Summary of Contents for Solimpeks TSE-V 200
- Page 1 Solimpeks Enameled Boiler Installation and User Manual...
- Page 3 INDEX Meaning of Warnings and Symbols Product Introduction Warranty Coverage Important Warnings Putting into operation Carrying and Placement of the product Maintenance and Repair Product range 200 L Enameled Boiler Connection Diagram 300 L Enameled Boiler Connection Diagram Equipment - Electric Heating Resistances Fault Detection...
-
Page 4: Meaning Of Warnings And Symbols
MEANING OF WARNINGS AND SYMBOLS Information This symbol indicates user tips and particularly useful information DANGER It indicates a possible dangerous situation. Failure to observe the warning may result in serious injury or death. ATTENTION Indicates a possible warning or caution situation. CENTER OF GRAVITY The center of gravity of the load. -
Page 5: Product Introduction
When it comes to the use of renewable energy, the choice of the hot water storage tank is crucial. Solimpeks product models are very practical to use thanks to their high energy efficiency and spa- ce-saving design. -
Page 6: Warranty Scope
1-year warranty. Automatic control failures are only covered by a 1-year warranty. The product warranty provided by Solimpeks does not cover malfunctions arising from the failure to use the device under normal conditions of use. -
Page 7: Important Warnings
IMPORTANT WARNINGS The chemical imbalance of the water supply can lead to reduced heating efficiency of the stora- ge tank and related equipment. It is important to check the water chemistry before installing the storage tank as the water quality will affect the reliability of the system. Lime formation in the boiler can shorten the service life of the tank. -
Page 8: Putting Into Operation
The recirculation line should be constructed as shown in the installation diagrams. In the Solimpeks boiler product range, the sensor sleeves are placed at the most suitable levels for the tem- perature distribution in the tank. Install the sensors as shown below in the locations indicated for each product without starting the system. - Page 9 Solimpeks boiler product groups are heavy, so care should be taken when carrying the product to the place where it will be installed. You can find the weight of the product you have purchased in the table of boiler weights in this booklet.
-
Page 10: Maintenance And Repair
MAINTENANCE AND REPAIR The anode rod should be replaced periodically every 12 months after the boiler is com- missioned. This should be done by an authorized service center. In the boilers, water entry to the boiler is prevented by closing the valve at the mains water line inlet. -
Page 11: General Information
1 1/4“ 1 1/4“ 1 1/4“ 1 1/4“ Feed water in inch Anode rod 1” 1” 1” 1” Domestic water in inch Sensor 1/2“ 1/2” 1/2“ 1/2” *Solimpeks reserves the right to make changes to this table at any time. - Page 14 EQUIPMENTS - ELECTRIC HEATER RESISTANCE Cable 2x4mm 220 - 230 V / 50 Hz Type Features 220 - 230 V / 50 Hz Operating voltage Heating capacity 3 kW Heat field 30-70°C — Cable length Heating rod length 25 cm Screw threads R 1 1/4"...
- Page 15 Fault Detection The pressure in the system is constantly decreasing. The pump is probably activating too late. Is there air in the system? Bleed the system; increase the system pressure to min. static pre-pressure + Operating temperature difference Bring to 0.5 bar; continue to increase the Is ΔT chosen open large? pressure if necessary;...
- Page 16 Use of this installation and operating manual in whole or in part is protected by copyright. Any use outside of copyright is subject to the permission of SOLIMPEKS. In particular, this includes the reproduction/copying, translation, microfilming and electronic storage of this manual.
