Sony CDX-CA400 Product Manual

2002 SONY MOBILE
PRODUCT GUIDE
CDX-CA400
FM/AM Compact Disc Player
Audio Power Specifications
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
23 watts per channel minimum continuous average power into 4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more than 5%
total harmonic distortion.
CD Player Section
Signal-to-noise ratio
Frequency response
Wow and flutter
Tuner Section
FM
Tuning range
Antenna terminal
Intermediate frequency
Usable sensitivity
Selectivity
Signal-to-noise ratio
Harmonic distortion at 1 kHz
Separation
Frequency response
Power Amplifier Section
Outputs
Speaker impedance
Maximum power output
General
Outputs
Tone controls
Power requirements
Dimensions
Mounting dimensions
Mass
Supplied accessories
Note
This unit cannot be connected to a digital preamplifier or an equalizer.
Design and Specifications subject to change without notice.
Downloaded from: https://www.usersmanualguide.com/
90 dB
10 – 20,000 Hz
Below measurable limit
87.5 – 107.9 MHz
External antenna connector
10.7 MHz
11 dBf
75 dB at 400 kHz
65 dB (stereo), 68 dB (mono)
0.7% (stereo), 0.5% (mono)
33 dB at 1 kHz
30 – 15,000 Hz
Speaker outputs
4 – 8 ohms
50 W × 4 (at 4 ohms)
Audio outputs
Power antenna relay control lead
Power amplifier control lead
Bass ±10 dB at 20 Hz (CDX-CA400)
Treble ±10 dB at 20 kHz (CDX-CA400)
12 V DC car battery (negative ground)
Approx. 178 × 50 × 177 mm
(7 1/8 × 2 × 7 in.) (w/h/d)
Approx. 182 × 53 × 161 mm
(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)
Approx. 1.2 kg
(2 lb. 10 oz.)
Parts for installation and connections (1 set)
Front panel case (1)
Card remote commander
RM-X115
• CD/MD Control
• Detachable Face
• MBP (My Best Position)
• 50W x 4 High Power
• Supplied Wireless Remote
(RM-X114)
• 8fs, 1-Bit D/A Converter
• Active Servo Control
• 60 Degree Install
• CD-RW Playback
• Indicates step-up
AM
Tuning range 530 – 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
Plug shown with wires facing viewer.
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
• D-Bass
• SSIR-EX Tuner
• 18FM + 12AM memory presets
• Rear Preout
• 7-segment LCD
• Active Display w/Demo Mode
Harness Plug Configuration
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
Wire Color Description
White Left front +
Green Left rear +
Purple Right rear +
Gray Right front +
Blue/white AMP Remote
Blue ANT Remote
Red Accessory
Black Ground
White/black Left front -
Green/black Left rear -
Purple/black Right rear -
Gray/black Right front -
Sky blue ATT
Illumination
Yellow Battery
