Owner's Manual
Thank you, and congratulations on your choice of the BOSS GT-8
Guitar Effects Processor.
Before using this unit, carefully read the sections entitled:
• USING THE UNIT SAFELY (page 2–3)
• IMPORTANT NOTES (page 4)
These sections provide important information concerning the proper
operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of
every feature provided by your new unit, Owner's manual should be read in
its entirety. The manual should be saved and kept on hand as a convenient
reference.
■ Printing Conventions in This Manual
• Text or numerals enclosed in square brackets [ ] indicate buttons.
[WRITE]
[SYSTEM]
• EXP pedal is an abbreviation of "expression pedal."
• Reference such as (p. **) indicate pages in this manual to which you can refer.
* All product names mentioned in this document are trademarks or registered
trademarks of their respective owners.
Copyright © 2004 BOSS CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written
permission of BOSS CORPORATION.
WRITE button
SYSTEM button
