Page 1 Installation Manual IGIFLE Issue 1.00 VISION-64 ® Security Controller...
Page 2: Copyright Notice
 Vision-64 Installation Manual VISION-64® Security Controller Document Part Number MACC110I Document Issue 1.00 Date Released 1st March 2005 Firmware Revision V1.03 Hardware Revision D or higher CO PY R I G HT NOTICE TE L E P E RM I T N OT E Copyright ©...
Page 3: Table Of Contents
Contents  CONTENTS COPYRIGHT NOTICE ................................... II TRADEMARKS ..................................... II NOTICE OF LIABILITY ................................. II TELEPERMIT NOTE ..................................II SECTION 1 OVERVIEW ..............................1-1 FEATURES ....................................1-1 OVERVIEW ....................................1-1 SECTION 2 INSTALLING THE HARDWARE .........................2-1 MOUNTING THE CABINET ..............................2-1 MODULE SPACES ..................................2-1 PANEL LED INDICATORS .................................2-1 PANEL ADDRESS SELECT ................................2-2 KEYPAD BUTTON FUNCTIONS ...............................2-2...
Page 4  Vision-64 Installation Manual SECTION 5 ACCESS PROGRAMMING .........................5-1 USER DEFAULT TABLE ................................5-2 USER PIN CODES ..................................5-2 Erase User ......................................... 5-2 Change Own PIN ..................................... 5-2 Change Other PIN ....................................5-2 Add PIN ........................................5-3 Delete PIN ........................................ 5-3 View PIN ........................................5-3 USER TOKENS ..................................5-3...
Page 5 Contents  Reset Alarm Memory On Disarm ....................................6-3 Duress Allowed ..........................................6-3 Acknowledge All Faults ........................................ 6-3 Single Button Arming Allowed – All On ................................. 6-3 Single Button Arming Allowed – Part On ................................6-3 Link To Common Area ........................................6-3 Single Button Part Oﬀ...
Page 6  Vision-64 Installation Manual 5 – Burglary Handover ........................................7-5 6 – Burglary 24-Hour ........................................7-5 7 – Tamper 24-Hour ........................................7-5 8 – Hold Up 24-Hour ........................................7-5 9 – Medical 24-Hour ........................................7-5 10 – Panic 24-Hour ......................................... 7-5 11 –...
Page 7 Contents  Output Status ......................................8-1 Turn Output On/Oﬀ ....................................8-1 OUTPUT PROPERTIES ................................8-2 Output Name ......................................8-2 Event Type ........................................ 8-2 2 – AC Trouble ..........................................8-2 3 – Telephone Line Trouble ......................................8-2 4 – Comm Fail – Destination 1 / 2 ..................................... 8-2 5 –...
Page 8  Vision-64 Installation Manual Output Polarity ....................................... 8-6 Normally Open Going Low ......................................8-6 Normally Open Going Low With Pre Delay ................................8-6 Normally Open Latching Low ....................................8-6 Normally Open Pulsing Low ....................................... 8-6 Normally Open One Shot Low ....................................8-6 Normally Open One Show Low + Retrigger ................................
Page 9 Contents  Alarm On Telephone Line Fail If Armed .................................. 9-5 Alarm On Telephone Line Fail If Disarmed ................................9-6 Display ‘Phone In Use’ ........................................9-6 Country ........................................9-6 Set SMS Password ....................................9-6 Call Back Number ....................................9-6 RAS Security PIN ..................................... 9-7 Log Threshold ......................................
Page 10  Vision-64 Installation Manual General Options ....................................10-3 Keypad Extinguish ........................................10-3 Greeting On Arm ...........................................10-3 Greeting On Disarm ........................................10-3 Enable Rear Tamper ........................................10-3 PIN To Change Area ........................................10-3 Report Keypad Temperature ....................................10-3 Display Area Indicators .......................................10-3 Beeper Options ..................................... 10-4 Trouble Alerts ..........................................10-4...
