Summary of Contents for SRC SR-1
- Page 1 SR-1 Instruction Manual Page 1 of 11...
- Page 2 Contents Tool’s Characteristic ---------------------------------------------------------------3 Technical Parameter ---------------------------------------------------------------4 Safety Instructions ------------------------------------------------------------------5 Preparation ---------------------------------------------------------------------------6 Operating Demonstrate ------------------------------------------------------------7 Maintenance and Service ---------------------------------------------------------8-9 Exploded Drawing ------------------------------------------------------------------10 Part List -------------------------------------------------------------------------------11 Page 2 of 11...
- Page 3 Characteristic: ■ Light Weight ■ High-Speed Operation, Big Power ■ Low Noise ■ Small Shock ■ Long Stroke ■ Ergonomics Handle ■ Easy Maintenance ■ Sets up to diameter 4.8mm (3/16”) standard rivets in all materials ■ Rear Adjustable vacuum security system for turning on or turning off mandrel retention function and which is a safety device for operation when detached the mandrel container and which can also save compressed air by adjusting the volume of air when using retention function.
- Page 4 Technical Parameter： Riveting Capacity： Diameter 2.4mm~4.8mm all material standard rivet Air Pressure： 4~7 KGF Stroke： 20 mm Pull Force@5Bar： 8 KN Weight： 1.3 KG Tool Dimension(mm)： 300 X 122 X 265 Page 4 of 11...
-
Page 5: Safety Instructions
Safety Instructions： This instruction manual must be read with particular attention to the following safety direction, by any person installing, operating, or servicing this tool. Never dismantle the tool without first having thoroughly studied the instructions given in this User Manual and applying them. Always use the tool in accordance with the specified safety instructions. - Page 6 Preparation： The tool must be connected to an air filter. This unit filters the compressed air to separate dirt and condensate. A pressure regulator with a preferred setting of 6bar must be installed. Use dry and clean materials (hose, couplings, fittings, etc.) to connect the tool to the filter.
-
Page 7: Operating Process
Operating Process： 1. Connect the air supply then switch ON/OFF valve (48) to “ON” position. （ （ （ （ see Fig 1） ） ） ） Fig 1 2． ． ． ． Adjust the vacuum security system anti-clockwise the vacuum system is on then adjust to optimal volume of air, with the result that the rivet can be sucked well by tool at any orientation. - Page 8 Priming： When the stroke may be reduced and rivets are not fully placed by one operation of the trigger after 100,000 cycles, the tool need to oil. Please use the attached a bottle of lubrication oil in the box. 1．Disconnect air supply to tool and switch ON/OFF valve(48) to “OFF” position. 2．Remove seal screw (70) and seal (69).(see Fig 3) Fig 3 3.
-
Page 9: Troubleshooting
Head Cleaning and Oiling： Every 10.000 cycles the tool should be oiling one drop of lubricating oil on the Jaws. (see Fig 5) Disconnect air supply and air valve switch. Dismantle the riveter head by wrench. Fig5 One drop oil on the Jaws Use wrench to disassemble head components and cleaning these parts ，... - Page 10 Page 10 of 11...
- Page 11 PART NO. DESCRIPTION PART NO. DESCRIPTION SR-1-01 NOSEPIECE SR-1-44 SUBORDINATE TUBE SR-1-02 O-RING SR-1-45 O-RING SR-1-03 NOSEPIECE CASING SR-1-46 CONNECTING BASE SR-1-04 JAW CARRIER SR-1-47 O-RING SR-1-05 JAWS (1set=3pcs) SR-1-48 ON/OFF ASSEMBLY SR-1-06 PUSHER SR-1-49 AIR VALVE ROD SR-1-07 JAW PUSHER SPRING...
