Summary of Contents for J.ASSY Selenium ELECTRIC
- Page 1 INSTRUCTION MANUAL...
- Page 2 Resolution 680 - Anatel: This equipment is not entitled to protection against harmful interference and cannot cause interference in duly authorized systems. For more information see the Anatel website: www.anatel.gov.br 07768-20-04649 15359-22-04649...
-
Page 3: Table Of Contents
Crop Exchange Hydraulic Alternator Connecting the Alternator to the Tractor Turning on the Alternator Switching Off the Alternator Alternator Kit Selenium Electric Distribution Wiring Pro Wiring Installation Pro Electric Dosing Line ECU Installation Wifi antenna installation GPS Antenna Installation Lift Sensor Installation Virtual Terminal Confi... -
Page 4: Presentation
Presentation Doser Doser Easy-to-handle pneumatic seed doser, which has a high singulation doser, which has a high singulation performance, designed so that there is no regulation in the fi eld. Conductor Doser 1.05.0353 Developed to perform line automation in planters with Pro Selenium driver mechanical transmission by cardan subassembly kit... - Page 5 Doser/Feeder The Selenium Electric Seed Doser/ Feeder consists of a pneumatic Electric motor selenium feeder driven by individual electric motors per row, replacing the planter's entire 1.05.0139 mechanical transmission system, Motor Kit 100 RPM where all planting control is done 1.05.0142...
-
Page 6: Main Components
Main Components Selenium Gravity seed 1.05.0077 nozzle kit Selenium Gravity seed nozzle kit 1.05.0178 swivel nozzle 2.5 In Selenium Gravity seed swivel 1.05.0160 nozzle kit swivel nozzle 3 In 1.05.0391 Selenium seed nozzle kit quick coupling with double screen Selenium front air intake kit 1.05.0099 1.05.0101 Selenium display kit... - Page 7 Disk, Organizer and Rosette Set Trim Kit (Blanket) 1.05.0060 Conductor - High Nozzle Trim Kit (Blanket) 1.05.0061 Conductor - Low Nozzle Selenium Seed 2.02.0119 Conductor Technical Specifications VT1 Rework Selenium Seed 2.02.0160 Conductor Vacuum Nozzle diameter JM2 (wo/hole) Rework 2.02.0163 Deimensions: Selenium Seed Sonductor 414mm (Al) x 206mm (An) x...
- Page 8 1.05.0141 1.05.0260 Selenium Electric Driver Selenium Electric Driver Doser Selenium Rail Subassembly Kit Rail Subassembly Kit Electric motor support kit 1.05.0139 Doser 100 RPM motor kit Selenium Electric 1.05.0142 Motor outer protective cover kit 1.05.0228 Pro Selenium latch kit 1.05.0353...
-
Page 9: Handling
Handling Choice of crop Each crop has a unique kit and there is no need to perform any adjustment or adjustment on the disc, organizer and rosette assembly. Vacuum/lid side Seed side Lower Organizer Disc Singulator Disc Hole Rosette Organizer Ring Lower Ring Organizing blades Disc Color... -
Page 10: Disc Assembly
Disc Set To correctly insert the disc assembly into the doser, follow the steps: Gauntlet Gauntlet Gauntlet Disc Lock (counterclockwise) 2. Rotate the disc lock 1. Open the doser cover by turning counterclockwise to the end of its the Gauntlet counterclockwise. stroke. -
Page 11: Crop Exchange
Crop Exchange 1. Push the Hopper drawer, in the direction indicated in the image below (image 1), until the end of the course. In this position, Hopper will be closed, displaying the indication ““CLOSED FECHADO”. Selenium filled with seeds Hopper Drawer Image 1. -
Page 12: Hydraulic Alternator
SELENIUM has a display that offers the possibility of monitoring the result the possibility of monitoring the result of the organization of the seeds on the disk. After checking the singulation, keep the display closed. Hydraulic Alternator The alternator is the equipment responsible for producing the electrical energy that powers the motors of the ELECTRIC SELENIUM only. - Page 13 Chassis mounting with narrow Chassis mounting with wide pipe. pipe. List of planter line numbers, alternator rpm and tractor oil consumption. Oil fl ow ² (I/min) No. of rows Recomen.¹ Min. Max. up to 20 3,000 14.1 2,000 3,000 2,500 17.7 3,500 3,000...
