Sealey PREMIER LONG REACH Instructions

Your new jack is produced and manufactured to a high standard of dependability and will, if used according to these instructions and properly
maintained, give you years of trouble free performance
Important: REAd ThESE inSTRuCTiOnS CAREfuLLY. nOTE ThE SAfE OpERATiOnAL REQuiREmEnTS, WARningS And CAuTiOnS.
uSE ThiS JACK CORRECTLY And WiTh CARE fOR ThE puRpOSE fOR WhiCh iT iS inTEndEd. fAiLuRE TO dO SO mAY CAuSE dAmAgE
And/OR pERSOnAL inJuRY And WiLL invALidATE ThE WARRAnTY. RETAin ThESE inSTRuCTiOnS fOR fuTuRE uSE.
1. SAfETY pRECAuTiOnS
Ensure the jack is in sound condition and good working order. take

action for immediate repair or replacement of damaged parts.
Use genuine parts only. The use of improper parts may be
dangerous and will invalidate the warranty.
Locate the jack in a suitable, well lit work area.

Keep work area clean and tidy and free from unrelated materials.

use jack on level and solid ground, preferably concrete. Avoid

tarmacadam as jack may sink in.
Place wedges under wheels of vehicle (but ensure that wheels of

jack can freely move).
Ensure the vehicle handbrake is engaged, engine is switched off

and transmission is in gear (or "Park" if automatic).
Ensure minimum distance of 0.5mtr between vehicle and static

objects such as doors, walls, etc., to allow for vehicle tilting.
Ensure there are no passengers in the vehicle.

Ensure all non-essential persons keep a safe distance whilst the

jack is in use.
only place jack under those lifting points recommended by vehicle

manufacturer (see vehicle handbook).
check the lifting point is stable and centred on the jack saddle.

Ensure the jack wheels are free to move and that there are no

obstructions.
 DanGEr! Use the jack for lifting only, NOT for supporting the lifted load.
use suitable capacity axle stands under the vehicle before

proceeding with any task.
Ensure that there are no persons or obstructions beneath the vehicle

before lowering.
use a qualified person to maintain or repair the jack's hydraulic system.

Do not operate the jack if damaged.

Do not allow untrained persons to operate the jack.

Do not exceed the rated capacity of the jack.

Do not allow the vehicle to move while supported by the jack, or

use the jack to move the vehicle.
Do not jack the vehicle if there is a risk of spillage of fuel, battery

acid, or other dangerous substances.
Do not work under the vehicle until axle stands have been

correctly positioned.
Do not use the jack for purposes other than that for which it is

intended.
Do not top up the hydraulic system with brake fluid. use hydraulic

jack oil only.
Do not adjust the safety overload valve.

When not in use store jack, fully lowered, in a safe, dry, childproof area.

 WARning! It is very dangerous to go under a vehicle which is
supported by a jack even if additional supports are used. Do not go
under a vehicle unless it is supported by adequately rated axle stands.
 impORTAnT! Ensure that you can see the saddle and
jacking point throughout the jacking operation in case
there is any relative movement.
2. SpECifiCATiOn
model: ............................................ TJ6 .................TJ10 ............ TJ15
capacity.......................................... 6ton ................10ton .............. 15ton
Min. saddle height .................... 170mm .............170mm ........... 195mm
Max. saddle height ................... 580mm .............605mm ........... 600mm
Max. chassis height ................... 220mm .............270mm ........... 265mm
Length...................................... 1310mm ...........1600mm ......... 1750mm
Weight ............................................82kg ............... 123kg ............. 145kg
Models nos: TJ6, TJ10.v3, TJ15.v2.
.
InstructIons for:
TROLLEY JACKS
pREmiER LOng REACh
TJ10
TJ15
3. bEfORE uSE
3.1 Assemble the handle.
Insert the handle into the socket and fix it with the screw provided.
3.2 check oil level.
3.2.1 Ensure the jack is resting on level ground and that the ram is
fully retracted. Hold open the release valve for 10 seconds by
lifting and turning the handle clockwise
3.2.2 remove the access plate from the top of the jack. Identify the
filler plug in the top surface of the main barrel and remove it.
the oil level should be level with the bottom of the filler hole.
3.2.3 If necessary, top up with hydraulic oil. use only sealey
hydraulic jack oil (see your authorised sealey dealer).
TJ6
tJ6,tJ10.V3,tJ15.V2 - 1 - 220208
