STARFRIT 024300 Manual

BEFORE FIRST USE

READ THE INSTRUCTIONS BEFORE USE

Blades are sharp, handle with care. Do not plug the appliance into an electrical outlet before it's ready to be used.
NOTE: Remove all parts & accessories and dispose of packaging.

1. Unscrew the blade base from the cup and carefully remove the silicone gasket.
2. Wash all removable parts & accessories in hot soapy water and dry thoroughly or place in the dishwasher.
   NOTE: Do not immerse the motorized base or the power cord in water or any other liquids.
3. Wipe the motorized base with a damp cloth and dry thoroughly.
4. Insert the gasket back into the groove of the blade base. Ensure the gasket is securely in place by pressing all around.

TIPS AND RECOMMENDATIONS

NOTE: For best results read the following tips:

• Do not fill the cup passed the MAX line.
• Do not attempt to blend firm food such as potatoes, grind meat or mix dough.
• Do not process hot food or liquids.
• Cut fruits and vegetables into small pieces.
• Place ingredients in the following order: Liquids, frozen ingredients, fresh ingredients.
• Fill the cup half way with liquids.
• If the blade stops spinning, unplug the appliance immediately. Remove the cup and shake it to unblock the blade. If the blade is still obstructed add some liquid or reduce the solid food.

SPEED CONTROL

• Use thePULSE control to crush ice or frozen fruits into small pieces. Hold the speed control to PULSE for short bursts. Then use the LOW speed ''I'' or HIGH speed ''II'' to obtain the desired consistency.
• Use thePULSE control to grind coffee beans, nuts and whole spices.
• Use LOW ''I'' control to obtain a thick, chunky texture.
• Use HIGH ''II'' control for a creamy, smooth texture.

BLADES

• Use theblending blade for smoothies, icy beverages, dips and spreads.
• Use thegrinding blade to grind coffee beans, nuts, grains and whole spices.

*Always add liquid to blend

*Always add liquid to blend

TO USE

1. Pour the desired ingredients in the cup until the MAX line is reached.
   NOTE: Cut the fruits/vegetables into small pieces.
2. Attach the desired blade base to the cup. Ensure that the blade is securely tightened and the gasket is in place.
3. Place the cup assembly onto the motorized base and align the symbol marked on the blade base with the symbol marked on the base and turn clockwise to align with the symbol. Make sure the cup is securely locked before operating.

   The appliance has a locking mechanism that prevents the appliance from operating or blade from turning if the cup is not securely attached to the blade base.
4. Plug the appliance into a standard 120-volt AC electrical outlet.
5. Select the desired speed control. Hold the speed control to PULSE for short bursts if processing ice or frozen fruits/vegetables. For continuous blending, select the LOW speed ''I'' or HIGH speed '' II ''.

   Do not operate the appliance for more than two minutes continuously.
6. Turn OFF "O" the appliance and unplug from electrical outlet when done blending.
7. Remove the cup assembly from the motorized base.
8. For immediate consumption, replace the blade base with travel lid.
9. Clean parts and accessories immediately after each use.

CLEANING & CARE

Ensure the appliance is unplugged from the electrical outlet and the blade has stopped turning before handling or cleaning the appliance.

1. Disassemble all parts & accessories.
   NOTE: Remove the silicone gasket only if necessary.
2. Wash in soapy, hot water or place in the dishwasher. Wash after each use.
   NOTE: Do not place the motorized base or cord in a dishwasher
3. Dry all the parts & accessories thoroughly.
4. Wipe the motorized base with a soft, damp cloth and dry thoroughly.
5. R eassemble the blender for compact storage. Ensure the silicone gasket is properly in place.
6. For safe storage, always store the blades with the cups.

Blades are sharp handle with care while cleaning. Use a brush to clean the blades to avoid injuries. Do not touch blades with bare hands.