Page 11 Contents  RF Signal Low ..........................................11-2 Comms Trouble R1 ........................................11-2 Comms Trouble R2 ........................................11-2 Comms Test Fail ..........................................11-2 Buss Trouble ............................................11-2 Default PIN Trbl ..........................................11-2 Date And Time ..........................................11-2 Cabinet Tamper ..........................................11-2 Panel Missing ..........................................11-2 Siren Trouble ...........................................11-2 Telco Line Trouble .........................................11-2 LAN Overload ..........................................11-2 Comm+ Overload .........................................11-2 Accessory Overld ..........................................11-2...
Page 12  Vision-64 Installation Manual Name ........................................11-9 Time ........................................11-10 Day ........................................11-10 Function .......................................11-10 Disabled ............................................11-10 Area On/Oﬀ ..........................................11-10 Area Part On/Oﬀ ......................................... 11-10 Operate Output .......................................... 11-10 Timer Group ..........................................11-11 Index ........................................11-11 SYSTEM HOLIDAYS ................................11-11 Name ........................................11-11 Start Stop Dates ....................................11-11...
Page 13: Features
 Supervised LAN Keypads (Maximum 8 Keypads) Programming  Keyswitch Input You can program the Vision-64 either by a keypad or using a  256 History Event Memory personal computer using the VisionLink upload/download  Fully Menu Text Programmable software.
Page 15: Installing The Hardware
Figure 2: Metal Box – Module Space Allocations PA N E L L E D I N DI CATO RS The Vision-64 PCB has two LED indicators (Dialler and Status Figure 1 : Cabinet Dimensions LED’s) which display the following information.
Page 16: Panel Address Select
Table 3 Panel Node Address Select numbers. The [] key allows you to navigate through menus or to toggle characters The node switch should be left at Panel 1 position for Vision-64. OFF-OFF-OFF when programming text or telephone numbers. Pressing the [] key when the...
Page 17: Status Icons & Led Indicators
Section 2 - Installing the Hardware  Keypad DIP Switch Address Settings All On Keypad To Address Flashing Alarm Keypad 1 Oﬀ Oﬀ Oﬀ Area is oﬀ. Green Keypad 2 Oﬀ Oﬀ Flashing Area not ready to turn on Keypad 3 Oﬀ...
Page 19: Wiring Diagrams
 SE CT ION 3 Wiring Diagrams ZO NE WIRING The Above diagrams display the zone wiring conﬁgurations using Normally-Closed Alarm contacts and Normally-Open Alarm Contacts. When using Normally-Open Alarm Contacts you Note must select Inverted Seal for each zone in MENU 3-1-8. A shorted loop is a tamper condition for all EOL zone conﬁgurations.
Page 20: Eol Resistor Colour Code
 Vision-64 Installation Manual EOL R ES ISTO R CO LOU R CO D E T E R M I N A L D E S C RI P T I ON S Nº Name Description Earth wire from this terminal is connected to Earth the Mains earth.
Page 22  Vision-64 Installation Manual Connect To Cabinet Tamper 16Vac 22VA Plug Pack GREEN YELLOW YELLOW 12VDC 7Ah Sealed Lead Acid Battery Accessories (e.g. PIR Detectors) Connect To Zone Terminals LAN + Keypad / LAN - LAN Expansion Device LAN A...
Page 23: Programming Overview
 SE CT ION 4 Programming Overview he Vision-64 Control System incorporates a menu text driven N AV IGAT IN G T H E M E N U S interface. This interface is very similar to that found on many Using the up and down arrow keys to navigate, locate the mobile phones.
Page 24: Alpha Text
 Vision-64 Installation Manual AL PH A T EX T T E L E P HO N E N UM B E RS Text descriptions are available for Area Name, Zone Name, To program, select primary telephone number under MENU 5-...
Page 25: Service Mode
Programming Overview  S ERV ICE MO DE T R IG G E R IN G A D U RE S S A L A RM Service mode when activated disables dialler reporting, prevents If your PIN is 2580, to send a duress report when the area is oﬀ, all alarms and prevents all users from arming the system.
Page 26: Zone Array
 Vision-64 Installation Manual ZON E A RR AY BA S I C RE P O RT I N G RE F E R E N C E The feature allows you to view the condition of all zones on The following table is a shortform point ID listing.
