Investigate packs fed by cut-through,...
Page 45 [44] Identify units [46] Remove that get clock signals [45] Is PUC identified unit from FC464 pack fed or DIF from service by blown fuse identified [DLP-527] [DLP-511] [47] Remove from service units TABLE E identified in MESSAGE VARIABLE Step 44 using RMV:DT a, CONTR b! a = Member number TABLE E messages...
Page 46 [51] Does TABLE F fuse blow MESSAGE VARIABLE again RST:DT a, CONTR b! a = Member number [54] Depress and hold RST:EST a, CONTR b! of frame ON pushbutton RST:VIF a, CONTR b! removed for 2 seconds RST:DIF a, CONTR b! b = Member number of controller [52] Restore...
Page 47 SD-4A011-01 ISD-109 TABLE A SD-4A011-02 ISD-117 [6] Rotate [1] Is any PWR SD-4A083-01 ISD-103 ROS/OFF switch OFF lamp lighted FRAME PROCEDURE to ROS position at TSI frame SD-4A011-01 DLP-516 SD-4A011-02 DLP-517 SD-4A083-01 DLP-518 [2] Determine [7] Identify which power switch [8] Replace [11] Rotate fuses to be...
Page 48 SUSPECTED [7] Clear diagnostic [1] Type FAULTY failure by replacing [2] Is code [5] See NOTE 1. message 3 EQUIPMENT packs on equipment 0002 still Is printed listed in list using TAP-101 obtained response TABLE A NULL PACK TEST GENERATED [3] Type messages listed in...
Page 49 [8] Type INIT:TLP! SUSPECTED [13] Clear FAULTY [9] Type [11] See NOTE 1, diagnostic failure EQUIPMENT ALW:TLP:TSI! Page 1. Is by replacing packs printed response on equipment list using TAP-101 NULL PACK TEST GENERATED [10] Type message 3 listed in TABLE A, Page 1 [12] Clear diagnostic failure by analyzing raw...
Page 50 [2] Type SUSPECTED [4] Clear DGN:TSI a, CONTR b|IPUB c :TLP! FAULTY diagnostic failure [3] See NOTE 1. [1] Type EQUIPMENT by replacing Is printed ALW:TLP:TSI! a = Failing TSI member number packs on equipment response b = Failing controller list using member number TAP-101...
Page 51 ISD-103 [1] At power switch with PWR OFF lamp lighted, rotate to ROS/OFF switch [4] Rotate [3] Does ROS/OFF switch power alarm to normal [2] Replace bulk converter sound position located in same bay as power switch [DLP-509] [5] Replace original bulk converter [DLP-509]...
Page 52 [8] Depress ROS/OFF switch [9] Remove fuse associated with FC554 pack with lighted LED [TABLE A] [15] Investigate [13] Does for short on power alarm +3 volt bulk [10] Replace FC554 pack sound converter bus (SD-4A083-01) [11] Replace fuse [12] Depress and hold ON pushbutton for 2 seconds [14] Rotate ROS/OFF switch...
Page 53 140V A FROM DPCD A DISTRIBUTION +3 VOLT OSTART CONVERTER +24V AF CIRCUIT ISD-111 B DISTRIBUTION +9 VOLT OSTART CONVERTER +24V AF CIRCUIT ISD-112 C DISTRIBUTION +24V +3 VOLT OSTART +24V AF DISTRIBUTION CONVERTER CIRCUIT +24V AF CIRCUIT ISD-110 ISD-113 D DISTRIBUTION +3 VOLT OSTART...
Page 54 TIMING AND CONTROL CIRCUIT FS 11 SD-4A023-01 P/O FUSE PANEL 12 VOLT REFERENCE PU BUS POWER AND ALARMS NETWORK CIRCUIT +12REF 0AB OR 1AB DRIVERS AND RECEIVERS FS3 SD-4A011-01 FB152 0LB OR 1LB BUS POWER SWITCH IPUB0 OR IPUB1 CONVERTER KS20738,L4 +3VC PUB 0BA OR 1BA...
Page 55 TACC0A OR TACC1A +3V CONVERTER C000 OR C100 SD-4A023-01 SPC01A OR SPC11A +3V CONVERTER C001 OR C101 SD-4A024-01 P/0 FUSE PANEL +140VA FROM +3V CONVERTER C005 OR C105 A0A OR A1A DCPD 0START B0A OR B1A +3V CONVERTER C008 OR C108 FROM ISD-110 +24VAF...
Page 56 +24VAF P/0 FUSE PANEL FROM 0START ISD-110 D0A OR D1A +140VA FROM DCPD SPC00A OR SPC10A D0B OR D1B SD-4A024-01 P/0 FUSE PANEL D0C OR D1C A0B OR A1B +9V CONVERTER C016 OR C116 B0B OR B1B D0D OR D1D D0E OR D1E C0B OR C1B +9V CONVERTER...
Page 57 +3V CONVERTER C032 OR C132 +3V CONVERTER C033 OR C133 SPC00A OR SPC10A SD-4A024-01 +3V CONVERTER C036 OR C136 P/0 FUSE PANEL +140VA FROM A0C OR A1C DCPD +3V CONVERTER C037 OR C137 0START B0C OR B1C FROM ISD-110 +3V CONVERTER C041 OR C141 +24VAF C0C OR C1C SPC01A OR SPC11A...
Page 58 +3V CONVERTER C048 OR C148 P/O FUSE PANEL +3V CONVERTER C052 OR C152 +140V A FROM A0D OR A1D DCPD SPC01A OR SPC11A SD-4A024-01 OSTART B0D OR B1D +3V CONVERTER C056 OR C156 FROM ISD-110 +24V AF C0D OR C1D +3V CONVERTER C060 OR C160 TACC0A OR TACC1A -3V CONVERTER C070 OR C170...
Page 59 +3V CONVERTER C080 OR C180 P/O FUSE PANEL SPC01A OR SPC11A +140V A FROM SD-4A024-01 A0E OR A1E DCPD +3V CONVERTER C084 OR C184 OSTART B0E OR B1E +3V CONVERTER C090 OR C190 FROM ISD-110 PUBIC0A OR PUBIC1A +24V AF SD-4A022-01 C0E OR C1E +3V CONVERTER C092 OR C192...
Page 60 OS lamp ISD-109 [1] Rotate ROS/OFF switch lights to ROS position [6] Rotate [2] Depress ROS/OFF switch [5] Does ROS/OFF switch power alarm to normal sound position [3] Replace blown fuse [4] Depress and hold ON pushbutton for 2 seconds [7] Depress ROS/OFF switch...
Page 61 [11] Identify fuses associated with converters fed by blown fuse [DLP-516] [12] Remove fuses [17] Investigate cut-through, [16] Does [13] Unseat converters fed by bent backplane power alarm blown fuse pins, etc, for sound short [14] Replace fuses (SD-4A011-01) [15] Depress and hold ON pushbutton for 2 seconds [18] Depress ROS/OFF switch [19] Remove fuses associated with converters...
Page 62 [27] Depress ROS/OFF switch [28] Identify fuses associated with converter fed by blown fuse [DLP-516] [29] Remove fuses [35] Investigate wiring to [34] Does [30] Replace converter just converter power alarm seated connector for sound short (SD-4A011-01) [31] Reseat any converters left unseated [36] Rotate [32] Replace fuses...
Page 63 [37] Replace FB152 pack fed by blown fuse [TABLE B] [41] Rotate [40] Does ROS/OFF switch power alarm [38] Replace blown fuse to normal sound position [39] Depress and hold ON pushbutton for 2 seconds [42] Depress ROS/OFF switch TABLE B FUSE FB152 [43] Investigate...
Page 64 +140V A FROM DPCD A THROUGH E OSTART CONVERTER +24V AF CIRCUIT ISD-119 F THROUGH L OSTART CONVERTER CIRCUIT +24V AF ISD-120 +24V +24V AF DISTRIBUTION CIRCUIT ISD-118 M THROUGH P OSTART CONVERTER CIRCUIT +24V AF ISD-121 Q THROUGH W OSTART CONVERTER +24V AF...
