Step 1
Ensuring the holes in the
walls of the tubes (Fig. 2)* are
lined up with the slots in the
channel guides, insert the
tubes into the channel guides.
Step 2
Bolt the tubes into the
channels using the supplied
1/4-20 bolt, plastic Bearings,
and Nuts. Tighten the nut until
it touches off on Spacer. Ensure
the tubes move freely in the
channel guides.
*Product diagram on last page, for reference.
Trail Kitchen Accessory: JP54-073
TRAIL KI TCHEN
BASIC SINK KI T
I N S TA L L AT I O N I N S T R U C T I O N S
Designed to be used with the JP54-038 Trail Kitchen
Heavy. D uty. Adventure.
Tools Needed:
1/8" Allen Wrench
5/32" Allen Wrench
3/8" Wrench/Socket
7/16" Wrench/Socket
parts list:
JP46-016 Hardware Assembly Package
JP56-026 Counter Support Arm
JP56-047 Flip-Open Countertop Assembly
JP209-171 Counter Bracket Support
UO136-3302 Blue Collapsible Sink
