Summary of Contents for Zastone D9000
- Page 2 Introduction of the Machine ■ Front Panel Keys and Buttons Functions left main mode press the key and set the left band to be the main [MAIN·BAND] band mode left volume key [VOL] switch it clockwise to increase the left side volume of the machine;...
-
Page 3: Lcd Screen Display
under the standby mode, press the key to choose the DUPLEX of the main band mode; hold the key to start or close the monitor mode of the main band mode under the standby mode, press the key to choose the power level of the main band mode;... - Page 4 indication for the storage channel number indication for deleting or adding the scan channel indication for the priority channel scan indication for starting the meteorological warning channel indication for TSSI/RSSI indication for RSSI or the startup of the monitor function indication for the high power, middle power and low power indication for the mute subcarrier frequency...
- Page 5 Keys and Buttons Functions Crystal Interface The interface to connect the control panel or the microphone Data Interface The interface of TNC data transmission Antenna Terminal It is used to connect the antenna wire, and the antenna impedance is 50 ohm. External ACC Connector The cigar lighter can be connected by matching it to the start line (HCC01).
- Page 6 Increase the frequency value, record the position or setting value of the channel. Down Decrease the frequency value, record the position or setting value of the channel. Emergency Warning Key Hold the key to start the warning function, cancel the operation with a short press Receiver/Transmitter Indicator The green LED indicator light will be on as the...
- Page 7 after the is displayed on the screen then press the key to switch the duplex of the main channel to DUP+ and DUP –or close the duplex. Start the Scan Operation Under the standby mode, press the key first, after the is displayed on the screen then press the key to start the frequency scan of...
- Page 8 transmit power to high power, medium power or low power. Marks： The function can not be set as under the aeronautical frequency range and the radio frequency. Function Setting of the DTMF Under the standby mode, press the key first, after the is displayed on the screen then press the...
-
Page 9: Basic Operation
Basic Operation ■ Power On/Off of the Vehicle Mounted Station Power Key ◇ Power On of the Vehicle Mounted Station Under the shutdown state, press the key for a second to turn on the walkie-talkie. After the walkie-talkie begins to beep loudly and there appear some messages on the LCD display screen, directions and the present operating frequency will show on the screen. - Page 10 As 1MHz adjusting step value is selected, the number below 100kHz will disappear. As to adjust the frequency of the main engine, press the corresponding [DIAL] knob, you will enter the adjustment mode of MHz. With this state, modify the band switch, and the frequency can be immediately adjusted by 1MHz step value.
- Page 11 VHF/UHF Taiwan 50W/50W High Power: Medium Power: 15W*/15W* 15W* Low Power: 5 W*/5 W* The output power can be changed in the process of transmission. The output power can also be selected by microphone keyboard. Press the key on the microphone keyboard first, and then press the key to respectively select the high power, medium power and low power.
- Page 12 key to switch it to MR storage pattern, press the again, it can be swtiched to the mode of CALL channel. ·Under the standby mode, as the vehicle mounted station is in the mode of MR stirage or the CALL channel mode, press the key, and it can be changed to the VFO mode.
- Page 13 ② Hold down the [M/CALL·MW] of the corresponding band for one second. ·The indicator of “MR” and the storage channel number begin to blink. ③ Switch the [DIAL] and select the storage channel that needs to be cleared. ④ Hold down the [CLR](DUP·MONI) for one second to clear. ·As there appears 3 alert sounds, the frequency is cleared.
- Page 14 Function Set for the Overall Unit ① Press the key, the operation menu screen will be displayed. ② Press the key (right side ) and enter the function menu. ③ Switch the [DIAL], select the “SET MODE” menu group and push the [MHz TUNE]. ④...
- Page 15 OFF: Close the fan function ON: Start the fan function AUTO: automatic fan control Default: AUTO ■ Automactic Repeater OFF: Close the automactic repeater RPT1: repeater function of the common frequency RPT2: repeater function of the dissimilar frequency Default: OFF ■...
- Page 16 frequency range of the FM transmitter: 64-108MHz Default: 64.5MHz ■ Weather Alert OFF: close the weather alert ON: start the weather alert Default: OFF ■ Factory Reset VFO: recover the left band, right band, redio, aviation, and the VFO frequency in the amplitude frequency range PART: recovert the overall unit and set the menu parameters FULL: full recovery of the machine...
