The 301 continues the simple and clean top/front panel interface, while maintaining the LED front 1/0. Accompanied by a toolless, screwless tempered glass side panel, the 301 is quality you can see, feel and experience!

Specifications

Model	301
Color	Black, White
Case Type	Mini Tower
Material	Tempered Glass, SECC
MIB Compatibility	Micro ATX, Mini ITX
Expansion Slots	PCI-E Slot x 4
Maximum Compatibility	VGA Card Length: 31Omm (Height: 162mm) VGA Card Length (With Front Fan + Radiator 35mm):265mm CPU Heatsink Height: 160 mm
Front Ports	2 x USB 3.0 HD Audio
Internal Drive Bays	1 x 3.5"/2.5 2 x 2.5"
Thermal Solution Compatibility	2 x 120mm Front Fan / 240mm Radiator 1 x 120mrn Rear Fan / 120mrn Radiator 2 x 120mm Bottom Fan (Occupy a PCI-E slot)
Power Supply Compatibility	PSII: ATX12V Length up to 160mm
Product Dimension (HxWxD)	365mm x 188mm x 370mm (14.3'' x 7.4" x 14.6")
Product Dimension with screw & handle height(HxWxD)	365mm x 208mm x 370mm (14.3" X 8.1'' X 14.6")
Package Dimension (HxWxD)	450mm x 272mm x 458mm (17.7"x 10.7"x 18")
Net Weight	6.57KG/ 14.41b
Gross Weight	7.63KG/ 16.81b

Package Content

Case Structure

Case Structure - Part 1
Case Structure - Part 2
Case Structure - Part 3

3.5"/2.5" Drive Bay
2.5" Drive Bay
Front Fan/ Radiator Mounting Area
Rear Fan/ Radiator Mounting Area
Bottom Fan Mounting Area
Motherboard Mounting Area
CPU Cooler Installation Cut-Out Hole
PCI-E Expansion Slot
Extra PCI-E Supporting Mounting Hole
Power Supply Mounting Area
Shock-Proof Stand

Installation Guide

(Please follow the related chapters to assemble)

Opening the Chassis
For SECC side panel, please remove the two thumb screws and lift up. For Tempered Glass side panel, please remove by pressing the handle on top of panel.
Power Supply Installation
Parts Required: Hexagon Head Screws Power supply can be mounted on the top bracket
Motherboard Installation
Parts Required: MotherboardStand-Off, Motherboard Stand-Off Socket, Hexagon Head Screws
Expansion Card Installation
Parts Required: Hexagon Head Screws, Graphics Card Holder
I/O Wires Installation

HD Audio Header

LED Pipe Power Header
Ensure the beveled edge of the PSU connector is properly aligned with the beveled edge of the LED light connector
*RGB lighting will be available in some regions. For RGB installation, please download on the product page.

USB3.0 Header
3.5"/2.5" Drive Bays Installation
Parts Required: 2.5" HDD Screws
Fan / Liquid Cooling Radiator Installation & Bottom Fan Installation
Parts Required: Water-cooling System Washer
Hiding Cable Lines
Completing Installation
Parts Required: Cable Ties

Notices and Warranty

Notices

Please follow the user manual for installation.
When installing the computer components, please use the antistatic precautions to prevent ESD (electrostatic discharge) damage. This can cause injury to the installer and/or damage to the machine. Incorrect installation may burn motherboard and other system components.
To avoid any damages, please do not use this product for any other purpose than its intended use.
Any modifications may damage the product.
Please remove all internal devices before shipping or moving. (Including power supply, hard drive, CD-ROM, motherboard and CPU, etc)

Warranty
* For more detailed warranty information, please visit In Win retail website at www.in-win.com.
* The actual product is subject to change without prior notice. In Win Development Inc. reserves the right to make final modifications.
