- Page 1 Home Energy Storage Battery Pack HOMEE11 Installation Manual June 2019 | Ver.1.0 Green Solutions Inc. proprietary...
- Page 2 The manual contains important information on safety and the proper way to install Home Energy Battery Pack HOMEE11 manufactured by Green Solutions Inc. (GSI). Before the product is installed, users should read the manual carefully and follow all instructions required throughout the entire installation process. If there is a question on the requirements described or safety procedures, please contact GSI customer service: contact@greensolutions.co.
-
Page 3: Table Of Contents
2.2 Battery pack operation instructions 2.3 Tools 2.4 Warning labels 3. Installation 3.1 Installation location 3.2 HOMEE11 installation 3.2.1 Mount the battery pack to the wall 3.2.2 Connect the battery pack to inverter 3.3 HOMEE11 expansion 3.3.1 Mount an extension Pack to the wall 3.3.2 Connect the expansion Pack to the master Pack... -
Page 4: Introduction
(reserved), LCD display (reserved), dry contact output, MOS failure protection (dual protection), LED display, RS232 /RS485 communication. 1.1.2 Expandability The HOMEE11 can be easily extended by connecting to extra battery packs. Maximum number of extensions is 2 (including the master HOMEE11). 1.2 Packaging materials... -
Page 5: Components
1.3 Components RS232 to RS845 conversion module 1.4 Specifications 1.4.1 Dimensions and weight Item Measurements Length 741±3mm Width 530 ±3mm Height 217 ±2mm Weight 110 kg Green Solutions Inc. proprietary... -
Page 6: Performance
Step 3: 0.2C (43.2A) discharging to 42.0V; cycles≥80% Step 4: 10 minutes idling; Step 5: to repeat step 1 to 4 for 4000 cycles. To record the volume after 4000 cycles and compare with the first cycle Green Solutions Inc. proprietary... -
Page 7: Conditions Requirement
Discharging temperature -20℃ - 55℃: Storage Recommended storage temperature 25±5℃ temperature Temperature 25±2℃ Standard testing condition Humidity 60±5%RH 1.4.4 Cable requirement Power cable 25mm Copper terminal SC25-8 1.4.5 Communication ports Protocol RS232 to RS485 Channel Green Solutions Inc. proprietary... -
Page 8: Safety
2.2 Battery pack operating instructions Please follow the instructions below: (1) Do not expose the HOMEE11 to direct sunlight. Do not locate the battery pack in a high ambient temperature environment above 55℃ or expose to fire. (2) Do not drop, deform, impact or pierce the battery pack enclosure. It may be result in electrolyte leaking or burning. -
Page 9: Tools
Use professional electricians tools to prevent electrical shocks or short circuits. 2.4 Warning labels The product label is located on the left side of the battery pack. The grounding labels is located on the top of the battery pack. Green Solutions Inc. proprietary... -
Page 10: Installation
(5) The area is corrosive gas and fluid free. (6) Do not use the Battery module offshore. (7) The HOMEE11 can be installed both indoor and outdoor with no minimum space clearances around installation as long as environment conditions are met. The recommended... - Page 11 (4) On the top side of the stand there are studs on both ends. Hang the battery pack on the studs temporarily. (5) Then use 8.8 grade M6 screw to tighten the battery pack to the wall mount bracket with 10 N.m torque. Green Solutions Inc. proprietary...
- Page 12 On/OFF switch cover and insulated gasket. (4) Connect the communication cable provided to the communication port on the inverter. The other end of the cable connects to the BMS port through the soft tube (RS485/RS232). Green Solutions Inc. proprietary...
- Page 13 (circuit breaker) in the battery chassis. (8) Replace the bottom cover with switch cover and insulated gasket. Fix and tighten the screw with 6 Nm torque. And also replace the cover of inverter. Green Solutions Inc. proprietary...
-
Page 14: Homee11 Expansion
2 (including the master HOMEE11). 3.3.1 Mount the extension pack on the wall Install the extension pack on the right side of the master HOMEE11 and ensure that both packs share the same distance from the ground with 200mm side by side separation. Follow the installation procedure in section 3.2.1 and install the pack to the wall. - Page 15 /RS485/RS232 ports. And then insert the cables to the P+/P-/RS485/RS232 ports of the extension pack. (5) Connect the electrical and communication cables to the extension pack: P+ to positive, P- to negative and communication cable to RS485 port. Extension Green Solutions Inc. proprietary...
- Page 16 (7) Turn on the circuit breaker Ensure both circuit breakers of master battery pack and extension pack are turned on. (8) Reconnect the bottom cover Ensure both bottom covers of master battery pack and extension pack are reconnected. Green Solutions Inc. proprietary...
-
Page 17: Final Check Before Use
If the voltage is higher than 0V, contact GSI or authorized distributors. (2) Move the switch to ON position and measure the voltage. If the voltage is lower than 42V, contact GSI or authorized distributors. Green Solutions Inc. proprietary... -
Page 18: Power On And Off Procedures
(2) Power off Power off: when BMS is in working state, press "RESET" button and the duration is greater than 6S and less than 10S. When the indicator is fully on, BMS will enter the power down state. Green Solutions Inc. proprietary... -
Page 19: Computer Operation Procedures
Please follow the procedures below: 3.4.4 Computer operation procedures The RS485 communication port on the BMS is used to connect to the computer Extend the battery Green Solutions Inc. proprietary... - Page 20 4）On the left-hand side is the interface for parameter simulation. To the right there is “status monitoring” and “control test” interface. For instance, there is no control test function. To configure BMS settings, please contact your installer or seller. Users are not allowed to change the settings. Green Solutions Inc. proprietary...
- Page 21 (2) Multiple Battery Monitoring Interface This interface offers monitoring for all parameter simulation associated with battery modules at the different addresses. The parameter to be monitored is determined by “Pack No.” of the “real time monitoring interface”. Green Solutions Inc. proprietary...
- Page 22 - Over-voltage protection value > over-voltage protection recovery value > over-voltage alarm value > over-voltage alarm recovery value - Under-voltage protection value < under-voltage protection recovery value < under-voltage alarm recovery value < under-voltage alarm recovery value Green Solutions Inc. proprietary...
- Page 23 4) The cycle number represents the number of completed charge and discharge process. This parameter is accumulative and in general it will only be used for maintenance or replacement of the BMS. 5)“Barcode” is the factory model number of the BMS. Green Solutions Inc. proprietary...
-
Page 24: Troubleshooting
5.3 Wet battery If the battery pack becomes wet or immersed in water, ensure nobody touches the enclosure then contact GSI or authorized distributor for technical support. Green Solutions Inc. proprietary... -
Page 25: Battery Damage
GSI or authorized distributor. If there is evidence damage during transportation, restore the packaging and return to GSI or authorized distributors. Attention Damaged battery may leak electrolytes or flammable gas. If this happens, contact GSI after sales service immediately. Green Solutions Inc. proprietary... -
Page 26: Technical Information
-20℃ ~ 35℃ storage for 3 months, Storage temperature capacity recovering ≥95% • -20℃ ~ 45℃ storage for 1 month, capacity recovering ≥95% Recommended storage temperature: 25±5℃ Product internal resistance ≤50mΩ Dimensions 740mm×530mm×217mm Weight 110kg (approx.) Certification UL、CSA Ingress production class IP54 Green Solutions Inc. proprietary... -
Page 27: Appendix
7. Appendix Communication connection: Communication RS232 Conversion to RS485 Pin Illustration Green Solutions Inc. proprietary...
