Summary of Contents for In Win 101 TUF GAMING

  • Page 1 User Manual...
  • Page 2 Product Story ASUS TUF GAMING Alliance Design To capture the vibes of the TUF GAMING motherboards, In Win and ASUS have united to design the 101 TUF GAMING chassis. The exterior screams TUF, as the rugged steel enclosure is covered with a military design while donning the TUF GAMING Alliance emblem.
  • Page 3: Specifications

    Package Dimension (HxWxD) 506 x 282 x 532mm (19.9" x 11.1" x 20.9") Net Weight 7.85kg / 17.4lb Gross Weight 9.15kg / 20.2lb * In Win products comply with RoHS regulation. * Specifications may vary based on different regions.
  • Page 4 Case Structure Power Button Logo HDD/Power LED Indicator USB 3.0 Ports Audio Ports (Earphone and Microphone) 2.5" Drive Bay TUF GAMING Alliance RGB Panel Power Supply Mounting Area...
  • Page 5 Case Structure 3.5" /2.5" Drive Bay Side Fan/ Radiator Mounting Area Rear Fan/ Radiator Mounting Area Bottom Mounting Area/ Radiator Mounting Area Motherboard Mounting Area PCI-E Expansion Slot Extra PCI-E Supporting Mounting Hole Fan Dust Filter Shock-Proof Stand...
  • Page 6: Product Content

    Product content 101 TUF GAMING Chassis QR Code Card Accessories Bag TUF GAMING Alliance RGB Panel...
  • Page 7: Package Content

    Package Content Motherboard Stand-off x 7 Motherboard Stand-off Socket x 1 Hexagon Head Screws x 18 2.5" HDD Screws x 12 Cable Tie x 10 Water-cooling System Washers x 8 Graphics Card Holder x 1 RGB Pin Header x 2...
  • Page 8: Opening The Chassis

    Installation Guide 1. Opening the Chassis For the side panel, please pull the two tooless clips and lift up. up to 200mm 2. Power Supply Installation Parts Required: Hexagon Head Screws. Power supply can be mounted on the top bracket. 3.Motherboard Installation Parts Required:...
  • Page 9: Expansion Card

    Installation Guide 4.Expansion Card Installation Parts Required: Hexagon Head Screws, Graphics Card Holder.
  • Page 10 Installation Guide 5.2.5”/ 3.5” Drive Bays Installation 6. RGB Panel Installation Parts Required: RGB Panel Please install the RGB panel on the top of the chassis, and then insert RGB-strip into the 4-pin RGB-strip header directly on the motherboard.
  • Page 11 Installation Guide 7. I/O Wires Installation POWER SWH.D.D LED POWER SW H.D.D LED PORT2_2 Blue 10 9 Brown SENCE2_R SENSE_SEND Purple 8 PORT2_R Yellow 6 5 Green SENSE1_R PORT1_R White 4 3 Orange PRESENCE# 1 Black PORT1_L Red USB3.0 Header LED Pipe Power Header Ensure the beveled edge of the PSU connector is properly aligned with the beveled Edge of the LED light connector.
  • Page 12 Installation Guide 8. The instructions of RGB-Strip cable If your motherboard support the RGB luminous effect, please follow the direction of sign and insert RGB-strip into the 4-pin RGB-strip header directly on the motherboard.
  • Page 13 Installation Guide 9. Fan / Liquid Cooling Radiator Installation Parts Required: Water-cooling System Washer. 10. Completing Installation...
  • Page 14 (Including power supply, hard drive, CD-ROM, motherboard and CPU, etc) ◆ Warranty * For more detailed warranty information, please visit In Win retail website at www.in-win.com. * The actual product is subject to change without prior notice. In Win Development Inc.
  • Page 15 Copyright © 2018 In Win Development Inc. All Rights Reserved.
