Summary of Contents for Solimpeks TSE-V 200
- Page 1 Solimpeks Enameled Boiler Installation and User Manual...
- Page 2 Enameled Bo�ler...
- Page 3 INDEX Meaning of Warnings and Symbols Product Introduction Warranty Coverage Important Warnings Putting into operation Carrying and Placement of the product Maintenance and Repair Product range 200 L Enameled Boiler Connection Diagram 300 L Enameled Boiler Connection Diagram Equipment - Electric Heating Resistances Fault Detection...
-
Page 4: Meaning Of Warnings And Symbols
MEANING OF WARNINGS AND SYMBOLS Informat�on Th�s symbol �nd�cates user t�ps and part�cularly useful �nformat�on DANGER It �nd�cates a poss�ble dangerous s�tuat�on. Fa�lure to observe the warn�ng may result �n ser�ous �njury or death. ATTENTION Ind�cates a poss�ble warn�ng or caut�on s�tuat�on. CENTER OF GRAVITY The center of grav�ty of the load. -
Page 5: Product Introduction
When it comes to the use of renewable energy, the choice of the hot water storage tank is crucial. Solimpeks product models are very practical to use thanks to their high energy efficiency and spa- ce-saving design. -
Page 6: Warranty Scope
1-year warranty. Automatic control failures are only covered by a 1-year warranty. The product warranty provided by Solimpeks does not cover malfunctions arising from the failure to use the device under normal conditions of use. -
Page 7: Important Warnings
IMPORTANT WARNINGS The chemical imbalance of the water supply can lead to reduced heating efficiency of the stora ge tank and related equipment. It is important to check the water chemistry before installing the storage tank as the water quality will affect the reliability of the system. Lime formation in the boiler can shorten the service life of the tank. -
Page 8: Putting Into Operation
The recirculation line should be constructed as shown in the installation diagrams. In the Solimpeks boiler product range, the sensor sleeves are placed at the most suitable levels for the tem perature distribution in the tank. Install the sensors as shown below in the locations indicated for each product without starting the system. - Page 9 Solimpeks boiler product groups are heavy, so care should be taken when carrying the product to the place where it will be installed. You can find the weight of the product you have purchased in the table of boiler weights in this booklet.
-
Page 10: Maintenance And Repair
MAINTENANCE AND REPAIR The anode rod should be replaced periodically every 12 months after the boiler is com- missioned. This should be done by an authorized service center. In the boilers, water entry to the boiler is prevented by closing the valve at the mains water line inlet. -
Page 11: Product Range
PRODUCT RANGE Enamel Coated Boliers GENERAL INFORMATION Expanded serpentine surface area, designed for heat pumps. The inner surfaces of the boiler are advanced technology enamel coating. 200-400 μm enamel thickness. Electrostatic painted galvanized steel body. All surfaces in contact with clean water are hygienic and smooth, which does not allow bacterial growth. It is used for the preparation and storage of hot water together with solar collectors and heat sources. - Page 12 TSE-V 200 FOR HEAT PUMP PRO TSE-V D 300 C - C Limits Of Use Pipe Connection Hot Water Outlet inch G 1 1/4 " Max. Working Pressure Cold Water Inlet inch G 1 1/4 " Test Pressure Magnesium Anode inch G 1 1/4 "...
- Page 13 TSE-V D 300 TSE-V 300 FOR HEAT PUMP PRO C - C Limits Of Use Pipe Connection Hot Water Outlet inch G 1 1/4 " Max. Working Pressure Cold Water Inlet inch G 1 1/4 " Test Pressure Magnesium Anode inch G 1 1/4"...
- Page 14 TSE-V D 300 TSE-V 500 FOR HEAT PUMP PRO C - C Limits Of Use Pipe Connection Hot Water Outlet inch G 1 1/4 " Max. Working Pressure Cold Water Inlet inch G 1 1/4 " Test Pressure Magnesium Anode inch G 1 1/4 "...
- Page 15 EQUIPMENTS - ELECTRIC HEATER RESISTANCE Cable 2x4mm V / 50 Hz Features Operat�ng voltage V / 50 Hz Heat�ng capac�ty 3 kW Heat f�eld 30-70°C Cable length — Heat�ng rod length 25 cm Screw threads R 1 1/4" Compl�ance All products Touch�ng l�ve parts can result �n electr�c shock, caus�ng l�fe-threaten�ng �njur�es and may cause burns.
- Page 16 Use of th�s �nstallat�on and operat�ng manual �n whole or �n part �s protected by copyr�ght. Any use outs�de of copyr�ght �s subject to the perm�ss�on of SOLIMPEKS. In part�cular, th�s �ncludes the reproduct�on/copy�ng, translat�on, m�crof�lm�ng and electron�c storage of th�s manual.
