Certa CTPIMPDRLLA User Manual

Powerplus 20v brushless impact drill
Hide thumbs

Advertisement

Table of Contents

POWERPLUS 20V
BRUSHLESS IMPACT DRILL
(SKIN ONLY)
CTPIMPDRLLA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTPIMPDRLLA and is the answer not in the manual?

Questions and answers

Related Manuals for Certa CTPIMPDRLLA

Summary of Contents for Certa CTPIMPDRLLA

  • Page 1 POWERPLUS 20V BRUSHLESS IMPACT DRILL (SKIN ONLY) CTPIMPDRLLA...
  • Page 2 Safety & Warnings Overview Before First Use Operation Cleaning & Care Specifications...

  • Page 3: Safety And Warnings

    SAFETY & WARNINGS General Power Tool Safety Warnings • Prior to use, thoroughly read and understand the user guide. Failure to follow instructions can result in injury and property damage. • The equipment must not be operated by anyone who is not familiar with the user guide.
  • Page 4 Personal Safety • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious injury.
  • Page 5 Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Drill Safety Instructions • Hold power tool by insulated gripping surfaces when performing operations where the cutting accessory or fastener may contact hidden wiring.
  • Page 6 Battery Tool Use and Care • Only recharge the battery with the provided charger to avoid a risk of fire. • Use only designated battery packs for your tool to avoid injury and fire risks. • When battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws, or other small metal objects that can make a connection from one terminal to another.
  • Page 7 Description of Symbols Pay attention to all the signs and symbols shown in these instructions and on your tool. Make a note of these signs and symbols. Interpret the signs and symbols correctly to ensure safe operation. Important. Read the instructions for use before starting the machine. Wear safety goggles.
  • Page 8 Do not throw it into water. Battery pack is part of the recyclable resources. End of life machines contain valuable materials and therefore they should not be placed in household waste. The brand would ask you to play your part in protecting resources and help protect the environment by returning this machine to a return point (if one is available) when it reaches the end of its life.
  • Page 9 OVERVIEW Torque selector Battery charger (sold separately) Battery capacity indicator Gear selector switch Changeover switch Push lock button ON/OFF switch Quick-change drill chuck Li-ion battery pack (sold separately) LED lamp...

  • Page 10: Before First Use

    OPERATION Fitting and Removing the Battery (Sold Separately) Note: This product is designed to be used with CT20VBAT20A - Certa PowerPlus 20V 2.0Ah Lithium Battery, and CT20VHTLBCHB - Certa PowerPlus 20V Rapid Charger (65W) (sold separately). The battery should always be removed whenever you are not using the tool and especially when you are adjusting or transporting the tool to avoid accidental operation.
  • Page 11 Charging the Battery Pack (Sold Separately) Note: This product is designed to be used with CT20VBAT20A - Certa PowerPlus 20V 2.0Ah Lithium Battery, and CT20VHTLBCHB - Certa PowerPlus 20V Rapid Charger (65W) (sold separately). Remove the battery pack (5) from the handle by pressing the push lock button (8) downwards.
  • Page 12 Temperature Guidelines for Charging: • Caution: Avoid charging batteries in temperatures below 4.5°C or above 40.5°C. • Optimal Conditions: Best performance and battery life are achieved when charged at an air temperature around 24°C. • Tool Temperature Limits: Charging will not occur if the tool's temperature is below 0°C or above 45°C.
  • Page 13 Torque Setting • The cordless screwdriver is fitted with a mechanical torque selector. • The torque for a specific size of screw is selected with the set-collar (1). The correct torque depends on several factors: The type and hardness of material in question. The type and length screws used.
  • Page 14 Drilling • For drilling purposes, move the set-collar to the last step, ‘Drill’. In this setting, the slip clutch is inactive. • The maximum torque is available in drilling mode. Forward/Reverse Switch • Use the changeover switch (3) located above the ON/OFF switch (4) to select the rotation direction of the drill and to lock it to prevent accidental activation.
  • Page 15 On/Off Switch The ON/OFF switch (4) allows for infinitely variable speed control. The further you press the switch, the higher the speed. Changeover ON/OFF switch switch Changing Gears Adjust the selector switch to shift between higher and lower speeds. Change gears only when the tool has stopped to avoid damaging the gear unit.
  • Page 16 Battery Capacity Indicator • The three-colour LEDs indicate the battery capacity as soon as you press the ON/OFF switch (4): All LEDs illuminate: The battery is fully charged. Yellow and red LEDs illuminate: The battery has an adequate remaining charge. Red LED only: The battery is empty;...
  • Page 17 Changing the Tool • Important: Set the changeover switch (3) to its centre position when performing any work (e.g., changing the tool, maintenance). • The device is equipped with a quick-action chuck (9) featuring an automatic spindle stop. • Open the chuck (9). Ensure the opening (a) is wide enough to accommodate the tool (drill bit or screwdriver bit).

  • Page 18: Cleaning And Care

    Caution! Actual vibration values may vary based on the application. Implement measures to protect against vibrations considering the entire workflow, including times when the tool is under no load or turned off. Regular maintenance, keeping hands warm, taking breaks, and planning work efficiently are essential.

  • Page 19: Specifications

    Torque settings 20 + 3 Forward and reverse rotation Chuck clamping width Max.13mm Rechargeable battery (LI-Ion) Nominal voltage Capacity CERTA 2.0Ah/4.0Ah Charger Rated power input Input voltage 220-240V-50/60Hz Output voltage 21V, 1.5A Disposal This marking indicates that this appliance should not be disposed with other household wastes.
  • Page 20 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com...
