Product Introduction............................................. 2
Technical Specifications ......................................... 2
Packing List..................................................... 3
Appearance and Assembly ....................................... 3
Front panel ......................................................................................................... 3
Back cover ......................................................................................................... 3
Bottom................................................................................................................ 4
Assembling support............................................................................................ 4
System connection ............................................................................................. 4
Buttons introduction............................................. 6
Machine buttons................................................................................................. 6
Remote control keys (optional) .......................................................................... 7
Introductions to Display Modes................................... 8
1. Preset mode .................................................................................................... 8
2.Card Reading Mode ...................................................................................... 17
3.USB Working Mode...................................................................................... 17
Statement ...................................................... 19
Trademark Statement ........................................... 19
Table of Contents
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aigo F5005
Summary of Contents for Aigo F5005
-
Page 1: Table Of Contents
自主科技 自由生活 Product Introduction... 2 Technical Specifications ... 2 Packing List... 3 Appearance and Assembly ... 3 Front panel ... 3 Back cover ... 3 Bottom... 4 Assembling support... 4 System connection ... 4 Buttons introduction... 6 Machine buttons... 6 Remote control keys (optional) ... -
Page 2: Product Introduction
自主科技 自由生活 Product Introduction The F5005 multimedia digital photo frame is used the 8" (8-inch) TFT-LCD panel and the multimedia technology, it has the following features: Rotating/zooming-in/zooming-out/moving/reviewing pictures and 9-picture reviewing (3×3) Automatically displaying pictures in slide show mode, supporting 13 kinds of special display effect... -
Page 3: Packing List
自主科技 自由生活 Resolution of Liquid Crystal Display (LCD): 800×480 Effective display area: 158*99.36mm Packing List Refer to the information on the colored box (including accessories and optional accessories). Appearance and Assembly Front panel 1. LCD 2. Receiving window for remote control signals (reserved) 3. -
Page 4: Bottom
Multicolor F5005 and carefully separate the compete frame from the screen. Next, to separate the inner frame from the outer frame, press the back of the inner frame firmly and ease the two frame apart. Now simple choose your new frame color and replace, reversing the procedure above. - Page 5 自主科技 自由生活 Figure 4.5...
-
Page 6: Buttons Introduction
自主科技 自由生活 Buttons introduction Machine buttons: Up Joystick button: 1）Move up the cursor at the menu. 2）Open brightness adjustment menu at playing interface. 3）Switch picture control bar and music control bar (After use button “ENTER” open the control bar). 4）Shift up when zoom in picture. 5）Pageup at the first line of 9-picture thumbnail. -
Page 7: Remote Control Keys (Optional)
自主科技 自由生活 “ENTER” button: 1）Confirm perform selected item. 2）Open control bar at the file playing interface. “ESC” button： Exit Power switch: Turn on or cut off the power supply. When it is on OFF, the power is off; when it is pushed upwards to ON, the power is on;... -
Page 8: Volume Keys
1. Preset mode： After assembling support and connect adapter well, turn on the power supply without memory card inserted, to see the“aigo” logo interface. Start interface will be seen on screen. According to “System Setup”(User could setup image ,music, movie, file list and calendar as start interface, default setting is calendar, Figure 6.1). - Page 9 自主科技 自由生活 Select NAND icon and press “ENTER” button at the card menu, the system enter the function select interface. (Figure 6.3). 1-1> At the function select interface, select picture view mode will appear by the 9-picture thumbnail mode. (Figure6.4). Press“Esc” button to return function select interface.
- Page 10 自主科技 自由生活 Through the Joystick you can choose one of 9-picture thumbnail, press ENTER button display selected picture. And then play the pictures which in current directory automatically, press “ESC” button to stop playing, return 9-picture thumbnail by press “ESC” button again. During display picture, through Joystick brightness menus of screen （figure 6.5a）...
- Page 11 自主科技 自由生活 The functions of picture control bar are shown as below figure 6.7. Status Play/Pause Press STOP key at control bar back to function select interface；press “ESC” button at picture view menu back to 9-picture thumbnail. 1-2>At the function select interface, through Joystick choose music play menu（figure 6.8）.
- Page 12 自主科技 自由生活 System search music files in the current memory equipment and play them automatically. During music playing, uses the control bar to perform control operation, the functions are shown as figure 6.9. Press move the option to “play mode” ,there are three modes in this option, “standard”, “ repeat one” and “dir. repeat”, press “ENTER”...
- Page 13 自主科技 自由生活 The functions of video control bar are shown as figure 6.12. Under function switch, Press information, play mode”, at the item of play mode , press “ENTER” to switch “standard play, repeat one, dir repeat”. Time Status Play/pause Press “ESC”...
-
Page 14: Delete File
自主科技 自由生活 You can delete or copy files at the list. Delete file： button to shift cursor to target file， press ” （figure6.15） ，press symbol“ User can choose multi-files to operate. （Figure 6.16）. Figure 6.14 button, the left of file will appear the selected button again to cancel selection. - Page 15 自主科技 自由生活 After you select file, long press “ENTER” button to open operation menu.（Figure 6.17）. Press button and shift cursor to icon deleted.（figure 6.18） Press “ENTER” button return to file management menu. Copy file： Press button and shift cursor to target file, press Figure 6.16 Figure 6.17 ，press “ENTER”...
- Page 16 自主科技 自由生活 “ ”. After file select, press button to open file operation menu, select If the space of the memory device is not enough, error information will be shown, copy operation unsuccessful. 1-5>At the function select interface, through Joystick the system setup menu.（figure 6.20）.
-
Page 17: Card Reading Mode
自主科技 自由生活 The buttons’ operation method is shown as below： button：shift items or choose parameters. or “ENTER” button：enter the selected item, confirm the setup result. or “ESC” button： Back to the up-level item/the previous picture or forward to the next picture. 2.Card Reading Mode：... - Page 18 自主科技 自由生活 After the USB interface of the equipment is connected to a portable memory, the system enters the USB Host mode (as shown in figure 6.23) When use “USB Host” function, USB stick and other USB equipments will be named to“UDISK” and appear at file list.
-
Page 19: Statement
Statement aigo pledges this: For the F5005 series products, the guarantee period is one year since the purchase date. For any faults caused by non-human factors in the normal use of the device, aigo provides free repair. For any faults by the human factors or after the guarantee period, aigo provides paid maintenance and relevant materials. - Page 20 自主科技 自由生活...
- Page 21 自主科技 自由生活...
- Page 22 自主科技 自由生活...