Page 27: Menu Reference Table
Programming Overview  M EN U R EF E RE N CE TAB L E The Vision Controller includes a simple text menu system which makes all levels of programming extremely easy. Once a valid PIN has been entered followed by the MENU key, the system will automatically determine which menus and options the PIN holder has access to and only those items will be displayed.
Page 28  Vision-64 Installation Manual Inputs Outputs Comms Commands Commands Commands AUMI 3-0-0 Zone Status AUMI 4-0-0 Output Status 5-0-0 Set Domestic Number 3-0-1 Zone Array 4-0-1 Turn Output On/Oﬀ 5-0-1 Call /Answer RAS 3-0-2 Bypass Zones 5-0-2 Call Forward On/Oﬀ...
Page 29 Programming Overview  Devices System Commands Commands 6-0-0 Keypad Status 7-0-0 Panel Status 6-0-1 RF Status 7-0-1 System Trouble 6-0-2 Serial Status 7-0-2 History Log 6-0-3 Output Status 7-0-3 Domestic Default 6-0-4 P / Supply Status 7-0-4 Factory Default 6-0-5 GSM Status 7-0-5 Template Default 6-0-6 Ethernet Status...
Page 31: Access Group
 SE CT ION 5 Access Programming he Vision-64 has 48 users which can each use any combination parameters are checked and if the user has a matching access of pin, radio keyfob or a proximity token to operate the group assignment to the reader access group assignment then system.
Page 32: User Default Table
 Vision-64 Installation Manual USE R D E FAU LT TA B LE Access > PIN Codes > Parameter User 1 User 2 - 48 Change Own PIN MENU 1-1-0    Add PIN 2580 This command allows a user to change their own PIN.
Page 33: Add Pin
Access Programming  If you attempt to enter a new PIN which already exists the Access > PIN Codes > system will display PIN Not Allowed. The next time the original View PIN MENU 1-1-4  PIN holder disarms the system they will be notiﬁed that their PIN Note code has been compromised.
Page 34: Delete Token
 Vision-64 Installation Manual U S E R RF K E Y FOB S To add token for Ur001 John Smith This section outlines how to add and delete RF keyfobs. RF Swipe New Token Keyfobs provide an alternate method for users to turn the Press OK or MENU system on and oﬀ.
Page 35: Test Keyfob
Access Programming  Press [OK] to delete the RF Keyfob ID number and exit or press U S E R P RO P E RT I E S [MENU] to exit without saving. This section outlines user properties including User Name, Area Assignment, User Options, Erase User and Access Group.
Page 36: User Option
 Vision-64 Installation Manual Use the up and down arrow keys to highlight the option then will prompt the user to automatically bypass each faulted zone. To prevent users from being able to force arm an area you will need to press the [ON] key to enable or the [OFF] key to disable.
Page 37: Access Assignment
Access Programming  Using the numeric keys, enter the Timer Group. Valid entries Variable pin lengths are useful for increasing security levels. are 1 – 8 or 0 to disable. Another use would be to program a single digit code to trigger an output.
Page 38: Prox Readers
This menu allows you to program the name or location description of the prox reader. Up to 10 diﬀerent Readers can be used on the Vision-64. This can comprise of 8 keypads with Access > Prox Reader > built-in Readers and 2 additional Readers connected via an...
Page 39: Reader Options
Access Programming  To Arm In Part Mode Access > Prox Reader > Present the token three times within 5 seconds and the area will arm Reader Options MENU 1-6-3  in Part Mode 2. Arming Allowed Disarming Allowed Part Mode 2 can only be activated if there are zone programmed for Part Mode 2.
Page 41: Area Programming
 SE CT ION 6 Area Programming he Vision-64 has 8 diﬀerent areas each with its own speciﬁc Example: Simple Two Area System programmable options. 1) Assign zones to area 1 and area 2 Under the commands menu you can interrogate the status of 2) Assign the home areas for the keypads an area, turn chime mode on/oﬀ, move to an area or arm and...
