Sign up for our Technical Support Website http://connect.kabalodging.com/
ACTIVATE PIN / CREATE PIN FOR BELLMAN'S AUTHORIZATION
To ACTIVATE PIN:
Swipe a General Master Authorization
keycard through the Front Desk Unit.
Press
7
Press
2
Press
3
Press
4
Arrow down to Accept PIN? Press 1
Arrow down to Create PIN? Press 1
then press <ENTER>
Settings are now active.
G4
To CREATE PIN:
Swipe a General Master Authorization
keycard through the Front Desk Unit.
Press
6
Press
2
Press
2
Arrow down to Authorization? Enter #
{each BA keycard must have it's own
authorization number.}
For BA's use #'s between 121-160
Arrow down to Create PIN? Press 1
write down the PIN code. Then press
<ENTER> swipe card. PIN# is now active
lodging-tech@kaba-ilco.com
1-800-906-4526
