MORryde STABILIZER Owner's Manual

MORryde STABILIZER
INTENDED USE & FEATURES
When parked, stabilizers control the side-to-side rocking of a chassis for a sturdier camping experience.
•
• NOTE: The stabilizer system will not lift the rear tires of the unit off the ground and is not a substitute for jacks.
To adjust to varying terrains, the arms are controlled independently of one another.
•
Stabilizers have a wide base of support to provide a stable feel in the motorhome.
•
WARNING
Stand clear of the stabilizer assembly during the extension and retraction of the stabilizer legs. Do not put any part
of your body between the stabilizer and the ground or between the stabilizer and the chassis.

PARTS LISTING

•
Outriggers
•
Stabilizer assembly
•
Optional foot plate on the
end of the stabilizer leg
•
Hardware

OPERATING PROCEDURE

1
Step
Use the extend and retract
buttons in the coach to extend
or retract the stabilizer legs. The
arms operate and are controlled
independently of one another.
NOTE: Once the stabilizers are either fully extended or fully retracted, it is important to return the buttons to the neutral position. As a precaution, the thermal
overload breaker on the circuit will trip if the button is depressed for too long and will reset automatically after cooling off. However, this should not be
regularly used as a cue for when to release the buttons.
WARNING: If a buzzer sounds when turning the key in the ignition of the coach, one or both of the stabilizer legs is extended. To resolve, retract the legs.
O W N E R ' S M A N U A L
Stabilizer
Assembly
2
Step
TO EXTEND: Press the "EXT" buttons
until each leg reaches the ground. The
sound of the motor will change pitch as
the legs begin to take weight. Adjust
each side independently for
desired stability.
Outriggers
Foot Plate
Foot Plate
3
Step
TO RETRACT: Press the "RET"
buttons simultaneously until
each leg is fully retracted.