Page 42: Turn All Areas On
 Vision-64 Installation Manual A001 Security System Areas > Commands > A002 Area 2 Name Turn All Areas On MENU 2-0-2    A003 Area 3 Name Press  OK or MENU This command allows you to turn on all areas that your PIN has been assigned to at the same time.
Page 43: General Options
Area Programming  Single Button Arming Allowed – All On Areas > Properties > This option allows users to simply press the ON key to turn the area General Options MENU 2-1-1  ON. All zones being armed must be sealled. If open and close reports are programmed, the user ID number will report as 000.
Page 44  Vision-64 Installation Manual Pulse Count Handover Allowed Arm/Disarm Speaker Beeps Via Keyswitch This option allows zones from the same area that have both pulse This option allows audible beeps via the speaker output to verify to count and pulse count time programmed the ability to hand over the user that they have successfully turned the area On or Oﬀ...
Page 45 Area Programming  Report Exit Error Silent Burglary Alarm This option allows the system to report and Exit Error Alarm. When selected, the panel will activate the strobe output when a silent burglary zone has triggered an alarm. An exit error occurs when an entry/exit delay zone becomes unsealled during exit delay time and remains unsealled at the end of exit delay Fire Alarm time.
Page 46: Area Te Sti N G
 Vision-64 Installation Manual Using the numeric keys, enter the new account number. Use Areas > Area Testing > the up and down arrows to select special characters BCDEF. User Test Interval MENU 2-9-1  Account Dest 2 A001 1604000000...
Page 47 Area Programming  Areas > Area Testing > Test Options MENU 2-9-3  User Test Required Reserved Reserved Reserved Reserved Walk Test Reports Walk Test 24-Hour Zones Walk Test Fire Zones The above options are programmable per area. Enter [MENU] + [2] + [9] + [3] and select the area from the list then press [OK].
Page 49: Input Programming
SE CT ION 7 Input Programming he Vision-64 is capable of controlling up to 64 inputs in Enter [MENU] + [3] + [0] + [0] and select the zone you want to either hardwire or wireless conﬁguration. Each input can view from the list then press [OK].
Page 50  Vision-64 Installation Manual The keypad will display the following zone array information Inputs > Commands > for Zones 97 to 112. Set Chime Zones MENU 3-0-3   9990000000000111 1 7890123456789012 0 This menu allows you to program zones to be monitored when ---------------- 0 chime mode is activated.
Page 51: Zon E D E Fault Ta B L E
ZON E D E FAULT TA B L E The table below lists the default values for all zone parameters in the Vision-64. By default, zones 5 to 16 are set as Instant zones and zones 17 to 64 are set as Not Used. Zones marked as Not Used do not require EOL resistors to be ﬁtted.
Page 52  Vision-64 Installation Manual Inputs > Commands > Inputs > Zone Properties > Smoke Sensor Reset MENU 3-0-5 Zone Type MENU 3-1-1     This command allows you to reset smoke sensors. When This menu allows you to conﬁgure the zone type or behaviour initiated this command will cause any outputs programmed as for every zone in the system.
Page 53 Input Programming  3 – Burglary Instant 1 If a horn speaker is connected and programmed, a distinct ﬁre sound will be heard to indicate that it is a ﬁre alarm that has registered. The Zones programmed as Instant 1 will immediatly cause the alarm ﬁre sound via the horn speaker is diﬀerent than the burglary sound.
Page 54  Vision-64 Installation Manual Access Group When pulse count hands over from one zone to another and an alarm is triggered, a cross alarm report will be sent to the central There are 8 diﬀerent access groups. station. Door Access Group Example...
Page 55 Input Programming  Repeat Step 2 until all options are programmed as required, Inputs > Zone Properties > then press [OK] to save and exit or press [MENU] to exit Report Route MENU 3-1-6  without saving. 0 = Report Events To Log Only 1 = Report Events To Destination 1 + Log Lockout Dialler 2 = Report Events To Destination 2 + Log...
Page 56  Vision-64 Installation Manual Sensor Watch Inputs > Zone Properties > Setting this option causes the system to monitor the zone’s activity Zone Options MENU 3-1-8  while the corresponding area is in the disarmed state. If the zone fails to unseal and reseal at least once during the Sensor Watch...