Page 65 P/O FUSE PANEL 0AB OR 1BA TACC CKT TACC0A OR POWER N0A OR N1A TACC1A 0RED SD-4A023-02 DIODE N0B OR N1B CIRCUIT POWER SWITCH AND N0C OR N1C ALARM CIRCUIT OSTART ISD-119 0ST OR 1ST OSTART ISD-120 SD-4A011-02 OSTART FS 2 ISD-121 0LA OR 1LA OSTART...
Page 66 +3V CONVERTER C00A OR C10A P/O FUSE PANEL +140V A SPC01A OR SPC11A FROM A0A OR A1A +3V CONVERTER C00B OR C10B SPC CIRCUIT DCPD SD-4A024-02 OSTART B0A OR B1A +3V CONVERTER C00C OR C10C FROM ISD-118 +24V AF C0A OR C1A +3V CONVERTER C00D OR C10D SPC00A OR SPC10A SPC CIRCUIT...
Page 67 +3V CONVERTER C00F OR C10F SPC01A OR SPC11A SPC CIRCUIT SD-4A024-02 +3V CONVERTER C00G OR C10G P/0 FUSE PANEL +140VA FROM A0B OR A1B DCPD TACC0A +3V CONVERTER C00H OR C10H SD-4A023-02 TAC CIRCUIT 0START B0B OR B1B FROM ISD-118 +3V CONVERTER C00J OR C10J +24VAF C0B OR C1B...
Page 68 PBIC0A +3V CONVERTER C00M OR C10M SD-4A022-02 PBI CIRCUIT P/O FUSE PANEL +140V A FROM A0C OR A1C +3V CONVERTER C00N OR C10N DCPD SPC01A OR SPC11A OSTART SPC CIRCUIT B0C OR B1C SD-4A024-02 FROM ISD-118 +24V AF +3V CONVERTER C000 OR C100 C0C OR C1C SPC00A OR SPC10A +3V CONVERTER C00P OR C10P...
Page 69 +3V CONVERTER C00Q OR C10Q SPC01A OR SPC11A SPC CIRCUIT SD-4A024-02 +3V CONVERTER C00R OR C10R P/0 FUSE PANEL +140VA FROM A0D OR A1D DCPD +3V CONVERTER C00S OR C10S 0START B0D OR B1D FROM SPC00A OR SPC10A ISD-118 +3V CONVERTER C00T OR C10T SPC CIRCUIT SD-4A024-02 +24VAF...
Page 70 ISD-117 OS lamp [1] Rotate ROS/OFF switch lights to ROS position [6] Rotate [2] Depress ROS/OFF switch [5] Does ROS/OFF switch power alarm to normal sound position [3] Replace blown fuse [4] Depress and hold ON pushbutton for 2 seconds [7] Depress ROS/OFF switch...
Page 71 TABLE A FUSE CONVERTERS FUSE CONVERTERS BAY 0 FED AT LOC BAY 1 FED AT LOC 0-80-55 1-80-55 ISD-118 ISD-118 0-76-11 1-76-11 0-76-15 1-76-15 0-17-02 1-17-02 0-17-08 1-17-08 0-17-14 ISD-119 1-17-14 ISD-119 TABLE B 0-17-20 1-17-20 0-17-26 1-17-26 FUSE CIRCUIT PACK FUSE CIRCUIT PACK BAY 0...
Page 72 [10] Remove fuses associated with converters fed by blown fuse [TABLE A, Page 2] [11] Unseat converters fed by blown [15] Investigate fuse [TABLE A, Page 2] cut-through, [14] Does bent backplane power alarm pins, etc, for sound [12] Replace fuses short (SD-4A011-02) [13] Depress and hold ON pushbutton...
Page 73 [25] Depress ROS/OFF switch [26] Remove fuses associated with converter fed by blown fuse [TABLE A, Page 2] [27] Replace converter just [32] Investigate seated near converter [31] Does connector for power alarm [28] Reseat any converters sound short (SD-4A011-02) left unseated [29] Replace fuses [33] Rotate...
Page 74 [34] Replace FB152 pack fed by blown fuse [TABLE B, Page 2] [37] Depress [38] Rotate [36] Does and hold ON ROS/OFF switch power alarm pushbutton to normal sound for 2 seconds position [35] Replace blown fuse [39] Investigate cut-through, bent backplane pins, etc, for short (SD-4A011-02)
Page 75 [40] Identify units [42] Remove that get clock [41] Is PUC identified unit signals from FC463 or DIF from service pack fed by blown identified [DLP-527] fuse [DLP-511] TABLE D [43] Remove from service the units MESSAGE VARIABLE identified in RMV:VIF a, CONTR b! a = Member number Step 40 using...
Page 76 [47] Did fuse blow again [50] Depress and hold ON pushbutton for 2 seconds TABLE E MESSAGE VARIABLE [48] Restore RST:EST a, CONTR b! a = Member number [51] Rotate ROS/OFF units that b = Controller were removed switch to normal RST:DT a, CONTR b! number position (OS lamp...
Page 77 SD-4A011-01 ISD-109 [1] Rotate and depress SD-4A011-02 ISD-117 ROS/OFF switch [2] See TABLE A. Remove fuse powering FB152 pack [7] Rotate [6] Is LED ROS/OFF switch [3] Replace FB152 pack lighted on to normal FB152 pack position [4] Replace fuse [5] Depress and hold ON pushbutton for 2 seconds [8] Investigate...
Page 78 SUSPECT [2] Is TSI FAULTY [7] Clear diagnostic [1] Type [5] See NOTE 1. failing diagnostic EQUIPMENT failure by replacing OP:TLPQUEUE;ALL! Is printed in UTYMN column packs on equipment response of response list using TAP-101 NULL PACK TEST GENERATED [6] Clear diagnostic [3] Type failure by analyzing CLR:TLPQUEUE;TLPFILE a!
Page 79: Power Switch
OFF SW ON SW LAMP TEST SW OFF SW PWR OFF OFF & ON SW OFF NORM (ROS) OFF KEY ON SW (ROS) ON SW Issue 6 DEC 1997 234-151-012 PAGE 1 of 1 POWER SWITCH...
Page 80 [1] Type DGN:TSI a, CONTR b| IPUB c :TLP! [3] Clear diagnostic [2] Did TLP failure by analyzing a = Failing TSI member number abort message raw data and replacing b = Failing controller reoccur any suspect packs member number using TAP-102 c = Failing IPUB member number SUSPECTED...
Page 81 [1] TLP tape being used is not correct issue for this generic. Obtain correct TLP tape [2] Demount tape SUSPECTED [DLP-512] FAULTY [7] Clear diagnostic [5] See NOTE 1. EQUIPMENT failure by replacing Is printed packs on equipment [3] Mount correct tape response list using TAP-101 [DLP-506]...
Page 82 [1] TLP tape being used does not contain TSI data file. Obtain correct TLP tape [2] Demount tape SUSPECT [DLP-512] FAULTY [7] Clear diagnostic [5] See NOTE 1. EQUIPMENT failure by replacing Is printed packs on equipment response [3] Mount correct tape list using TAP-101 [DLP-506] NULL PACK TEST GENERATED...
Page 83 SUSPECTED FAULTY [5] Clear diagnostic [1] Mount [2] Type [3] See NOTE 1. EQUIPMENT failure by replacing TLP tape in TABLE A Is printed packs on equipment [DLP-506] messages response list using TAP-101 NULL PACK TEST GENERATED [4] Clear diagnostic failure by analyzing raw data and replacing any suspect...
Page 84 [1] At power switch with PWR OFF ISD-103 lamp lighted, rotate and [3] Was a depress ROS/OFF switch FC464 pack Page 2 identified [2] Use SD tables to identify packs getting power monitored by FC512 with lighted LED [TABLE A] [4] Identify units that get clock signals from...
Page 85 [8] Determine if any identified packs are fused [DLP-529] [9] Remove any fuses if required [10] Unseat packs [13] Does identified Page 3 power alarm sound [11] Replace fuses [14] Depress ROS/OFF [12] Depress and hold switch ON pushbutton for 2 seconds [15] Remove fuse feeding FC512 pack with...
Page 86 [21] Depress ROS/OFF switch [22] Remove any fuses for a pack to be seated [DLP-529] [26] Does [32] Have all Page 4, [23] Seat a pack power alarm packs been Step 42 sound seated [24] Replace fuses [25] Depress and hold ON pushbutton for 2 seconds [33] Repeat from Step 21...
