TIGHTENING
BASE SCREW
KNOB
2 PCS
A
PLASTIC BASE
1 PC
PRODUCT ASSEMBLY
1.
Take out the Plastic Base (A) and check the components as illustrated.
a, If the dimension of umbrella tube is 1.9", just put 1.9" Pipe Sleeve (C1) into the Extend Pole (B).
b, If the dimension of umbrella tube is 1.5", put 1.5" Pipe Sleeve (C2) into C1, and then put them
together into the Extend Pole (B). Then attach 2 pcs of Tightening Knobs (Part 1) to fix the Pipe Sleeve.
C1
B
10
3
WASHER
1 PC
1 PC
B
C1
EXTEND POLE
1 PC
1
1
a
RS PLASTIC OUTDOOR
PATIO UMBRELLA STAND
1981481
4
ALLEN
WRENCH
1 PC
C2
1.9" PVC
PIPE SLEEVE
PIPE SLEEVE
1 PC
C1
B
1.5" PVC
1 PC
C2
1
1
b
Advertisement
Table of Contents
Related Manuals for Red Shed 1981481
Summary of Contents for Red Shed 1981481
- Page 1 RS PLASTIC OUTDOOR PATIO UMBRELLA STAND 1981481 TIGHTENING ALLEN BASE SCREW WASHER KNOB WRENCH 2 PCS 1 PC 1 PC 1 PC PLASTIC BASE EXTEND POLE 1.9″ PVC 1.5″ PVC PIPE SLEEVE PIPE SLEEVE 1 PC 1 PC 1 PC...
- Page 2 Put the Extend Pole (B) into the Plastic Base (A), attach the Washer (Part 3) and Base Screw (Part 2) using Allen wrench. Take off the cap to fill in with sand or water. Seal the cap back. You finish the assembly! SAND WATER CAUTION:...
