自主科技,自由生活 产品简介 本产品为F5050多媒体数码相框,使用6.5英寸TFT-LCD显示面板,采用多媒体技术,具有以 下特点: l 图片具有旋转/ 9 画面(3*3)浏览功能; l 图片自动幻灯片播放,具备多种特殊播放效果; l 图片具有翻转记忆功能; l 用户可设置自动播放间隔时间; l 支持 SD、MMC 主流存储卡; l 最大可支持 1200 万像素图片文件; l 支持 U 盘数据存储设备; l 内置存储器;可以存储十六张左右任意大小的图片; 包装内容 R电源适配器 R说明书 RUSB转接线 R跟踪卡 R合格证 R精品手册 R三包卡 注:以上各附件以实物为准。 外观、组装结构 前部 1 显示屏 2 前框...
Freedom in technology Freedom in life Important safety instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Page 25
Freedom in technology Freedom in life l This product is hot-swappable. However, it is suggested to power off this product before plugging/unplugging your memory card, to protect the memory card or other devices. l We strongly recommend you to use the power adapter delivered with this product to ensure the display effect.
Page 26
Freedom in technology Freedom in life Table of Contents Product Introductions ....................24 Packing List .........................24 Appearance and Assembly ..................24 Front panel..................................24 Back cover...................................25 Bottom ..................................25 Assembling Stand ..............................26 Power Connection..............................26 Button Introductions ....................27 Machine buttons ......................27 Operational Introductions ..................27 Function Select................................28 Image...................................28 Calendar ..................................30 Favorite..................................30...
Freedom in technology Freedom in life Product Introductions The F5050 multimedia digital photo frame is used the 6.5" (6.5-inch) TFT-LCD panel and the multimedia technology, it has the following features: l Rotating/zooming-in/zooming-out/moving/reviewing pictures and 9-picture reviewing (3×3) l Automatically displaying pictures in slide show mode, supporting many kinds of special display effect l Supporting the customized interval of automatic display.
Freedom in technology Freedom in life Back cover ESC Button Up Button Enter Button Left Button Right Button Down Button Power Button 10 Power Indicator 11 Radiator 12 Back Frame Figure 2 13 Stand Bottom 14 USB port 15 SD/MMC Card Slot 16 DC Power Jack Figure 3 北京华旗资讯数码科技有限公司...
Freedom in technology Freedom in life Assembling Stand Insert the front end of the stand to the slot on the back cover, and then push the stand as illustrated in Figure 4, until the support is locked properly (Figure 4) . Figure 4 Power Connection Connect the power cable of the power adapter delivered with the photo frame to the...
Freedom in technology Freedom in life Button Introductions Machine buttons 1) Move up the cursor at the menu. Up Button 2) Rotate picture clockwise while viewing. 1) Move down the cursor at the menu. Down Button 2) Rotate picture counter-clockwise while viewing. 1) Move the cursor to the left at the menu.
Freedom in technology Freedom in life Function Select Select each function: image, calendar, favorite, file and setup. 。 : Move cursor • • 。 :Enter the selected function interface • 。 ESC: Go back to up-level menu Image Select icon, press to enter image interface, Firstly, appear the 9-picture view mode.
Page 32
Freedom in technology Freedom in life NOTE: If a SD\MMC card and a USB drive have connected to the equipment before startup, it will read image in USB drive first. If connect these memories after boot-strap, it will read image in the later one. Play photo: •...
Freedom in technology Freedom in life Calendar Select icon,press to enter calendar interface. • : Lookup year. • : Lookup month. The left interface is time and alarm clock window, top left corner will circle display image in currently memory. Bottom left corner is alarm clock window; on the right is calendar window, press to enter calendar setup menu, as the following figure.
Freedom in technology Freedom in life File Select icon,press to enter file management interface. Equipment selection window List window Folder window File list Preview picture window In file management interface. If there is no external memory, and this machine will read the internal memory, if it has connected external memory, it will appear icon at the right of the equipment selection window.
Page 35
Freedom in technology Freedom in life The operation for folders and files to select folder, press to enter selected folder. Move cursor into list window, press to return to up-level folder. Press to move cursor into file list. • Move cursor. •...
Page 36
Freedom in technology Freedom in life If there is same name nominal file, it will appear follow figure. It means the paste has failed. Select "ok" to exit this dialog box. Note: When copy pictures from external memory to internal memory (NOR Flash), the system will rename those pictures with number, and realign.
Freedom in technology Freedom in life Setup Select icon,press to enter setup interface. • Move cursor. • Adjust parameter. • Exit. The content of setup menu Setup the transition effect in auto play mode: random, None, Zigzag Top, Zigzag Bottom, Box, Blinds (LR), Shutter, Spiral, Transition Effect Bardoor (TD), Bardoor (LR), Cross, Cross Comb, Stripe (TD), Mask, Dissolve, Bar, Push (LR), Diagonal (LB2RT), Diagonal...
Freedom in technology Freedom in life Connect external equipment l Connect USB drive/SD/MMC card This machine can connect USB drive and SD/MMC memory card. •Turn on the power •Connect USB drive with the accessory USB cable •Connect SD/MMC card through bottom slot NOTE:Since there are many brands of cards, please test the compatibility on the spot when you buy the cards (this product could not support pirate cards).If the machine couldn’t read the card after checking the inserted end of the card is right, please turn off...
Freedom in technology Freedom in life Trouble Shooting Malfunctions Possible Causes Methods Check whether the Power Indicator Power off or Power Indicator broken adapter is connected unlighted well Check whether the adapter is connected Adapter connected wrongly or power on No Start-up Interface well or whether power abnormally...
Freedom in technology Freedom in life Technical Specification F5050 Model Name LCD Size 6.5-inch, 4:3 analog TFT LCD Active area LCD Panel 137 (W)×86.58(H) mm product Resolution 480(RGB) x 234 Format JPEG (base line) Photo Play Max. resolution 12 Mega-pixel DC input +5VDC,1A MAX Power Consumption...
Freedom in technology Freedom in life Limited Warranty l We pledge this: For the F5050 series products, the guarantee period is one year since the purchase date. For any faults caused by non-human factors in the normal use of the device, we provides free repair. For any faults by the human factors or after the guarantee period, we provide paid maintenance and relevant materials.
Page 42
Freedom in technology Freedom in life 北京华旗资讯数码科技有限公司 Version:1.0...
Page 43
Freedom in technology Freedom in life 北京华旗资讯数码科技有限公司 Version:1.0...