Page 87 [34] Does [36] Have all power alarm packs been TABLE D sound seated MESSAGE VARIABLE RST:DT a, CONTR b! a = Member number of unit removed RST:VIF a, CONTR b! b = Member number RST:EST a, CONTR b! of controller [35] Investigate RST:DIF a, CONTR b! for short near...
Page 88 external sweep trigger to terminal indicated in TABLE B. SUMMARY Using raw data analysis information obtained in TAP-102, Type in TABLE A messages. Verify that first failing test SDs/CDs, and circuit pack SDs signal, trace path of failing raw data is printed twice to verify correct loop address. Resend last TABLE A message with RPT option deleted for bits to isolate and clear fault.
Page 89 [8] Set up infinite loop by typing [11] Connect external [9] Was [10] Set up scope EX:TSI a:PH d,ADR e-f! sweep trigger to SYNC option for signal tracing See TABLE A, Page 1 terminals indicated used [TABLE A, using external for a, d, e, and f.
Page 90 [14] See NOTE 2. Using raw data analysis information, [15] Is fault TSI SDs/CDs, PK failing Page 4 located and test data, and circuit cleared pack SDs, signal trace path of failing bits to isolate and clear fault [16] Any [17] See CAUTION 1.
Page 91 [19] Type OP:MACLI,CLASS MTCE! [20] Type [23] Set up loop STOP:MACLI,CLASS MTCE,SUBCLASS a! again using TABLE A, [22] Is a = Subclass assigned faulty TSI (see Page 1 messages previous message response) diagnostic (delete RTP) or result DLP-508 if required, and repeat from [21] See TABLE A, Page 1 for a, b, and c.
Page 92 TABLE A [1] Test [2] Did power alarm CIRCUIT NONBULK BULK FRAME system PACKS CONVERTERS CONVERTERS circuits respond ATP [DLP-526] SD-4A011-01 DLP-533 DLP-516 SD-4A011-02 DLP-533 DLP-517 SD-4A083-01 DLP-518 FR switch DLP-529 [10] At TTY, type [3] At TTY, type DGN:TSI a, CONTR b|IPUB c :TLP! DGN:TSI a, CONTR b|IPUB c ;RPT 15:PH1!
Page 93 TABLE B PROCEDURE PROCEDURE NUMBER Replace Bulk Converter NTP-005 (245A With 245A) Replace Bulk Converter NTP-009 (245C With 245C) Replace Bulk Converter (245A With 245C) NTP-010 Standard SPC (Two 245A Converters in Bay) Replace Bulk Converter (245A With 245C) NTP-011 Wideband SPC (Three 245A Converters in Bay) Replace Bulk Converter...
Page 94 NOTES [2] See TABLE A, 1. It is assumed Controller [1] See Notes 1 and remove fuse that an attempt and 2. Is TSI associated with has been made Controller 0 or 1 unit at the +140V powered down Distribution Frame to Controller restore power...
Page 95 [7] Insert [8] Remove [6] Does light [9] Insert new fuse ITE 4715 glow brightly new Pilot into Capacitor and then fuse Main fuse Charging Tool extinguish [11] See CAUTION. At the top rear Page 3 [10] Remove of TSI frame, remove ITE 4715 power connector Capacitor...
Page 96 [16] Switch affected NOTES converter to 3. If you have OFF position reached this point without replacing any frame components in the TSI bay, there are [17] At affected [19] Switch [18] Do LEDs TSI frame, install damaged filter affected on equipped appropriate fuses circuit parts in...
Page 97 errors occur. It also tests to ensure that the TSI is able to SUMMARY Phase 20/23 checks the ability of the TSI to operate and receive data from either of the duplicated TMS halves. This verify autonomous switching from active to standby when example depicts a breakdown of data for a typical failure.
Page 98 TABLE A — NORMAL OPCODES PUWB OPCODE ORDER 35-24 0000 NO-OP order. If this code is detected, the order sequencer returns to its idle state with no all-seems-well pulse generated and no error source register strobe 0400 Connect receiver side of the switching and permuting circuit denoted by bits 0 and 1 of enable address bus (E0 &...
Page 99 TABLE A — NORMAL OPCODES (Contd) PUWB OPCODE ORDER 35-24 1100 Disconnect a path in transmit side of the switching and permuting circuit, denoted by E0 & E1. The transmit TSM and busy/idle map memory are then read; then, if no errors are detected, transmit TSM is written with disconnect code;...
Page 100 TABLE B — MAINTENANCE OPCODES PUWB OPCODE ORDER 35-24 4440 Read a Buffer Memory "A" output data register in two switching and permuting circuits 4500 Read a maintenance Buffer Memory "A" output data register in two switching and permuting circuits 4600 Read a Buffer Memory "B"...
Page 101 TABLE B — MAINTENANCE OPCODES (Contd) PUWB OPCODE ORDER 35-24 7140 Advance autonomous timing circuits 16 twisted ring counter phases with time slot counter advances inhibited 7400/ 170/ Read status register in Controller 0/1 7440 7500/ 172/ Read error source register in Controller 0/1. Bit 29 of the write bus indicates the controller.
Page 102 TABLE C — ADDRESS ASSIGNMENTS FOR OPCODE 0120 OCTAL READ POINT ADDRESS Reply Register Originating serial switch Terminating serial switch Serial recorrelator Serial decorrelator 23-26 Unassigned Time slot counter, Phases A and T Time slot counter, Phases R and D Unassigned Twisted ring counter Unassigned...
Page 103 TABLE D — ADDRESS ASSIGNMENTS FOR OPCODE 0130 OCTAL WRITE POINT ADDRESS PU error source register word 0 PU error source register word 1 Clear growth flip-flops, SPC 0 or SPC 2 Write growth flip/flops, SPC 0 or SPC 2 Clear growth flip/flops, SPC 1 or SPC 3 Write growth flip/flops, SPC 1 or SPC 3 Exercise primary error source register 0...
Page 104 TABLE E — ADDRESS ASSIGNMENTS FOR OPCODE 0172/173 OCTAL ERROR SOURCE REGISTER READ POINT ADDRESS All seems well Autonomous Primary Autonomous secondary sense and lock Auxiliary Receive TSM Parity Transmit TSM Parity Buffer Memory "A" Parity Buffer Memory "B" Parity Unassigned Loading one Detector (TRPF) PCM Transmitter Seems Well...
Page 105 is in Controller 0. In this example, an FA 1781 was found to SUMMARY To determine which controller is failing, Bit 5 of the 7500 be defective. The circuit was located in Controller 0, SPC 2 OPCODE must be observed. Bit 5 is a 0, indicating the failure Level 6 at Location 06-05.
Page 106 failure, the signal on output leads to Controller 0 were SUMMARY To determine failing controller, observe Bit 5 of 7554 OPCODE. opposite in polarity but distorted. The output of PCM In example, Bit 5 is set indicating failure is in Controller transformer is inputted to FB 221B circuit (SD-4A084, FS 11 1.
Page 107 transformer. Example shows failure occurred in TSI 40, SPC 0 SUMMARY This example is to determine if both controllers are failing Level 3. The failure was caused by a cold solder joint on TSI Phase 20 with same test and mismatches. Identical failures in PCM-splitting transformer for SPC 0 Level 3 at 124-09.
Page 108 suspected for this type of failure. The failure in this SUMMARY Both controllers failing differently indicates that failure example was caused by a defective transmit A-link coaxial might not be confined to the TSI under test. Also, the TSI/ cable from TSI 24 — Controller 0, Switch 0, Level 6. TMS A-link coaxial cable and the associated TMS hardware are The Network must be simplexed and the TSI-B Phase 20 must be...
Page 109 helper units, and are assumed to be non-faulty. If faults SUMMARY Phase 23 checks the ability of the TSI to operate and verify are suspected in the helper units, Phases 8 or 9 of the TMS autonomous switching from active to standby when errors diagnostics should be performed.
