- Page 1 • Please read this manual carefully before using the product you purchase and keep it well for future use. • Please note that images and sketch maps in this manual may be different from the actual product.
- Page 2 Disclaimer The default password is used for your first login. To ensure account security, please change the password after your first login. You are recommended to set a strong password (no less than eight characters). maximum extent permitted by applicable law, the product described, with its hardware, software, firmware ⚫...
- Page 3 change without prior notice. Update will be added to the new version of this manual. Use of this manual and product and the subsequent result shall be entirely on your own responsibility. In no event shall we be ⚫ reliable to you for any special, consequential, incidental, or indirect damages, including, among others, damages for loss of business profits, business interruption, or loss of data or documentation, or product malfunction or information leakage caused by cyber attack, hacking or virus in connection with the use of this product.
-
Page 4: Environmental Protection
for any consequences resulting from illegal operations of the device. The illustrations in this manual are for reference only and may vary depending on the version or model. As a result, some of the ⚫ examples and functions featured may differ from those displayed on your monitor. This manual is a guide for multiple product models and so it is not intended for any specific product. -
Page 5: Safety And Compliance Information
proper storage, use and disposal of this product, national laws and regulations must be observed. Safety and Compliance Information Safety Symbols The symbols in the following table may be found on installation-related equipment. Be aware of the situations indicated and take necessary safety precautions during equipment installation and maintenance. - Page 6 indicated by the symbols to avoid hazardous situations and use the product properly. Symbol Description WARNING! Indicates a hazardous situation which, if not avoided, could result in bodily injury or death. CAUTION! Indicates a situation which, if not avoided, could result in damage, data loss or malfunction to product. NOTE! Indicates useful or supplemental information about the use of product.
- Page 7 Installation This device is a class A product and may cause radio interference. Take measures if necessary. ⚫ Make sure the power supply voltage is correct before using the camera. ⚫ Do not drop the camera or subject it to physical shock. ⚫...
- Page 8 The sensor may be burned out by a laser beam, so when any laser equipment is being used, make sure that the surface of the ⚫ sensor not be exposed to the laser beam. While shipping, the camera should be packed in its original packing. ⚫...
- Page 9 Do not use organic solvents, such as benzene or ethanol when cleaning the front glass surface. ⚫ Never look at the transmit laser while the power is on. Never look directly ⚫ at the fiber ports and the fiber cable ends when they are powered on. Use of controls or adjustments to the performance or procedures other ⚫...
-
Page 10: Regulatory Compliance
Regulatory Compliance FCC Part 15 This equipment has been tested and found to comply with the limits for digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. - Page 11 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. LVD/EMC Directive This product complies with the European Low Voltage Directive 2006/95/EC and EMC Directive 2004/108/EC.
- Page 12 WEEE Directive–2002/96/EC The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner .
-
Page 13: Table Of Contents
Contents 1 Packing List ............. 1 2 Appearance............. 2 Dimensions and Appeara nce ............2 Cable Con necti on ................2 3 Mount Y our Camera ........3 Wall Mount .. - Page 14 Install the ActiveX ................13...
-
Page 15: Packing List
1 Packing List Item Quantity Camera User document Accessory pack Contact your local dealer package is damaged or incomplete. -
Page 16: Appearance
2 Appearance Dimensions and Appearance Φ 4.5mm (0.18 ") 39mm (1.54 ") Cable Connection IP Netw ork... -
Page 17: Mount Your Camera
Description Description RESET button Earth terminal Power interface Network interface specifications, latest product datasheets. ⚫ Press and hold the RESET button for at least ⚫ 15 seconds to restore factory default settings. Perform this operation within 10 minutes after device is powered on or the reset will fail otherwise. - Page 18 following part takes wall mount as an example. Ceiling mount is similar to wall mount and therefore is omitted here. 1 Locate the positions of the holes. 2 Drill holes on the wall. Use a Ø6-6. 5 mm drill bit. Paste install ation positi oni ng stickers on the wall and alig n the cross...
- Page 19 6 Adjust the 5 Mount your camera onto the wall and connect all cables. monitoring direction. Lead tappi ng screw s throug h the guide holes i n the base a nd fix them on the wall by using a s crewdriver. Adjust the ope ning of the universal j oints as re quire d.
-
Page 20: Start Your Camera
The preceding installation process is for concealed installation, during which holes are punched on the wall and cables are penetrated into the wall. If open installation is adopted, cables are not penetrated into the wall but threaded out from the outlet on one side of the base. Start Your Camera After verifying that your camera is properly mounted, connect the power cable to it and the other end of the cable to the mains. -
Page 21: Waterproof Components For An Rj45 Plug
Waterproof Components for an RJ45 Plug 1 Attach the seal ring to the waterproof connector. 2 Mount the waterproof components. Insert in order Seal ring 4 Insert the cable into the connector and screw the waterproof bolt in. 3 Insert the cylindrical waterproof ring into bolt. Cylindrical w a t er p r o o f ri n g Wa t e r p r o o f b ol t 5 Screw in the waterproof bolt lid. -
Page 22: Waterproof Tail Cable
In step 2, you can crimp the inner wires of the cable with the RJ45 plug first and then cover the waterproof components. You may also cover the waterproof components first. Waterproof Tail Cable Connect the tail cables and then take the following steps to protect the tail cables from water using waterproof tapes. The figures are only for illustration purpose. - Page 23 3 Protect other cables using insulating tapes. 4 Wrap all the tail cables together using insulating tapes. 6 Protect the tail cables using waterproof tapes. 5 Choose a start point for waterproof tapes. W ater pr o of ta p e...
-
Page 24: Set Your Camera Over The Lan
Avoid short circuit when insulating the cables. ⚫ Use self adhesive waterproof tapes that will stick together with the twisted cables. ⚫ Tighten waterproof tapes when wrapping the cables and make sure the cable connections are fully covered. ⚫ You are recommended to put the waterpr oof cables in a waterproof junction box whic h needs to be purchased separately. - Page 25 Please contact your dealer ⚫ EZStation. Please refer to the user manual of EZStation for detailed information. ⚫ 1. Connect your camera and your PC as shown in the figure below to ensure the routing is available. 2. Use EZStation to search online cameras automatically. 3.
-
Page 26: Access Your Camera
The default IP address is “192.168.0.13”. The default username is “admin” and the default password is “123456”. ⚫ To access your camera from a different subnet, set the gateway for your camera after you log in. ⚫ 5 Access Your Camera Access Your Camera Before you begin, check that: Your camera is operating properly and connected to the network. -
Page 27: Install The Activex
1. Open your browser, input the IP address of your camera (default IP is 192.168.0.13) in the address bar and then press Enter to open the login page. 2. Enter the username (default is “admin”) and password (default is “123456”) and then click Login. Install the ActiveX at your first login. - Page 28 1. Click Download. 2. Click Run to install the downloaded ActiveX. You may also click Save to download the file to your computer first. 3. Close the browser and follow the steps to complete the installation.
- Page 29 your first login with Windows 7, if the system does not prompt you to install ActiveX, follow these steps to turn off UAC: click the Start button, and then click Control Panel. In the ⚫ search box, type uac, and then click Change User Account Control Settings. Move the slider to the Never Notify position, and then click OK. After UAC is turned off, log in again. If the installation failed, open Internet Option in IE before login.
- Page 30 For Inquiries, Please Contact: Security Shop Vladimira Popovica 6/6/A606 11070 Belgrade, Serbia Tel: +381 11 318 68 68 office@macchina.rs Imported/Distributed by Security Shop doo Licensed by Hyundai Corporation Holdings, Korea Delivery and After Service shall only be covered within Serbia...
