Industrial Brush Cutter
(standard flow 16-25 gpm)
(high flow up to 60 gpm)
Operation and Maintenance Manual
Standard Flow Closed Front Starting Serial Number 03092
Standard Flow Open Front Starting Serial Number 42232
High Flow Closed Front Starting Serial Number 11721
High Flow Open Front Starting Serial Number 032568
Revision Date: November 2017
Advertisement
Table of Contents
Related Manuals for Skid Pro X4
Summary of Contents for Skid Pro X4
- Page 1 Industrial Brush Cutter (standard flow 16-25 gpm) (high flow up to 60 gpm) Operation and Maintenance Manual Standard Flow Closed Front Starting Serial Number 03092 Standard Flow Open Front Starting Serial Number 42232 High Flow Closed Front Starting Serial Number 11721 High Flow Open Front Starting Serial Number 032568 Revision Date: November 2017...
-
Page 2: Table Of Contents
Warning Decal Placement – Diagram D .................. 12 Warning Decals - Parts List D ....................12 Warning Decal Graphics ......................12 TORQUE SPECIFICATION TABLE ..................13 General Specification Table ..................... 13 SKID PRO ATTACHMENT WARRANTY ................14 Skid Pro Industrial Brush Cutter Rev. 11:17 Page 1... -
Page 3: About This Owner's Manual
NOTE: Additional safety equipment may be required depending on the operating environment and worksite conditions. Only qualified and trained personnel should operate, maintain, and service this attachment. Skid Pro recommends that you inspect this equipment regularly for leaks, cracks, or other conditions that may impair proper usage of the equipment. -
Page 4: About The Brush Cutter Attachment
ABOUT THE BRUSH CUTTER ATTACHMENT The brush cutter attachment is intended for use as a brush cutting and clearing tool. The primary use of the brush cutter attachment includes land clearing, landscaping, and grounds maintenance. Use of this equipment in any other manner is contrary to the intended use of the attachment. Attaching the Brush Cutter to the Carrier Machine NOTE: Before attempting to attach the brush cutter to the carrier machine, verify that all hydraulic couplings are compatible. -
Page 5: Brush Cutter Operation
BRUSH CUTTER OPERATION Operate this attachment with a carrier machine and protective door. Wear proper safety equipment as required by working conditions and local, state, and Federal laws. Never operate the brush cutter within 200 feet of people, animals, or damageable property. Clear the area of objects that could become projectiles, such as rocks, bottles, and construction debris. -
Page 6: Equipment Inspection Schedule
EQUIPMENT INSPECTION SCHEDULE We recommend that you inspect the equipment for damage and wear before every use. Use the following list as a guideline during equipment inspection. WARNING: Do not use hands to check for hydraulic leaks. Keep body parts away from leaking hydraulic lines and couplings that are under pressure. -
Page 7: Inspection Checklist
Inspection Checklist Are all safety notices and warning stickers in proper locations and visible? Are all safety guards properly installed and in good condition? Are there any visible hydraulic leaks? Is there oil visible in sight glass? ... -
Page 8: Parts Diagrams And Lists
PARTS DIAGRAMS AND LISTS Brush Cutter - Diagram A Skid Pro Industrial Brush Cutter Rev. 11:17 Page 7... -
Page 9: Brush Cutter - Parts List A
Brush Cutter – Parts List A ITEM NO. PART NUMBER DESCRIPTION QTY. 612-2-0020-3 Body, Open Front 612-2-0006-3 Body, Closed Front (Not Shown) 612-2-0005-2 Bearing Housing, Assembled 612-2-0008-2 Wire Protection, Upper 612-2-0012-3 Flywheel Assembly 612-3-0111-20 Motor Mounting Plate Standard Flow 612-2-0011 Chain Rod 612-3-0045 Debris Chain (Not Available with Roller Option) -
Page 10: Drive Assembly - Diagram B
Drive Assembly - Diagram B Skid Pro Industrial Brush Cutter Rev. 11:17 Page 9... -
Page 11: Drive Assembly - Parts List B
Drive Assembly - Parts List B ITEM # PART NUMBER DESCRIPTION QTY. 612-2-0024 Bearing Housing 612-2-0030 3.750 Bearing & Race 612-2-0025 Shaft 612-3-0110 Hub, high Flow 612-3-0060-HF Motor Assembly, High Flow 612-3-0111 Motor Mounting Plate, High Flow 612-3-0111-20 Motor Mounting Plate Standard Flow 612-3-0110-20 Hub, Stannard Flow 612-3-0063-2... -
Page 12: Flywheel Assembly - Diagram C
Flywheel Assembly - Diagram C Flywheel Assembly - Parts List C ITEM # PART NUMBER DESCRIPTION QTY. 612-3-0147 Fly Wheel Plate Mulcher Flywheel Optional, (Not Shown) 612-2-0037 612-2-0025 Drive Shaft 612-3-0013 Blade 612-2-0007-2 Wire Protection, Lower 612-3-0048 Blade Bolt HDW-LDZ113 1 1/8 Lock Washer HDW-HNGRC 113 12 1 1/8-12 Hex Nut Top Lock... -
Page 13: Warning Decal Placement - Diagram D
Warning Decal Placement – Diagram D Warning Decals - Parts List D ITEM # PART NAME DESCRIPTION QTY. Warning Decal Warning Keep Hands and Feet Away Warning Decal DANGER Debris Discharge Area Stay Back 200 Feet Warning Decal Do Not Operate Without Safety Chain In Place Warning Decal High Pressure Fluid Hazard Warning Decal... -
Page 14: Torque Specification Table
TORQUE SPECIFICATION TABLE General Specification Table Use the following torques when special torques are not given. Note: These values apply to fasteners as received from supplier, when dry. These values do not apply if lubricants are used. BOLT SIZES (SAE) TORQUE INCHES POUNDS-FOOT POUNDS-FOOT (NC Threads) -
Page 15: Skid Pro Attachment Warranty
If it is determined the defective parts are to be returned and they are not received by Skid Pro within 30 days of receiving the replacement parts, the Buyer will be charged for the cost of the replacement parts plus any shipping charges. - Page 16 PO BOX 982 Alexandria, MN 56308 Phone: 877-378-4642 FAX: 320-759-1057 www.skidpro.com sales@skidpro.com Skid Pro Industrial Brush Cutter Rev. 11:17 Page 15...