Page 110 examined in order to equate to the TMS under test. This SUMMARY The OPCODE and K-Code of the failing test must be examined to failure was caused by a bad receive coaxial cable from TMS 2, determine a TSI Phase 23 failure when failure is a Transmit Controller 1, Switch Unit 4, Switch 0 receive to TSI 28, Parity Failure (TRPF).
Page 111 OS Lamp [1] Rotate ROS/OFF switch lights to ROS position [2] Depress ROS/OFF switch [3] Remove fuses if required [4] Remove pack to be replaced [NOTE 1] [5] Clean and lubricate pack terminals and connector per approved procedures [6] Insert and insure proper seating of replacement pack [7] Replace any removed fuses NOTE 1...
Page 112 1. See FIG. 1, Page 2. On raw data printout for 9. Read subroutine prologue first failing test, locate last data word NOTE: On raw data printout, the sixth digit in printed fifth data word following mismatch data indicates number of subroutines called In first failing phase PIDENT: 2.
Page 113 NUMBER OF SUPPLEMENTARY DATA WORDS ADDRESS OF THAT PRECEDE DOLOOP DATA WORDS FAILING TEST IN LAST SUB- NUMBER OF DOLOOP DATA WORDS THAT ROUTINE CALLED PRECEDE SUBROUTINE DATA WORDS DGN: TSI 0 CONTR 0 PH 2 STF-BOF (16,00000000 00000000) NUMBER OF SUBROUTINES CALLED THAT BOUND THE FAILING TEST TEST MISMATCH...
Page 114 NOTE: Section 234-180-020 contains a description of 5. In TABLE A (Page 2), locate failing DIAL statement and DIAL statements use description column to determine meaning of data contained in second and third raw data words 1. Read several DIAL statements just before failing. following mismatch data Test to determine what was occurring prior to test.
Page 115 TABLE A DESCRIPTION OF DATA CONTAINED IN SECOND AND THIRD DATA WORD FOR EACH TYPE DIAL TEST STATEMENT DIAL TEST DIAL TEST DESCRIPTION* DESCRIPTION* STATEMENT STATEMENT CCBB A = B = 0, C = buffer bus address SCANI A (bits 11-2) = SP K code B = SP OPCODE to read scan points 0/(1540) CITOP Standard PUB format†...
Page 116 TABLE B LOCATION OF INFORMATION SECOND AND/OR THIRD DATA WORD SD-4A011-01 FRAME SD-4A011-02 FRAME SD-4A083-01 FRAME OPAD/OPCODE SD-4A023-01 (B8GB-B8GE) SD-4A023-02 (B8GB-B8GE) SD-4A085-01 (B20GA-B20GH) SD point address VER:SPMTX:SDP,MDN 0’a! a = SD point address Scan point address VER:SPMTX:SCP,MSN 0’a! a = Scan point address Issue 6 DEC 1997 234-151-012...
Page 117 On Summary Data Printout FIG. 1: In SD FS indicated: 1. Note monitor point address on first CD line under 10. Locate symbol number having same symbol name as V1 column indicated in Test Access PK for failing bit 2. Convert to decimal the octal failing bit in leftmost 11.
Page 118 MONITOR POINT ADDRESS 2 BIT REG TBRD FAILING BIT (OCTAL) 137D REGISTER NAME ANAL TLPFILE:SCLK 0, CONTR 0 SUMMARY DATA MSG STARTED 21007412 00010105 77777777 00060005 00000000 00000000 00001640 00100002 00001640 00150003 00012641 00050001 TERMINAL INDICATES 00010001 00000000 00000000 00000000 00000000 00000000 NUMBER B HALF TLPFILE 69 COMPLETED...
Page 119 SUMMARY meaning for each doloop [FIG. 1, Page 2]. If an endloop statement was not found in the subroutine, go to where the Locate failing test in last subroutine called. Look past failing test for endloop statements. For each endloop subroutine was called and look for endloop statements after statement located in the subroutine, use endloop label the CALLSUB statement.
Page 120 M52 DGN: TSI 0 CONTR 0 PH 2 STF-BOF (13,00000000 00000000) MSG STARTED EXPR ADDRESS IN NUMBER OF DOLOOPS THAT BOUND FAILING TEST LAST SUB. CALLED NUMBER OF SUBROUTINES CALLED TEST MISMATCH SUPPLEMENTARY DATA 28360 02000000 75777757 00000000 01000240 00000053 03200002 DOLOOP INDEX SUBROUTINE...
Page 121 NOTES [7] Locate the referenced endloop 2. First doloop statement closest to, but located is beyond EXPR data noted on innermost, next Step 1, Page 1 doloop located is [9] Does doloop next innermost, [10] Go to statement precede etc. [8] Locate doloop statement Step 14 location of EXPR...
Page 122 [17] In subroutine that called last subroutine checked for doloops, locate CALLSUB statement that called the subroutine [18] Note page and line number of CALLSUB statement [22] Are there any [21] Is endloop references endloop MACRO Page 5 between CALLSUB [19] Locate last address in referenced statement and end...
Page 123 [25] Locate the referenced endloop statement closest to, but beyond CALLSUB statement noted on Page 4, Step 18 [27] Does doloop [28] Go to statement precede [26] Locate doloop statement Step 32 location of using label (in parentheses) CALLSUB statement at endloop statement [31] Have number [29] Read any comments at...
Page 124 In first failing phase PIDENT: [36] Locate CALLSUB statement that called for last subroutine checked for doloops [FIG. 1, Page 2] [37] Note page and line number of CALLSUB statement [38] Locate endloop MACRO [41] Locate doloop in PIDENT reference statement using section label (in...
Page 125 In first failing phase PIDENT: [1] Locate first failing test using EXPR address on raw data printout [FIG. 1, Page 2] [2] Note page and line number of EXPR data [3] Locate endloop MACRO [6] Locate doloop in PIDENT reference statement using section label (in...
Page 126 DGN: TSI 0, CONTR 0 STF-BOF (13,00000000 000000000) MSG STARTED ADDRESS OF SUPPLEMENTARY DATA WORD FAILING TEST EXPR DATA NUMBER OF DOLOOPS THAT BOUND FAILING TEST TEST MISMATCH SUPPLEMENTARY DATA 28360 0200000 75777757 00000000 01000240 00002147 13000002 DOLOOP INDEX VALUES WHEN TEST FAILED 00100000 00000004...
Page 127 At tape transport: [1] Open interlocked cover door; at upper right of tape transport, pull interlock plunger out [2] Operate LOCAL/REMOTE LOCAL lamp pushbutton to obtain LOCAL lights lighted condition Tape reel and [3] Verify that empty lower (take-up) tape reel is take-up reel mounted same size or larger than tape reel to be mounted Page 2...
Page 128 [6] See WARNING 1. While depressing NOTES BRAKE RELEASE pushbutton, manually 1. To start tape on unwind approximately 5 feet of take-up reel, it tape and release BRAKE RELEASE may help to pushbutton moisten tape end (moistened fingers) and stick tape to reel axle [7] See WARNING 2.
Page 129 Tape movement stops [13] Depress STOP pushbutton REVERSE lamp lights until tape rewinds to BOT marker and stops [14] Depress REVERSE pushbutton 25 IPS lamp [15] Depress 5 IPS/25 IPS pushbutton to lights obtain 25 IPS lighted condition REMOTE lamp [16] Depress LOCAL/REMOTE pushbutton to lights obtain REMOTE lighted condition...
Page 130 SUMMARY failing test is not in automatic segment. If no segment Locate first segment statement before first failing test. statement is found before first failing test, failing test If segment statement has AUTO (ON) indicated, failing test is in automatic segment. is in automatic segment.
Page 131 In subroutine where first failing test is located: [7] Locate and note page and line number of first address in subroutine (000000) [8] Locate and note page and line number of [12] Was this [10] Is first failing test subroutine called Phase segment EXPR data...
Page 132 In subroutine that called last subroutine checked for segment statement: [17] Locate and note page and line number of first address in subroutine (000000) [18] Locate and note page and line number of CALLSUB [22] Was this [20] Is statement that called Phase subroutine called segment...
Page 133 In first failing phase PIDENT: [24] Locate and note page and line number of CALLSUB statement that called last subroutine checked for segment statement [30] Failing [26] Is test is in an segment MACRO automatic referenced segment [25] Locate reference section [27] Are any segment references...