Page 57 Press [OK] to DELETE the RF device and exit or press [MENU] to A D D IN G RF S E N S OR S exit without deleting. The Vision-64 panel supports a wide range of 3rd party wireless RF Sensor - Learn Mode movement sensors, door contacts and smoke detectors...
Page 58 7-10  Vision-64 Installation Manual GLOB A L INP U T O P T IONS Inputs > Global Input Options > Inputs > Global Input Options > Input Options MENU 3-4-2  EOL Value MENU 3-4-0  Tamper On Short...
Page 59 7-11 Input Programming  I N P U T T E ST I N G Inputs > Tamper Inputs > Tamper Options MENU 3-6-0  Inputs > Input Testing > Display Panel Tamper Walk Test All Zones MENU 3-9-0  ...
Page 60 7-12  Vision-64 Installation Manual Open and close the zone that needs to be tested. When the test has been completed the keypad will display: Zn001 Zone 1 Name Test Successful Press OK or MENU Press [OK] or [MENU] to exit.
Page 61: Output Programming
 SE CT ION 8 Output Programming he Vision-64 is capable of controlling up to 16 outputs. Output 1 Name Op001 The ﬁrst 4 outputs are on the main control board and an Is Off and Ready additional 4 outputs are provided using an output expander module.
Page 62  Vision-64 Installation Manual Output 1 Name Op001 Event Type Op001 Output Is Off To Turn ON, Press ON 36 - External Audible To Go Back Press OK Press 0-9 OK to SAVE 1 - Battery Trouble The keypad will display the following when the output is on. To This event type will cause the output to operate when the panel turn the output Oﬀ, press [OFF].
Page 63 Output Programming  10 – Destination 2 Kiss-Off 21 – Area Disarmed This event type will cause the output to operate when the panel This event type will cause the output to operate as soon as the receives a kiss-oﬀ acknowledgment from the receiving party while corresponding area is disarmed and will reset when the area is armed communicating to destination 2.
Page 64  Vision-64 Installation Manual 30 - Chime Zone Faulted 37 – Internal Siren This event type will cause the output to operate when a speciﬁc This event type will cause the output to operate when any audible Chime Zone is triggered and reset when the Chime Zone reseals.
Page 65 Output Programming  48 – Strobe 57 – Part Entry Time This event type is used to operate a stobe warning light. The output This event type will cause the output to operate when the Part Entry can be made to operate when any of the following events occur. timer is active and will reset when Part Entry time expires.
Page 66  Vision-64 Installation Manual Normally Open Pulsing Low Outputs > Properties > Output is normally open circuit and will pulse LOW when the event Output Polarity MENU 4-1-3  occurs. The output will reset when the output event restores. Use the Time Parameter to set the pulse duration.
Page 67 Output Programming  Horn Speaker (Output 1 or 2 Only) Outputs > Properties > This polarity can only be used for Output 1 and Output 2 when a horn Output Options MENU 4-1-5  speaker has been connected. Do Not Operate On Low Battery T I M ED O U T P U TS Display Overload Report Overload...
Page 68  Vision-64 Installation Manual OU T PU T T EST IN G Outputs > Testing > Outputs > Testing > Strobe Siren Test MENU 4-9-2   External Siren Test MENU 4-9-0   This menu allows you to test the any outputs programmed as This menu allows you to test the operation of any output event type 48, Strobe light.
Page 69 OU T PU T D EFAU LT TA B L E The table below lists the default values for all Output parameters in the Vision-64. Outputs 1 to 3 are High current digital outputs and Output 4 is the onboard relay output. Outputs 5 to 8 are available when the optional Output Relay Expander Board (CM110) is ﬁtted.
Page 71: Com M S Prog R Am M I N G Co M M An Ds
SE CT ION 9 Comms Programming he Vision-64 has a built in dialler that connects directly to COM M S PROG R AM M I N G CO M M AN DS a standard PSTN telephone line. To program the dialler you Comms >...
