Montage Concrete footings and wall supports Measure the positions of the posts on the ground. Ground mounting can be carried out in a number of ways, depending on the situation. For example: on concrete footings, on a foundation or on existing ground. In these instructions, we assume that the system is installed on concrete footings.
Page 3
Montage Corner assembly Assemble the other post and beam as shown. Use four M8 x 35 mm hex nuts and M8 washers. Mounting wall brackets First determine the positions on the wall for mounting the wall brackets. Drill holes for the mounting hardware.
Page 4
Montage Load bar mounting Insert the assembled corner assembly into the wall- mounted bracket. Pull the control cable outwards through the recess in the wall bracket. Secure the beam profile at the top with 3 bolts. The other bolt is used when the cassette is mounted on the system.
Page 5
Montage Installing the extension socket Connect an extension plug to the motor cable. Plug in the plug and lower it into the pole. Diagonal measuring Measure the system diagonally, if necessary shifting the concrete footing to achieve the correct position. Also accurately adjust the height using the adjustable foot, and secure the adjustable foot to the concrete footing.
Page 6
Montage Box assembly Remove the 2 bolts at the top of the beams on which the cassette will rest. Place the cassette on the beams and secure it with the bolts you've just unscrewed. Then fasten the stirrups using 4.2 x 19 mm crosshead countersunk screws. Assembly of runners Slide the runners onto the feet of the trunk supports as shown.
Page 7
Montage Fixing the runners Secure the runners with two M6 x 12 mm countersunk crosshead screws. Tension band adjustment Unfold the fabric to the end of the guide rail. Cord tension Pull the cord through the guide block and position the cord mark behind the cord tensioner.
Page 8
Montage Attaching the cord to the wheel Make a loop on the cord. Place the wheel in the loop and pull the cord taut, then secure with an M4.2 x 25 mm screw. Fitting the load bar cover Fit the load bar covers as shown. Installing the trunk extension support (optional) When the pergola is wider than 4.0 metres: screw the trunk extension support to the upper trunk using the screw...
Page 9
Montage Installing the hood extension Hook the cover extension with the brush into the upper cover and screw on the side guide with the 4.2 x 25 mm self-tapping screw CK-KK and press on the covers. Connecting the runners Lower the mantling system and place the runners on the load bar. Fasten the runners to the load bar using 4.2 x 32 mm countersunk flat-head screws.
Page 10
Installing the extension socket Connectez une prise rallonge au câble pour le moteur. Installing the extension socket Drill an 11 mm hole in the post cover. Insert a sheath through the hole and feed the motor cable through. Fit an extension plug to the awning motor cable motor cable.
