LED Security Light Sensors
MODEL
OL-S
1. To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts / abrasions and other hazards,
please read all warnings and instructions included with and on this product prior to installation
2. For commercial installation, service and maintenance of this product should be performed by a qualified, licensed electrician
3. For residential installation, if you are unsure about the installation or maintenance of this product, consult a qualified licensed electrician
4. DO NOT mount the unit against flammable surfaces
5. It is recommended that this security light is mounted at least 6' 6" off the ground
6. The security light should NOT be used in areas with limited ventilation or high ambient temperatures
7. The security light CANNOT be used with a dimmer switch, motion or occupancy sensor or other electronic switching device
8. This product is intended to be connected to a properly installed and grounded UL listed junction box
WARNING — RISK OF ELECTRICAL SHOCK
• Turn OFF electrical power at fuse or circuit breaker box before wiring product to the power supply
• Verify if the supply voltage is correct before installing (110V-240V)
• Make all electrical and grounded connections in accordance with the National Electric Code and any applicable local code requirements
• All wiring connections should be capped with UL listed wire connectors
WARNING — RISK OF PRODUCT DAMAGE
• NEVER connect fixture with power ON
• DO NOT mount or support product in a manner that can cut the outer wire jacket or damage the wire insulation
• Avoid covering LED products with insulation, foam or other materials that will prevent convection or conduction cooling
CAUTION
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
Electrical products can cause death or injury, or damage to property.
If in any doubt about the installation or use of this product, consult a competent electrician.
Tools Required for Installation:
Phillips screwdriver and level
The installation of the Security Light Motion Sensor requires making connections to house wiring. If you are not confident
making these connections safely, consult a qualified electrician.
REMINDER:
Apply silicone caulking around the edges of cover plate and in any open holes for a water-tight seal.
info@ortechindustries.com
www.ortechindustries.com
WARNING
WARNING — THE INSTALLATION MUST BE CARRIED OUT BY
A QUALIFIED ELECTRICIAN.
1. LED Security Light Sensors are suitable for using in dry and damp locations
2. Please keep the LED Security Lights away from any corrosive substance, and please use
dry cloth when you clean it
3. LED Security Light Sensors can only be installed by a qualified electrician
4. Before installation or maintenance, please disconnect the power to prevent electric shock
Application Notice
13376 Comber Way
Surrey BC V3W 5V9
375 Admiral Blvd
Mississauga
,
ON L5T 2N1
Instruction Manual
1-888-543-6473
1-888-541-6474
Advertisement
Table of Contents
Summary of Contents for Ortech OL-S
- Page 1 LED Security Light Sensors Instruction Manual MODEL OL-S WARNING WARNING — THE INSTALLATION MUST BE CARRIED OUT BY A QUALIFIED ELECTRICIAN. 1. LED Security Light Sensors are suitable for using in dry and damp locations 2. Please keep the LED Security Lights away from any corrosive substance, and please use dry cloth when you clean it 3.
- Page 2 LED Security Light Sensors Instruction Manual MODEL OL-S CAUTION INSTALLATION GUIDE 1. Turn OFF all power by removing fuse or flipping circuit breaker to OFF position 2. Screw motion sensor arm into the desired hole on junction box's cover plate.
- Page 3 LED Security Light Sensors Instruction Manual MODEL OL-S CAUTION INSTALLATION GUIDE Sensor Adjustments ** You MUST adjust the motion sensor on the light to the desired area before you can adjust the time and LUX settings. Time Setting The TIME setting controls how long the unit remains illuminated following activation and after all motion ceases.
- Page 4 (Reposition sensor) (Reposition sensor. Reduce Range) ORTECH reserves the right to modify at any time, without notice, any or all of our product's features, designs, components and specifications to meet market changes.