-
Page 14: Connecting The Alternator To The Tractor
Connecting the Alternator to the Tractor Before connecting the alternator, check that the tractor has a low pressure return installed. PRESSURE RETURN DRAIN Scenario 1 - The tractor has the low pressure return installed. PRESSURE RETURN DRAIN Scenario 2 - The tractor does not have the low pressure return installed. -
Page 15: Turning On The Alternator
IMPORTANT: The hydraulic motor has only one direction of rotation. Stay tuned, because if triggered incorrectly the alternator will not be turned on ATTENTION: Avoid accidents at connection time 1st - Connect the drain hose 2nd - Connect the return hose 3rd - Connect the pressure hose *Use reverse order for disconnection Turning on the Alternator... -
Page 16: Switching Off The Alternator
ATTENTION: Alternator rotation information can be viewed on the J.Assy ISO screen in the rpm tab. Turning off the Alternator If the return line is connected to the Remote Control Valve (VCR), it will be necessary to use the “Float” position of the hydraulic control:... -
Page 17: Selenium Electric Distribution Wiring
Increase the alternator rotation by opening the VCR oil flow in which the hydraulic hoses are connected, around 3,500 RPM, following the number of revolutions on the monitor. After the end of use, with the tractor stopped, turn the key of the tractor to turn it off. -
Page 18: Installation & Wiring
1 line 1.05.0084 MONITOR Maxiumu Current: 100A 4 lines Rotation Range: 2000 to 6500 RPM 1.05.0085 Oil Consumption: 14 to 45 LPM. Selenium Electric Gravity 1.03.0050 1.04.0030 ICOBUS ELECTRIC 3” Swivel Nozzle with Disk ECU Assembly Kits 1.03.0090 Selenium Electric Gravity 2.5”... -
Page 19: Pro Electric Dosing Line
HARNESS Kit (1.05.0222), it is possible to generate as many outputs as the number of physical sections of the machine, to ensure that the cables do not hinder the opening and closing movements of the planter. ISOBUS CABLE WIRING DISTRIBUTION POWER SOCKET 1 line 1.05.0084... -
Page 20: Ecu
To turn on the Pro Selenium, locate the driver controller box below the display. Plug the line cable plug into the 2-pin socket on the driver for power. 12V power supplied by 1 way or 4 way cables. Connector for 4-pin pulsed seed sensor (Dickey John standard sensor). -
Page 21: Ecu Installation
ECU Installation Guidelines: 1- Position in the central region of the machine, so that the tractor operator can see the operation indication led. 2 - The connectors must be facing downwards to prevent the accumulation of water. Installation of wifi antenna Guidelines: 1 - Installed in the central region of the machine using the fastening part provided (can be installed face down if necessary). -
Page 22: Lift Sensor Installation
Assembly notes: With the description of the brand logo, ECU, positioned upwards, the left side connects to the communication antenna and the right side to the GPS antenna. ECU Assembly Installation of the Lift Sensor The lift sensor must be installed so that it is activated when the machine is in the planting position and deactivated when the machine is lifted, but it is... -
Page 23: Virtual Terminal Configuration
Planting Quality of each line. For the correct operation of the Selenium Electric, it is necessary to make some adjustments in the settings tab, such as: Rate, Planter Measurements, Speed Filter, Speed Source, Line Addressing, Power Used and Lift Sensor Use. - Page 24 Settings menu. List of alarms set between high and low. Access password screen for alarm settings. List of alarms confi gured between maximum and mini- mum, enabled for confi guration. Confi guration of Implements Go to Settings > Implement In the implement icon, you must enter the correct measurements of the seeder, as re- quested in the screens below.
- Page 25 Mismatch screen: set the number of lines, distance between Custom screen: Select where each row will be positioned, long them, long and short wheel-output distance, hitch-wheel and or short. choose fi rst line 1 or 2. Custom screen: set the number of lines, distance between Adjustment screens: Tap the + or - button to increase and them, wheel-out distance, hitch-wheel, number of short and decrease the desired value.
- Page 26 Settings > Addressing For the correct functioning of wireless communication, all planting lines must be addressed. To address, enter the line number on the display, press record and bring the magnet pen closer to the driver located below the Selenium Electric display.
