Ortech FM1-MS5-5CCT Manual

PIR Motion Sensor
1. RISK OF SHOCK — House electric current can cause painful shock or serious injury unless handled properly.
For your safety, always remember to:
A) Turn OFF the power supply at the fuse or circuit breaker box before you install the fixture
B) Double-check all connections to be sure that they are tight and correct
2. This fixture is designed for use in a circuit protected by a fuse or circuit breaker. It is also designed to be installed in accordance with local
electrical
codes. If you are unsure about your wiring, consult a qualified electrician or local electrical inspector, and check your local electrical code
3. RISK OF CUTS — some metal parts in the fixture may have sharp edges. To prevent cuts and scrapes, wear gloves when handling the parts
4. Account for small parts and destroy packing material, as these may be hazardous to children
5. The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person
6. Terminal block and the suspending accessories are not included. Installation must be performed by a qualified person
OPTION 1: FLUSH MOUNT
Electrical Junction Box
STEP 1
Mounting Screws
ORTECH reserves the right to modify at any time, without notice, any or all of our product's features, designs, components
1.888.543.6473
www.ortechindustries.ca
Instruction Manual
APPLICATION NOTICE
TOOLS REQUIRED
Phillips
Screwdriver
INSTALLATION GUIDE
1. Pull the supply wires and house
ground wire from the Outlet Box.
Position the mounting plate over
the Junction Box. Mark the
location of the two holes located
on the Mounting Plate. Be sure to
mark only the narrow parts of the
Mounting
hole. Removeing Plate from the
Plate
ceiling. Drill the two holes using
the appropriate type and size drill
bit. Insert anchors into the holes.
(See Step 1)
and specifications to meet market changes.
13376 Comber Way,
Surrey, BC V3W 5V9
MOTION SENSOR FLUSH MOUNTS
FM1-MS5-5CCT | FM1-MS7-5CCT | FM1-MS9-5CCT
WARNING
WARNING — THE INSTALLATION MUST BE CARRIED
OUT BY A QUALIFIED ELECTRICIAN.
▪ LED Closet lights are suitable for using in damp
locations
Please keep the LED Closet lights away from any
▪
corrosive substance, and please use dry cloth
when you clean it
▪ Before installation or maintenance, please
disconnect the power to prevent electric shock
CAUTION
PLEASE READ INSTRUCTION BEFORE
COMMENCING INSTALLATION AND RETAIN FOR
FUTURE REFERENCES.
▪ Electrical products can cause death or injury, or
damage to property.
▪ If in any doubt about the installation or use of this
product, consult a competent electrician.
Wire Pliers Wrench
Cutters
STEP 2
Black
White
Ground
205 Summerlea Road,
Brampton, Ontario
2. Wire Connections : Connect the
house ground wire to the fixture
ground wire; connect the white
supply wire to the white fixture
wire; connect the black supply
wire to the black fixture wire by
5CCT
using the wire connectors.
switch
Carefully tuck all wires back into
the Junction Box. Adjust the 5CCT
switch. (See Step 2)