Page 134 [1] Locate segment statement that determined failing test was not in an automatic segment [2] Note segment statement index word address for later use (loop start address) [3] Locate first segment statement after first failing test [4] Note index word address of DIAL statement that follows segment statement located in Step 3 (loop end address)
Page 135 Converter ALM TABLE A LEDs light [1] Depress ROS/OFF BULK PWR OFF lamp lights switch CONVERTER LOCATION FUSE LOCATION 0C0A 0-14-12 0-07-08 0A0A 0C0B 0-14-36 0-07-09 0A0B 0C0C 0-14-60 0-07-10 0A0C [2] On bulk converter, operate switch 1C0A 1-14-12 1-07-08 1A0A to OFF position 1C0B...
Page 136 Converter ALM [8] See WARNING 3. Replace associated LED lights converter fuse [TABLE A, Page 1] [9] See WARNING 3. Operate converter switch to ON position Converter ALM LEDs go off PWR OFF lamp [10] At power switch, depress and hold goes off ON pushbutton for 2 seconds WARNING 3...
Page 137 OS Lamp [1] Rotate ROS/OFF switch lights to ROS position PWR OFF lamp lights [2] Depress ROS/OFF switch [3] Remove fuses if required [4] Remove pack to be replaced [5] Clean and lubricate pack terminals and connectors per approved procedures [6] Insert and insure proper seating of replacement pack [7] Replace any removed fuses...
Page 138 [1] Is clock [2] Type [4] Convert bits circuit pack to VER:UTYPE:TSI a! 18 through 22 [3] See FIG. 1. be removed a = Member number of to find EST Is bit 23 of word associated with TSI having clock member number 5 set to 1 TSI-B frame...
Page 139 [7] See FIG. 1, Page 1. [8] Convert bits Using printout received 18 through 22 of in response on Page 1, word 5 to determine Step 6, input message, EST frame member is bit 23 of word 5 number set to 1 [9] See FIG.
Page 140 TABLE A BITS OCTAL ASSOC TYPE TSI CLK WORD Frame type Frame type Clock 0 (DT=0001) (DT=0001) TSI-A * Member number * Member number Bit (0-10) ’16 (VIF=0011) (VIF=0011) SD-4A011-01 (DT, VIF, †DIF) (DT, VIF, †DIF) Clock 1 (DIF=0100) (DIF=0100) SD-4A011-02 Bit (11-21) Clock A...
Page 141 [1] See WARNING 1. On tape unit OK DMT controller, depress REQ DMT lamp lights pushbutton On tape transport: [2] Open interlocked cover door at upper right and pull Ready to interlock switch plunger outward demount tape [3] Operate LOCAL/REMOTE pushbutton to obtain LOCAL lighted condition [4] Depress REWIND pushbutton until tape movement stops...
Page 142 [1] Ensure ROS/OFF switch is rotated to ROS, then depress ROS/OFF switch [2] Unseat fuses that provide power to converter to be replaced [3] Replace converter [4] Reseat fuses and replace any blown fuses [5] Depress and hold ON pushbutton for 2 seconds Converter [6] At power switch, depress and hold TEST LED lights...
Page 143 [1] At power switch, [2] Momentarily [3] Do all ensure ROS/OFF switch depress TEST power switch is rotated to pushbutton and counterclockwise lamps light observe lamps position [4] Replace unlighted lamps using GE 387 or equivalent [5] Use TAD-126 to clear lamp fault Issue 6...
Page 144: Replace Power Switch
[1] At power switch rotate ROS/OFF OS lamp lights switch to ROS position PWR OFF lamp lights [2] Depress ROS/OFF switch Defective [3] Remove power switch fuses [TABLE A, B, or C switch on Page 2] removed [4] Cover apparatus below switch with drop cloth [5] See NOTE 1.
Page 145 TABLE A — SD-4A011-01 FRAME TABLE B — SD-4A011-02 FRAME BAY 0 BAY 1 BAY 0 BAY 1 SWITCH FUSE SWITCH FUSE SWITCH FUSE SWITCH FUSE FUSE FUSE FUSE FUSE LOCATION LOCATION LOCATION LOCATION LOCATION LOCATION LOCATION LOCATION 07-37 07-37 07-30 07-30 80-18...
Page 146 CONVERTER REQUIRED TO REMOVE CONVERTER CONVERTER REQUIRED TO REMOVE CONVERTER LOCATION LOCATION FUSE FUSE SWITCH SWITCH POWER SWITCH FUSE POWER SWITCH FUSE BAY 0 BAY 1 LOCATION LOCATION LOCATION LOCATION 80-31,76-31 0-80-18 0-07-37 80-31,76-31 1-80-18 1-07-37 ALC 0 ALC 1 80-58 0-80-64 0-07-37...
Page 147 CONVERTER REQUIRED TO REMOVE CONVERTER CONVERTER REQUIRED TO REMOVE CONVERTER LOCATION LOCATION FUSE FUSE SWITCH SWITCH POWER SWITCH FUSE POWER SWITCH FUSE BAY 0 BAY 1 LOCATION LOCATION LOCATION LOCATION 80-55 0-80-29 0-07-37 80-55 1-80-29 1-07-37 PUB 0 PUB 1 76-11,76-15 0-80-23 0-07-30...
Page 148 REQUIRED TO REMOVE CONVERTER REQUIRED TO REMOVE CONVERTER CONVERTER CONVERTER LOCATION LOCATION FUSE FUSE SWITCH SWITCH POWER SWITCH FUSE POWER SWITCH FUSE BAY 0 BAY 1 LOCATION LOCATION LOCATION LOCATION 80-59 0-80-65 0-07-46 80-59 1-80-65 1-07-46 PUB 0 PUB 1 76-18 76-18 76-14...
Page 149 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION REQUIRED TO REQUIRED TO CONTROL CONTROL LOCATION NAME NAME BAY 0 REPLACE PACK REPLACE PACK LOCATION LOCATION BAY 1 80-33 to 80-46 80-33 to 80-46 Power switch 0-80-63 PU BUS 0 (IPUB 0) Power switch 1-80-63 PU BUS 1 (IPUB 1)
Page 150 POWER CONTROLS POWER CONTROLS PACK PACK REQUIRED TO CONTROL CONTROL LOCATION REQUIRED TO LOCATION NAME NAME REPLACE PACK LOCATION BAY 0 REPLACE PACK LOCATION BAY 1 80-33 to 80-51 Power switch 0-80-29 PU BUS 0 (IPUB 0) 80-33 to 80-51 Power switch 1-80-29 PU BUS 1 (IPUB 0)
Page 151 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION LOCATION CONTROL REQUIRED TO CONTROL REQUIRED TO NAME BAY 0 NAME BAY 1 LOCATION REPLACE PACK LOCATION REPLACE PACK 56-59 Power switch 1-53-43 Frame PWR bay 1 (CONTR 1) 56-61 Power switch 0-53-43 Frame PWR bay 0 (CONTR 0) 50-all...
Page 152 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION LOCATION REQUIRED TO CONTROL REQUIRED TO CONTROL BAY 0 NAME BAY 1 NAME REPLACE PACK LOCATION REPLACE PACK LOCATION 80-37 to 80-55 80-37 to 80-55 Power switch 0-80-65 PU BUS 0 (IPUB 0) Power switch 1-80-65 PU BUS 1 (IPUB 1)
Page 153 POWER CONTROLS PACK LOCATION REQUIRED TO CONTROL BAY 0 NAME REPLACE PACK LOCATION Frame PWR bay 1 40-63, 67 Power switch 1-44-37 (CONTR 1) 40-68, 69 Frame PWR bay 0 36-22 to 36-69 Power switch 0-44-37 (CONTR 0) 28-02 to 28-61 28-65 Frame PWR bay 1 28-63, 67...
Page 154 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION LOCATION REQUIRED TO CONTROL REQUIRED TO CONTROL NAME BAY 0 BAY 1 NAME REPLACE PACK LOCATION REPLACE PACK LOCATION 80-01 to 80-14 Power switch 0-80-29 80-01 to 80-14 Power switch IPUB0 1-80-29 IPUB1 64-ALL 76-ALL Power switch...
