Introduction:
Data-Linc's SRM8200 is a license free 900MHz long range modem with dual Ethernet
and dual serial connectivity. The SRM8200 is a wireless high-performance modem
designed for heavy-duty industrial data communications. It has RF speed of up to 4
Mbps and is based on Adaptive FHSS, a new paradigm for band utilization that takes
optimal advantage of spectrum gaps. The SRM8200's range is up to 40 miles with line-
of sight (LOS) and may be extended with Repeaters and/or high gain antennas to
provide unsurpassed flexibility and performance. The SRM8200 may be configured via
web interface, Command Line Interface (CLI), Drag and Drop and SSH (Secure Shell).
1. Getting Started
Equipment included with every SRM8200 shipment package:
Quantity
Description
1
SRM8200
1
Power Supply 12VDC
1
Test Antenna
1
6 ft Cat5 Cable
Additional equipment needed for network setup:
• PCs running Windows 7 or later
• Web Browser (Internet Explorer, Firefox, Chrome, etc.)
Connections:
•
Connect the test antenna.
•
Connect the CAT5 Ethernet cable to the PC (for configuration).
•
Connect the unit to power using the included 12VDC power supply.
PN:163-11914-000
05/04/2020
SRM8200 Quick Start Guide
1
SRM8200 Quick Start Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Data-Linc Group SRM8200
Summary of Contents for Data-Linc Group SRM8200
- Page 1 Mbps and is based on Adaptive FHSS, a new paradigm for band utilization that takes optimal advantage of spectrum gaps. The SRM8200’s range is up to 40 miles with line- of sight (LOS) and may be extended with Repeaters and/or high gain antennas to provide unsurpassed flexibility and performance.
- Page 2 If your computer’s network interface is already configured with a static IP address and you don’t want to change it, it is possible to add another static IP address to match the range of the SRM8200. Instructions on how to do this may be found in the SRM8200 User Guide.
- Page 3 SRM8200 Quick Start Guide 3. Creating a Gateway - Endpoint Network PN:163-11914-000 SRM8200 Quick Start Guide 05/04/2020...
- Page 4 SRM8200 Quick Start Guide 4. SRM8200 Configuration In order to create a Gateway to Endpoint network as shown above, five basic configuration settings need to be changed. NOTE: Anytime you make a change to the configuration setting, make sure to click on ‘Update’...
- Page 5 Endpoint 6. Verifying Wireless Data Communication When wirelessly connected, the bottom LED should be ON (green) on each SRM8200. A flashing red indicates there is no RF link between the two SRM8200s. To verify wireless data communication, a simple ping test may be run. Below is a screenshot for ping response from the Gateway SRM8200 on IP address 192.168.111.101 to the Endpoint SRM8200 on IP address 192.168.111.100.
-
Page 6: Restore Factory Defaults
ESTORE ACTORY EFAULTS If you have changed the password on the SRM8200 and cannot log into the configuration screens or the terminal window, and do not know the SRM8200’s IP Address, you can restore the SRM8200 to default: 1. Open a Notepad document.
