Tools Required:
For your convenience we use Recex rust resistant zinc plated hardware.
You will need a #2 Philips or Robertson screwdriver a 1/2" wrench.
Package Contents
(A) Posts... 4
(B) Pagoda Header... 2
(C) X-Member... 4
(D) Long Slat... 8
(E) Short Slat... 14
(F) Canopy Slat... 13
(G) Header Brace... 4
Hardware:
•
2" Screw... 76
•
2 ½" Screw... 50
•
3 ½" Carriage Bolt... 8
•
Washer... 8
•
Hex Nut... 8
STEP 1. Build Frame
•
Set 2 posts on edge and place two x-members between them.
•
Arrange scallop cutouts to face each other
•
Center x-members on post and attach 6 inches from
each end using 2-1/2 inch screws.
•
Repeat for other frame
Pagoda Wedding Arbor
:
PA106
Advertisement
Related Manuals for All Things Cedar PA106
Summary of Contents for All Things Cedar PA106
- Page 1 Pagoda Wedding Arbor PA106 Tools Required: For your convenience we use Recex rust resistant zinc plated hardware. You will need a #2 Philips or Robertson screwdriver a 1/2" wrench. Package Contents (A) Posts… 4 (B) Pagoda Header… 2 (C) X-Member… 4 (D) Long Slat…...
- Page 2 3/4 their length into the ground and bolted to the side of each arbor leg. • Alternativly the arbor can be fitted with rebar post anchors available at your hardware store. ♥ ♥ Thank you for choosing All Things Cedar...