RECIPES

PINEAPPLE & BANANA SMOOTHIE

BLADE: Blending blade
INGREDIENTS:

• 1 cup (250 ml) frozen pineapple
• 1 banana, peeled
• 1 cup (250 ml) soy milk
• 1 tsp (5 ml) honey
• 1 tbsp. (15 ml) coconut flakes

PREPARATION:

• Add all ingredients into the cup. Attach the blending blade to the cup. Place the cup assembly onto the motorized base.
• PULSE all ingredients a few times and blend on HIGH speed "II" for a smooth, creamy texture. Add water as needed.

KALE & KIWI SMOOTHIE

BLADE: Blending blade
INGREDIENTS:

PREPARATION:

• Add all ingredients into the cup. Attach the blending blade to the cup. Place the cup assembly onto the motorized base.
• Blend on HIGH speed "II" for a smooth, creamy texture. Add water as needed.

IMPORTANT SAFEGUARDS

READ THE INSTRUCTIONS BEFORE USE

To reduce the risk of fire, electrical shock, serious personal injury and/or property damage:

1. To protect against electric shock, do not immerse, power cord, plug or product in water or expose to other liquids.
2. Keep the appliance out of the reach of children and pets. This product is not intended for use by children. Close adult supervision is necessary when any appliance is used near children. Do not leave the product unattended while it is in use.
3. Do not operate the product if it has a damaged power cord or plug, or after the appliance malfunctions or has been damaged in any manner. Do not attempt to examine or repair this product yourself. Please call the customer service number provided in this user manual.
4. Always unplug the appliance from the electrical outlet when not in use, before changing parts, cleaning or moving the appliance. To disconnect, switch control to OFF "O". Pull directly on the plug – do not pull on the power cord.
5. Do not plug or unplug the product into/from the electrical outlet with a wet hand.
6. Connect the power plug to an easily accessible outlet so that the appliance can be unplugged immediately in the event of an emergency.
7. Do not use attachments not recommended or not sold by the product manufacturer.
8. Do not use with programmable device.
9. This product is intended for indoor, non-commercial use. Do not use outdoors or for any other purpose.
10. Do not use appliance for anything other than its intended use.
11. Do not allow the power cord to hang (e.g., over the edge of a table or counter) or touch hot surfaces.
    DO NOT OPERATE THE APPLIANCE FOR MORE THAN 2 MINUTES CONTINUOUSLY. ALLOW THE APPLIANCE TO REST BETWEEN EACH USE.
12. Do not place the product on or near a hot gas or electric burner, or in heated oven or microwave oven.
13. Always use the blender on a flat, level, stable surface. Do not move the blender while it is in use.
14. The blades are sharp, must handle with care.
15. Make sure the blade and the cup are securely attached together before locking the cup into the base.
16. Do not attempt to remove the cup from the blade base while attached to the motor base. Do not remove the cup from the appliance while in use.
17. Do not operate the appliance for more than 2 minutes continuously. Allow the appliance to rest between each use.
18. Do not operate the blender if empty.
19. Do not blend hot liquids, use as a meat grinder or a food processor (blend thick mixture).
20. To avoid injuries, do not place the blade assembly directly on the motorized base. Always place the cup and blade assembly onto the motorized base.

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

POLARIZED PLUG: This appliance is equipped with a polarized plug (one blade is wider than the other). As a safety feature to reduce the risk of electrical shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this feature or modify the plug in any way. If the plug fits loosely into the AC outlet or if the AC outlet feels warm, do not use that outlet.

SPECIAL INSTRUCTIONS: A short power supply cord is provided to reduce the risk of becoming entangled in or tripping over a longer cord.

AN EXTENSION CORD MAY BE USED IF CARE IS EXERCISED IN THEIR USE:

• Minimize the risk of overheating by using the shortest UL or ETL listed cord possible.
• The marked electrical rating must be at least as great as that of the product.
• Never use a single extension cord to operate more than one appliance.
• Arrange the longer cord so that it will not drape over a countertop or tabletop where it can be tripped over, snagged, or pulled on unintentionally (especially by children).
• DO NOT alter the plug. DO NOT attempt to defeat the safety purpose of the polarized plug.