Page 72  Vision-64 Installation Manual See MENU 5-1-6 and MENU 5-1-7 to program the Call Forward Domestic Phone Number 2 ON and Call Forward OFF number sequence. Note 86538_ Press  0-9 OK to SAVE Comms > Commands > When the second number is complete press [OK] to program...
Page 73 Comms Programming  Enter [MENU] + [5] + [1] + [1]. The keypad will display the Press [OK] to save and exit or press [MENU] to exit without current Primary Telephone Number for Destination 1. saving. Primary Dest 1 P001 Comms >...
Page 74  Vision-64 Installation Manual Enter [MENU] + [5] + [1] + [7]. The keypad will display any Comms > Telephone Number > current Call Forward Oﬀ sequences. Call Forward On MENU 5-1-6   Call Forward Off N001 Digits ...
Page 75: Alarm On Telephone Line Fail If Armed
Comms Programming  Extend Handshake Wait Period To 1 Minute Comms > Properties > This option sets the panel to wait for up to 60 seconds to receive a Dialler Options MENU 5-2-1  valid handshake signal from the base station receiver. The handshake tone indicates to the panel that it has reached the security company’s Dialler Enabled base station receiver and can now send it’s pending reports.
Page 76: Alarm On Telephone Line Fail If Disarmed
 Vision-64 Installation Manual Alarm On Telephone Line Fail If Disarmed Comms > Properties > This option sets the panel to trigger an alarm when the telco line Set SMS Password MENU 5-2-7  fails provided that the area is turned OFF or disarmed. In a multi-area system this option is global and will be triggered if only one area in the system is in the disarmed state.
Page 77: Ras Security Pin
Comms Programming  Press [MENU] + [5] + [3] + [0]. The keypad will display the session is established then the system will send a ‘Log Overﬂow’ current Call Back telephone number if programmed. report. The panel will also log these events in its memory. Call Back Number N001 Press [MENU] + [5] + [3] + [2].
Page 78: Ras Allowed
 Vision-64 Installation Manual Allow ‘User Functions’ Via Remote Access Software  RAS Allowed Setting this option allows access to user functions via the RAS upload/ Callback Verify download software. If this option is not programmed, user functions  Abort RAS On Alarm will be disabled.
Page 79: Voice Access Code
Enter [MENU] + [5] + [3] + [7]. The keypad will display information for CLI number 1. Transmission Formats 9 -12 are not applicable on the Vision-64 control panel and should not be programmed. Other formats may CLI Number 1 require additional hardware or add on modules to function.
Page 80: Tx Format Dest 2
Emergency Route MENU 5-4-4  Transmission Formats 9 -12 are not applicable on the Vision-64 control panel and should not be programmed. Other formats may 0 = Report Events To Log Only require additional hardware or add on modules to function.
Page 81: Swinger Dialler
9-11 Comms Programming  Comms > Dialler Reporting > Comms > Dialler Reporting > Swinger Dialler MENU 5-4-5 Fire Report Delay MENU 5-4-7   (*** System Wide Parameter ***) SECONDS (*** System Wide Parameter ***) Swinger Dialler can be used to prevent a faulty or run-a-way PIR from continually re-triggering the zone and reporting to the This menu programs how long the panel will delay reporting ﬁre base station.
Page 82: Test Report Time
9-12  Vision-64 Installation Manual Communication Test Test Report Period Successful. 01-Every Day Press OK Press 0-9 OK to SAVE If the test fails, the keypad will prompt: Communication Test Use the up and down arrow keys to select the Test Report Fail.
Page 83: Test Route
9-13 Comms Programming  Comms > Comms Test > Test Route MENU 5-9-4  0 = Report Events To Log Only 1 = Report Events To Destination 1 + Log 2 = Report Events To Destination 2 + Log 3 = Report Events To Destination 1 & Destination 2 + Log 4 = Report Events To Destination 2 If Destination 1 Fails + Log This menu programs which destination will be used to send both manual and automatic test reports.
Page 85: Device Programming
 SECTION 1 0 Device Programming his chapter covers the diﬀerent device types and the Devices > Commands > numerous programmable options which can be used to RF Status MENU 6-0-1    control how a device operates. The commands menu allows you to view the status of any This command will display the type of RF receiver currently device in the system and will display its condition as well as the ﬁtted to the panel.
