Adaptive Steerables TCK2 Series Installation Manual

Installation Guide
QUICKLINK,
3/8" (2X)
Figure 1
Note:
Before installing, make sure that
loudspeakers are equipped with the right
eyebolts or other load rated hardware.
FIXED LENGTH
PULL BACK
CABLE-THIS
CABLE CONTROL
FIXED LENGTH
SPEAKER
THE TILTING OF (18", 22", OR 36")
H THE SPEAKER
CLUTCH LOCK
WITH EYENUT
G
END LOOP
OF PULL BACK
CABLE
EYEBOLT
SPEAKER
Figure 2
1 of 2
FIXED LENGTH CABLE (2X)
(18", 22", OR 36")
.188 OVAL
SLEEVE (8X)
.188 THIMBLE
(2X)
.25 SHACKLE
(4X)
The Steerables Dual Pulley Tilt Cable kit serves as a suspension and pull
back device for flyable loudspeakers in a wide range of rigging applications. It
provides an easy and infinite adjusting features for loudspeakers and objects
weighing up to 220 lbs (134 Kg). The Steerables TM dual Pulley Tilt Cable Kit
comes in standard fixed length of 18", 22", 30", 36" and 40. Custom length
Dual Pulley Tilt Cable kits are also available.
Note to installers
Due to the wide variety of wall structures, materials and mounting
methods, the installing contractor must exercise proper judgment in
selecting the mounting area and hardware.
As a guide, the installation, when complete should be capable of
supporting 5 times the actual applied load. Also, always use a back up
safety system such as a safety cable.
To assure a trouble free installation, read through and follow these
instructions carefully before beginning. If you have doubts about
the integrity of the structure you are mounting to or you are not
sure about the proper hardware to use, consult a structural and/or
hardware specialist.
Be sure that all of the following items are included in this kit before
proceeding:
2 pcs Fixed length cable (18, 22 or 36)
FIXED
6 pcs 3/8" quicklink
LENGTH
PULL BACK
CABLE-THIS CABLE (2X)
2 pcs Snatch block pulley
CABLE CONTROL
THE TILTING OF
2 pcs Wire rope clip, 1/8"
THE SPEAKER
Step 1: Attach fixed length cables
Attach one end of each fixed cable to the top anchor points of the speaker
CLUTCH LOCK
WITH EYENUT
(such as eyebolt, track fitting, etc) using supplied quicklink (Figure 1)
Step 2: Assemble pull-back cable to fixed cable
Attach the clutch lock's eye nut to one of the rear suspension point
END LOOP
(such as eyebolts, track fitting, etc) of the loudspeaker using supplied
OF PULL BACK
CABLE quicklink (Figure 2).
EYEBOLT
Step 3: Attach the end loop of the pull back cable to the other rear
suspension point (such as eyebolts, track fitting, etc) of the loudspeaker
using supplied quicklink (Figure 3).
END LOOP
OF PULL BACK
CABLE
Steerables™ Dual Pulley Tilt Cable Kit
Figure 3
TCK2-SERIES
END LOOP
OF PULL BACK
1 pc Pull back cable
CABLE
1 pc Clutch lock assembly
2 pcs Threadlock, .02 Oz tube
1 pc Instruction sheet
SNACTH BLOCK
PULLEY
PULL BACK
CABLE
Figure 4
FIXED
LENGTH
CABLE
REV01-10292024
