Summary of Contents for SAHLINS 2042
- Page 1 No 9972-2042010 LINE MACHINE 2042 USER MANUAL...
-
Page 2: Table Of Contents
CONTENT Thank you for choosing a SAHLINS product! ....................3 Safety rules ..............................4 Introduction..............................7 Technical data ............................... 8 Components ..............................9 Operation ..............................10 Before starting ..........................10 Assembly ............................ 10 Manoeuvring ............................... 12 Maintenance ............................... 15 (EN) EC declaration of conformity (SV) EG-försäkran om överensstämmelse (FR) EC... -
Page 3: Thank You For Choosing A Sahlins Product
THANK YOU FOR CHOOSING A SAHLINS PRODUCT! We want you to be happy with your equipment. This instruction manual has been written to facilitate its safe handling and maintenance. Please read the manual thoroughly before using the equipment so that you are aware of the safety measures you need to take when using it. -
Page 4: Safety Rules
SAFETY RULES General safety Measures 1. Read and acquaint yourself with all of the warnings, precautionary measures and instructions in the user and care manual, and read and learn the importance of all the signs on and around the equipment. In case of any doubt, ensure that you have answers to all your questions before starting the work. - Page 5 20. Before starting on operating equipment, ensure that no people, animals, tools, spare parts or other foreign objects are present in, on, under or around it. Check that all protective and safety equipment is correctly installed and in satisfactory condition 21.
-
Page 7: Introduction
INTRODUCTION Line machine 2042 is a portable overhead cable winch for running overhead cable and bare wire on a pilot rope drum - demolition and replacement using a split drum. The winch is constructed in three manageable base units: engine with gearbox, frame and drum holding frame that can be quickly connected to a wooden post. -
Page 8: Technical Data
TECHNICAL DATA LINE MACHINE 2042 Model 2042 Pulling speed 0 - 100 m / min Pulling force Max 400 hp Engine Honda type GX 160, four-stroke, air-cooled, petrol 5.5hp Power 5.5 hp Self-braking worm gear, forward and reverse. Self-braking (automatic... -
Page 9: Components
COMPONENTS ARTICLE NUMBER NAME 2042-3000 Honda petrol engine 5,5 hp 2050-0180 Exhaust hose 2042-0010 Storage box 2040-0111 Pilot rope drum 7512-060550 Pilot rope 6 mm x 550 m 2042-0020 Post frame 9809-010 Line spreader... -
Page 10: Operation
OPERATION BEFORE STARTING The line machine is reliable in design to provide safety. It can help you to perform your work logically and make your job easier. However, it is important that you follow these instructions carefully as improper handling can be hazardous. Check that all equipment has not been damaged or deformed. - Page 11 Mounting the drum - Lift off the eccentric lock on the left side of the bracket (1), fold up the bearing cover, check that the groove in the drive shaft points forwards, upwards and to the side and insert the drum to be used. - Insert the shaft pin on the drum into the milled groove on the drive shaft (2).
-
Page 12: Manoeuvring
MANOEUVRING WARNING Before operating the machine, read the operating instructions for the Honda GX 160 engine unit and make sure that you understand how the controls work. Check that all equipment to be used has not been deformed or damaged in any way. Speed is controlled using the engine throttle. - Page 13 The drum should only be used with a genuine 3-stroke Polynite with a min. breaking load of 800 kp. (6 mm L 550/1100 m) For any other ropes, contact Sahlins Sweden AB for approval before use. Use swivels between the traction rope and the cable sleeve.
- Page 14 Using the steel wire drum WARNING! Before pulling in, check that cable has not been damaged or incorrectly spliced. WARNING! When pulling, make sure that the pulling force does not exceed the rope’s pulling strength. (See the technical data) WARNING! Always use a line spreader during all kinds of pulling to prevent accidents.
-
Page 15: Maintenance
MAINTENANCE Engine maintenance See the operating instructions for the Honda GX 160. General maintenance Check and lubricate the shaft coupling and drum locks. Check the tow line regularly for signs of damage. Transportation and storage of the line machine Transport and store the machine in its original storage box. -
Page 16: (En) Ec Declaration Of Conformity (Sv) Eg-Försäkran Om Överensstämmelse (Fr) Ec Déclaration De Conformité (De) Eg-Konformitätserklärung (It) Dichiarazione Ce Di Conformità
(EN) EC DECLARATION OF CONFORMITY (SV) EG-FÖRSÄKRAN OM ÖVERENSSTÄMMELSE (FR) EC DÉCLARATION DE CONFORMITÉ (DE) EG-KONFORMITÄTSERKLÄRUNG (IT) DICHIARAZIONE CE DI CONFORMITÀ... - Page 17 Sahlins Sweden AB Företagsvägen 2 512 64 Holsljunga, Sweden +46(0)320 209 330 | sales@sahlins.com 01/05/2021...