- Page 27 Addressing screen: list with the lines to Addressing screen: still blank. confi gure the addresses. Addressing screen: waiting for the Addressing screen: line successfully magnet to approach. addressed. Power Setting Settings > Power On this screen you should check if the Alternator option is selected. Settings menu.
- Page 28 Lift Sensor Screen. Variable Seed Rate The Selenium Electric system has the functionality to carry out the dosage of seeds at a variable rate, to carry out the rates it is necessary to have in hand the prescription maps of the areas where the planting will be carried out. You must enter the map fi les to be worked on the monitor.
-
Page 29: Maintenance
Maintenance For the Electric and PRO systems, always check in advance the entire electronic structure of the system, to confirm that everything is working in perfect condition before the harvest. Preventive maintenance before planting Disc, organizer and rosette assembly: assembly, organizer and rosette. Check disk Replace the assembly when there is excessive wear on any of the following parts:... -
Page 30: Relay Replacement
3.Graphite powder in the doser and in the seed: Check that the doser and seed are lubricated with graphite powder before each planting. If it is not, it is necessary to apply graphite powder to improve performance. Graphite on the disc: Check that the graphite on the back of the disc (side with the rosette) is worn. -
Page 31: Selenium Pro Servo Motor Replacement
Remove the screws and thus the top cover of the alternator Located inside the relay, and disengage the interconnected wires. Then unscrew and replace. Servo Motor Replacement Have a 1.05.0227 Selenium Pro Servo Kit unit on hand. Open the doser cover and remove the seed disc as indicated in the manual. - Page 32 Disassemble the servo motor tongue On the other side of the Selenium, by unscrewing the part. remove the driver's protective cover with the aid of a screwdriver. 5.Loosen the screws securing the servo Remove servo motor carefully motor to the driver Replace servo motor and reassemble.
-
Page 33: Causes X Troubleshooting
After reading the warning, tap “Accept.” A calibration prompt will appear in progress Following the warning of “Calibration Complete!” Causes and Troubleshooting 1. Regarding seed treatment, do I have any limitations on the use of Selenium dosers or not? Yes, oily treatments, liquid inoculants, directly in the seed box can greatly compromise the plantability of the system. - Page 34 5.What is the power source of the Selenium Electric? The system is driven via a 100A and 24V hydraulic alternator.
- Page 35 At least one row least one line in line Green icon is set to “Always Selenium automation, however cut by red planting” the J.assy system is ignoring this information Driver does not Check if the Line - Servo recognize the servo motor is...
- Page 36 Indicatives and Urgency Product Alarm text Alarm Description Solutions Electric Change the Engine locked Rotation-Exertion Selenium motor Electric Change the Engine fired Rotation-Exertion Selenium motor Check Electric Communication Signal line General Communication Selenium Failure Signal cables and antenna Maximum speed reached by the engine.
- Page 37 Indicatives and Urgency Product Alarm text Alarm Description Solutions The sensor is likely to be Seed Sensor damaged. It is None sensor Missing necessary to perform the replacement. Check the air pressure and also Seed Faults-Doubles that there are no Sensor Singulation impurities in the...
- Page 38 Alternator high Indication that the alternator is rotating Energy speed above the indicated. Voltage-free Energy It is not passing current. alternator No GPS signal. Check for ISObus GPS Speed GPS unavailable signal or the GPS in the J.Assy ECU.
-
Page 39: Disposal
Disposal Equipment must be sent to your nearest J.Assy reseller partner, or to the implement’s assembler in cases involving a direct purchase, at the end of its service life. From there, the disposal will be carried out by those responsible in the appropriate... -
Page 40: J.assy Quality Policy
CERTIFICATION MANAGEMENT SYSTEM "Provide quality products and services that exceed the expectations of our customers, ensuring compliance with legal and technical requirements, the development and manufacture of reliable products, considered true works of art, using innovative technological solutions, through investment in research and people to ensure productivity and a process of continuous improvement."... - Page 41 After following the guidelines mentioned in this manual, your SELENIUM doser will be ready for planting. IN CASE OF QUESTIONS OR POSSIBLE PROBLEMS CONTACT THE SALES REPRESENTATIVE OR THE RESELLER IN YOUR REGION, OR ACCESS: www.jassy.ag...
- Page 42 www.jassy.ag...
