Red Shed 2085884 Instruction Manual

RS 10FT SKELETON
Instruction Manual
SKU# 2085884
Thank you for purchasing the Life-Skeleton with Lighted Eyes!
Below you'll nd assembly instructions and other information to get
maximum enjoyment from your purchase!
Please read instructions carefully before use.Retain for future reference.
P A C K A G E C O N T E N T S
LABELED PARTS
A B C
Front Base Back Base Right Foot
G H I J K
Right Femur T-Bar Pelvis Ribcage
Left Femur Support Pole
O P
A. Front Base 1pc I. T-Bar Support Pole
B. Back Base 1pc J. Pelvis
C. Right Foot 1pc K. Ribcage
D. Left Foot 1pc L. Spine
E. Right Fibula 1pc M. Right Arm
F. Left Fibula 1pc N. Left Arm
G. Right Femur 1pc O. Skull
H. Left Femur 1pc P. Ground Stakes
Skull Ground Stakes
P R E P A R A T I O N
Estimated Assembly Time: 15 - 20 minutes
Before assembling the product, carefully remove all parts from the box and lay out on a at surface.
Make sure all parts are present. Compare parts with package contents list.
If any part is missing or damaged, do not attempt to assemble, install or operate the product.
Read through directions before assembling.
1
1
B
A
D E F
1. Set front and back base parts (A and B) on a
level and stable surface. Connect the two base
parts and ensure the pushpins are locked
in place.
4
Left Foot Right Fibula
Left Fibula
G
L M N
E
Spine Right Arm
Left Arm
4. Place right femur (G) onto the right bula
(E). Repeat the process for the left femur (H)
and left bula (F).
1pc
1pc
1pc
1pc 7
I
1pc
1pc
1pc
5pcs
J
G H
7. Ensure the pelvis (J) is in the upright
position and locked into place with the pole
of the T-bar (I) positioned upward.
A S S E M B L Y I N S T R U C T I O N S
2 3
D
C
E F
D
C
2. Take right foot (C) and place the heel over the 3. Place right bula (E) onto the right foot (C).
post on the front base (A). Repeat the process Repeat the process for the left bula (F) and the
with the left foot (D) and back base (B). left foot (D).
5 6
I
I
H
G
J
F
5. Insert the T-bar (I) into the openings 6. Connect the pelvis (J) and T-bar (I) to the upper femurs (G,H) by
of the lower pelvis (J). sliding the "T" into the corresponding openings of the bones. Push
together and lock into place.
8 9
L
K
8. Connect the ribcage (K) and spine (L) by 9. Connect the wires between ribcage (K)
placing the ribcage (K) upside down on a at and spine (L).
surface. With the spine (L) upside down,
slide it onto the ribcage (K) and lock into
place.
2
A S S E M B L Y I N S T R U C T I O N S
10
M
K
M
K
H
11
O
K
11. Insert skull (O) into the top of the body.
13
L
J
I
K
13. The recommended method to attach the upper body and lower body is
to lay each section at. Place the assembled upper body onto the item's box.
Lift the lower body and slide the T-bar (I) into the spine (L) and gently lock
into place.
M
K
10. Lay at the connected ribcage and spine (K,L) to attach the arms (M,N).
Insert the right arm (M) into the upper body (K,L). Repeat process for the left
arm (N).
12
O
K
12. Connect the wires between skull (O) and assembled body.
