Razer HAMMERHEAD TRUE WIRELESS X Manual

INTRODUCTION

Light it up with the Razer Hammerhead True Wireless X —high performance earbuds engineered to illuminate every beat Packing a 60ms low latency Gaming Mode along with custom-tuned 13mm drivers, brace yourself for audio that rises above the noise.

WHAT'S NEEDED

• Devices with Bluetooth audio capability
• Internet connection for app installation

LET'S GET YOU COVERED

You've got a great device in your hands, complete with a 2-year limited warranty coverage. Now maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com

Got a question? Ask the Razer Support Team at support.razer.com

TECHNICAL SPECIFICATIONS

• Headphone frequency response: 20 Hz —20 kHz
• Headphone impedance: 32
• Headphone sensitivity: 91 db @ 1 mw / 1 kHz
• Headphone input power: 8 mw (max input)
• Headphone drivers: 13 mm
• Headphone Connector: Bluetooth 5.2
• Microphone pick up pattern: Omnidirectional
• Microphone signal-to-noise ratio: 64 dB
• Microphone sensitivity: -26 dBFS
• Weight:
  • Charging Case: 0.09 lbs / 42 g
  • Earbuds: 0.02 lbs / 10 g each

GETTING STARTED

CHARGING YOUR RAZER HAMMERHEAD TRUE WIRELESS X
For first time use, connect the charging case to a USB port using the charging cable without removing the earbuds. For subsequent use, the charging case and the earbuds can be charged independently.

Wait until your Razer Hammerhead True Wireless X is fully charged.

BATTERY INDICATOR FOR THE CHARGING CASE
When Plugged In

	Status
Static red	Charging
Static green	Fully charged

When Unplugged

	Status
Static green	Battery full
Static orange	Battery low
Blinking red	Battery critical

PAIRING TO A MOBILE DEVICE
When trying to connect your Razer product, remember to keep it within 1 meter of your mobile device.

1. While inside the charging case, simply open the lid to enter pairing mode.


2. Enable Bluetooth on your mobile device and select Razer Hammerhead TWS X from the list of devices found.


3. Wait for pairing to complete. You will hear an audio prompt when the earbuds have successfully paired and connected to your device.


If the earbuds fail to connect to your audio source, the earbuds will stay in search mode then power off after 3 minutes. If this happens, simply repeat the steps again to pair.
Once the earbuds have been paired, it will automatically try to connect to that paired mobile device every time the charging case's lid is opened, or the earbuds are powered on Your earbuds can only connect to one mobile device at a time

USING YOUR EARBUDS

GAMING MODE
While connected, triple tap then hold the last tap for at least 2 seconds on any earbud to activate gaming mode. Once enabled, your earbuds will function at a lower latency; giving you real-time audio feedback while gaming. Repeat the same gesture to disable gaming mode.

For best performance, it is recommended to keep your earbuds within a very close distance of the audio source

USING THE SILICONE EARBUD SLEEVES
The silicone earbud sleeves offer increased comfort, sound isolation, and security. The soft texture feels better against your ear compared to bare plastic. Device audio improves by separating it from surrounding noise. The sleeves also help to keep the earbud secure by providing grip.

To use them, simply insert the earbud into the corresponding sleeve, and make sure each air vent is properly aligned with the sleeve opening.

POWER ON/OFF
To power off the device, simply place the earbuds back inside the charging case and close the lid. Opening the lid if they are in the charging case will power them on.

FUNCTION BUTTON QUICK REFERENCE
The following functions are only available when the earbuds are paired to a mobile device.

RAZER AUDIO APP
Making advanced customization just got a whole lot easier for your Razer Hammerhead True Wireless X earbuds. With the Razer Audio app, learn all its gestures, select from predefined EQs or customize one as needed, remap what each tap or gesture function does and much more— anytime, anywhere.

SAFETY AND MAINTENANCE

SAFETY GUIDELINES
In order to achieve maximum safety while using your Razer Hammerhead True Wireless X, we suggest that you adopt the following guidelines:
Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to support.razer.com for assistance.
Do not take apart the device (doing so will void your warranty) and do not attempt to operate it under abnormal current loads.
Keep the device away from liquid, humidity or moisture. Operate the device only within the specific temperature range of 0ºC(32 ºF)to 40º C (104 ºF).Should the temperature exceed this range, unplug and/or switch off the device in order to let the temperature stabilize to an optimal level.
The device isolates external ambient sounds even at low volumes, resulting in lowered awareness of your external surroundings. Please remove the device when engaging in any activities that requires active awareness of your surroundings.
Listening to excessively loud volumes over extended periods of time can damage your hearing. Furthermore, legislation of certain countries permits a maximum sound level of 86db to affect your hearing for 8 hours a day. We therefore recommend that you reduce the volume to a comfortable level when listening for prolonged periods of time. Please, take good care of your hearing.

MAINTENANCE AND USE
The Razer Hammerhead True Wireless X requires minimum maintenance to keep it in optimum condition. Once a month we recommend you clean it using a soft cloth or cotton swab to prevent dirt buildup. Do not use soap or harsh cleaning agents.
