INSTALLATION INSTRUCTIONS
For your safety, upon receipt of your Wall Rack, read this instruction sheet
carefully before starting any installation and assembly.
This Rack system must be anchored securely to the wall in a manner that safely supports
the weight of the rack, equipment, and cable loads. Due to the varying types and
conditions of wall substrate, anchoring and selection of hardware should be performed
by qualified personnel only. Anchoring hardware should be a minimum of 1/4" diameter.
XWR-3619-18HD
This product is UL listed and intended to house UL
Listed ITE, Audio or Video equipment and must be
installed by a qualified professional. This unit is not
intended for use as a fire enclosure.
Visit our website at
www.Belden.com
WALL MOUNT SWING RACK
CAUTION:
Instructions for the following Racks:
XWR-4819-18HD
Maximum Load Capacity
XWR-3619-18HD: 200 lbs.*
XWR-4819-18HD: 200 lbs.*
* Load evenly distributed
Page 1 of 6
008-XWRHD-1
08/25/2008
Rev 1
07/06/2010
Advertisement
Related Manuals for Belden XWR-3619-18HD
Summary of Contents for Belden XWR-3619-18HD
- Page 1 XWR-3619-18HD XWR-4819-18HD Maximum Load Capacity This product is UL listed and intended to house UL XWR-3619-18HD: 200 lbs.* Listed ITE, Audio or Video equipment and must be XWR-4819-18HD: 200 lbs.* installed by a qualified professional. This unit is not * Load evenly distributed intended for use as a fire enclosure.
- Page 2 INSTALLATION INSTRUCTIONS WALL MOUNT SWING RACK Visit our website at www.Belden.com Page 2 of 6 008-XWRHD-1 08/25/2008 Rev 1 07/06/2010...
- Page 3 If there is damage, please notify the freight carrier immediately to file a damaged freight claim. Once you have inspected the packaging for any damage; carefully remove your rack from the packaging. Visit our website at www.Belden.com Page 3 of 6 008-XWRHD-1 08/25/2008...
-
Page 4: Mounting Hole Pattern
Figure 1 provides the dimensions for layout. Rack frame should be square and level when properly mounted. Hole Pattern shown for left side hinge. Reverse for right side hinge. Figure 1 Visit our website at www.Belden.com Page 4 of 6 008-XWRHD-1 08/25/2008 Rev 1 07/06/2010... - Page 5 Before starting installation verify that you received a rack with equipment mounting criteria based on the table below. Ordering Equipment Depth Height Mtg Hole Rack Part Number Mtg Width Thread Type XWR-3619-18HD 19” 36” 10-32 18” XWR-4819-18HD 19” 48” 10-32 18”...
-
Page 6: Equipment Installation
(see Figure 2 & 3). The pins are attached to the stationary frame with lanyards so they are not misplaced when removed. Visit our website at www.Belden.com Page 6 of 6 008-XWRHD-1...
