Arctic Air Tower+ (AATPLS-MC2, AAPC-MC4) Manual

WHAT'S INCLUDED

Overview

ASSEMBLY

Place Arctic Air® Tower + down so that the front grill is facing up while base is being assembled.
Assemble the two Base halves by inserting the tabs on one half into the slots on the other half.
Align the assembled Base with the Arctic Aire Tower+. Pull the Power Cord through the hole in the center of the assembled Base.
Insert Tower Pegs(C) into Base Slots (D) and turn the Base clockwise (towards to the LOCK symbol) until it locks in place.
Pull the excess slack of the Power Cord through the hole. Plug the cord into a wall-outlet.

USAGE

USING ICE BOOST:

Unscrew top from ice pack and place aside. Fill with cold water and place in freezer until frozen.
When Ice Boost is frozen, open the drawer and slide into the slot as shown.
Repeat as needed when Ice Boost is no longer cold.

For Best Results, We recommend freezing and placing Ice Boost in water tank prior to filling to avoid overfilling and spilling. This will also help cool your water down quicker, for faster, better results.

FILLING THE TANK
Pull out the drawer on the backside of the unit. Using a pitcher or other container, fill until MAX line. Be sure to at least fill until over MIN line or water pump will not function properly. For Best Results, use cold water and/or ice boost.

FAN SPEED
Arctic Air® Tower + has 4 fan speeds - Low, Medium, High and Turbo. To set the desired speed, press the button on the top control panel.

COOLING CONTROL
Press the button to activate COOLING control. You can choose HIGH cooling mode, LOW cooling mode or keep it turned off.

LIGHT SETTINGS
Light brightness can be adjusted to be dimmer or brighter based on your preference. Lights default to high brightness, & when button is pressed, brightness can be adjusted to half-brightness, or off.

TIMER
You can set an auto-off timer for 2, 6, 8, or 12 hours. Simply press the button until your duration is selected. To cancel, press until no longer lit.

OSCILLATION
Arctic Air® Tower + also has wide-coverage oscillation built-in. Press the button once for continuous oscillation, or press again to stop the unit where it is currently is.

MAINTENANCE

FILTER
To access filter, remove front grill by pressing tab on the top of the grill - place aside. Using the finger cut-out on the top of the filter, pull the filter towards you and remove.

We recommend weekly cleaning of your Arctic Air® Tower + and filter to keep in best working condition, and replacing the filter every 3-6 months.

HAND WASH: Hand wash gently with warm water & soap. Shakeout excess water and let air dry.

If you see mold on the filter or notice a musty smell, stop and clean the filter before further use. Soak the cartridge with equal parts clean water and white vinegar - allow to sit for 45-60 minutes. Rinse with warm water, wring out and let air dry.

UNIT CLEANING

To prepare for cleaning, run Arctic Air® Tower+ until all water has emptied from the water tank, or hold Arctic Air® Tower+ over a sink and carefully dump out to avoid splashing or spilling.
If you notice water tank is dirty, use a small, bendable brush (i.e. toothbrush, bottle brush, etc) and carefully clean the inside of the tank until clean. Rinse clean with warm water.

To Order A New Filter or Customer Service:

	Web: www.ArcticAirTowerFAQ.com
	Call: 1-888-611-6750
	Email: ArcticAirTower@rephelpdesk.com

Do not carry Arctic Air@ Tower+ when filled with water. Some water may remain in unit even if tank is empty.
Use only clean water. If needed, use distilled water.
Please read and follow regular maintenance as recommended in "Maintenance"section of this guide.
Arctic Air® Tower+ works best in non-polluted areas. Large dust/dirt particles may reduce lifetime of unit.
We recommend use only in dry locations. If using in a moist area or environment, take care not to get water on external areas of the product.
If a leak or spill occurs on the surface of device, unplug Arctic Aire Tower+ and let it dry for 24 hours. Then, use as normal.
Do not place in direct sunlight for extended periods of time.
Before not using Arctic Airs Tower+ for extended periods of time, empty the water tank, turn unit on, and set to highest fan speed for at least 4 hours. This will dry out then filter and inside of your unit.
Only use the original power adapter and cord supplied in the package.
Do not touch the power supply or power cord with wet hands.
Unplug Arctic Aire Tower+ when cleaning, removing/replacing filter, or moving the device.
For best results, place Arctic Airs Tower+ on a higher surface like a table or countertop.
Do not place Arctic Aire Tower+ near a heater or any electrical equipment.
Do not place the device in passage ways or high traffic areas where there is a possibility of tripping or knocking it over.
Do not allow any foreign objects inside Arctic Air® Tower+.
Do not place items on top Arctic Aire Tower+.
Do not block the front and back grills of the device.
Do not turn the device upside down.
Do not submerge the Arctic AireTower + underwater or other liquids.
Do not place Arctic Aire Tower+ near open flames or fire sources.
People with limited physical, visual or mental abilities or lacking proper experience and/or knowledge should never use the device without supervision of those responsible for their safety or those capable of assistance in using the device.
The device can be switched off completely only when disconnected from the power supply.
The manufacturer does not bear any responsibility for any damage from failure to comply with this product guide.
A replaceable water filter is designed specifically for this product. If your cartridge has been broken or damaged, you can purchase a replacement.

FOR BEST RESULTS

PRE-SOAK FILTER:
To ACTIVATE COOLING, soak your filter under running cold water.

USING ICE BOOST:
Fill and Freeze Ice Boost pack prior to use. Place in water tank prior to filling to avoid overfilling.

FILL WITH PITCHER:
Place on flat surface & fill tank from a water pitcher. a water pitcher.

USING COOLING CONTROL:
Control cooling output by pressing button. You can choose HIGH cooling mode or LOW cooling mode.

DO NOT USE ARCTIC AIR WATER MAY LEAK OUT ONTO FLOOR.

Experience the cooling comfort of Arctic Airo Tower+.
If you have any questions or problems, go to: www.ArcticAirTowerFAQ.com
If you can't find the answer or do not have access to the internet, call our customer service line Monday-Friday 9am to 6pm EST: 1-888-611-6750
