Green Solutions HOME E10 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HOME
E10
0
Installation Manual
Issue: 2.6
Date: Apr 2023
Document Links:
Installation
Manual
1
Installation
Video

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOME E10 and is the answer not in the manual?

Questions and answers

Related Manuals for Green Solutions HOME E10

Summary of Contents for Green Solutions HOME E10

  • Page 1 HOME Document Links: Installation Manual Issue: 2.6 Date: Apr 2023 Installation Installation Manual Video...

  • Page 2: Table Of Contents

    The information included in this manual is accurate at the time of publication. However, this manual is subject to change without prior notice. In addition, the illustrations in this manual are meant only to help explain system configuration concepts and installation instructions. Please note the images shown are for illustration purposes only.

  • Page 3: General Information

    01 General Information 1.1 Introduction This manual provides the installation instruction of the Green Solution Inc. (referred as GS in this document) residential battery E10 (referred as E10 in this document). Please keep this manual in good condition for later reference.

  • Page 4: Warning Labels

    1.5 Warning labels Cautions, risk of electric shock. Keep the battery pack away from children. Keep the battery pack away from open flame or ignition sources. The battery pack should not be disposed of with household waste at the end of its working life. The battery pack should be disposed of at a proper facility for recycling.

  • Page 5: Product Specifications

    2.2 Product specifications 2.2.1 Dimensions and weight Item Measurement Length 726 mm/28.6 in Width 240 mm/9.4 in Height 716 mm/28.2 in Weight 120 kg 2.2.2 Product specifications Item Specifications Nominal voltage 51.2 V Voltage range 40-58.2 V Nominal capacity 200.0 Ah Nominal/Usable energy 10.2/9.7 kWh Max.

  • Page 6: Part List

    2.3 Part list 2.3.1 Parts included in the package Mounting bracket x1 SEMS screws x2 Floor mounting bracket x2 Used in 3.4.1 E10 x1 Used in 3.4.3 Used in 3.4.4 Part 1 Part 2 Part 3 Part 4 Floor mounting bracket Ground connection nuts 2 m Power cables red x1, 3 m Communication cable...

  • Page 7: Installation

    03 Installation 3.1 Prerequisites 3.1.1 Make sure the installation location satisfies the following conditions E10 is certified for IP65 and can be installed indoors as well as outdoors. If installed outdoors, do not allow  E10 to be exposed to direct sunlight, rain and snow. The installation location should have good ventilation.

  • Page 8: Unboxing The Crate

    3.2.2 Installation equipment The weight of the E10 is approx. 120 kg/264 lb, 2 or more persons are recommended for the installation task. Due to the heavy weight of the battery, a trolley with the following specifications is suggested to move the battery: Adjustable platform height >...

  • Page 9: Installation

    3.4 Installation 3.4.1 Installation location The E10 can be installed both indoor and  outdoor (for outdoor installation, please refer to the following diagram for guidance). Do not expose the E10 to direct sunlight, rain and snow. The E10 can be mounted on a vertical wall ...
  • Page 10 3.4.4 Installing the E10 battery Use the trolley to unload the E10 crate near installation area.  Lift and stand battery upright onto trolley. Ensure brakes on trolley are applied.  With mounting bracket installed properly on the wall, move the E10 close to the mounting bracket and lift the E10 upwards.
  • Page 11 3.4.5 Mounting the E10 on the bracket Align the E10 to the center mounting bracket.  Open the protection front cover.  Drive the M5*12mm SEMS wall mount lock screws through the mounting bracket into the mounting holes  and tighten them to a torque of 2.5 N.m. 3.4.6.

  • Page 12: Connect The E10 To An Inverter

    3.5 Connect the E10 to an inverter Open the protection cover and remove the waterproof cover with a screwdriver.  Ensure the E10 breaker is switched to OFF position.  Making positive (+, red) and negative (-, black) power connections to that of an inverter (refer to the ...

  • Page 13: Operating Instructions

    Re-install waterproof cover and close the protective cover.  Close 04 Operating Instructions 4.1 Power switch and connection panel The connection panel of the E10 shown below allows the users to access to all the connection terminals of the product. Items Connector Type Remark...

  • Page 14: Power On/Off Procedures

    4.3 Power On/Off procedures 4.3.1. Power On procedure After connecting all the cables to the E10 battery, switch the breaker to ON position.  Push the BMS switch.  Check the LED panel on the E10 for a green status light. (It takes 1 min for the E10 to be powered up. ...

  • Page 15: Others

    05 Others 5.1 Certifications Item Standard Pack certifications UL1973/IEC62619/CE/FCC/UKCA/MSDS UL1973/UL9540A/IEC62619 Cell certifications JIS8715-2/SII Crush & Nail UN38.3 Transportation certifications UN38.3 5.2 System maintenance The E10 must be charged at least once every three months if it is not in use. It is NOT recommended to have the E10 stayed in idle or turned off for more than three months.

  • Page 16: Uninstallation

    Insufficient ventilation  Failure to follow safety cautions and instructions.  Unauthorized maintenance and modification.  Inverter failure or overcurrent.  Force majeure.  External influences, such as unusual physical or electrical stress.  Paired and used with incompatible inverter. ...

  • Page 17: Appendix 1: Deye Inverter Power-On / Power-Off Procedures

    Appendix 1: Deye inverter power-on / power-off procedures A1.1 Power-on the Deye inverter Unload the protective cover of the inverter.  Connect the E10 properly by following the procedures in the E10 installation manual.  Ensure the inverter is connected properly with grid and PV (if available). ...
  • Page 18 A1.2 Power-off the Deye inverter Unload the protective cover of the inverter.  If there is a grid connection, turn the main  grid switch (AC) to off position. If there is a PV connection, disconnect the  PV by turning the DC switch to off position. Release the ON/OFF button (located on the ...

  • Page 19: Appendix 2: E10 Wi-Fi Setup Procedures

    Appendix 2: E10 Wi-Fi setup procedures Turn on the E10 battery.  Locate the Wi-Fi button and press for 7 seconds until a flashing green LED is obtained, then E10 enters  into a paring mode. Turn on the Wi-Fi and Bluetooth on a ...
  • Page 20 Search in the Apple App store or Google Play store for “Smart Life – Smart Living”. Click download and  open. Click “Sign up” and then register. Follow the steps to select country/region and enter email address.  Click “Get Verification Code” A verification code will be sending to the email address. Enter the Verification ...
  • Page 21 After the verification is completed. Set and enter a password to complete the user registration.  Use the email address and password to login to the APP. Select both “Data Analysis” and “Personalization”  and click “Go to App”.
  • Page 22  the paring mode (green Wi-Fi LED blinking). When it shows “Discovering devices”, click the “Add” button. Choose the home Wi-Fi and click “Next”. HOME E10 will show up. Wait for the installation to complete.  When the pairing up is successful, the green Wi-Fi LED will stay solid on.
  • Page 23 When the installation is completed. A notice “Home E10 added successfully” will be shown. After the setup  is completed, battery information can be checked from the APP interface. For connecting to a second E10 battery, repeat the step 8 to 11 above.
  • Page 24 www.greensolutions.co...
