ONIKUMA K10 - Headsets Manual

Packaging contents

Before unpacking the device, ensure that the packaging is undamaged and contains the following items:

• headphones;
• signal-power cable;
• user manual.

Device maintenance

1. Any damage caused by improper use or attempted repair is not covered by the warranty. There are no service parts inside the packaging, repairs may only be carried out by authorized service center.
2. Do not allow the device to come into contact with oil, grease or any similar liquid.
3. Regular cleaning allows of long term use and maintains proper operation. Use a soft cloth to clean the device.

Device operation

1. The headphones are compatible with both audio devices with a single 3.5mm jack headphone output and devices with a 3.5mm jack headphone output and a 3.5mm jack microphone input. Examples of such devices are laptops, tablet PCs or smartphones.
2. When putting on the headphones, make sure that the cable is on the left side. Connect the cables (headphone, microphone and USB) to the corresponding inputs/outputs of the audio device.
3. The headphones will be automatically recognized by the audio device, and the driver will be automatically installed. When using the headset with a computer, make sure the microphone switch is turned on. If the headset does not work properly, go into the sound settings and set the corresponding output device (headphones) and input device (headphone microphone).
4. Set the preferred headphone volume.

Technical specification

Type: gaming headphones for gamers
Compatibility: Windows, Mac, Android, iOS
Design: closed, on-ear
Transducer diameter: 50 mm
Impedance: 32 Ω
Power consumption: < 100 mA
Sensitivity: 105 dB (±3 dB)
Frequency range: 20 - 20000 Hz
Microphone: built-in (6 x 2.7 mm)
Microphone sensitivity: -42 dB (±3 dB)
Microphone on/off switch: remote control on cable
LED lighting: RGB
Communication: wired
Wire length: 2,2 m

Safety rules

	Please read the user manual in detail before use. Please also keep it for future reference. The manual contains rules for the safe use of the device.
	After receiving the product, please unpack and check whether it is complete and whether there is any damage caused by transportation. If there is damage caused by transportation, please do not use this product and contact the dealer or manufacturer as soon as possible.
	THE DEVICE MUST NOT BE DISPOSED OF WITH HOUSEHOLD WASTE. This symbol indicates that this product must not be disposed of with household waste, according to the EU and your national law. In order to prevent potential damage to the environment or health, the used product must be recycled. In accordance with current legislation, unusable electrical and electronic devices must be collected separately at the designated facilities for recycling, acting on the basis of applicable environmental standards.
	The product described in this manual comply with European directives and it is therefore CE marked.
	The manufacturer is not liable for damage caused by improper use.
	The device operates on the power supply of DC 5V – do not connect to a power supply with different parameters. Disconnect the product from the power supply by pulling on the power plug – do not pull directly on the wire! If you find the power cable is damaged – do not use it!
	Indoor device, keep away from moisture. Do not store or use the device near a fire source!
	Do not expose the device to high temperatures!
	In the event of a malfunction, disconnect the device from the power supply immediately!
	Do not use the headphones at maximum volume for long periods of time due to the possibility of hearing damage!