Page 155 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION LOCATION REQUIRED TO CONTROL REQUIRED TO CONTROL NAME NAME BAY 0 BAY 1 REPLACE PACK LOCATION REPLACE PACK LOCATION Power switch 0-80-29 80-01 to 80-14 80-01 to 80-14 Power switch IPUB0 1-80-29 IPUB1 64-ALL Fuse 1-07-26...
Page 156 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION LOCATION REQUIRED TO CONTROL REQUIRED TO CONTROL NAME NAME BAY 0 BAY 1 REPLACE PACK LOCATION REPLACE PACK LOCATION 80-14 to 80-32 Power switch 0-80-42 80-14 to 80-32 Power switch 1-80-42 C0IPUB1 C1IPUB1 76-14 to 76-32 Power switch 0-76-42...
Page 157 [1] See FIG. 1. Connect a 10k ohm, .5 watt resistor across the test leads of a voltmeter [4] Does [2] See TABLE A, Page 2 and NOTE 1. voltage measure Remove fuse A Page 2 between +21 to +27 volts [3] Connect (+) lead of voltmeter [FIG.
Page 158 [7] See NOTE 2. Connect (+) lead of [8] Does voltmeter [FIG. 1, voltage measure Page 3 Page 1] to anode of between +1 volt diode C; (—) lead and -1 volt to ground [FIG. 2] [9] See TABLE A. Remove fuse B and replace shorted diode C.
Page 159 [10] Replace fuse A [16] See NOTE 1, Page 1. Connect (+) lead of [13] Does voltage voltmeter [FIG. 1, Page 1] [11] Remove fuse B measure between to anode of diode D; +21 to +27 volts (—) lead to ground [FIG.
Page 160 [17] Does [19] See TABLE A, voltage measure Page 2. Replace between +1 volt fuse B and —1 volt [18] See TABLE A, Page 2. Remove fuse A and replace shorted diode D. Repeat from Step 10, Page 3 Issue 6 DEC 1997 234-151-012 PAGE 4 of 4...
Page 161 At frame power switch [1] Rotate ROS/OFF OFF NORM and switch clockwise OS lamps light to ROS position [3] Are LEDs on converters and circuit packs lighted SD4A011-01 [DLP-533] SD4A011-02 [DLP-533] [2] Depress and hold SD4A083-01 [DLP-529] TEST pushbutton for 2 seconds [4] Identify power controls associated with out-of-service [6] Repeat...
Page 162 [1] At TTY, type DUMP: DIF a,CREG! a = Member number Wait for response [4] Remove from service DIF controller associated [3] Are [2] Determine clock both DIF with TSI controller under configuration for DIF test by typing controllers CONTR 0 and CONTR 1 using same RMV: DIF a, CONTR b! hardware and software...
Page 163 [7] Restore controller [6] See NOTE 1. removed from service Re-enter by typing same message entered RMV: DIF a, CONTR b! in Step 5 by typing Wait for response RMV: DIF a, CONTR b! a = Member number Wait for response b = 1 for clock 0 b = 0 for clock 1 [12] Remove from...
Page 164 1. Define error using PMDs [TABLE A] End of procedure TABLE A ERROR DEFINITION ERROR DEFINITION PMD-006 Fault isolated by TNFRISAD. PMD will indicate PMD-021 Fault isolated by TNFRTMMN. This is a matched or that one controller of suspect member failed nonunique type error which occurred in both access test.
Page 165 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-105 Fault isolated by TNFRTSMN. Fault type is nonunique PMD-056 Fault isolated by TNFRTMMN. Retry was performed class-4 transient (retry passed). Error will and failed. This is a match type fault which occurred in one controller only; therefore, it is be PFE, PFO, RTSMPF, TTSMPF, BIMPF, or ASWF in both controllers (ASWF) hard unique (ASWF)
Page 166 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-172 PMD-160 Fault isolated by TNFRTSMN. Fault type is nonunique Fault isolated by TNFRTSMN. A receive or transmit class-4 transient (retry passed — both time slot memory parity failure has been detected controllers). Error in AINT error source register in the AINT and/or SAL error source registers in or sense and lock register may be AINT only, CE, both controllers.
Page 167 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-212 Fault isolated by TNFRXMIT. Fault type is either PMD-217 Fault isolated by TNFRXMIT. Fault type is either TRPF, TMM, or TSW. Channel is busy to a time slot. TRPF, TMM, or TSW. Channel is busy to a time slot. In attempting to trace call through network, TTSM In attempting to trace call through network, memory did not have appropriate data.
Page 168 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-231 Fault isolated by TNFRXMIT. Fault type is TMM or PMD-224 Fault isolated by TNFRXMIT. Fault type is either TRPF, TMM, or TSW. Channel is busy to time slot. TSW error in both controllers but channel on In attempting to trace call through network, which error occurred is not involved in network mismatch in TMS routing F/F was found.
Page 169 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-241 PMD-235 Fault isolated by TNFRXMIT. Fault type is TMM or Fault isolated by TNFRXMIT. Fault type is either TSW error occurring in both controllers. Check of TRPF, TMM, or TSW. Path was found on failing time busy idle memory map bits against TS memory was slot.
Page 170 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-251 Fault isolated by TNFRXMIT. Fault type is transient PMD-305 Fault isolated by TNFRMMRT. Fault type is nonunique RSW (retry passed). Fault is probably not in TSI class-3 hard. Network connection from failing recording error, but in transmisson subunit channel in BMA to maintenance channel in BMD made.
Page 171 TABLE A (Contd) ERROR DEFINITION ERROR DEFINITION PMD-313 Fault isolated by TNFRMMRT. Fault type is nonunique PMD-365 Fault isolated by TNFRTSMN. Fault type is class-3 hard. No test made. Attempt to make loop- nonunique class-4 hard (retry failed). Error is around connection of network failed DWMM in both controllers PMD-360...
Page 172 FRAME J4A001B-1, SD-4A083-01 POWER CONTROLS POWER CONTROLS PACK PACK LOCATION LOCATION REQUIRED TO CONTROL REQUIRED TO CONTROL BAY 0 BAY 1 NAME NAME REPLACE PACK LOCATION REPLACE PACK LOCATION (FC512) (FC512) 64-02, 03 64-02, 03 Power Switch 0-44-37 Frame PWR bay 0 Power Switch 1-44-37 Frame PWR bay 1...
Page 173 SD-4A011-01 [4] Type [1] Which TSI SD-4A011-02 Page 3 frame is being VER:UTYPE:TSI a! a = TSI frame tested SD-4A083-01 [2] Type VER:UTYPE:TSI 02! PF VER:UTYPE:TSI a! M 49 VER:UTMN;OPT (), CUR: FIN 16006.02, UTYN TSI UTYN TSI a = Even member number MEMN ME OPER, of TSI frame...
Page 174 [5] See FIG. 1, Page 1. [6] Convert bits Using printout received 18 through 22 of in response on Page 1, word 5 to determine Step 3, input message, EST frame member is bit 23 of word 5 number set to 1 [7] See FIG.
Page 175 [11] See FIG.1, [12] Convert bits page 1. Is bit 18 through 22 to 23 of word 5 find EST member set to 1 number [13] See TABLE A, Page 4. Using appropriate TSI type and generic, determine which octal translation words are associated with TSI CLK [14] See FIG.
Page 176 TABLE A BITS OCTAL ASSOC TYPE TSI CLK WORD Frame type Frame type Clock 0 (DT=0001) (DT=0001) TSI-A * Member number * Member number Bit (0-10) ’16 (VIF=0011) (VIF=0011) SD-4A011-01 (DT, VIF, †DIF) (DT, VIF, †DIF) Clock 1 (DIF=0100) (DIF=0100) SD-4A011-02 Bit (11-21) Clock A...
Page 177 SUMMARY TABLE A Call up recent change (RC) Form 700 on CRT. Using TTY, fill RC:UTYPE;CHG;OPT(EQP,GROW),TST: UTYN a, in blanks on RC Form 700 to change submember equipage. ORNU b, Using the assigned order number, activate the recent change; then verify current translations. MEMN c, (----, ----), SUBMEM d,...