Page 86: Keypad Volume
10-2  Vision-64 Installation Manual The status line will scroll the keypad voltage, temperature and Keypad 001 Volume home area while the keypad type and ﬁrmware version number are continuously displayed. Press OK to SAVE Use the up and down arrow keys to select the output expander that you want to view, then press [OK] to select.
Page 87: Home Area
10-3 Device Programming  Repeat Step 2 until all options are programmed as required, Devices > Keypads > then press [OK] to save and exit or press [MENU] to exit Home Area MENU 6-1-3  without saving. Keypad Extinguish This menu allows you to assign each keypad to a default home Setting this option conﬁgures the panel to automatically turn oﬀ...
Page 88 10-4  Vision-64 Installation Manual Devices > Keypads > Devices > Keypads > Beeper Options MENU 6-1-5 Emergency Keys MENU 6-1-6   Trouble Alerts Audible Keypad Fire Entry Warning Report Keypad Fire Exit Warning Audible Keypad Medical Chime Tone...
Page 89 10-5 Device Programming  Report Keypad Panic Use the up and down arrow keys to highlight the option then press the [ON] key to enable or the [OFF] key to disable. Setting this option allows the panel to send a Panic report (event 44) to the base station when a Keypad Panic Emergency Alarm has been Repeat Step 2 until all options are programmed as required, triggered via the keypad.
Page 90 10-6  Vision-64 Installation Manual Report RF Keyfob Panic Using the numeric keys, enter the number of hours for the RF supervision time. Valid times are 0 - 255 hours, 0 = No Setting this option will cause the panel to send a Panic report to the Supervision.
Page 91 10-7 Device Programming  S ER I A L DE VIC E O P TI O NS Flow Control Devices > Serial Device > 00 - No Handshaking Device Type MENU 6-3-0  Press 0-9 OK to SAVE 0 = Disabled 1 = Serial Printer Use the up and down arrow keys to select the Flow Control 2 = Computer...
Page 92 10-8  Vision-64 Installation Manual Reserved Devices > Ethernet > Reserved Options MENU 6-6-1  Reserved Reserved 0 = Reserved 1 = Reserved Reserved for future use. 2 = Reserved Devices > Access Controller > Reserved for future use. Options MENU 6-7-3 ...
Page 93 10-9 Device Programming  Devices > X10 Device > Options MENU 6-8-2  Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved for future use. Devices > X10 Device > Options MENU 6-8-3  Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved for future use.
Page 95: System Commands
Line 1 Displays: trouble events. The panel number that you are getting information from (eg. Panel 001 P001 Node 1 = Panel 1 etc). The vision-64 is only conﬁgured to work Vision 64 Ver 1.02 with one panel. Date and Time...
Page 96 11-2  Vision-64 Installation Manual Buss Trouble SYSTE M T RO U B LE MES SAGE S This trouble message will display if the panel failed to communicate The following list shows the systems trouble messages including to a system device which is connected to the LAN bus (e.g. keypad a description of what has caused the trouble event to occur.
Page 97: Default Memory
11-3 System Programming  Default Memory System > Commands > Domestic Default MENU 7-0-3  Service Mode This command will conﬁgure the control panel for Domestic This trouble message will display while the system is in Installer format reporting (eg. mobile telephones etc). All alarm restore Service mode.
Page 98: System Clock
11-4  Vision-64 Installation Manual When the time is set correctly press [OK] to save and exit or System > Commands > press [MENU] to exit without saving. Template Default MENU 7-0-5  System > Clock > This command allows the installer to download pre-conﬁgured...
Page 99: System Timers
11-5 System Programming  When ﬁnished press [OK] to save and exit or press [MENU] to System > Timers > exit without saving. Entry Time 1 MENU 7-2-1  Australian Daylight Savings Times At the time of writing this document QLD, the NT and WA do SECONDS (*** System Wide Parameter ***) NOT participate in daylight savings.
