JmGO N1 Manual

Scope of Delivery

Remote Control

1. Power On/Off
2. Direction Keys
3. Return
4. Settings
5. Google Assistant
6. Confirm
7. Home
8. Menu
9. Volume

• After the projector is turned on, press and hold the settings button and the menu button on the remote control for 3 seconds at the same time to enter Bluetooth pairing.
  This remote has been evaluated to meet general RF exposure requirement.
  This remote can be used in portable exposure condition without restriction.

Product Manual

Power on/off: The power button is a physical button, short press to power on or off.

Download and Install of JMGO App

• JMGO App is a mobile application for multi-screen interaction with JMGO projector. Using JMGO App can help you obtain better projection experience.
• Mobile phone for remote control—the mobile phone is also a remote control with JMGO App, and the projection remote control is more convenient.

Product Laser Safety Parameters

Laser Safety Standard: Class 1 in compliance with the IEC 60825-1:2014
The maximum output of laser radiation: 0.39mW
Emission Wavelength:
Blue: 455-475nm
Red: 635-655nrn
Green: 515-535nrn

Class 1 Laser product
Do not stare into the beam
RG2
Complies with IEC60825-1:2014 and IEC 62471-5:2015.

Safety Warning: This product contains a laser module. Do not disassemble or modify this module in a manner not specified in the manual without authorization. Failure to follow this guideline may result in personal injury.
As with any bright source, do not stare into the direct beam, RG2 EC 62471-52015.

Warnings

1. EUT operation temperature range: 0°C to 40°C,
2. Do not store the device in temperatures lower -20°C and higher than 60°C
3. Adapter shall be installed near the equipment and shall be easily accessible.
4. To power the device, please use a matching power supply adapter offered by the authorized producer, unauthorized adapter may cause charger exploding or damage the machine.
5. Plug the adapter power socket in 100-240VAC socket, others may cause charger exploding or damage the machine. The plug considered as disconnect device of adapter.
   Adapter:
   Input: AC 100 240V 50/60Hz 2.0A
   Output: 24V 4.17A 100W
   Technical description:
   Rating: 24V 4.17A
   Frequency Range: Bluetooth: 2402 - 2480MHz
   2.4G WiFi (20 MHz): 2412 - 2472 MHz
   2.4G WiFi (40 MHz): 2422 - 2462 MHz
   5G WiFi (H20): 5180 - 5240 MHz
   5G WiFi (H40) 5190 - 5230 MHz
   5G WiFi (H80): 5210MHz
   5G WiFi: 5745 - 5825MHz
   Transmit power: Bluetooth: 3.32dBm EIRP
   2.4G WiFi: 15.03 dBm EIRP
   5G WiFi: 17 88 dBm EIRP

Safety Notice

• Read this product manual thoroughly before attempting to use this product. Store the product manual in a safe location so it may be referenced at any time.
• Do not look directly into the light lens of the device as your eyes may be damaged by a strong laser.
• When the projector is working, do not block the projection lens with any object,
• If you encounter an issue with the product, do not attempt to disassemble it without authorization. Contact professional after-sales personnel to resolve the issue,
• Note: The model approval code is shown on the product nameplate.

After-Sales Service Policy

After-Sales Service Channels
If you encounter any problems while using the product, contact us through one of the following channels:
After-Sales Website: https://smart.jmgo.com/
After-Sales service email: after-sales@jmgo.com
