- Page 1 Mini Brush Cutter Operation and Maintenance Manual Revision Date: December 2024...
-
Page 2: Table Of Contents
Weekly Inspection ........................5 Monthly Inspection ........................5 Inspection Checklist ........................6 Safety Chain Placement ......................6 PARTS DIAGRAMS AND LISTS ....................7 SKID PRO ATTACHMENT WARRANTY ................14 Skid Pro Mini Brush Cutter Rev. 12-24 Page 1... -
Page 3: About This Owner's Manual
NOTE: Additional safety equipment may be required depending on the operating environment and worksite conditions. Only qualified and trained personnel should operate, maintain, and service this attachment. Skid Pro recommends that you inspect this equipment regularly for leaks, cracks, or other conditions that may impair proper usage of the equipment. -
Page 4: About The Brush Cutter Attachment
ABOUT THE BRUSH CUTTER ATTACHMENT The brush cutter attachment is intended for use as a brush cutting and clearing tool. The primary use of the brush cutter attachment includes land clearing, landscaping, and grounds maintenance. Use of this equipment in any other manner is contrary to the intended use of the attachment. Attaching the Brush Cutter to the Carrier Machine NOTE: Before attempting to attach the brush cutter to the carrier machine, verify that all hydraulic couplings are compatible. -
Page 5: Brush Cutter Operation
BRUSH CUTTER OPERATION • Operate this attachment with a carrier machine and protective shield. • Wear proper safety equipment as required by working conditions and local, state, and Federal laws. • Never operate the brush cutter within 200 feet of people, animals, or damageable property. Clear the area of objects that could become projectiles, such as rocks, bottles, and construction debris. -
Page 6: Equipment Inspection Schedule
EQUIPMENT INSPECTION SCHEDULE We recommend that you inspect the equipment for damage and wear before every use. Use the following list as a guideline during equipment inspection. WARNING: Do not use hands to check for hydraulic leaks. Keep body parts away from leaking hydraulic lines and couplings that are under pressure. -
Page 7: Inspection Checklist
Inspection Checklist Are all safety notices and warning stickers in proper locations and visible? Are all safety guards properly installed and in good condition? Are there any visible hydraulic leaks? Is there oil visible in sight glass? ... -
Page 8: Drive Assembly
787-01-0001 MINI BRUSH CUTTER PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. 787-02-0002-36 36" FLYWHEEL ASM 787-02-0002-48 48" FLYWHEEL ASM 787-02-0001-36 MOWER BODY ASM - 36" 787-02-0001-48 MOWER BODY ASM - 48" DRIVE ASSEMBLY DIRECT DRIVE MOTOR 612-3-0025 INSPECTION COVER... - Page 9 BLADE BOLT 787-03-0020 .375 BLADE BOLT SPACER HW-1.125 LW 1 1/8" LOCK WASHER HW-1.125-12 TLHN 1 1/8" -12 INTERNAL LOCKING NUT 787-03-0019 MINI BRUSH CUTTER BLADE 612-3-0059 SHAFT HUB GEN 1 MOWER 612-3-0097 DOWEL 3/8" X 1-1/4" - PULL OUT...
- Page 10 BLADE BOLT 787-03-0020 .375 BLADE BOLT SPACER HW-1.125 LW 1 1/8" LOCK WASHER HW-1.125-12 TLHN 1 1/8" -12 INTERNAL LOCKING NUT 787-03-0019 MINI BRUSH CUTTER BLADE 612-3-0059 SHAFT HUB GEN 1 MOWER 612-3-0097 DOWEL 3/8" X 1-1/4" - PULL OUT...
- Page 11 787-01-0001 DRIVE ASSEMBLY PARTS BREAKDOWN...
- Page 12 787-01-0001 DRIVE ASSEMBLY PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. 612-2-0010 MOWER SPINDLE HW-.375-16X.75FS 3/8"-16 X 3/4" FLAT HEAD CAP SCREW 612-3-0063 SEAL PROTECTION 612-3-0058 SEAL 612-3-0054 BEARING, CONE 612-3-0053 BEARING RACE 612-2-0008 WIRE PROTECTION, UPPER HW-.500-20NYLG8 1/2"-20 NYLOCK NUT G8 HW-.500-20X2.5G8 1/2"-20 X 2.5 HH G8 612-2-0009...
- Page 13 787-02-0010-ASM MQT-BOBCAT STYLE QT ASM MINI QUICK TACH 32 " (BOBCAT) 2 " 24" 28" 8 " MAX (WITH SIDE PLATES ON)
-
Page 14: Parts Breakdown
787-02-0010-ASM PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. 787-02-0004 MQT - BOLT ON 787-02-0007 MQT - LOCATING BRACKET 787-03-0035 MQT - BOLT ON SIDE HW-.375-16X1.125G8 3/8"-16X1-1/8" GRADE 8 HW-.375-16NYLG8 3/8"-16 NYLOCK GRADE 8 HW-.750-10X2.0G8 3/4"-10 X 2" HH G8 HW-.750-10NYLG8 3/4"-10 NYLOCK NUT G8 REMOVE SIDE PLATES AND LOCATE INSIDE... - Page 15 787-02-0009-ASM CII-COMMON IND INTERFACE ASM ADJUSTABLE IN 1/8" INCREMENTS SHIPS STANDARD AT 9-1/2" MAX = 9-1/2" (OUTSIDE HOLES) MIN = 9" (INSIDE HOLES) 9 1/2" COMMON INDUSTRY INTERFACE (MACHINE (TORO DINGO) HEIGHT) 2 " MAX CENTER DISTANCE 2 "± 4 "...
- Page 16 787-02-0009-ASM PARTS BREAKDOWN ITEM NO. PART NUMBER DESCRIPTION QTY. 787-02-0003 CII QT - BOLT ON 787-02-0008 CII QT - BOLT ON TOP BAR HW-.375-16X1.125G8 3/8"-16X1-1/8" GRADE 8 HW-.375-16NYLG8 3/8"-16 NYLOCK GRADE 8 HW-.375 SAE FW G8 3/8" SAE WASHER G8 HW-.750-10X2.0G8 3/4"-10 X 2"...
- Page 17 787-01-0001 MINI BRUSH CUTTER REPLACEMENT DECALS ITEM NO. PART NUMBER DESCRIPTION QTY. DECAL-3-0004 3X10 "WARNING" DECAL-3-0006 2.250X10 "DANGER" DECAL-3-0008 3X5 "HIGH PRESSURE FLUID" DECAL-3-0009 3X3 "READ OWNERS MANUAL" DECAL-3-0010 5X5 "DO NOT OPERATE WITHOUT SA DECAL-3-0170 787-01-0001 serial# DECAL-3-0172 36" WIDTH DECAL, SILVER LETTER DECAL-3-0171 48"...
-
Page 18: Skid Pro Attachment Warranty
This warranty shall not apply to any attachment’s wear items, or attachments that have been repaired or altered outside the Skid Pro factory in any way, or that has been subject to misuse, negligence or accident beyond Skid Pro’s recommended use and/or machine rated capacity. - Page 19 PO BOX 982 Alexandria, MN 56308 Phone: 877-378-4642 FAX: 320-759-1057 www.skidpro.com sales@skidpro.com Skid Pro Mini Brush Cutter Rev. 12-24 Page 15...