Page 100 11-6  Vision-64 Installation Manual Press [OK] to save and exit or press [MENU] to exit without System > Timers > saving. Part Entry Time MENU 7-2-3  System > Timers > Output Pre-Alert MENU 7-2-5  SECONDS (*** System Wide Parameter ***) This menu allows you to program the Part Mode Entry Delay time also know as entry guard.
Page 101: System Power Options
AC fail at the same time and should be left voltage below 10.2 volts, then a Battery Test Failed report will be sent. disabled when using the Vision-64 panel. A Battery Test restore will be sent when the battery is re-connected or replaced.
Page 102 11-8  Vision-64 Installation Manual Arming Allowed On Low Battery Display LAN + Current Overload Setting this option will allow the system to be armed even though the Setting this option allows the keypad to display a system trouble panel currently has a low battery condition.
Page 103: Name
SYST E M S CH E D U L E S press [OFF] to turn the siren oﬀ. The Vision-64 has 8 schedules each with a start and stop time as well as the day of the week and holidays. These schedules can Repeat Steps 2 and 3 until the desired siren tone is achieved be used to operate outputs, arm and disarm diﬀerent areas at...
Page 104: Time
11-10  Vision-64 Installation Manual Day Sk001 System > Schedules > S M T W T F S Hol Time MENU 7-5-1   Y Y Y Y Y Y Y Press 1-8 OK to SAVE Start Time Stop Time...
Page 105: Timer Group
SYST EM H OL IDAYS Holiday Dates H001 The Vision-64 has provision for up to 8 individual holiday time Start 12am Stop 12am periods which can be used to allow or deny access to users or to...
Page 106: System Options
11-12  Vision-64 Installation Manual SYSTE M O PT IO N S System > System Options > System > System Options > Area Options MENU 7-7-1  General Options MENU 7-7-0  Area 1 = Common Area Display LAN Fail...
Page 107: Fault Acknowledge All Areas
11-13 System Programming  Fault Acknowledge All Areas System > Options > Setting this option allow system trouble faults to be acknowledged Keypad Hi/Lo Temp MENU 7-7-3 from any area or keypad on the system without the need to toggle ...
Page 108: Report/Log Entry/Exit Installer Menu
11-14  Vision-64 Installation Manual Report/Log Entry/Exit Installer Menu Using the numeric keys, enter the language option as required then press [OK] to save and exit or press [MENU] to exit Setting this option will cause the panel to make a log entry and to without saving.
Page 109 11-15 System Programming  If the battery has failed the test, the keypad will display: Battery Test Failed. Please Call For Service. Press OK to Continue Press [OK] to exit. » » E N D S E C T I O N « « Issue 1.00 Copyright ©...
Page 111: Programming Examples
Opening a Door using a Single Digit Code (4 =Normally Open One Shot Low) The Vision-64 can be used to operate an electrically controlled Set Output 5 - Time Parameter MENU 4-1-4 = 000 000 005 000 door using a single digit code. The example assumes User 10 (5 seconds) and Output 5 are being used.
Page 112: Operating An Output With A Schedule
12-2  Vision-64 Installation Manual Operating an Output with a Schedule Assign the user to Access Group 4, MENU 1-4-5. Users can belong to multiple Access Groups allowing access to multiple To automatically operate an output using a schedule, select doors.
Page 115: Specifications
 SECTION 1 3 Speciﬁcations Compatible CM100 Voice Command Module Panel Description Vision-64 (Part Number CC110) Accessories CM105 16/32 Zone Expander Voltage Input 16-22 VAC CM106 8/16 Piggy Back Zone Expander CM110 4 Way Relay Output Module Current 22 VA min 3 wire plug pack adapter or...
Page 117: Index
 SECTION 1 4 Index Access Programming......5-1 Date & Time ........11-4 ADDRESS SELECT Daylight Saving Keypad .
Page 118 14-2  Vision-64 Installation Manual Horn Speaker Tone......11-8 PIN Retry Count....... . 5-7 PROGRAMMING Alpha Text .
Page 119 14-3 Index  Siren Swinger........11-9 User Test Required ......6-7 Smart Lockout .