Page 178 TABLE B [3] Was recent change SUCCESSFULLY RC ORNU b SUCCESSFULLY TESTED TESTED, and Page 3 RC ORNU b SUCCESSFULLY BUFFERED SUCCESSFULLY BUFFERED [TABLE B] RC:UTYPE;CHG;OPT(EQP,GROW),BUF: UTYN a, ORNU b, MEMN c, ME (----,----), [4] Analyze output message for SUBMEM d, SME ( e error;...
Page 179 TABLE C [7] Determine cause [5] Enter RC ORNU b ACTIVATED [6] Was recent for rejection; RCACT:ORNU a! change ACTIVATED repeat from Step 5 RC:UTYPE;CHG;OPT(EQP,GROW),BUF: UTYN a, a = RC order [TABLE C] with correct input number ORNU b, message MEMN c, (----, ----), SUBMEM d,...
Page 180 TABLE D [11] Enter INPUT MESSAGE OUTPUT MESSAGE input message VER:UTYPE:b c,SME f! VER:UTMN;OPT(SME),CUR: FLN a, UTYN b, per TABLE D MEMN c, ME d, SUBMEM f, SME e, a = Floor location number [12] Are b = Unit Type = VIF, DT, TGR, TSI, EST, DIF, or SP output message c = Member number of growth associated frame format and data...
Page 181 [1] Read NOTE 1. [4] Does output [2] Was message Enter message message indicate accepted and did per TABLE A ATP and RESTORE diagnostic run COMPLETED [7] Refer [5] Is this [3] Analyze trouble to growth job output message; installer; assisted by repeat from ATP required...
Page 182 TABLE A SUMMARY Call up RC Form 701 on CRT. Using TTY, fill in blank fields RC:UTYPE,CHG;OPT(EQP,DEGROW),TST: UTYN a, on form to degrow state of submember equipage (SME) from OPER to SGRO and/or from SGRO to GROW and/or from GROW to ORNU b, UNEQ.
Page 183 [5] Analyze output TABLE B [4] Was recent message for error; RC ORNU b SUCCESSFULLY TESTED change SUCCESSFULLY repeat from TESTED and RC ORNU b SUCCESSFULLY BUFFERED Step 2, Page 1. SUCCESSFULLY with corrected RC:UTYPE,CHG;OPT(EQP,DEGROW),BUF: UTYN a, BUFFERED [TABLE B] input data ORNU b, MEMN c,...
Page 184 TABLE C [8] Determine cause for rejection; RC ORNU b ACTIVATED [7] Was recent repeat from change ACTIVATED RC:UTYPE,CHG;OPT(EQP,GROW),BUF: UTYN a, Step 6, Page 2, [TABLE C] with correct input ORNU b, message MEMN c, (----, ----), [9] Does output [12] Is it necessary SUBMEM d, (OPER, SGRO),...
Page 185 CRT displays TABLE D [13] See CAUTION 2. Enter RC Form 701 OP:RCFORM 701! RC:UTYPE;CHG;OPT(EQP,DEGROW),TST: UTYN a, ORNU b, RC Form 701 filled in MEMN c, (----, ----), and entered [14] Fill in blanks on RC Form 701 SUBMEM d, e ), per TABLE D to degrow submember Page 5...
Page 186 [16] Analyze output TABLE E [15] Was recent message for error; RC ORNU b SUCCESSFULLY TESTED change SUCCESSFULLY repeat from TESTED and Step 13, Page 4, RC ORNU b SUCCESSFULLY BUFFERED SUCCESSFULLY with corrected RC:UTYPE,CHG;OPT(EQP,DEGROW),BUF: UTYN a, BUFFERED [TABLE E] input data ORNU b, MEMN c,...
Page 187 TABLE F [19] Determine cause for rejection; RC ORNU b ACTIVATED [18] Was recent repeat from change ACTIVATED RC:UTYPE,CHG;OPT(EQP,GROW),BUF: UTYN a, Step 17, Page 5, [TABLE F] with correct input ORNU b, data MEMN c, (----, ----), [20] Does output [23] Is it necessary SUBMEM d, (SGRO, GROW),...
Page 188 TABLE G RC:UTYPE;CHG;OPT(EQP,DEGROW),TST: UTYN a, CRT displays [24] See CAUTION 3. Enter RC Form 701 OP:RCFORM 701! ORNU b, RC Form 701 MEMN c, (----, ----), filled in and entered [25] Fill in blanks on SUBMEM d, e ), RC Form 701 per TABLE G to degrow submember to UNEQ REMARKS------------------------------! Page 8...
Page 189 [27] Analyze output TABLE H [26] Was recent message for error; RC ORNU b SUCCESSFULLY TESTED change SUCCESSFULLY repeat from TESTED and Step 24, Page 7, RC ORNU b SUCCESSFULLY BUFFERED SUCCESSFULLY with corrected RC:UTYPE,CHG;OPT(EQP,DEGROW),BUF: UTYN a, BUFFERED [TABLE H] input data ORNU b, MEMN c,...
Page 190 TABLE I [30] Determine RC ORNU b ACTIVATED [29] Was recent cause for rejection; change ACTIVATED repeat from Step 28, RC:UTYPE,CHG;OPT(EQP,GROW),BUF: UTYN a, [TABLE I] Page 8, with correct input data ORNU b, MEMN c, (----, ----), [31] Does output SUBMEM d, (GROW, UNEQ), message indicate...
Page 191 [1] Read NOTE 1. Enter RST:EST a,ESU b! a = Member number of growth associated b = Submember number of growth ESU [7] Refer [5] Is this [4] Does output [2] Was message trouble to growth job message indicate accepted and did installer;...
Page 192 [1] Enter [4] Assure that VER:TRKNAME,TAN a;DETL! [5] Using output [2] Is output VIU/DTU/DIU a = First trunk assignment message, record message format identified in number of trunks OTAN number correct per output message is served by VIU/DTU/DIU for use later TABLE A VIU/DTU/DIU to to be degrown...
Page 193 [2] Does output message show [3] Enter [1] Enter set COMPLETED TRK COUNT 120 trunk status trunk status for TAN of VIU/DTU/DIU message per message per being degrown. TABLE C TABLE A See TABLE B [4] Does output Page 2 message show COMPLETED TRK COUNT 120 for TAN of VIU/DTU/DIU...
Page 194 [5] Enter trunk status message per TABLE E [6] Using output message, record 0TAN of each [10] Have all trunk not set to CAD.DSA [8] Does output trunks recorded state. See TABLE F message indicate in Step 6 been set trunk is in CAD.DSA to CAD.DSA state state per TABLE F...
Page 195 [1] Enter [2] Read NOTE 1. Does OP:OOSUNITS:a! output message a = VIF or DT or indicate any out-of- service VIUs/DTUs/DIUs in degrowth VIF/DT/DIF [3] Clear diagnostic failure; ATP required VIU TOP-234-151-025 DTU TOP-234-151-045 DIF TOP-234-151-055. Repeat from Step 1 NOTE 1 The spare VIU/DTU/ DIU must not be...
Page 196 TABLE A [1] Enter [2] Was VIU/ remove DTU/DIU removed RMV:a b,c d! message per from service TABLE A a = VIF or DT or DIF b = Member number of degrowth associated VIF/DT/DIF System [5] Determine c = VIU or DTU or DIU denied why request was d = Submember number of...
Page 197 [1] Enter RMV:EST a,ESU b! a = Member number of [2] Was ESU EST associated with removed degrowth VIU/DTU/DIU from service b = Submember number of ESU associated with degrowth VIU/DTU/DIU System [5] Determine denied why request was request [3] Output denied;...
Page 198 [1] Obtain CIN assignments of TANTOTANs on SPC being affected [2] At MTCE channel, enter message for [5] Have all [3] Was one TANTOTAN on list in Step 1 TANTOTANs assigned COMPLETED SUCCESS ORD:TANTOTAN;a,CIN b:CIN c! to SPC being message received a = RLS (to take down TANTOTAN) or affected been CONN (to connect TANTOTAN)
Page 199 At associated TSI controller: [1] Rotate ROS/OFF Switch OS lamp lights to ROS position [2] Depress ROS/OFF Switch to OFF position [3] Place drop cloth under connector board to be replaced Page 2 [4] Label and disconnect all twisted pair backplane wiring [5] At front of frame, remove six screws that secure connector board to frame [6] Transfer the coaxial cables from...
