Summary of Contents for Talk electronics Edwards Audio TT1
- Page 1 V1.0 TALK Electronics Edwards Audio Series TT1 User Manual TALK Electronics 3 Eliot Close CAMBERLEY Surrey GU15 1LW Phone: +44(0)8456 123 388 www.talkelectronics.com...
- Page 2 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE POWER SUPPLY UNIT COVER. THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL. Please read this manual carefully and keep it in a safe place for future reference.
- Page 3 • Before connecting the AC power cord to the Power supply unit, make sure the voltage of the Power supply unit, as marked on the label on thebottom, corresponds to the local electricity supply. • If this apparatus does not operate normally in particular, if there are any unusual sounds or smells, unplug it immediately and consult an authorised dealer, service agent or re-seller.
- Page 4 Table of Contents 1. Safety Instructions 2. Un-packing list 3/4. Setup & Connections 5. Adjustments 6. Operation 6. Guarantee Thank you for purchasing an Edwards Audio series turntable, with care over the correct installation we are sure that it will give many years of pleasure Inside the box you will find the following items supplied as standard:- 1.
- Page 5 Remove one of the foam pieces and then remove the top cover and rear foam piece. Under the top cover you will find a large square of foam in the top of which you will find the counterweight, remove the counterweight from the foam and place it somewhere safe.
- Page 6 In most cases your dealer may have already fitted a cartridge for you, in which case you can skip this section and move on to the section on setting the tracking weight. To fit the cartridge can be quite difficult, especially if you have not done it before, however if you follow this step by step guide you should have no problems.
- Page 7 that the cartridge does not twist and is still parallel in the headshell. Re-check that the stylus is still on the cross and then go to the second point (if provided) and confirm that it is OK, KEEP RE-ADJUSTING UNTIL IT IS CORRECT. With the stylus guard removed, gently screw the counter weight on from the rear until the arm is in balance, I.e.
- Page 8 dealer distributor registered website www.talkelectronics.com. manufacturer take responsibility for defects arising from accident, misuse, abuse, wear and tear, neglect or through unauthorised adjustment and/or repair, neither can they accept responsibility for damage or loss occurring during transit to or from the person claiming under the guarantee. THE WARRANTY COVERS parts and labour costs for ten years from the purchase date.
- Page 9 Dimensions WxHxL......450mm x 105mm x 350mm Weight................5.5kg Power consumption (Max)............3.0W Performance is ultimately dependent upon the quality of the Mains supply is part of TALK Electronics 3 Eliot Close, Camberley, Surrey GU15 1LW UK Telephone 08456 123388 or 07736 421928 fax 01276 613250 email:- info@talkelectronivs.com website:- www.talkelectronics.com...
