Summary of Contents for UFO MicroLED 5000T
- Page 1 PRODUCT USER GUIDE MicroLED 5000T Illuminator Rev: C6 PLEASE READ THIS USER GUIDE BEFORE INSTALLING OPERATING OR PERFORMING MAINTENANCE ON THE ILLUMINATOR UNIT E357731...
- Page 2 Warning: The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer than 2.7 metres is not expected. UFO will accept no liability for damage, or associated claims, caused by not following the installation and safety instructions contained within this user guide.
-
Page 3: Installation
This luminaire is powered by a 12V Power Supply Unit or 12V Constant Voltage Driver. Remove the PSU/driver from its box. Connect the jack plug into the socket in the back, and the illuminator is now ready for connection. UFO LIGHTING... -
Page 4: Operation
OPERATION CONNECTION There are 3 connections required – the fiber port, the mains supply and the DMX cable. The fiber port should be connected first. Connect and secure the fiber optic connector into the silver collar and secure using the M5 locking screw RJ45 DMX data sockets are provided at the rear of the Illuminator. - Page 5 OPERATION UFO LIGHTING...
-
Page 6: Standalone Control
OPERATION Note: A termination resistor of 120Ώ should be fitted at the end of DMX universes across DMX + and DMX-. Although systems having a few devices and short cable runs may work well without, it is always recommended that a termination plug be fitted Plug the mains plug into the electrical supply socket. -
Page 7: Setting The Dmx Address
0 Twinkle OFF 1 to 255 slow to fast The Twinkle wheel oscillates backwards and forwards avoiding the open segment. When Channel 5 value is set to 0 the Twinkle wheel will stop opposite the open segment to give full light. UFO LIGHTING... - Page 8 OPERATION Standard Color Color Values GREEN BLUE WHITE Fire (008) Orange (018) Golden Amber Apricot (014) Canary (Y89) Green (G78) Jade (G96) Turquoise (C47) Italian Blue (C45) ...
-
Page 9: Safety Guidance
The outer body of the illuminator may become hot - keep away from all combustible materials and DO NOT locate this illuminator within 200mm (8”) of any flammable surface. • The illuminator must not be run without the fiber optic harness fitted. MAINTENANCE LOG Date Maintenance Undertaken UFO LIGHTING... -
Page 10: Troubleshooting
PSU failed Replace PSU illuminated Unit is dead no LED array failure Contact UFO light output but LED power Recycle power to illuminator or switch on via re Switched off via remote control unit indicator is still... -
Page 11: Technical Specification
Wavelength and Luminous Flux Blue: 457nm / 23m White: 4000K / 145lm Supply Voltage 90264Vac Mains Running Current 0.06A @ 240Vac Mains Voltage VA rating 14VA External PSU Type Power Pax, 12V, 2A, 24W Motor Type 12v stepper motor UFO LIGHTING... - Page 12 INSTALL United Kingdom • United States • Germany • Europe • Universal Fiber Optics Ltd Universal Fiber Optics USA LLC UFO Licht GmbH Home Place Coldstream 1749 Northgate Blvd Friendsfactory AG Gutenbergstraße 1 TD12 4DT Sarasota FL34234 85737 Munchen Deutschland...