Page 200 [7] Secure new connector board to frame using six screws [8] Connect all backplane wires that were disconnected in Step 4. Strip back wires and rewrap. If the wires will not reach or break during rewrap, run a new twisted pair to replace defective wire [9] Remove drop cloth [10] Restore power by depressing and holding ON pushbutton for 2 seconds...
Page 201 At associated TSI controller: OS lamp [1] Rotate ROS/OFF switch lights to ROS position [2] Depress ROS/OFF switch to OFF position [3] At rear of TSI frame, locate ED-4A148-30 DS-120 connector board having bad splitting transformer [4] Place drop cloth under work area [5] Using a low wattage soldering iron, carefully unsolder and remove...
Page 202 Converter [11] See WARNING 3. Replace both associated LED lights converter fuses [TABLE A, Page 1] [12] See WARNING 3. Operate both Converter LED converter ON/OFF switches to ON goes off position PWR OFF lamp [13] At power switch, depress and hold goes OFF ON pushbutton for 2 seconds WARNING 3...
Page 203 Converter ALM TABLE A LEDs light [1] Depress ROS/OFF BULK PWR OFF lamp lights switch CONVERTER LOCATION FUSE LOCATION 0C0A 0-14-12 0-07-08 0A0A 0C0B 0-14-36 0-07-09 0A0B [2] On both bulk converters in the bay, 0C0C 0-14-60 0-07-10 0A0C operate ON/OFF switch to OFF 1C0A 1-14-12 1-07-08...
Page 204 [10] See NOTE 3. Connect load share cable between converters Converter ALM [11] See WARNING 3. Replace both associated LEDs light converter fuses [TABLE A, Page 1] [12] See WARNING 3. Operate both converter ON/OFF switches to ON position Converter ALM LEDs go off PWR OFF lamp [13] At power switch, depress and hold...
Page 205 Converter ALM TABLE A LEDs light BULK PWR OFF CONVERTER LOCATION FUSE LOCATION lamp lights [1] Depress ROS/OFF switch 0C0A 0-14-12 0-07-08 0A0A 0C0B 0-14-36 0-07-09 0A0B 0C0C 0-14-60 0-07-10 0A0C [2] On both bulk converters in the 1C0A 1-14-12 1-07-08 bay, operate ON/OFF switch to OFF 1A0A...
Page 206 [9] See NOTE 2. Connect load share cable between converters Converter ALM [10] See WARNING 3. Replace both associated LEDs light converter fuses [TABLE A, Page 1] [11] See WARNING 3. Operate both converter ON/OFF switches to ON position Converter ALM LEDs go off NOTE 2 PWR OFF lamp...
Page 207 Converter ALM TABLE A LEDs light BULK PWR OFF [1] Depress ROS/OFF CONVERTER LOCATION FUSE LOCATION lamp lights switch 0C0/A 0-14-12 0-07-08 0A0/A 0C0/B 0-14-36 0-07-09 0A0/B 0C0/C 0-14-60 0-07-10 0A0/C [2] On all three bulk converters in 1C0/A 1-14-12 1-07-08 1A0/A the bay, operate ON/OFF switches...
Page 208 [9] Install 841998503 PWB bypass assembly in converter "B" location [10] Install protective covers in converter "B" location [11] See NOTE 3. Connect load share cable between converters [12] See WARNING 3. Replace associated Converter ALM converter fuses in positions LEDs light "A"...
Page 209 Converter ALM TABLE A LEDs light BULK PWR OFF CONVERTER LOCATION FUSE LOCATION [1] Depress ROS/OFF lamp lights switch 0C0/A 0-14-12 0-07-08 0A0/A 0C0/B 0-14-36 0-07-09 0A0/B 0C0/C 0-14-60 0-07-10 0A0/C [2] On both bulk converters in 1C0/A 1-14-12 1-07-08 1A0/A the bay, operate ON/OFF switch 1C0/B...
Page 210 Converter ALM [9] See WARNING 3. Replace associated LEDs light converter fuses [TABLE A, Page 1] [10] See WARNING 3. Operate both converter ON/OFF switches to ON position Converter ALM LEDs go off PWR OFF lamp [11] At power switch, depress and hold goes off ON pushbutton for 2 seconds WARNING 3...
Page 211 Converter ALM LEDs light [1] See NOTE 1. Depress PWR OFF lamp lights NOTES ROS/OFF switch 1. In this application, three [2] On both bulk converters in the bay, 245A converters operate ON/OFF switch to OFF position replace two 245C converters. [3] See NOTE 2.
Page 212 TABLE A [11] See WARNING 3 and NOTE 5. Converter ALM Replace all three converter BULK LEDs light fuses [TABLE A] CONVERTER LOCATION FUSE LOCATION 0C0/A 0-14-12 0-07-08 0A0/A 0C0/B 0-14-36 0-07-09 0A0/B 0C0/C 0-14-60 0-07-10 0A0/C 1C0/A 1-14-12 1-07-08 1A0/A 1C0/B 1-14-36...
Page 213 SUMMARY replacement procedure: stencil kit, digital VOM, plastic/ rubber sheets or equivalent insulating material, electrical If the office has no spare capacitors or diodes available, tape, screwdrivers (standard and Phillips*), needlenose Do Not execute this procedure, and notify next level of pliers, trouble light, soldering iron, markers for leads, support per local practice.
Page 214 [7] See CAUTION 1. [14] Using VOM, [16] Abort Install insulating determine which procedure [8] See NOTE 2 [15] See NOTE material around unit diode is bad and TABLE A. Is 2 and TABLE A. and notify filter capacitor (expected ohms, 100K there a shorted next level of Is there a...
Page 215 [18] Stamp proper identification on new capacitor being installed SCREWS [19] Properly orient new capacitor and secure in unit mounting ring Capacitor replaced Figure 3 - Diode Sample [20] Carefully place new capacitor in unit and replace three mounting ring screws [21] Reconnect leads and resistor to capacitor and ensure polarity as observed earlier...
Page 216 [25] Remove soldered leads from diode and insulate properly [26] Remove diode from assembly plate Diode replaced [27] Install new diode to assembly plate and orient in proper manner [28] Remove insulation and resolder wire leads [29] Replace diode mounting plate screws to frame Page 5 [30] Remove insulation materials...
Page 217 [31] Switch affected 245- type converters to OFF position [33] At ABC frame, [32] At affected insert ITE 4715 peripheral frame, [34] Does lamp Capacitor Charging install frame glow brightly Tool or equivalent fuses that and extinguish into associated were previously Pilot fuse removed [35] At affected...
Page 218 [1] See Caution 1. At [2] Was MTC terminal enter: RMV:TSI a,ALC b RMV:TSI a,ALC b! COMPLETED a = TSI Member Number message received b = TMSP Network Half (0 or 1) [4] Contact [3] Is OS next level of lamp lit technical on A-Link...
Page 219 [7] Remove Circuit pack to be replaced [8] Clean and lubricate replacement pack terminals and connector per approved local procedures [9] Insert and insure proper seating of circuit pack replacement [10] Depress and hold ON pushbutton for approximately 2 seconds [11] Rotate ROS/OFF switch to normal position...
Page 220 ITEM ISSUE ITEM ISSUE ITEM ISSUE ITEM ISSUE ITEM ISSUE ITEM ISSUE TPG-000 ISD-121 DLP-514 DLP-549 IXL-001 ISD-122 DLP-515 CKL-891 NTP-002 DLP-516 TAP-123 TNG-893 NTP-003 TAP-124 DLP-517 DLP-518 NTP-004 TAP-125 TAD-126 DLP-519 NTP-005 DLP-520 NTP-006 TAP-127 DLP-521 NTP-007 TAP-128 TAP-129 DLP-522 NTP-008 TAP-130...

Lucent Technologies 4ESS SWITCH Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Lucent Technologies 4ESS SWITCH

Summary of Contents for Lucent Technologies 4ESS SWITCH

Page 25: Maintenance Philosophy

Page 32: Supplementary Data

Page 79: Power Switch

Page 144: Replace Power Switch
